iBoardTouch LTE55-003V+ User manual

INSTRUCTION MANUAL
Before connecting, operating or adjusting this product, please read the manual completely.
Please keep this manual for future reference.
LTE55-003V+
LTE65-003V+
LTE70-003V+
LTE75-003V+
LTE84-003V+
Interactive Flat Panel

Contents
Important Information 1
Important Safety Precautions 2
Important Notice 4
Identification of Controls 5
Remote Control 6
Setting Up 7
Connections 8
Basic Operations 10
System Settings 12
Network Settings 13
Menu List
Troubleshooting 20
Specifications 21
15
Using USB Multi Media Player 17

1
IMPORTANT INFORMATION
If the IFP is not positioned in a stable location, it can be potentially hazardous due
to falling. Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
! Use cabinets or stands recommended by the manufacturer of the IFP.
! Only use furniture that can safely support the IFP .
! Ensure the IFP is not hanging over the edge of the supporting furniture.
! Do not place the IFP on tall furniture (for example, cupboards or bookcases)
without anchoring both the furniture and the IFP to a suitable support.
! Do not position the IFP on cloth or other materials placed between the IFP
and supporting furniture.
! Increase children’s awareness of danger caused by falling down of the IFP, or
being hurt by bumping into the IFP.
Warning:
To prevent the spread of fire, keep candles or other
open flames away from the IFP all the times.

2
Important Safety Precautions
Electricity may cause personal injuries and property damage if improperly handled. The IFP has been engineered and
manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRIC SHOCK OR
FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong the service life of your IFP, please read the following precautions
carefully before using the product.
All warnings on the product and in the instruction manual must be observed closely.
7.Power cord protection---
1. Read these instructions---All operating instructions must be read and understood before the product is operated.
2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.
3. Note all warnings---
4. Follow all instructions---All operating instructions must be followed.
5.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments which are not
recommended by the manufacturer. Use of improper attachments can result in accidents.
6. Power source---This product is intended to be supplied with a listed power supply indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your product dealer or local power company. For added protection
for this product during a lightning storm, or when it is left unattended and unused for a long period of time, unplug it from the
wall outlet and disconnect the cable system.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
NOTE: Where the mains plug or an appliance coupler is used as the disconnected device, the disconnected device shall remain
readily operable.
8.Overloading---Do not overload wall outlets, extension cords, or convenience receptacles on other
equipment as this can result in a risk of fire or electric shock.
9.Entering of objects and liquids---Never insert an object into the product through vents or openings. High voltages are
present in the product and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not
spill water or liquid on the product.
10. Servicing---Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally or has been dropped.
11.Damage requiring service---If any of the following conditions occurs, unplug the power cord from the AC outlet and
request a qualified service technician to perform repairs.
a. When the power cord or plug is damaged.
b. When liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not
described in the instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in
the product indicates that the product needs servicing.
12. Replacement parts---In case the product needs replacement parts, make sure that the service person uses
replacement parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.
13. Safety checks---Upon completion of service or repair work, request the service technician to perform safety
checks to ensure that the product is in proper operating condition.
14. Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to install the product according to
the method recommended by the manufacturer. This is a safety feature.

3
Important Safety Precautions (Continued)
15. Stand---Use only with the trolley stand or wall mount specified by the
manufacturer, or sold with the apparatus. Do not place the product on an unstable
trolley stand or wall mount. Placing the product on an unstable base can cause the
product to fall, resulting in possible serious injuries as well as damage to the
product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by
the manufacturer.
16.Careful move---When a trolley is used, be cautions when moving the
trolley/apparatus combination to avoid injury from the product tipping over.
Sudden stops, excessive force and uneven floor surfaces can cause the product to
fall from the trolley.
Never attempt to move the IFP unless the AC power cord has been disconnected.
17. Lightning---Unplug this apparatus during thunder storm or when unused for
long periods of time.
For added protection during a thunder storm, or when the IFP is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna. This will prevent damage to the equipment due to lightning and
power-line surges.
18. Do not use this apparatus near water---for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool,
and the like.
Do not use immediately after moving from a low temperature to high temperature
environment, as this causes condensation, which may result in fire, electric shock,
or other hazards.
19. Clean only with dry cloth---Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a soft cloth for
cleaning.
20. Ventilation---Do not block any ventilation openings. Install the IFP in
accordance with the manufacturer instructions. The vents and other openings in
the cabinet are designed for ventilation. Do not cover or block these vents and
openings since insufficient ventilation can cause overheating and/or shorten the life
of the product. Do not place the product on a bed, sofa, rug or other similar
surface, since they can block ventilation openings. This product is not designed for
built-in installation; therefore do not place the product in an enclosed space such as
a bookcase or rack, unless proper ventilation is provided or the manufacturer’s
instructions are followed.
21.Heat sources---Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
22.Panel protection---The display panel used in this product is made of glass.
Therefore, it can break when the product is dropped or impacted upon by other
objects. Be careful not to be injured by broken glass pieces in case the display panel
breaks.
23.Pixel defect---The display panel is a very high technology product, giving you
finely detailed pictures. Occasionally, a few non-active pixels may appear on the
screen as a fixed point of blue, green or red. Please note that this does not affect
the performance of your product.
WARNING: For continued safety, apparatus with class I construction shall be
connected to a mains socket outlet with a protective earthing connection.
The apparatus should not be exposed to dripping or splashing liquids
and that no objects filled with liquids, such as vases, shall be placed on the
apparatus.

Important Notice
About After-Image
Cleaning and
Maintenance
The extended use of fixed image program material can cause a permanent
on the screen.
This background image is viewable on normal programs in the form of a stationary
fixed image. This type of irreversible screen deterioration can be limited by
observing the following steps:
A. Reduce the brightness/contrast setting to a minimum viewing level.
B. Do not display the fixed image for extended periods of time.
C. Turn the power off when not in actual use.
Important Information Regarding Use of Video Games,
Computers, Captions or Other Fixed Image Displays.
after-
!Do not allow a still picture to be displayed for an extended period, as this can cause
a permanent after-image to remain on the screen.
Examples of still pictures include logos, video games, computer images, teletext
and images displayed in 4:3 mode.
CAUTIONS:
!The permanent after-image on the screen resulting from fixed image use is not an
operating defect and as such is not covered by the warranty.
!This product is not designed to display fixed images for extended periods of time.
About Location/
Environment
Do not use in hot and cold rooms (locations)
!When the unit is used in rooms (locations) with low temperature, the picture may
leave trails or appear slightly delayed. This is not a malfunction, and the unit will
recover when the temperature returns to normal.
!Do not leave the unit in a hot or cold location. Also, do not leave the unit in a
location exposed to direct sunlight or near a heater, or in high humidity, as this may
cause the cabinet to deform and the to malfunction, and affect the IFP’s
performance .
screen
!Environment condition:
Operating temperature: 5°C – 35°C
Operating humidity: 20 – 80 % ( no moisture condensation )
Storage temperature: -15°C – 45°C
Storage humidity: 10 – 80 %
Atmospheric pressure: 86 kPa ~106 kPa
To clean this unit, wipe with a soft, dry cloth.
Clean the cabinet with a soft, lint-free cloth, If the cabinet is especially dirty, moisten a
soft, lint-free cloth in a weak detergent solution, squeeze the excess moisture from
the cloth, then wipe the cabinet with the cloth. Use a clean cloth to dry the cabinet.
Use eyeglass cleaner to remove stubborn dirt from the screen.
Never use alcohol, paint thinner or benzine to clean this unit.
!Clean the screen with a soft, lint-free cloth.
!
!
Carrying or Moving
the IFP
! When you move the IFP , hold the frame of the IFP .
Be aware of the danger or harm which may caused by carrying or moving the IFP ,
as the bezel is very thin.
When transporting, do not subject the unit to shocks or vibration, or excessive
force.
!
!
4

1. : USB standard interface of the IFP,enable
connection to USB2.0 standard devices.
2. : USB standard interface of the OPS,enable
connection to USB2.0 standard devices.
Note: If no OPS, the USB port has no function.
3. :Switch the IFP power on or standby.
4. : Press the button to display input source menu
or exit the menu screen.
5. : Press the button to return to previous menu.
6. : Press the button to display desktop (Home
page) on the screen.
7. : Press the button to open the setting menu.
8. : Press the button to turn down the volume.
9. : Press the button to turn up the volume.
Remote Sensor
Power Indicator
Identification of Controls
5
AC I N
13 14
2
1
3
4
5
6
HD MI 1
HD MI 2
HD MI 3
US B
US B 3. 0
VG A
OU T
VG A
VG A
AUDIO
PC I N 1
AUDIO
PC I N 2
TO UC H
OU T 578 9 10 11 12
AV IN SP DI F LAN OUT RS -2 32
VG A WAN I N
AUDIO
PC I N 3
1.
WIFI port for transmitting or receiving network signal.
2. USB2.0/3.0
USB standard interface, enable connection to
USB2.0, USB3.0 standard devices. When connecting,
please select the appropriate port.
3.HDMI1/2/3 Input
To connect with those equipments with HDMI or DVI
interface, for example, Set-top box or DVD player. (A
HDMI-to-DVI adapter cable is required when you are
connecting a DVI-equipped device to the IFP.)
4.VGA OUT
The currently selected PC IN 1/2/3 signal output.
2
5.PC IN1/2/3
Enable connection to PC or other external devices
with VGA/AUDIO ports.
6.TOUCH OUT
Control the external devices by native touch
control (For example computer). (Only for
PC1/2/3、HDMI1 signal.)
7.AV IN
Connect an AV device to this jack.
8.S/PDIF digital audio output
Connect a digital sound system to this jack.
9.
Connect headphones to this jack. IFP is the
current audio output.
10.LAN OUT
The built-in router output port. Connection to
another computer or other Internet enabled
devices.
11.WAN IN
The built-in router input port. Connect to the
external network.
12.RS232
For service, software upgrades and the other
uses.
13. AC IN
Plug the AC cord into this jack and into a power
outlet.(~100-240V 50Hz/60Hz)
14. Power Switch
Push to (1) to connect the power, push to (O ) to
cut off.
Note: Power switch can not be covered, and should
keep the power switch can be conveniently
operated.
1 2 3 4 5 6 7 8 9

6
Remote Control
●
●
This operation manual provides a description based on operating functions with the remote control.
In different mode, some buttons may have different function.
Note
0
1 2 3
456
7 8 9
0
1 2 3
456
7 8 9
USB DVD
POWER
TV
INFO
MENU
PC
CH VOL
P.M
OK
AV VGA
RC-J55-0B
ZO OM
EXIT
SLEEP
MUTE
HOME
INPUT
S.M
HDMI
SNAP FREEZE
Select sound mode
Set up the sleep timer
Select picture mode
Select the screen size
Return to previous menu
or exit the on-screen menu
Mute the sound
Display or exit the setting menu screen
Coloured buttons(RED/GREEN/YELLOW/BLUE)
delete or add a shortcut.
In all applications, use the red button to
Switch to HDMI mode
Switch to VGA mode
0-9 number buttons
Switch to AV mode
Switch to TV mode
Displ ay OPS on the scr ee n
Press to enter or exit the disc tray
: Play/Pause button
: STOP button
/ : Fast forward/fast reverse
/ : Previous/next
Return to the previous channel
VOLUME UP/DOWN
Control buttons for USB/DVD Multi Media Player
Go to USB multi media player
Go to DVD multi media player
To confirm or enter a sub-menu or toggle
between options during MENU operation.
Use Arrow buttons to navigate in on-screen
menu.
CHANNEL UP/DOWN
To freeze the current picture
Note: If no DVD, this button has no function.
Note: If no OPS, VGA1 mode will be displayed
on the screen.
Note: If no RF, this button has no function.
Switch the IFP power on or Standby
Display or exit input source menu
Display or exit the current
program information
Display desktop (Home page)on the screen
Take screenshot and store the data
onto
take screenshot and store the data
onto
or USB Drive.
your connected USB device.
If USB device is not connected ,
built-in SDcard.
Folder's Location: go to
Applications, then choose ES File
Explorer

Setting Up
Installing remote control Batteries
Battery precautions:
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be
sure to follow the instructions below.
·Place batteries with their terminals corresponding to the (+) and (–) indications.
·Different types of batteries have different characteristics. Do not mix batteries of
different types.
·Do not mix old and new batteries. Mixing old and new batteries can shorten the
life of new batteries and/or cause old batteries to leak chemicals.
·Remove batteries as soon as they are non-operable. Chemicals that leak from
batteries can cause a rash. If chemical leakage is found, wipe with a cloth.
·Dispose of batteries in a proper manner.
·If the remote control is not used for an extended period of time, remove the
batteries.
·The batteries shall not be exposed to excessive heat such as sunshine, fire or the
like.
Open the battery cover.
1
Insert two AAA batteries into the battery compartment. Make sure that the +
and – symbols on the batteries match the + and – symbols in the battery
compartment.
2
Replace the cover.
3
Selecting a location You should select a location for the IFP:
·Where direct light does not reflect on the screen.
·That has indirect and soft lighting.
·Where the IFP has access to a power outlet.
Note: Watching IFP in total darkness or with a reflection on the screen may cause
eyestrain.
To install remote control batteries:
Aiming the remote control Use the remote control by pointing it towards the remote sensor on the front of
your IFP. Objects between the remote control and the remote sensor may prevent
proper operation.
Cautions regarding use of remote control
·Do not expose the remote control to shock. In addition, do not expose the remote
control to liquids, and do not place in an area with high humidity.
·Do not install or place the remote control under direct sunlight. The heat may
cause deformation of the unit.
·The remote control may not work properly if the remote sensor window of the
main unit is under direct sunlight or strong lighting. In such a case, change the angle
of the lighting or the IFP set, or operate the remote control closer to the remote
sensor window.
30
30
5m
7
0
1 2 3
456
7 8 9
0
1 2 3
456
7 8 9
USB DVD
POWER
TV
INFO
MENU
PC
CH VOL
P.M
OK
AV VGA
ZOOM
EXIT
SLEEP
MUTE
HOME
INPUT
S.M
HDMI

AV devices
DVD/VCD
Game console
Y
W
R
Digital sound
system
PC, etc.
VGA devices
PC OUT
Y
W
R
Serial port cable
VGA cable
AV cable
AV adapter
Network cable
Computer, etc.
Internet devices
Network connection
Before using headphones,
adjust the device volume so
as to avoid excessive levels, as
hearing damage may result.
AV OU T
VI DE O AU DI O
Y
W
R
S/PDIF cable
Audio cable
Camcorder
Satellite signal receiver
Computer, etc.
Network cable
Headphone cable
Audio input devices
1. Connect the female plug to the AC socket on the unit.
2. Connect the male plug to the wall outlet as illustrated.
=This product should be operated only from the type
of power source indicated on the marking label.
=Always unplug the AC cord from power outlet when
not using for a long period of time.
Note:
AC I N
=When connecting an external device to the IFP, make sure that the IFP and the device are turned off.
=Check the plugs at the ends of cables to make sure that they are the correct type before you try plugging them into jacks on the IFP.
=Make sure that all plugs are securely inserted into the jacks. Loose connections can result in image or color problems.
=The illustration of the external device may be different depending on your model.
=Refer to the operating manual of the external device as well.
Cautions Before Connecting
Connections
Tighten the WiFi antenna in clockwise direction. The WiFi
Inside AP. When network cable is plugged in WAN port, the antenna will generate WiFi network.
antenna is able to access WiFi network.
HDMI cable
USB cable
USB devices
3.0
2.0
HDMI cable
HDMI cable
PC OUT
VGA cable
Audio cable
USB cable
USB devices
VGA cable
VGA cable
Note: 1.The IFP is multiple USB port designed(1x3.0, 3x2.0), when connect with
USB device, please select the appropriate port.
2.The signal of Audio or Video output are IFP generated.
3.The VGA output is signal of what has been currently selected from PC1/2/3.
Audio cable
Camcorder
HDMI devices
DVD
Game console
PC, etc.
VGA devices
Monitor
Front USB ports
8
AV IN SP DI F LAN OUT RS -2 32
VG A WAN I N
AUDIO
PC I N 3
HD MI 1
HD MI 2
HD MI 3
US B
US B 3. 0
VG A
OU T
VG A
VG A
AUDIO
PC I N 1
AUDIO
PC I N 2
TO UC H
OU T
2.0 2.0
Set top box
Satellite signal receiver
Set top box

9
DVI devices
DVI to HDMI cable
Audio cable
Use a DVI to HDMI adapter cable to
cnnect to the HDMI terminal. Connect the
audio cable to the PC IN1 AUDIO jack.
L R
AU DI O OUT PU T
DV I OU T
DVD
Camcorder
Game console
VGA OUT AUD IO
OUT
USB
Not: After installation of the driver, it can control the external computer by native touch
control. (Only for PC1/2/3、HDMI1 signal)
VGA cable
Audio cable
Computer
USB cable
Connections
HD MI 1
HD MI 2
HD MI 3
US B
US B 3. 0
VG A
OU T
VG A
VG A
AUDIO
PC I N 1
AUDIO
PC I N 2
TO UC H
OU T
Set top box
Satellite signal receiver
Connect PC with VGA cable or HDMI cable.
Connect TOUCH OUT with USB cable to PC USB port.
Please choose the proper method of connection based on your device.
HD MI
USB HD MI
HDMI cable
USB cable

Basic Operations
Note: If the IFP does not receive a displaying signal for a certain time, the IFP goes into standby mode.
Plug the power cord into an AC power outlet. Press Power Switch on the IFP.
Now the IFP is in standby mode. Wait a moment until the power indicator lights up, then press POWER to turn on the
IFP. (Be sure to wait for a few seconds before pressing POWER button. If you promptly press POWER button then the IFP
may not respond or act wrongly.)
Press button again to turn off the IFP and put the IFP in standby mode.
To cut off the power completely, press Power Switch on the IFP.
Warning: When the IFP is in standby mode, power is still flowing into the IFP. For the sake of energy saving and safety issue, please press
Power Switch to completely cut off the power. After you turn off the IFP, you should wait for at least 5 seconds (the power
indicator goes out)before you turn it on again.
1
2
3
Turning the IFP on or off
Using the software keyboard
Upper case/lower case shift
Input language (English/Chinese) shift
Backspace (delete one character leftward)
Symbol shift
Shift between English/Chinese symbol
Confirm the input and return
Chinese input method
Note: The onscreen software keyboard may vary, but its operation method is the same.
中文输入法（Google拼音输入法）
10

1
2
Touch once outside the MENU, the MENU
will be show , you can press and drag
to any place of the screen, then touch once to
MENU.
When displaying at USB interface, touch
once at the lower part of the screen, the
display control menu will appear.
display the
(p.12)
(p.15)
Basic Operations
11
Switch to the Home page (Android Interface)
Switch to different input source, i.e. HDMI, VGA, etc.
Touch the bottom of the
screen and drag upward
to make the MENU
appear.
Switch to the TV menu screen
Switch to the OPS interface
Show TV system program
Shortcuts you created on Home page
Show all applications
Go to your web Browser.
Open the System Setup menu.(p.13)
Go to normal TV viewing.
Go to your (p.17) USB multi media player.
Switch to the OPS interface
Home Page Overview
Note: The layout of menu may vary upon different models you purchased.
Note: If no OPS, VGA1 mode will be displayed on the screen.
Note: If no OPS, VGA1 mode will be
displayed on the screen.
Touch the screen and drag to the left direction to
return to Home Page
2
Not: When using the app Camera, store the data onto your connected USB device. If USB
device is not connected , built-in SDcard.
Folder's Location: go to Applications, then choose ES File Explorer
store the data onto
or USB Drive.
1
Go to your web Browser.
Go to your local USB multi-media player.(p.17)
Energy saving, the backlight brightness is decreased.
Link to Google Play.
Select the aspect ratio (display proportions) according to your video signal
type or personal preference.

12
System Settings
Display information
Display system information or
restore to factory default.
To set on-screen language
To set default input method
To set Android keyboard(AOSP)
Wallpaper Setting
Note: To manually set date and time, you should
toggle “Set date and time automatically
from the Internet” to OFF.
Network Setting (p.13)
Display current network status.
Internal routing setting
If the internal AP doesn’t work,
reset via Internal Routing
Hardware Reset.
Input the default UserName:
admin, skip the default
password setting as there is
no default password, then
press Login button login.
Change the UserName and Password:
Enter the Site contents menu, select
Management, then Password.
Press OK to access its edit menu.
Force this application to stop
Uninstall this application
Clear data of this application

13
Network Settings
Select Setup Wizard
Select Gateway
Next
Wired Network Setting
Next
Next
Next
Next
Finished
Next
Static IP
DHCP Client
PPPOE
PPTP
L2TP
There are five methods to connect with
network, choose your preferred one.
If all Internet IP information is
provided by your ISP, then
choose Static IP.
Automatically obtain IP
information from your ISP. If your
ISP doesn’t provide a designated
IP for you, then choose DHCP
Client.
Passward Setting Format
WiFi Password of
Internal Router in IFP.
Point to Point Tun ne li ng
Protocol. Your ISP will provide
y o u w i t h L o g i n I D a n d
password.
Layer 2 Tunneling Protocol.
Your ISP will provide you with
Login ID and password. Usually
this option is applicable to DSL
service.
Ethernet Point to Protocol.
Your ISP will provide you with
Login ID and password. Usually
this option is applicable to DSL
service.

14
Network Settings(Continued)
Select Setup Wizard
Next Select Wireless ISP
Next
Connect
Next
Next
Finished
Select
Wireless,
then Site
Survey
Select your desired
WiFi signal.
Next
Next
Next
Next
Confirm Site Survey
Wireless Network Setting
Passward Setting Format
WiFi Password of Internal
Router in IFP.
Successfully
connected, return
to Site contents.
Input
Password

Menu List
Turn the Surround sound effect on or off. Surround
Treble Adjust Treble (high sounds).
Bass Adjust Bass (low sounds) .
Sound
Alone Press OK to turn off the picture on your IFP and listen to the program audio only.
Balance Adjust volume level of right and left speakers.
AVC Select [On] to equalize overall volume levels across all channels.
Select [Off] to turn off the auto volume control.
SPDIF Output Select the digital audio output mode for S/PDIF.
Select [RAW] to output audio signal as its original format.
Select [PCM] to output audio signal by PCM format.
(digital signal only)
Sound Mode Select your favourite sound mode for each input [Alive] / [Standard] / [Music] /
[Movie] / [News] / [User].
15
Menu Time
OSD Language Select on-screen menu language.
Setting
Restore To Default
Select OSD menu display time.
Reset all settings to factory defaults.
Noise Reduction Select the noise reduction mode to reduce picture noise (snow)You can
select Weak, Middle, Strong, or Off.
Set up the overall brilliance of the screen.
Backlight
Color temperature Select the color temperature. You can select Warm, Cool or Normal.
Brightness Adjust the brightness.
Contrast
Adjust the contrast.
Saturation
Adjust the color saturation.
Tint
Adjust the image hue. (Only for NTSC system)
Sharpness
Adjust the sharpness.
Screen
The backlight brightness is decreased. [Off] /[Save1] / [Save2]
Energy Save
Aspect ratio Select the aspect ratio (display proportions) according to your video signal
type or personal preference [16:9] /[4:3] / [Panorama] / [Just Scan]/
[Zoom1] / [Zoom2] .
Clock Adjust the screen size.
Phase Adjust the focus of stable images.
Horizontal Position Move the image right or left.
Vertical Position Move the image up or down.
Auto Tune
Automatically adjust the image settings such as position and phase.
DLC Enhance the contrast ratio between light and dark areas of the picture.
You can select On or Off. If this is set to On, Backlight cannot be
adjusted.
MWE Select magic picture demo mode.
Picture Mode Select your favourite picture mode for each input
/ [Soft] / [User].
[Dynamic]
[Standard] /
MEMC Selects Low/Middle/High from to reduce motion blur, thus to improve
picture quality. Selects off to turn off this function.
Note: Some models without MEMC function will according to your
purchase model.

Menu List
16
Sleep Time
Off Time
On Time
Time
Date
Current Time
Set the duration of time until the IFP automatically goes into Standby
mode.
[Off] / [10 Minutes] / [20 Minutes] / [30 Minutes] / [60 Minutes] /
[90 Minutes] / [120 Minutes] / [180 Minutes] / [240 Minutes].
Set On timer to turn on the IFP automatically to source at a certain
time.
Set Off timer to switch the IFP to standby at a specified time.
Set current date manually.
Set current time manually.
Lock Keypad
Change Logo
Power on Source
Parental Control
Lock System
Set Password
Navigate to the Parental Control menu and input the correct
password to access. Select Change Logo item, press OK to
access and change Logo.
Note: 1. Save the logo which you are about to change in the USB
stick. The logo file sizes should be <512K, and rename it
as boot0.jpg.
2. Insert the USB stick into the USB port on the Android
board.
Password settings.
Set to ON, is locked. Reset settings to factory
defaults just input the correct password.
Restore To Default
,
Select Parental Control menu, press OK to access the menu. Now a password is
required to input. (The default password is 0000. The unit provides a super password
“2580”.)
The IFP buttons is locked.
OFF: Select to enable the panel buttons.
ON: Select to disable the panel buttons.
Power on Source Setting, in MEMORY mode, when the IFP
powered on, it will automatically switch to the source when it
powered off last time. otherwise, it is in setting mode.

Using USB Multi Media Player
You can connect a USB storage device to your IFP to view compatible photo, movie on the large screen of the IFP or play
compatible music so that the sound can be output from the IFP’s speaker.
To use USB multi media player, please go to USB source by pressing USB button. Or you can press Home button to display
Home Page and then select USB Drive icon to access.
Notes:
·
·
·
·
·
·
Never remove the USB storage device or turn off the IFP while using the USB storage device.
It is recommended that you back up your USB device data.
The USB menu may vary in different situation.
If you want to pull out the USB device, please exit USB mode first. For instructions on using your USB device, refer to
the user’s manual of your USB device.
Please name your files in English. Otherwise the file names can not be shown correctly.
Certain types of USB device may not be compatible with this IFP.
Using USB multi media player
USB multi media interface introduction
Method 1: Press USB button to access
Method 2: From Home Page, select
USB Drive icon to access.
17
Video: Select to play compatible movie.
Music: Select to play compatible music.
Picture: Select to view compatible photos.
All: Select to show all files so that you can easily select any file to play.
To select and play files from different sources.
(you can select from local disk device (USB device),
network DLNA device, network SAMBA device)

Previous photo
Play/pause
Next photo
Rotate anti-clockwise
Rotate clockwise
Show information
Return to previous menu
Note: You can also use (Play/Pause), (STOP), (Previous), (Next) on the remote control to operate.
Playing settings
Playing Photo
With the photo viewer, you can view compatible photos (in JPG, BMP or PNG format). Also you can zoom, rotate photo, etc.
Note: The photo viewer supports JPG, BMP, PNG format images, but not all JPG, BMP, or PNG files are compatible with the
IFP due to technical update.
Using USB Multi Media Player
Playing Music
With the USB music player, you can play compatible music (in MP3 or AAC format).
Note: The USB music player supports MP3, AAC format audio files, but not all MP3 or AAC files are compatible with the IFP
due to technical update.
Return to previous menu
Previous song
Pause/Play Show information
Show playlist
Repeat mode select
Next song
repeat to play single music, repeat to play all music
files in current folder when it plays to the end, no repeat
when it plays to the end.
Note: You can also use (Play/Pause), (STOP), (Previous), (Next) on the remote control to operate.
18
