IBC Cleaner LC User manual

IBCTM Brand Cleaner LC Instruction Manual
Thank you for choosing the IBC Brand Cleaner LC. The IBC Brand Cleaner LC is a high-performance device
designed for cleaning the ferrule end faces of LC connectors and MU connectors. Please carefully read these
instructions before using this device. Please keep the instructions for future reference.
1. Safety precautions
Though our device is deemed safe, improper usage or handling can still inflict injury to others.
IBC Brand Cleaner LC is designed to clean LC connectors and MU connectors only. US Conec is not
liable for damage caused in attempt to apply this device to other applications.
2. Notes on usage
Do NOT attempt to disassemble as this can cause damage to the device and void the warranty.
Do NOT try to re-use the cleaning cloth as this will eliminate the cleaner’s effectiveness and void warranty.
Do NOT touch the cleaning cloth as this will cause contamination.
Do NOT pull the cleaning cloth, use only the device body.
Do NOT use this cleaner when the cloth is empty. This may can cause damage to the connector.
3. Notes on storage for extended periods
Do not leave the cleaner exposed to to direct sunlight, high temperature or high humidity over an extended
period. The dust cap should be closed at all times when device is not in use
4. Cleaner construction
No. Part Name Function
A Tip Lead the cleaning cloth to the optical connecter end face.
B Nozzle Lead tip to the optical connecter end face.
C Lock Button Push the button to extend and contract the nozzle.
D Outer Shell Push the outer shell to clean the connector.
E Guide Cap Acts as dust cap or cleaning adapter for connector plug.
F Indicator Provides indication of remaining cleaning cloth.
残量 残量確認窓外観 先端部外観
多
少
無
A. Tip
B. Nozzle
D. Outer Shell
C. Lock Button
F. Indicator E. Guide Cap
Standard Mode Extended Mode
Pull Nozzle while
pushing button.
Pull Nozzle
Red
Red
Tip (Black)
No Cloth
(Black)
Cloth
Tip (Black)
View of Indicator View of the Nozzle end
Full
Little
Empty
Identification of remaining cloth
(White)
View of the Nozzle end
Cloth
(White)
Push Lock Button
Slide
(White)
Cloth
Slide
Slide

5. Applications
Connector inside adapter Connector plugs alone
1. Remove Guide Cap from the device. 1. Open the Cover on the Guide Cap.
2. Insert tip of cleaner into LC Adapter 2. Insert LC connector into the Guide Cap.
3. Push the Outer Shell to start cleaning the LC
connector end face. A “pop” sound indicates end of
cleaning process. Close the cover after use.
Be careful not to slant the IBC Brand Cleaner LC while
inserting into the adapter.
Do not overly exert force during insertion as this may
cause damage to both the connector and the IBC
Brand Cleaner LC.
If pushing Outer Shell is inhibited, remove IBC Brand
Cleaner LC from adapter and ensure that there is no
sizable debris inhibiting the cleaning process.
3. Push the Outer Shell to start cleaning the LC
connector end face. A “pop” sound indicates end of
cleaning process. Close the cover after use.
Be careful not to slant LC connector while inserting into
the Guide cap.
Do not overly exert force during insertion as this may
cause damage to both the connector and the IBC
Brand Cleaner LC.
If pushing Outer Shell is inhibited, remove IBC Brand
Cleaner LC from adapter and ensure that there is no
sizable debris inhibiting the cleaning process.
CLICK !!
Push straight.
Guide Cap
LC Plug
Guide Cap
Cover
Standard Extended Mode
LC Adapter
Note: This drawing shows only LC, but this product will clean MU. Note: This drawing shows only LC, but this product will clean MU.
POP !!
