IBM 73P3309 User manual
IBM
Multi-Burner
Plus
User’s
Guide
IBM
Multi-Burner
Plus
User’s
Guide
Note:
Before
using
this
information
and
the
product
it
supports,
be
sure
to
read
the
information
under
Appendix
D,
“Service
and
Support,”
Appendix
E,
“IBM
Statement
of
Limited
Warranty
-
Z125-4753-07
-
11/2002,”
and
Appendix
F,
“Notices.”
First
Edition
(May
2004)
©
Copyright
International
Business
Machines
Corporation
2004.
All
rights
reserved.
US
Government
Users
Restricted
Rights
–
Use,
duplication
or
disclosure
restricted
by
GSA
ADP
Schedule
Contract
with
IBM
Corp.
Contents
Safety:
Read
first
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.v
General
safety
guidelines
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. vii
Service
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. vii
Power
cords
and
power
adapters
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. vii
Extension
cords
and
related
devices
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. vii
Plugs
and
outlets
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. vii
Batteries
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. viii
Heat
and
product
ventilation
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. viii
CD
and
DVD
drive
safety
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.ix
About
this
book
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.xi
Registering
your
product
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.xi
Chapter
1.
Introduction
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-1
Product
description
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-1
Software
description
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-1
Installation
requirements
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-2
Before
you
begin
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-2
Handling
precautions
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-2
Drive
controls
and
connectors
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 1-3
Chapter
2.
Installation
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-1
Installing
the
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-1
Step
1.
Opening
the
computer
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-1
Step
2.
Unpacking
the
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-1
Step
3.
Setting
the
configuration
jumpers
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-1
Step
4.
Mounting
the
drive
in
the
bay
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-2
Step
5.
Attaching
the
cables
to
the
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-2
Step
6.
Completing
the
hardware
installation
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-3
Step
7.
Installing
the
software
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-3
Step
8.
Setting
up
the
system
for
CD
playback
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-3
Using
the
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-3
Using
recordable
media
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-3
Using
single
and
double-sided
DVD-RAM
media
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-4
Removing
the
disc
from
the
cartridge
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-4
Using
CD-R
and
CD-RW
discs
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-5
Using
the
drive
with
CDs
and
DVDs
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-6
Securing
a
disc
in
a
vertically
mounted
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-6
Manually
ejecting
a
disc
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-7
Using
the
DVD
Player
software
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-7
Before
using
the
software
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-7
Using
the
DVD
Player
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-7
Changing
the
DVD
region
code
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-7
Using
drive
letter
access
(DLA)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-8
Using
the
RecordNow
software
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-8
RecordNow
projects
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-9
Making
a
bootable
CD
or
DVD
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-9
About
CD
and
DVD
images
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-9
Using
Intervideo
WinDVD
Creator
Plus
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-9
Maintaining
the
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-10
Handling
and
caring
for
a
disc
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-10
Caring
for
the
drive
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. 2-10
©
Copyright
IBM
Corp.
2004
iii
Appendix
A.
Product
specifications
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. A-1
Appendix
B.
Problem
solving
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. B-1
Appendix
C.
Customizing
the
device
driver
configuration
settings
.
.
.
.
.
.
.
.
. C-1
Enabling
DMA
for
Windows
Me
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. C-1
Enabling
DMA
for
Windows
2000
Professional
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. C-1
Enabling
DMA
for
Windows
XP
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. C-2
Enabling
digital
audio
extraction
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. C-2
Appendix
D.
Service
and
Support
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. D-1
Online
technical
support
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. D-1
Telephone
technical
support
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. D-1
Appendix
E.
IBM
Statement
of
Limited
Warranty
-
Z125-4753-07
-
11/2002
.
.
.
.
.
. E-1
Part
2
-
Country-unique
Terms
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. E-4
Part
3
-
Warranty
Information
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. E-13
Appendix
F.
Notices
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. F-1
Trademarks
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. F-1
Electronic
emissions
notices
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. F-2
Federal
Communications
Commission
(FCC)
statement
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. F-2
iv
IBM
Multi-Burner
Plus
User’s
Guide
Safety:
Read
first
Before
installing
this
product,
read
the
Safety
Information.
Antes
de
instalar
este
produto,
leia
as
Informações
de
Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs
sikkerhedsforskrifterne,
før
du
installerer
dette
produkt.
Ennen
kuin
asennat
tämän
tuotteen,
lue
turvaohjeet
kohdasta
Safety
Information.
Avant
d’installer
ce
produit,
lisez
les
consignes
de
sécurité.
Vor
der
Installation
dieses
Produkts
die
Sicherheitshinweise
lesen.
Prima
di
installare
questo
prodotto,
leggere
le
Informazioni
sulla
Sicurezza.
Lees
voordat
u
dit
product
installeert
eerst
de
veiligheidsvoorschriften.
Les
sikkerhetsinformasjonen
(Safety
Information)
før
du
installerer
dette
produktet.
Antes
de
instalar
este
produto,
leia
as
Informações
sobre
Segurança.
Antes
de
instalar
este
producto
lea
la
información
de
seguridad.
©
Copyright
IBM
Corp.
2004
v
Läs
säkerhetsinformationen
innan
du
installerar
den
här
produkten.
vi
IBM
Multi-Burner
Plus
User’s
Guide
General
safety
guidelines
Always
observe
the
following
precautions
to
reduce
the
risk
of
injury
and
property
damage.
Service
Do
not
attempt
to
service
a
product
yourself
unless
instructed
to
do
so
by
the
IBM
HelpCenter.
Use
only
an
IBM
authorized
service
provider
who
is
approved
to
repair
your
particular
product.
Note:
Some
parts
can
be
upgraded
or
replaced
by
the
customer.
These
parts
are
referred
to
as
Customer
Replaceable
Units,
or
CRUs.
IBM
expressly
identifies
CRUs
as
such,
and
provides
documentation
with
instructions
when
it
is
appropriate
for
customers
to
replace
those
parts.
You
must
closely
follow
all
instructions
when
performing
such
replacements.
Always
make
sure
that
the
power
is
turned
off
and
that
the
product
is
unplugged
from
any
power
source
before
you
attempt
the
replacement.
If
you
have
any
questions
or
concerns,
contact
the
IBM
HelpCenter.
Power
cords
and
power
adapters
Use
only
the
power
cords
and
power
adapters
supplied
by
the
product
manufacturer.
Never
wrap
a
power
cord
around
the
power
adapter
or
other
object.
Doing
so
can
stress
the
cord
in
ways
that
can
cause
the
cord
to
fray,
crack
or
crimp.
This
can
present
a
safety
hazard.
Always
route
power
cords
so
that
they
will
not
be
walked
on,
tripped
over,
or
pinched
by
objects.
Protect
the
cord
and
power
adapters
from
liquids.
For
instance,
do
not
leave
your
cord
or
power
adapter
near
sinks,
tubs,
toilets,
or
on
floors
that
are
cleaned
with
liquid
cleansers.
Liquids
can
cause
a
short
circuit,
particularly
if
the
cord
or
power
adapter
has
been
stressed
by
misuse.
Liquids
can
also
cause
gradual
corrosion
of
the
power
cord
terminals
and/or
the
connector
terminals
on
the
adapter
which
can
eventually
result
in
overheating.
Always
connect
power
cords
and
signal
cables
in
the
correct
order
and
ensure
that
all
power
cord
connectors
are
securely
and
completely
plugged
into
receptacles.
Do
not
use
any
power
adapter
that
shows
corrosion
at
the
ac
input
pins
and/or
shows
signs
of
overheating
(such
as
deformed
plastic)
at
the
ac
input
or
anywhere
on
the
power
adapter.
Do
not
use
any
power
cords
where
the
electrical
contacts
on
either
end
show
signs
of
corrosion
or
overheating
or
where
the
power
cord
appears
to
have
been
damaged
in
any
way.
Extension
cords
and
related
devices
Ensure
that
extension
cords,
surge
protectors,
uninterruptible
power
supplies,
and
power
strips
that
you
use
are
rated
to
handle
the
electrical
requirements
of
the
product.
Never
overload
these
devices.
If
power
strips
are
used,
the
load
should
not
exceed
the
power
strip
input
rating.
Consult
an
electrician
for
more
information
if
you
have
questions
about
power
loads,
power
requirements,
and
input
ratings.
Plugs
and
outlets
If
a
receptacle
(power
outlet)
that
you
intend
to
use
with
your
computer
equipment
appears
to
be
damaged
or
corroded,
do
not
use
the
outlet
until
it
is
replaced
by
a
qualified
electrician.
©
Copyright
IBM
Corp.
2004
vii
Do
not
bend
or
modify
the
plug.
If
the
plug
is
damaged,
contact
the
manufacturer
to
obtain
a
replacement.
Some
products
are
equipped
with
a
three-pronged
plug.
This
plug
fits
only
into
a
grounded
electrical
outlet.
This
is
a
safety
feature.
Do
not
defeat
this
safety
feature
by
trying
to
insert
it
into
a
non-grounded
outlet.
If
you
cannot
insert
the
plug
into
the
outlet,
contact
an
electrician
for
an
approved
outlet
adapter
or
to
replace
the
outlet
with
one
that
enables
this
safety
feature.
Never
overload
an
electrical
outlet.
The
overall
system
load
should
not
exceed
80
percent
of
the
branch
circuit
rating.
Consult
an
electrician
for
more
information
if
you
have
questions
about
power
loads
and
branch
circuit
ratings.
Be
sure
that
the
power
outlet
you
are
using
is
properly
wired,
easily
accessible,
and
located
close
to
the
equipment.
Do
not
fully
extend
power
cords
in
a
way
that
will
stress
the
cords.
Connect
and
disconnect
the
equipment
from
the
electrical
outlet
carefully
Batteries
All
IBM
personal
computers
contain
a
non-rechargeable
coin
cell
battery
to
provide
power
to
the
system
clock.
In
addition
many
mobile
products
such
as
Thinkpad
notebook
PCs
utilize
a
rechargeable
battery
pack
to
provide
system
power
when
in
portable
mode.
Batteries
supplied
by
IBM
for
use
with
your
product
have
been
tested
for
compatibility
and
should
only
be
replaced
with
IBM
approved
parts.
Never
attempt
to
open
or
service
any
battery.
Do
not
crush,
puncture,
or
incinerate
batteries
or
short
circuit
the
metal
contacts.
Do
not
expose
the
battery
to
water
or
other
liquids.
Only
recharge
the
battery
pack
strictly
according
to
instructions
included
in
the
product
documentation.
Battery
abuse
or
mishandling
can
cause
the
battery
to
overheat,
which
can
cause
gasses
or
flame
to
“vent”
from
the
battery
pack
or
coin
cell.
If
your
battery
is
damaged,
or
if
you
notice
any
discharge
from
your
battery
or
the
buildup
of
foreign
materials
on
the
battery
leads,
stop
using
the
battery
and
obtain
a
replacement
from
the
battery
manufacturer.
Batteries
can
degrade
when
they
are
left
unused
for
long
periods
of
time.
For
some
rechargeable
batteries
(particularly
Lithium
Ion
batteries),
leaving
a
battery
unused
in
a
discharged
state
could
increase
the
risk
of
a
battery
short
circuit,
which
could
shorten
the
life
of
the
battery
and
can
also
pose
a
safety
hazard.
Do
not
let
rechargeable
Lithium-Ion
batteries
completely
discharge
or
store
these
batteries
in
a
discharged
state.
Heat
and
product
ventilation
Computers
generate
heat
when
turned
on
and
when
batteries
are
charging.
Notebook
PCs
can
generate
a
significant
amount
of
heat
due
to
their
compact
size.
Always
follow
these
basic
precautions:
v
Do
not
leave
the
base
of
your
computer
in
contact
with
your
lap
or
any
part
of
your
body
for
an
extended
period
when
the
computer
is
functioning
or
when
the
battery
is
charging.
Your
computer
produces
some
heat
during
normal
operation.
Extended
contact
with
the
body
could
cause
discomfort
or,
potentially,
a
skin
burn.
v
Do
not
operate
your
computer
or
charge
the
battery
near
flammable
materials
or
in
explosive
environments.
v
Ventilation
slots,
fans
and/or
heat
sinks
are
provided
with
the
product
for
safety,
comfort,
and
reliable
operation.
These
features
might
inadvertently
become
blocked
by
placing
the
product
on
a
bed,
sofa,
carpet,
or
other
flexible
surface.
Never
block,
cover
or
disable
these
features.
viii
IBM
Multi-Burner
Plus
User’s
Guide
CD
and
DVD
drive
safety
CD
and
DVD
drives
spin
discs
at
a
high
speed.
If
a
CD
or
DVD
is
cracked
or
otherwise
physically
damaged,
it
is
possible
for
the
disc
to
break
apart
or
even
shatter
when
the
CD
drive
is
in
use.
To
protect
against
possible
injury
due
to
this
situation,
and
to
reduce
the
risk
of
damage
to
your
machine,
do
the
following:
v
Always
store
CD/DVD
discs
in
their
original
packaging
v
Always
store
CD/DVD
discs
out
of
direct
sunlight
and
away
from
direct
heat
sources
v
Remove
CD/DVD
discs
from
the
computer
when
not
in
use
v
Do
not
bend
or
flex
CD/DVD
discs,
or
force
them
into
the
computer
or
their
packaging
v
Check
CD/DVD
discs
for
cracks
before
each
use.
Do
not
use
cracked
or
damaged
discs
General
safety
guidelines
ix
x
IBM
Multi-Burner
Plus
User’s
Guide
About
this
book
This
guide
contains
information
on
the
IBM
®
Multi-Burner
Plus,
and
is
available
in
the
following
languages:
v
Brazilian
Portuguese
v
Czech
v
English
v
French
v
German
v
Italian
v
Japanese
v
Simplified
Chinese
v
Slovak
v
Spanish
v
Traditional
Chinese
v
Turkish
The
guide
is
divided
into
the
following
parts:
Chapter
1,
″Introduction″
This
chapter
contains
product
and
software
descriptions
and
installation
requirements
for
the
IBM
Multi-Burner
Plus.
Chapter
2,
″Installation″
This
chapter
contains
hardware
and
software
installation
instructions
and
operating
information
for
the
IBM
Multi-Burner
Plus.
Appendixes
The
appendixes
contain
information
on
v
Product
specifications
v
Problem
solving
v
Customizing
the
device
driver
configuration
settings
v
Help
and
service
v
Warranty
and
notices
Be
sure
to
retain
your
proof
of
purchase.
It
might
be
required
for
warranty
service.
Registering
your
product
Thank
you
for
purchasing
this
IBM
product.
Please
take
a
few
moments
to
register
your
product
and
provide
us
with
information
that
will
help
IBM
to
better
serve
you
in
the
future.
Your
feedback
is
valuable
to
us
in
developing
products
and
services
that
are
important
to
you,
as
well
as
in
developing
better
ways
to
communicate
with
you.
Register
your
product
on
the
IBM
Web
site
at
http://www.ibm.com/pc/register
IBM
will
send
you
information
and
updates
on
your
registered
product
unless
you
indicate
on
the
Web
site
questionnaire
that
you
do
not
want
to
receive
further
information.
©
Copyright
IBM
Corp.
2004
xi
xii
IBM
Multi-Burner
Plus
User’s
Guide
Chapter
1.
Introduction
This
chapter
contains
product
and
software
descriptions
and
installation
requirements
for
the
IBM
Multi-Burner
Plus.
Product
description
This
option
package
is
intended
for
multimedia
applications.
The
drive
comes
with
a
CD
containing
software
for
the
following
operating
systems:
v
Microsoft
®
Windows
®
2000
Professional
v
Microsoft
Windows
Millennium
Edition
(Me)
v
Microsoft
Windows
XP
Your
option
package
contains
the
following:
v
User’s
Guide
and
Software
CD
(contains
Multi-Burner
Plus
User’s
Guide
and
Software
Applications)
v
IBM
Multi-Burner
Plus
Drive
v
Four
mounting
screws
(M3
x
5-mm,
slotted)
v
IDE
cable
v
IBM
Multi-Burner
Plus
Quick
Start
Guide
v
Laser
Safety
Guide
Contact
your
place
of
purchase
if
an
item
is
missing
or
damaged.
Be
sure
to
retain
your
proof
of
purchase;
it
might
be
required
to
receive
warranty
service.
See
Appendix
D,
“Service
and
Support,”
on
page
D-1
for
technical
support
information.
Your
Multi-Burner
Plus
is
compatible
with
the
DVD
Forum
DVD-Multi
Recorder
specification,
and
can
record
as
well
as
read
DVD-RAM,
DVD-RW,
and
DVD-R
(for
General,
650
nm)
media.
Your
drive
can
also
record
and
read
the
DVD+RW
Alliance
DVD+RW
and
DVD+R
formats.
In
addition,
your
drive
can
record
CD-R,
CD-RW,
(Standard,
High-Speed,
Ultra-Speed,
and
Ultra-Speed+)
media,
and
uses
buffer
underrun
prevention
technology
for
reliable
CD
and
DVD
burning.
Your
Multi-Burner
Plus
can
read
many
other
formats
including
DVD
Video,
Video
CD,
audio
CD,
multiple-session,
extended
architecture
(XA)
CDs,
and
Kodak
CDs.
The
Multi-Burner
Plus
is
designed
for
installation
in
a
computer
that
uses
integrated
drive
electronics
(IDE)
or
enhanced
IDE
(EIDE)
architecture.
Software
description
Your
IBM
Multi-Burner
Plus
User’s
Guide
and
Software
CD
contains
the
following
software:
v
Intervideo
WinDVD
Creator
Plus
This
software
enables
you
to
record
video
files
to
DVD-RW,
DVD-R,
DVD+RW,
and
DVD+R
media
that
can
be
played
in
most
stand-alone
DVD
players.
You
can
also
use
this
software
to
edit
and
modify
your
own
video
assets
prior
to
recording.
DVD-RAM
recording
is
also
supported.
If
you
have
an
analog
or
IEEE
1394
capture
device
installed
in
your
computer,
you
can
use
this
software
to
record
video
from
a
camera.
v
IBM
Drive
Letter
Access
(DLA)
This
software
enables
you
to
write
directly
to
CD
and
DVD
media
using
the
drive
letter
as
you
would
if
you
were
writing
to
a
diskette.
You
can
also
format
DVD-RAM,
DVD-RW,
DVD-R,
DVD+RW,
and
DVD+R
media.
With
DLA,
you
can
drag-and-drop
files,
create
new
directories,
or
save
files
from
almost
any
application
directly
to
your
Multi-Burner
Plus.
©
Copyright
IBM
Corp.
2004
1-1
v
UDF
reader
This
software
enables
you
to
install
software
for
reading
DVD-RAM,
DVD-RW,
DVD+RW,
and
CD-RW
media
on
other
computers
with
DVD
drives.
v
IBM
Record
Now
This
software
enables
you
to
copy
CDs,
create
audio
CDs,
create
MP3
CDs,
and
author
data
CDs.
You
can
also
use
RecordNow
to
write
data
to
DVD-RAM,
DVD-RW,
DVD-R,
DVD+RW,
and
DVD+R
discs
for
use
in
other
computers
or
compatible
consumer
electronics
products.
You
can
also
create
bootable
CDs
and
save
CD
images
for
later
recording.
v
IBM
Simple
Backup
This
software
enables
you
to
create
full
or
incremental
backups
of
your
system
files
on
DVD-RAM,
DVD-RW,
DVD-R,
DVD+RW,
DVD+R,
CD-R,
or
CD-RW
media,
and
allows
you
to
restore
your
computer
if
it
crashes.
v
Intervideo
WinDVD
This
software
enables
you
to
play
back
DVD
videos
on
your
computer
or
to
play
video
files
from
your
hard
disk
drive.
Note:
Some
graphics
adapters
such
as
the
FIREGL,
Intergraph,
and
3dLabs,
do
not
support
DVD
video
playback.
Installation
requirements
Be
sure
that
your
computer
meets
the
following
system
requirements
before
installing
the
drive:
v
Minimum
microprocessor:
Intel
®
Pentium
®
or
equivalent
For
DVD
authoring
and
playback,
you
must
have
an
Intel
Pentium
II
266MHz
microprocessor
or
higher
and
AGP
2X
Video.
v
Minimum
RAM:
32
MB
(Systems
with
UMA:
64
MB)
v
Windows
2000
Professional,
Windows
Me,
or
Windows
XP
v
An
available
5.25-in.
drive
bay
v
An
available
parallel
IDE
connection
v
70
MB
available
hard
disk
space
for
installation,
620
MB
available
hard
disk
space
for
every
hour
of
VCD-quality
MPEG-1
video,
and
2
GB
available
hard
disk
space
for
every
hour
of
DVD-quality
MPEG-2
video
v
Screen
resolution
of
at
least
1024
x
768
pixels
required
for
DVD
authoring
functions
v
Audio
adapter
supporting
44.1
or
48
kHz
sampling
rate
v
Optional
stereo
speakers
Before
you
begin
Before
you
install
the
Multi-Burner
Plus,
read
the
information
in
the
following
sections.
Handling
precautions
Use
the
following
handling
precautions
to
protect
your
drive:
v
Keep
the
Multi-Burner
Plus
in
the
antistatic
bag
until
you
are
ready
to
install
the
drive.
Limit
your
movement
when
installing;
movement
can
cause
static
electricity
to
build.
v
Handle
the
drive
with
care.
Dropping
or
jarring
the
drive
can
damage
the
components
inside
the
drive.
v
Do
not
force
insertion
of
the
IDE
or
power
cables.
Doing
so
might
damage
the
connector
or
the
drive.
1-2
IBM
Multi-Burner
Plus
User’s
Guide
Drive
controls
and
connectors
The
following
diagrams
show
the
location
and
functions
of
the
drive
controls
and
connectors.
Front
view
of
the
drive
RECORDER
MULTIM U LT I
1Disc
drawer
This
drawer
is
where
you
load
and
unload
a
disc.
2Busy
indicator
This
light
comes
on
when
the
drive
reads
from,
writes
to,
or
plays
a
disc.
3Emergency
eject
hole
This
hole
provides
access
to
the
eject
mechanism
to
remove
a
disc
from
the
drive.
4Open/Close
button
This
button
opens
and
closes
the
disc
drawer
when
you
push
it.
Rear
view
of
the
drive
Pin 1
1Reserved
2Audio-out
connector
This
connector
transmits
the
analog
audio
signals
to
an
audio
adapter.
3Configuration
pins
These
pins
are
used
to
set
the
drive
configuration.
4IDE
port
This
connects
the
drive
to
the
IDE
cable.
5Power
connector
This
connects
the
drive
to
the
power
cable.
Chapter
1.
Introduction
1-3
1-4
IBM
Multi-Burner
Plus
User’s
Guide
Chapter
2.
Installation
This
chapter
contains
hardware
and
software
installation
instructions
and
operating
information
for
the
IBM
Multi-Burner
Plus.
Installing
the
drive
Complete
the
following
steps
to
install
the
drive:
Step
1.
Opening
the
computer
1.
Turn
off
the
computer
and
all
attached
devices.
2.
Unplug
all
power
cords
from
the
computer
and
all
attached
devices.
3.
Remove
the
cover
from
the
computer.
Refer
to
your
computer
documentation
for
instructions
on
removing
the
computer
cover.
Step
2.
Unpacking
the
drive
1.
Before
opening
the
antistatic
bag
that
the
drive
is
packed
in,
touch
the
bag
to
an
unpainted
metal
surface
for
at
least
two
seconds.
This
drains
the
static
electricity
from
the
package
and
your
body.
2.
Remove
the
drive
from
the
bag.
If
you
must
put
the
drive
down,
place
the
antistatic
bag
on
a
flat,
padded
surface,
and
place
the
drive
on
the
antistatic
bag.
Step
3.
Setting
the
configuration
jumpers
You
can
configure
your
drive
as
master
1,
slave
2,
or
cable-select
3,
by
placing
the
jumper
over
the
configuration
pins
as
shown.
Use
the
following
guidelines
to
determine
the
correct
configuration
for
your
drive.
v
Configure
the
drive
as
a
master
if
it
will
be
the
only
device
that
is
connected
to
the
IDE
cable.
This
is
the
preset
configuration.
v
Configure
the
drive
as
a
slave
if
it
will
be
the
second
device
on
an
IDE
cable.
Be
sure
to
configure
the
other
device
as
a
master.
In
some
cases,
a
hard
disk
drive
might
require
a
“master
with
slave
present”
jumper
setting
when
another
device
on
the
same
cable
is
configured
as
a
slave.
For
more
information
on
setting
configuration
jumpers
on
other
devices,
refer
to
the
documentation
that
comes
with
your
computer.
v
Some
computers
use
special
ATA
cables
with
two
wires
reversed
in
the
device
connectors
so
that
the
drives
can
be
configured
by
the
cable
instead
of
by
jumper
position.
Use
the
cable-select
position
only
for
computers
that
are
equipped
with
these
special
cables.
See
the
documentation
that
comes
with
your
computer
to
determine
if
your
ATA
adapter
requires
that
you
place
the
jumpers
in
the
cable-select
position.
©
Copyright
IBM
Corp.
2004
2-1
If
you
place
the
jumper
in
the
cable-select
position,
the
IDE
cable
automatically
assigns
the
master
and
slave
settings
based
on
the
position
of
the
drive
on
the
cable.
You
must
use
the
cable-select
setting
for
this
cabling
system
whether
the
drive
is
the
only
device
or
the
second
device
connected
to
the
cable.
The
drive
closest
to
the
IDE
controller
is
automatically
the
master
drive.
Any
other
devices
on
the
IDE
cable
must
also
be
set
to
cable-select.
Step
4.
Mounting
the
drive
in
the
bay
Attention
Be
sure
to
use
the
M3
x
5-mm
mounting
screws
in
the
option
package
when
securing
screws
directly
into
the
drive.
Using
screws
that
are
too
long
might
damage
the
drive.
You
can
mount
the
drive
horizontally
or
vertically
in
the
computer.
If
you
mount
the
drive
vertically,
you
must
secure
any
discs
that
you
place
into
the
drive
before
the
drive
tray
is
closed,
or
the
drive
will
not
be
able
to
read
the
disc
properly.
1.
Slide
the
drive
into
the
bay.
Your
computer
might
have
required
procedures
for
installing
storage
devices.
For
more
information
on
storage
devices,
refer
to
the
documentation
that
comes
with
your
computer.
2.
Align
the
drive-bay
screw
holes
with
the
threaded
holes
in
the
drive
housing
or
mounting
bracket.
3.
Thread
the
screws
in
loosely
to
check
their
position.
Two
screws
are
usually
used
on
each
side.
Verify
that
the
alignment
is
correct;
then
tighten
the
screws
to
secure
the
drive.
Do
not
overtighten.
Step
5.
Attaching
the
cables
to
the
drive
The
following
diagram
shows
where
to
connect
the
cables
to
the
drive.
1.
Attach
a
40-pin
IDE-cable
connector
1to
the
IDE
connector
on
the
drive.
Align
the
cable
so
that
the
color-coded
edge
is
closest
to
the
power
cable
connector
2.
Use
the
80-conductor
high
speed
IDE
cable
that
is
provided
with
this
option
if
there
is
no
cable
attached
to
the
IDE
port,
if
there
is
only
one
device
connector
on
the
computer
IDE
cable,
or
if
the
existing
cable
in
your
computer
is
a
low-speed
40-conductor
type.
The
IDE
cable
can
have
up
to
three
connectors.
For
the
best
signal
quality
when
you
are
connecting
only
one
device
to
the
IDE
cable,
connect
one
end
of
the
cable
to
the
IDE
port,
and
connect
the
other
end
of
the
cable
to
the
device.
Do
not
use
the
middle
connector.
If
you
are
connecting
two
devices
to
the
IDE
cable,
connect
one
end
of
the
cable
to
the
IDE
port,
and
connect
the
master
and
slave
devices
to
the
remaining
connectors
on
the
other
end.
Many
computers
have
two
cables
for
attaching
up
to
four
ATA
devices.
For
best
performance,
attach
fast
devices
(hard
disk
drives)
to
the
cable
that
is
connected
to
the
primary
IDE
port,
and
connect
the
drive
or
other
slower
devices
(CD-ROM
drives,
tape
drives,
diskette
drives)
to
the
cable
that
is
connected
to
the
secondary
IDE
port.
2.
Attach
a
four-pin
power
cable
2to
the
power
connector
on
the
drive.
Be
sure
that
the
cables
will
not
be
pinched
or
crowded
by
the
computer
cover
and
that
all
other
cable
and
power
connections
are
secure.
2-2
IBM
Multi-Burner
Plus
User’s
Guide
