IBT SWITCH..IT User manual

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 1
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
switch...it
Installation Guide
V1.11

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 2
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Contents
Installation instructions............................................................................................................................. 3
Caution Safety Instructions! ..................................................................................................................... 3
Mechanical Installation instructions ......................................................................................................... 3
LAN integration......................................................................................................................................... 3
IP Address set-up....................................................................................................................................... 4
Set-up Client IP Address.......................................................................................................................... 4
Set-up Client Netmask............................................................................................................................. 4
Set-up Client Gateway............................................................................................................................. 4
Set-up NTP Server Address..................................................................................................................... 4
Set-up Unit Number ................................................................................................................................. 4
Getting started.......................................................................................................................................... 4
Frame connections..................................................................................................................................... 5
Pinout switch…it 1-RU Frame.................................................................................................................. 6
RS-232 Port *.......................................................................................................................................... 6
LAN Interface ........................................................................................................................................... 6
Pinout System cards.................................................................................................................................. 7
Switch…it - SER-2 dual RS-422 Port....................................................................................................... 7
Switch…it - GPIO parallel In/Out card ..................................................................................................... 7
switch…it TCP/IP Protokolle ................................................................................................................... 8
switch…it Systemkabel............................................................................................................................ 8
Serial RS-422 cable for IBT panel / matrixes Snell, Miranda, Nevion(Multicon) .....................................8
Serial RS-422 cable for switcher Kahuna, MVS-3000/65xx,XtendD, DD30,KAYAK............................... 9
Serial RS-422 cable for switcher Sony MVS-6000/8000 Mischer............................................................ 9
Serial RS-422 cable for Stagetec Nexus ............................................................................................... 10
Serial RS-422 cable for „first“ IBT-UMD of daisy chain bus...................................................................10
Serial RS-422 cable for IBT-UMD daisy chain bus................................................................................ 11
Serial RS-422 cable for Multiviewer Miranda KX Serie .........................................................................11
Serial RS-422 cable for Multiviewer Evertz MVW VIP A8 Duo.............................................................. 12
Serial RS-422 cablel for Multiviewer Evertz Quad VIP 4....................................................................... 12
GPIO input / output connections............................................................................................................ 13
Troubleshooting ....................................................................................................................................... 14
GUI can not open (Website not found) .................................................................................................. 14
Daten per FTP ins System übertragen fails with timeout....................................................................... 14
Webpanel can not connect..................................................................................................................... 14
TSL Protocol........................................................................................................................................... 14
Nvision Protocol ..................................................................................................................................... 14
Nevion MRP Protocol............................................................................................................................. 15
Common specifications........................................................................................................................... 16
Frame version depending specifications............................................................................................... 16
Changeindex............................................................................................................................................. 16

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 3
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Installation instructions
Caution Safety Instructions!
This manual is intended for qualified operating personnel. Electronic technical
knowledge is required for the handling of this device or system in order to avoid the risk
of electric shock or equipment damage. Perform only those referred to in this manual
Installation and Operating Instructions unless you are qualified on these instructions
also make interventions.
Always disconnect power supply before opening the frame!
This device operates in the specified voltage range without the need for manual
adjustment is required.
For the wiring different power cord can be used that meet the product safety
requirements of the country in which they are used. For this device, a power cord with a
protective conductor is required. The power cord must be rated for a nominal voltage of
240V / AC.
To ensure safety and permanent fire protection, all fuses may be replaced only by
identical fuses with identical electrical data for the corresponding fuse location.
Mechanical Installation instructions
To avoid damages on the 19“ mounts of the frame, we recommend the use of 19“ rack
mount rails.
Important!
In order to ensure a sufficient convection ventilation, we reccoment above and below
our frame 1-RU distance.
If the installation situation does not allow the recommended distance above and below
the device, the device can be equipped, as an available option with a fan and a cross
ventilation.
LAN integration
We recommend to use a virtual-LAN (V-LAN) for the IBT Interfaces inner core
“switch..it” components, like Frames and Panels.
Communication to the external components for example production switchers,
multiviewers or matrixes should be done via a router gateway.

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 4
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
IP Address set-up
Set-up Client IP Address
Turn the LCD wheel knob on the front panel to the right until you reach the menu entry Client IP Address.
1. Push the knob to enter the edit mode
2. Turn the knob to the right / left to put the cursor to one of the four address sub-segments.
3. Push the wheel knob again to edit the selected sub-segment and turn the wheel to the right, to
increment the address segment, or to the left to decrement the address segment.
4. To confirm the change of a sub-segment press once the wheel knob, this will also exit the sub-
segment edit mode.
5. Move to the next sub-segment and continue with point 2, or if you are finished to set-up all sub-
segments continue with point 6..
6. If you have entered the right values for all sub-segments, turn the wheel to the right until accept
changes appear and press the wheel knob once again, to confirm and exit the edit mode.
If you like to discard the changes turn the wheel knob to the left until discard changes will appear
and confirm by pressing wheel knob
Set-up Client Netmask
Turn the LCD wheel knob on the front panel to the right until you reach the menu entry Client Netmask.
Follow the instruction of “Set-up Client IP Address point 1-6”
Set-up Client Gateway
Turn the LCD wheel knob on the front panel to the right until you reach the menu entry Client Gateway.
Follow the instruction of “Set-up Client IP Address point 1-6”
Set-up NTP Server Address
Turn the LCD wheel knob on the front panel to the right until you reach the menu entry NTP Server
Address.
Follow the instruction of “Set-up Client IP Address point 1-6”
Set-up Unit Number
If the system is a single frame system unit number is by default “0.0.0.1”
Turn the LCD wheel knob on the front panel to the right until you reach the menu entry Unit Number
Follow the instruction of “Set-up Client IP Address point 1-6”
Getting started
Go to http://www.ibt-interfaces.de/download-support/
Section switch...it Downloads
1. Load the latest “switch...it quick start guide”
2. Load the latest “switch...it Panel installation guide”

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 5
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Frame connections
1. Power connector with fuses 2 x 1,6AT
3. RS-232 (upper connector) debug port
4. RS-422 serial communication ports (optional)
5
.
GPIO Interface
outputs (optional)
2. Ethernet port (lower connector)
6.
GPIO Interface
inputs
(optional)

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 6
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Pinout switch…it 1-RU Frame
RS-232 Port *
RJ-45 B8 female
Pin Nr. Signal
1 n.c.
2 n.c.
3 n.c.
4 Rx
5 Tx
6 n.c.
7 n.c.
8 GND
* For future use
LAN Interface
RJ-45 B8 female
Pin Nr. Signal
1 Tx +
2 Tx -
3 Rx +
4 n.c.
5 n.c.
6 Rx -
7 n.c.
8 n.c.
Frame 1.0 serial number < XX-00242, selling date before 06.05.2015
Forced to 10Mbit half duplex. Intelligent switches need to be set either to 10 Mbit half duplex, to
avoid duplex mismatch errors.
Frame 2.0 serial number >= XX-00242, selling date after 06.05.2015
Auto sensing (normally 100 Mbit full duplex).

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 7
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Pinout System cards
Switch…it - SER-2 dual RS-422 Port
Port 1 (lower) Port 2 (upper)
D-Sub. B9 male D-Sub. B9 male
Pin Nr. Signal Pin Nr. Signal
1 n.c. 1 n.c.
2 /TxD 2 /TxD
3 RxD 3 RxD
4 GND 4 GND
5 n.c. 5 n.c.
6 GND 6 GND
7 TxD 7 TxD
8 /RxD 8 /RxD
9 n.c. 9 n.c.
Switch…it - GPIO parallel In/Out card
GPI Outputs (lower): GPI Inputs (upper):
HD-D-Sub. B26 female HD-D-Sub. S26 male
Pin Nr. Signal Pin Nr. Signal
1 /out 1 1 Opto - / In 1
2 /out 2 2 Opto - / In 2
3 /out 3 3 Opto - / In 3
4 /out 4 4 Opto - / In 4
5 /out 5 5 Opto - / In 5
6 /out 6 6 Opto - / In 6
7 /out 7 7 Opto - / In 7
8 /out 8 8 Opto - / In 8
9 /out 9 9 Opto - / In 9
10 /out 10 10 Opto - / In 10
11 /out 11 11 Opto - / In 11
12 /out 12 12 Opto - / In 12
13 /out 13 13 Opto - / In 13
14 /out 14 14 Opto - / In 14
15 /out 15 15 Opto - / In 15
16 /out 16 16 Opto - / In 16
17 n.c. 17 n.c.
18 n.c. 18 n.c.
19 n.c. 19 n.c.
20 n.c. 20 n.c.
21 n.c. 21 n.c.
22 * + Volt² 22 * + Volt²
23 * + Volt² 23 * + Volt²
24 * Comm. contact 1-16 24 Comm. Opto + Volt in
25 GND 25 GND
26 GND 26 GND
! GPI outputs solder a connection between Pin24 and Pin 25, or use a potential free external GND.
! GPI inputs solder a connection between Pin 23 and Pin 24, or use a potential free external voltage.
* The current in sum on pin 22 and 23 must not exceed 450mA !.
* The sum currents of the GPIO outputs 1-16 must not exceed 1,5A
² Caution ! +Volt is +24V in frame version 1.0 and +7,5V in frame version 2.0 (See specification section)

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 8
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
switch…it TCP/IP Protokolle
IBT switch…it Panel Protokoll
Probel SWP-02
Probel SWP-08
TSL 5.0
VTS IMD Monitore
Kahuna 360 serial Tally
Sony ROT16
LAWO Remote MNOPL
Nevion MRP
RT Soft Remote Desk
Grass Valley GVS Tally
Miranda Kaleido Remote
switch…it Systemkabel
Serial RS-422 cable for IBT panel / matrixes Snell, Miranda,
Nevion(Multicon)
SER-2 to switch…it Panel RS-422
SER-2 to Nevion matrix with Multicon (Probel) Protocol
SER-2 to Miranda Nvision
SER-2 to Probel Sirius marix
SER-2 to Probel matrix TM Serie
SER-2 to SER-2
D-Sub. S9 (male) to D-Sub. S9 (male)
1 2
Drawing:

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 9
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Serial RS-422 cable for switcher Kahuna, MVS-3000/65xx,XtendD,
DD30,KAYAK
SER-2 to Switcher DD30 MPK/ACOS Protokoll
SER-2 to Switcher MVS-3000 / MVS-65xx
SER-2 to Switcher XtendD MPK/ACOS Protokoll
SER-2 to Switcher KAYAK MPK/ACOS Protokoll
SER-2 to Switcher Kahuna
D-Sub. S9 (male) to D-Sub. S9 (male)
1 2
Drawing:
Serial RS-422 cable for switcher Sony MVS-6000/8000 Mischer
SER-2 to System Control Unit (MKS-8010B Editor Panel Port D-Sub B15)
D-Sub. S9 (male) to D-Sub. S15 (male)
1 2
Drawing:

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 10
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Serial RS-422 cable for Stagetec Nexus
SER-2 to IBT UMD
D-Sub. S9 (male) to PS-2 (male)
1 2
Drawing:
Serial RS-422 cable for „first“ IBT-UMD of daisy chain bus
SER-2 to IBT UMD
D-Sub. S9 (male) to D-Sub. S9 (male)
1 2
Drawing:

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 11
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Serial RS-422 cable for IBT-UMD daisy chain bus
IBT UMD to IBT UMD
D-Sub. S9 (male) to D-Sub. S9 (male)
1 2
Drawing:
Serial RS-422 cable for Multiviewer Miranda KX Serie
SER-2 to Multiviewer KX-16
D-Sub. S9 (male) to RJ-45 S8 (male)
1 2
Drawing:

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 12
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Serial RS-422 cable for Multiviewer Evertz MVW VIP A8 Duo
SER-2 to Multiviewer VIP A8 DUO
D-Sub. S9 (male) to HD- D-Sub S15 (male)
1 2
Drawing:
Serial RS-422 cablel for Multiviewer Evertz Quad VIP 4
SER-2 to Quadsplit VIP 4
D-Sub. S9 (male) to Screw connection
1 2
Drawing:

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 13
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
GPIO input / output connections
GPIO card IN / OUT to GPI IN / OUT
HD-D-Sub.S26 (male on cable) to GPI Outputs
HD-D-Sub.B26 (female on cable) to GPI Inputs
The drawing shows a manufactured cable:
(GPIO OUT = Male on cable and female on unit card)
(GPIO IN = Female on cable and male on unit card)
Drawing:

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 14
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Troubleshooting
GUI can not open (Website not found)
Check that our GUI servertask is running, if not.
Start GUI server:
Windows Startmenue -> switch…it -> switch…it start server
Stop GUI server:
Windows Startmenue -> switch…it -> switch…it stop server
Daten per FTP ins System übertragen fails with timeout
1. Check that the switch..it frame can be pinged on the expected IP-Address.
2. Check the Network connection (lower RJ-45) connector on the switch...it frame to be connected.
3. Check the switch...it frame IP address see set-up client IP-address section in this installation guide.
4. Check that the Unit IP-Address in the GUI -> Menu -> System Set-up page is entered as expected
without leading zeros.
Example:
Right: 192..44.32.10
Wrong: 192.044.032.010
Webpanel can not connect
1. Check that the GUI IP-Address in the GUI -> Menu -> System Setup page is entered as expected
without leading zeros. Expected is here the IP-Address of the configuration PC itself
Example:
Right: 192..44.32.10
Wrong: 192.044.032.010
Furthermore check that our GUI servertask is running, if not.
Start GUI server:
Windows Startmenue -> switch…it -> switch…it start server
Stop GUI server:
Windows Startmenue -> switch…it -> switch…it stop server
TSL Protocol
Serial TSL v3.1 parameters 38400, Parity Even, 1 Stopbit.
TCP/IP TSL v5.0 Port 8901
Nvision Protocol
Serial parameters 38400, Parity None, 1 Stopbit.
If the matrix is switching with an offset, please modify the matrix configuration set-up.
Use the vendors configuration software, to report Input/Output 1 as a 0 in the Nvision serial protocol.

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 15
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Nevion MRP Protocol
Firmware must be grater or equal version 2.6.2
TCP/IP MRP Protokoll Port 4381

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 16
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
Common specifications
• Dimension (WxHxD)
19“ 1HE 447 x 44 x 480 mm
• Power consumption
approx.100 Watt
• Operating range
Temperature 5°C to 30°C
Relative Humidity
20% to 80% non-condensing
• Storage
Temperature –20°C to 60°C
Relative Humidity
5% to 95% non-condensing
Frame version depending specifications
Frame 1.0 serial number < XX-00242 selling date before 06.05.2015
• Power supply
AC 230V~ max. 1A
• Wight
approx. 9,5Kg
Frame 2.0 serial number >= XX-00242 selling date after 06.05.2015
• Power supply
AC 100-240V~ max. 1A
• Wight
approx. 7,0Kg
Changeindex
Version Date Done by Change
v1.00 18.05.2010 NK Neu erstellt
v1.01 31.05.2010 NK Korrektur Multiviewerkabel Seite 11
v1.02 04.06.2010 NK Textkorrekturen
v1.03 01.02.2011 NK Spezifikationen hinzugefügt und Korrektur GPI Stromaufnahme
v1.04 15.03.2012 NK Miranda Nvision Kabel
v1.05 25.09.2012 NK Sonderkabel für Sony, Evertz und Stagetec hinzugefügt
v1.06 26.09.2012 NK VTS IMD Monitor TCP/IP Protokoll hinzugefügt
v1.07 29.05.2013 NK MVS-3000 / MVS-65xx hinzugefügt
v1.08 06.06.2013 NK Troubleshooting hinzugefügt
v1.09 29.01.2015 NK Korrektur der Pfeile im Übersichtsbild / Kabel KAYAK Mischer / Troubleshooting div
v1.10 06.07.2015 NK Changed to English language, added IP address stuff and Frame 2.0 specifications
v1.11 09.12.2016 NK Modify Nvision troubleshooting and changed IBT address

switch..it Installation Guide
Subject to change date: 09.12.2016
Page 17
IBT Interfaces, Schwalbenstr. 6, 63322 Rödermark
Tel. [phone]
Fax. [phone]
E-Mail: [e-mail]
Web: www.ibt-interfaces.de
