iC-Haus iC-PV EVAL PV1M1 User manual

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 1/9
ORDERING INFORMATION
Type Order Designation Description Options
Evaluation kit iC-PV EVAL PV1M1 Populated with iC-PV and iC-MHM in QFN package
Ready-to-operate, supplied with magnet, CR1025 battery, adapter cable
Evaluation Software iC-MHM GUI GUI Software for Windows PC
Device setup le generation, board conguration via adapter
Related parts (to be ordered separately)
PC adapter iC-MB3 iCSY MB3U-I2C PC-USB adapter for BiSS/SSI w. I2C/SPI extension cable
iC-MB4 iCSY MB4U High-Performance PC-USB adapter for BiSS C
iC-MB5 iCSY MB5U High-Performance isolated PC-USB adapter for BiSS C
BOARD PV1M1
Figure 1: PV1M1 with iC-PV on top side.
PLUG CONFIGURATION
J2 BiSS connector (10-pole)
J1 Optional test connector
Figure 2: PV1M1 with iC-MHM on bottom side.
SENSOR COMPONENTS
U1 iC-MHM
U2 iC-PV
Figure 3: Location of the components
RELATED PRODUCTS AND DOCUMENTATION
•IC Documentation
→www.ichaus.de/PV_datasheet_en
→www.ichaus.de/MHM_datasheet_en
→www.ichaus.de/MHM_AN2_appnote_en
•GUI Software for Windows PC
→http://www.ichaus.de/MHM_gui_rte
→http://www.ichaus.de/MHM_gui
•BiSS-to-PC Adapter Descriptions
→http://www.ichaus.de/MB3U-I2C_datasheet_en
→http://www.ichaus.de/MB4U_datasheet_en
→http://www.ichaus.de/MB5U_datasheet_en
Copyright ©2014, 2016 iC-Haus http://www.ichaus.com

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 2/9
OVERVIEW OF KIT ITEMS
Figure 4: Evaluation kit. Scope of delivery:
PV1M1 module, CR1025 battery,
diametric 4 mm NdFeB magnet,
BiSS adapter cable.
Figure 5: End-of-shaft application example
Figure 6: Application of evaluation kit, iC-MB3 iCSY MB3U-I2C has to be ordered separately.

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 3/9
DESCRIPTION OF CONNECTORS
Figure 7: Footprint of PV1M1 (top view)
J2: BiSS connector to PC- USB adapter
(10-pole ribbon connector for adapter cable to Sub-D)
Pin Sub-D Name Function
J2-1 n.c. Not connected
J2-2 6 GND Ground
J2-3 2 MA Clock
J2-4 7 SLO Data Out
J2-5 3 NMA Clock (inverted)
J2-6 8 NSLO Data Out (inverted)
J2-7 4 VDD +5 V Supply
J2-8 9 SLI Opt. Data In
J2-9 5 NSLI Opt. Data In (inverted)
J2-10 NC NCS Opt. Not Chip Select (SPI)1
J1: Test connector
Pin Name Function
J1-1 MCL Multiturn Interface Clock Line
J1-2 MDI Multiturn Interface Data Line
J1-3 NERR Error Output (negative polarity)
J1-4 SDA I2C Data Line
J1-5 SCL I2C Clock Line
TPx: Test terminals
TP1 P1 Digital I/O port 1 iC-MHM
TP2 P2 Digital I/O port 2 iC-MHM
TP3 P3 Digital I/O port 3 iC-MHM
TP4 SIN Analog Sine iC-MHM (differential)
TP5 COS Analog Cosine iC-MHM (differential)
PRE PRE Preset Pin iC-PV

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 4/9
BiSS ADAPTER CABLE
Figure 8: BiSS adapter cable Figure 9: Typical BiSS slave to master connection
Figure 10: 10-pole connector (to board) Figure 11: BiSS 9-pole Sub-D connector (to PC-USB
adapter)
Connector to Board
(10-pole ribbon)
Pin Name Function
1 n.c. (not connected)
2 GND Ground
3 MA + Clock Input
4 SLO + Slave Data Output
5 MA - Clock Input, inverted
6 SLO - Slave Data Output, inverted
7 VDD +5 V Sensor Supply
8 SLI + Opt. Data In
9 SLI - Opt. Data In, inverted
10 NCS1Opt. Not Chip Select (SPI)
BiSS Connector to PC-USB Adapter
(9-pole Sub-D)
Pin Slave Master Function
1 n.c. (VB) (12 V Sensor Supply Output)
2 MA + MA + Clock Line
3 MA - MA - Clock Line, inverted
4 VDD VDD +5 V Sensor Supply Output
5 SLI - MO - Master Data Output, inverted
to Slave Data Input, inverted
6 GND GND Ground
7 SLO + SL + Data Line
8 SLO - SL - Data Line, inverted
9 SLI + MO + Master Data Output
to Slave Data Input
1
iC-MHM offers SPI interface mode. The Not Chip Select (NCS) of the SPI interface can be connected to J2-10
by closing JP2 (see Figure 15).

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 5/9
CIRCUIT SCHEMATIC
B
B
B
B
B B
B B
HALL SENSOR
PCOS
NSIN
CONTROL
AMPLITUDE
RAM
D
SIN
iC-MHM
LINE
DRIVER
BiSS
INTERFACE
EEPROM
iC-PV
HALL FRONTEND
SUPPLY SWITCH
OSCILLATOR
D
over JP1 on PV1M1
SIN
I2C MULTI MASTER
ERROR
MONITOR
MULTITURN COUNTER
SERIAL INTERFACE MT-INTERFACE
ERROR
optional preset line
MULTI MASTER
MONITOR
I2C
DIGITAL-IO
PSIN
NCOS
NERR
VDDS
PRE
DI_P1
VDDS
VDD
DO_P0
VDDVBAT
SEL
GNDA
P1
SCL
NERR
VDD
MCL
MDI
GND
SCL
SDA
P3
P2
NSIN
GNDS
MAO
SLO
NCOS
PSIN
PCOS
SDA
CLK_N1
SDA
SCL
MA
SLI
GND
100nF
1μF 100nF
MAO
MA
SLI
SLO
VDD
GND
1μF
100nF
100nF
Figure 12: Circuit principle. Connection of iC-MHM pin P3 to iC-PV pin PRE using JP1 is optional.

  
. -T   c 
    
   
    





 

 

 




i
1

 
 
    
 
    
   



 
1
 r  

so·


 
   
 












�  
 
  


   
 
  
  





  
   

    
Haus      
Figure 13: Circuit diagram. Do not install diode D1 for use with battery.

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 6/9
ASSEMBLY PART LIST
Figure 14: PV1M1 top side
ASSEMBLY PART LISTING: Top Side
Device Type Count Value Tol. Comment Assy Type Package Outline
C4 C 1 1 µF 10% X7R 10V SMD 0603
C5, C6 C 0 not assembled
C8 C 1 100 nF 10% X7R 10V SMD 0603
D1 D 0 PMEG2005 not assembled SMD SOD323
D2 D 1 LS-T67K red SMD PLCC2
J1 CONN 0 not assembled TH X4x1
J2 CONN 1 WSL10G TH W5x2
R1, R3 R 2 1 kΩ1% SMD 0603
R2 R 1 560 Ω1% SMD 0603
S1 Switch 1 B3S-1000 SMD 0603
U2 IC 1 iC-PV SMD QFN16
Table 1: Part listing top side

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 7/9
Figure 15: PV1M1 bottom side
ASSEMBLY PART LISTING: Bottom Side
Device Type Count Value Tol. Comment Assy Type Package Outline
C1, C2 C 2 10 µF 20% X5R 10V SMD 0603
C3, C7 C 2 100 nF 10% X7R 10V SMD 0603
U1 IC 1 iC-MHM SMD QFN28
U3 IC 1 24LC16B SMD SOT23-5
R4, R5 R 0 120 Ωnot assembled SMD 0603
JP12R 0 250 1% not assembled SMD 0603
JP23R 0 0 not assembled SMD 0603
Table 2: Part listing bottom side
2Using jumper JP1, the connection from iC-MHM pin P3, to iC-PV pin PRE can be made.
3
JP2 can be closed in SPI mode. The SPI Not Chip Select (NCS) is then connected to junction 2 pin 10 (J2-10).

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 8/9
PHYSICAL DIMENSIONS
3x
2.200
32
120°
120°
1.550
37.600
38
dra_pv1m1_pack_1, 2:1
TOP
SIDE
BOTTOM
Figure 16: Physical dimensions (board PV1M1)

preliminarypreliminary
iC-PV EVAL PV1M1
EVALUATION KIT DESCRIPTION
Rev A6, Page 9/9
REVISION HISTORY
Rel. Rel. Date∗Chapter Modication Page
A1 14-06-10 All Initial release All
Rel. Rel. Date∗Chapter Modication Page
A2 14-06-11 BOARD PV1M1 J2 connector description 2
ADAPTER CABLE AND
CONNECTORS
PV1M1 connector description 3
Rel. Rel. Date∗Chapter Modication Page
A3 14-09-05 PHYSICAL DIMENSIONS Chapter introduced 7
Rel. Rel. Date∗Chapter Modication Page
A4 15-01-14 ASSEMBLY PART LISTS Figure 10 updated 5
Rel. Rel. Date∗Chapter Modication Page
A5 15-12-01 BOARD PV1M1, ADAPTER
CABLE AND CONNECTORS,
APPLICATION EXAMPLE
Figure 1, 6 and 14 updated 1, 3, 8
Rel. Rel. Date∗Chapter Modication Page
A6 2016-06-03 ORDERING INFORMATION PC adapter iC-MB4 iCSY MB4U and iC-MB5 iCSY MB5U reworked 1
OVERVIEW OF KIT ITEMS Chapter reworked 2
BiSS ADAPTER CABLE Chapter reworked 4
