IBASE Technology ASB200-953 User manual

ASB200-953
Fanless System with
3.5” Disk-Size SBC System
User’s Manual
Version 1.0
(March 2022)

ii
ASB200
-
953
User Manual
Copyright
© 2022 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

ASB200
-
953
User Manual
iii
Compliance
This product has passed CE tests for environmental specifications and limits. This
product is in accordance with the directives of the Union European (EU). If users
modify and/or install other devices in this equipment, the CE conformity declaration
may no longer apply.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent chromium (Cr6+)
• Polybrominated biphenyls (PBB)
• Polybrominated diphenyl ether (PBDE)

iv
ASB200
-
953
User Manual
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
 Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
 Leave plenty of space around the device and do not block the openings for
ventilation. NEVER DROP OR INSERT ANY OBJECTS OF ANY KIND INTO
THE VENTIILATION OPENINGS.
 Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the device for ventilation.
NEVER INSERT OBJECTS OF ANY KIND INTO THE VENTILATION
OPENINGS.
 Use this product in environments with ambient temperatures -20˚C ~ 60˚C for
SSD, and 0˚C ~ 45˚C for HDD.
 DO NOT LEAVE THIS DEVICE IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20˚C OR ABOVE 80˚C. This
could damage the device. The device must be used in a controlled environment.
Care for your IBASE products:
 Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
 Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
 Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
 Do not place heavy objects on the top of the device.
 Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
 Do not walk on the power cord or allow anything to rest on it.
 If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
Do not disassemble, repair or make any modification to the device. Disassembly,
modification, or any attempt at repair could generate hazards and cause damage to
the device, even bodily injury or property damage, and will void any warranty.

ASB200
-
953
User Manual
v
CAUTION
Danger of explosion if internal lithium-ion battery is replaced by an incorrect type.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
 IBASE standard products:
IBASE offers a 24-month (2-year) warranty from the date of shipment. If the
date of shipment cannot be ascertained, the product serial numbers can be
used to determine the approximate shipping date.
 3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, HDD, power adapter, panel
and touchscreen.
＊ PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
 Product model name
 Product serial number
 Detailed description of the problem
 The error messages in text or in screenshots if there is any
 The arrangement of the peripherals
 Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
ASB200
-
953
User Manual
Table of Contents
Chapter 1 General Information ................................................................. 1
1.1 Introduction ............................................................................................. 2
1.2 Features .................................................................................................. 3
1.3 Packing List ............................................................................................ 3
1.4 Optional Accessories .............................................................................. 3
1.5 Specifications .......................................................................................... 4
1.6 Product View ........................................................................................... 6
1.7 Dimensions ........................................................................................... 10
Chapter 2 Hardware Configuration ....................................................... 12
2.1 Installations ........................................................................................... 13
2.1.1 HDD Installation ...................................................................... 13
2.1.2 M.2 Card Installation ............................................................... 14
2.1.3 Memory Installation ................................................................ 15
2.1.4 WiFi / 4G / 5G Antenna Installation ......................................... 16
2.1.5 Side Bracket Installation ......................................................... 17
2.1.6 Pinout for COM Ports, DC Power & Digital I/O Connectors ..... 18
2.2 Setting the Jumpers .............................................................................. 20
2.3 Jumper & Connector Locations on IB953 .............................................. 21
2.4 Jumpers Quick Reference ..................................................................... 22
2.4.1 Clear CMOS Data (JP1) ....................................................... 22
2.4.2 EDP Panel Power Selection (JP2) .......................................... 23
2.4.3 eDP Power Selections (JP4) ................................................... 23
2.4.4 AT / ATX Selection (JP6) ........................................................ 24
2.4.5 LVDS Panel Power / Brightness Selections (JP5 / JP7) ....... 24
2.5 Connectors Quick Reference ................................................................ 25
2.5.1 SATA Connectors (CN1, CN3) ............................................... 26
2.5.2 eDP Connector (CN2) ............................................................. 27
2.5.3 COM1 Serial Port (CN4) ...................................................... 28
2.5.4 DP Connectors (CN8, CN9) .................................................... 29
2.5.5 Audio Connector (J2) .............................................................. 30
2.5.6 Audio AMP Connector (J4) ..................................................... 31
2.5.7 USB2 #5 #6 (J6) ..................................................................... 32
2.5.8 DC-In Connector (J7) .............................................................. 32
2.5.9 LVDS CHB Connector (J12 - 2nd, J14 - 1st) ........................... 33
2.5.10 SATA Power Connector (J13) ................................................. 34
2.5.11 LVDS Backlight Connector (J15) ............................................ 34

ASB200
-
953
User Manual
vii
2.5.12 Digital I/O Connector (J17) ..................................................... 35
2.5.13 Front Panel Setting Connector (J18) ....................................... 36
2.5.14 COM2 Serial Ports (J19) ......................................................... 37
2.5.15 CPU Fan Power Connector (CPU_FAN1) ............................... 38
Chapter 3 Driver Installation ................................................................. 39
3.1 Introduction ........................................................................................... 40
3.2 Intel® Chipset Software Installation Utility ............................................. 40
3.3 VGA Driver Installation .......................................................................... 42
3.4 HD Audio Driver Installation .................................................................. 43
3.5 LAN Driver Installation .......................................................................... 44
3.6 Intel® Management Engine Drivers Installation ..................................... 46
3.7 Intel® Thunderbolt Drivers Installation .................................................. 48
Chapter 4 BIOS Setup ............................................................................ 50
4.1 Introduction ........................................................................................... 51
4.2 BIOS Setup ........................................................................................... 51
4.3 Main Settings ........................................................................................ 52
4.4 Advanced Settings ................................................................................ 53
4.5 Chipset Settings .................................................................................... 68
4.6 Security Settings ................................................................................... 72
4.7 Boot Settings......................................................................................... 73
4.8 Save & Exit Settings.............................................................................. 74
Appendix ...................................................................................................... 75
A. I/O Port Address Map ............................................................................ 76
B. Interrupt Request Lines (IRQ) ............................................................... 78
C. Watchdog Timer Configuration .............................................................. 79

1
Chapter 1
General Information
The information provided in this chapter includes:
 Features
 Packing List
 Optional Accessories
 Specifications
 Product View
 Dimensions

2
ASB200
-
953
User Manual
1.1 Introduction
The ASB200-953 compact box PC housing IBASE’s IB953 3.5-inch SBC
powered by Intel® Core™ processors with a 15W TDP threshold. Aimed at
smart applications in warehouse logistics management, factory automation
and the automotive industry, the ASB200-953 features high performance with
low power consumption. With black chassis color, it supports up to 64GB in
two SO-DIMM slots and 12V~24V wide-range DC power input. Useful I/O
ports on the front side include 3x USB 3.1, 1x USB 2.0, 2x DisplayPort, 1x
COM, and 2x GbE ports. The rear panel is equipped with digital I/O, power
button, HDD LED, DC-in terminal block and two antenna holes that can be
used with the optional WiFi accessory kit. The ASB210-953 variant comes
with fan support and TDP up to 28W.
ASB200-953
ASB210-953

General Information
ASB200
-
953
User Manual
3
1
1.2 Features
 System with IBASE IB953 3.5-inch SBC (TDP 15W for ASB200-953, 28W
TDP for ASB210-953)
 Onboard 11th Gen Intel® Core™ U-Series Processor
 Supports 3x M.2 sockets (B-Key/E-Key and M-Key)
 12V (-10%) ~ 24V (+10%) DC-in power input
 2x DDR4-3200 SO-DIMM, Max. 64GB
 3x USB 3.1, 1x USB 2.0, 2x Intel® GbE, 1x COM
 External GPIO, 2x DisplayPort, TPM (2.0)
 Optional VESA mount bracket
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
 ASB200-953 or ASB210-953 x 1
 3-pin Terminal Block (for power) x 1
 10-pin Terminal Block (for GPIO connector) x 1
 Side Brackets x 1
 Screws for Side Brackets x 4
 Screws for M key and E key M.2 x 2
 Power Adaptor and Power Cord x 1
1.4 Optional Accessories
 WiFi / Bluetooth Module Kit

4
ASB200
-
953
User Manual
1.5 Specifications
Product Name ASB210-953-i7M ASB210-953-i5M ASB200-953-i3M
Motherboard IB953AF-i7 IB953AF-i5 IB953F-i3
System
CPU Intel® Core™
i7-1185G7E
Intel® Core™ i5-
1145G7E
Intel® Core™ i3-
1115G4E
Memory 2 x DDR4-3200 SO-DIMM, Max. 64 GB
Storage 1 x M.2 M-key 2280, 1x 2.5’’ HDD or SSD
Power Supply 90W power adaptor
BIOS AMI BIOS
Watchdog Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
Mounting  Desktop or wall mount
 VESA mount (optional)
Dimensions 180mm (W) x 150mm (D) x 72mm (H)
7.08” (W) x 5.9” (D) x 2.83” (H)
Weight 1.5 kg
Certificate CE / LVD / FCC Class B
I/O Ports
Front I/O
 3x USB 3.1
 1x USB 2.0
 2x DisplayPort
 1x DB9 for COM#1 (RS232/422/485)
 2x LAN
Rear I/O
 1x Power button
 1x Digital I/O (4-in/4-out)
 2x Antenna holes
 1x HDD LED
 1x 3-pin DC-in terminal block for
12V (-10%) ~ 24V (+10%)
Expansion  3x M.2 sockets (B-Key/ E-Key and M-Key)

General Information
ASB200
-
953
User Manual
5
1
Environment
Temperature
 Operating:
0 ~ 45 °C (32 ~ 113 °F)
 Storage: -20~ 80 °C (-4 ~ 176 °F)
Relative
Humidity 5 ~ 90% at 45 °C (non-condensing)
Vibration
Protection
 Operating: 0.25 Grms / 5 ~ 500 Hz
 Non-operating: 1 Grms / 5 ~ 500Hz
Shock
Protection
 Operating: 20 g / 11 ms
 Non-operating: 40 g / 11 ms
All specifications are subject to change without prior notice.

6
ASB200
-
953
User Manual
1.6 Product View
Front View
ASB200-953
ASB210-953
No. Name No. Name
1 Antenna Holes 4 Digital I/O (4-In / 4-Out)
2 HDD LED 5 DC +12V~ +24V
Power Input
3 Power Switch

General Information
ASB200
-
953
User Manual
7
1
Rear View
ASB200-953
ASB210-953
No. Name No. Name
1 Antenna Holes 4 USB 3.1 Ports
2 Display Port 5 USB 2.0 Port
3 LAN Ports 6 COM Port

8
ASB200
-
953
User Manual
Oblique View
ASB200-953

General Information
ASB200
-
953
User Manual
9
1
ASB210-953

10
ASB200
-
953
User Manual
1.7 Dimensions
Unit: mm
ASB200-953

General Information
ASB200
-
953
User Manual
11
1
ASB210-953

12
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
 Installations
 Descriptions and locations of connectors
