About This Manual
This manual contains information that is needed when you use the
IBM ThinkPad* Dock II Expansion Unit (hereafter called the Dock II).
It is organized into the following chapters and appendixes:
Chapter 1, “Introduction” introduces the Dock II and describes
its features.
Chapter 2, “Using the Dock II” provides the procedures for
setting up the Dock II. Basic rules and operations for using the
Dock II are also described.
Chapter 3, “Using the Security Features” describes the ways you
can protect your Dock II against unauthorized use and theft.
Chapter 4, “Installing and Removing IBM Options” describes
how to install IBM options using both the documentation
provided with the options and this documentation.
Chapter 5, “Using the SCSI Controller” provides information
about the setup of the SCSI controller’s configuration.
Chapter 6, “Solving Problems” describes how you can detect
and resolve Dock II problems.
Appendix A, “Starting Up the Operating System” describes a
way to start up the operating system that resides on a device
attached to the Dock II.
Appendix B, “Using the SCSI Support Software” provides
information about the installation and use of the option device
drivers and the SCSI diagnostics utility program.
Appendix C, “Using the Selectable Program Load” shows how
to automatically load application programs into the memory of
the computer that enable the options installed in the Dock II
when only the computer is docked.
*Trademark of the International Business Machines Corporation.
Copyright IBM Corp. 1994 iii
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Appendix D, “Specifications” describes the specifications
associated with your Dock II, the power cords, and the ports.
Appendix E, “Product Warranties, Notices, and Statements”
contains the warranty statement of the Dock II, notices,
trademarks, FCC statement, CDCC statement, and EC directive
conformance statement.
iv IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com
all-guides.com

Information Notices
This User's Guide contains notices that relate to specific information or
text.
Note
Provides important hints, tips, guidance, or advice.
Warning
Indicates possible damage to programs, devices, system, or data. A
warning notice appears before the related instruction or situation in
which possible damage could occur.
Caution
Indicates situations that are potentially hazardous to you. A caution
appears in text before the instruction or situation that could be
hazardous.
Danger
Indicates situations that are potentially lethal or extremely hazardous
to you. It is indicated by the symbol ( ) and appears in text before
the instruction or situation that could be dangerous.
Important
Provides important information or guides that you should pay
attention to.
About This Manual v
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

vi IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Contents
About This Manual ............................ iii
Information Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Electrical Safety Notice ......................... xi
Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 1
Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Checking the Items ............................ 3
Locating Dock II Features ........................ 4
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Dock II Status Indicators ......................... 8
Changing Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warning Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 2. Using the Dock II ..................... 13
Setting Up the Dock II .......................... 14
Docking and Undocking the Computer ................ 16
Rules of Docking and Undocking .................. 16
Docking the Computer ........................ 19
Undocking the Computer ....................... 24
Turning On and Off the Computer and the Dock II ........ 28
Chapter 3. Using the Security Features ............... 29
Using the Security Lock ......................... 30
Security Lock Description ....................... 30
Key Positions and Their Functions ................. 31
Securing the Dock II with the Kensington Lock ........... 32
Securing the PCMCIA Cards ...................... 33
Ordering Additional Security Lock Keys ............... 35
Chapter 4. Installing and Removing IBM Options ........ 37
Handling Internal Options ........................ 38
Using the Display Shelf ......................... 39
Installing and Removing Devices in the 1-Inch-High Drive Space 46
Installing Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Copyright IBM Corp. 1994 vii
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Removing Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Installing and Removing Devices in the Half-High Drive Space . 52
Installing Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Removing Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Installing and Removing the ISA Adapter Cards .......... 57
Installing the Adapter Cards ..................... 57
Removing the Adapter Cards .................... 60
Using the PCMCIA Cards ........................ 61
Connecting External SCSI Devices ................... 62
Connecting Other External Options .................. 63
Removing and Installing the Top Cover ................ 64
Removing the Top Cover ....................... 64
Installing the Top Cover ....................... 66
Removing and Installing the Blank Bezel ............... 68
Removing the Blank Bezel for the 1-Inch-High and Half-High
Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Installing the Blank Bezel for the 1-Inch-High and Half-High
Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Removing the Blank Bezel for the ISA Adapter Cards ..... 70
Installing the Blank Bezel for the ISA Adapter Cards ...... 70
Releasing the Latch ............................ 71
Chapter 5. Using the SCSI Controller ................ 73
Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Connecting Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Assigning SCSI IDs .......................... 74
Terminating the SCSI Bus ....................... 75
Configuring the Host Adapter ..................... 76
Running the SCSISelect Utility .................... 76
Main Menu Options .......................... 77
Switch Block Settings .......................... 78
Chapter 6. Solving Problems . . . . . . . . . . . . . . . . . . . . . 81
Before Testing Is Started ......................... 83
Testing Your Dock II ........................... 85
Troubleshooting Charts . . . . . . . . . . . . . . . . . . . . . . . . . . 88
viii IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Computer Keyboard Problems .................... 88
External Display (CRT) Problems .................. 89
External Keyboard, External Numeric Keypad, or Pointing
Device Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Intermittent Problems . . . . . . . . . . . . . . . . . . . . . . . . . 93
LCD Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Option Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Printer Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Other Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Getting Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Appendix A. Starting Up the Operating System ........ 103
Planning for the Operating System Startup ............. 104
Starting DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Starting the OS/2 2.1 Operating System ............... 110
Appendix B. Using the SCSI Support Software ......... 115
Installing EZ-SCSI for Windows ................... 117
Installing EZ-SCSI for DOS ...................... 118
Reinstalling Adaptec EZ-SCSI ..................... 119
Viewing More Online Information .................. 120
readme.txt File . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Adaptec SCSI Interrogator ..................... 120
Formatting Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
scsifmt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Command Line Options ....................... 121
Running scsifmt . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
afdisk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Command Line Option ....................... 125
Running afdisk . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
General Hardware Troubleshooting ................. 131
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Appendix C. Using the Selectable Program Load ........ 133
Appendix D. Specifications . . . . . . . . . . . . . . . . . . . . . 135
Contents ix
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com
all-guides.com

Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . 135
Environmental Requirements . . . . . . . . . . . . . . . . . . . . . 135
Temperature, Relative Humidity, and Wet Bulb Temperature 135
Maximum Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . 136
Audio-Circuit Specifications . . . . . . . . . . . . . . . . . . . . . . 136
Speaker-In to Audio-Out ...................... 136
Speaker-In to Headphone Jack ................... 136
Speaker-In to Embedded Speaker ................. 137
IBM Power Cords ............................ 137
Appendix E. Product Warranties, Notices, and Statements .. 141
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Federal Communications Commission (FCC) Statement ..... 147
Canadian Department of Communications Compliance Statement 147
Avis de conformité aux normes du ministère des
Communications du Canada ..................... 148
European Community (EC) Directive Conformance Statement . 148
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
xIBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Electrical Safety Notice
CAUTION:
Do not operate the Dock II with the top cover removed. To install
the top cover, see “Installing the Top Cover” on page 66.
DANGER:
Power is controlled by the power switch of the Dock II or the
computer. For emergencies, always use easily accessible electrical
outlets to turn off the power by unplugging the Dock II power
cord. The outlet should be installed near the Dock II and should
be easily accessible.
DANGER:
To avoid a shock hazard, do not connect or disconnect any cables
or perform installation, maintenance, or reconfiguration of this
product during an electrical storm.
Copyright IBM Corp. 1994 xi
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

DANGER:
To avoid a shock hazard:
The power cord must be connected to an outlet that has been
properly wired and grounded according to your local wiring
rules.
This equipment must have an earth ground.
Apparaten skall anslutas till jordat uttag när den ansluts till
ett nätverk.
Jordet stikkontakt skal benyttes når apparatet tilkobles
datanett.
Laite on liitettävä suojakosketinspistorasiaan.
Any equipment to which this product is attached must also be
connected to an outlet that has been properly wired and
grounded according to your local wiring rules.
xii IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Turn everything OFF.
Attach signal cables to
receptacles.
First, remove power cord from
outlet.
To Disconnect
Turn device ON.
DANGER:
Turn everything OFF.
To Connect
Remove signal cables from
receptacles.
Remove all cables from devices.
Attach power cord to outlet.
First, attach all cables to devices.
Electrical current from power, telephone, and communication
cables is hazardous. To avoid shock hazard, connect and
disconnect cables as shown below when installing, moving or
opening the covers of this product or attached devices. The
power cord must be used with a properly-grounded outlet.
Note: In the U.K., by law, the power
cord must be disconnected after the
telephone line cable.
Note: In the U.K., by law, the telephone
line cable must be connected after the
power cord.
Electrical Safety Notice xiii
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

xiv IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com
all-guides.com

Chapter 1. Introduction
The Dock II provides expandability for the following IBM ThinkPad
computer systems (hereafter called the computer) providing the same
usability as a desktop computer system.
IBM ThinkPad 750 family
IBM ThinkPad 755 family
IBM ThinkPad 360 family
Portability of your computer is made easier because computer options
are installed in the Dock II, and docking and undocking are
effortlessly done. After your computer is docked to the Dock II, you
can readily use it with the Fail-safe Docking and Plug-and-Play
Ready features.
The Dock II has enhanced security features to protect it from theft
and unauthorized use.
This chapter contains:
Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Checking the Items ............................ 3
Locating Dock II Features ........................ 4
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Dock II Status Indicators ......................... 8
Changing Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warning Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Copyright IBM Corp. 1994 1
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Standard Features
The following summarizes the standard features on the Dock II.
Audio Features Speaker-in jacks
Audio-out jacks
A headphone jack
Stereo speakers
Compartments for CD-ROM drives
Security Features Security key lock
PCMCIA** card lock
A keyhole for Kensington** lock
Cable Management
Features An external diskette drive connector A keyboard/numeric keypad connector
A mouse/pointing device connector
A parallel connector
A serial connector
A SVGA connector
Desktop-Equivalent
Features Two full-size ISA adapter card slots A 1-inch-high drive space
A half-high drive space
External SCSI-II device connectors
Two PCMCIA slots
** PCMCIA is a trademark of Personal Computer Memory Card International Association, and Kensington is a
trademark of Kensington Microware Inc.
2IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Checking the Items
Check that you have the following items.
If any are missing or damaged, call your IBM marketing
representative or dealer.
Dock II Manual
Option Diskette Power Cord
Security Lock Keys Notes
1. An extra key is provided as a spare.
2. The key number is necessary when replacing lost keys.
See “Ordering Additional Security Lock Keys” on
page 35.
IDE Cable CD-ROM Extension Cable
Chapter 1. Introduction 3
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com

Locating Dock II Features
This section identifies the features for the Dock II. Symbols for
connectors are printed on the back of the Dock II above each
connector for easy identification.
Front View
4IBM ThinkPad Dock II User's Guide
Title: C78JAMST CreationDate: 05/06/94 19:15:58
All manuals and user guides at all-guides.com
