iCarsoft TPMS S2000 User manual

iCarsoft TPMS S2000
Quick Start Guide
Installation Steps
Warranty
1. Loosening the tire
3. Dismounting the sensor 5. Remounting the tire
4. Mounting the sensor and throttle
2. Dismounting the tire
English
IMPORTANT: Read these instructions
carefully and use this unit properly before
operating. Failure to do so may cause
damage and/or personal injury and will
void the product warranty.
Remove the valve cap and nut and deflate the tire.
Use the bead loosener to break the tire bead.
Clamp the tire on the tire changer,
and adjust the valve at 1 o’clock to
the tire fitting head. Use the tire
tool to dismount the tire bead.
Remove the cap and nut from the valve
stem, and then remove the sensor
assembly.
Place the tire on the rim, ensure that the valve starts on the
opposite side of the rim from the tire fitting head. Mount the tire
over the rim.
The sensor is guaranteed to be free from material and
manufacturing defects for a period of twenty-four (24) months or
for 31000 miles, whichever comes first. This warranty covers any
defects in materials or workmanship under normal use during the
warranty period. Excluded from the warranty are defects due to
improper installation and usage, induction of defect by other
products, damage due to collision or tire failure.
Step 1. Remove the cap and nut from
the valve stem.
Step 2. Place the valve stem through the valve hole of the rim,
ensuring the sensor body located on the inside of the rim.
Assemble the nut back on the valve stem with a torque of 4N·m,
then tighten the cap.
Any maintenance and repair work must be carried out by trained
experts. Failure to do so may result in the failure of the TPMS
sensor. iCarsoft does not assume any liability in case of faulty or
incorrect installation of the unit.
When replacing or servicing the sensor, please only use the
original valves and accessories provided by iCarsoft to ensure
proper sealing. It is mandatory to replace the sensor if it is
externally damage. Always remember to tighten the nut to the
correct torque of 4N·m.
When mounting/dismounting the wheel, follow the operation
guideline of wheel changer manufacturer strictly.
Do not race with the vehicle on which the LTR-01 RF
sensor is mounted, and always keep the drive speed under
240km/h.
To guarantee optimal performance, the sensors may only
be installed with original valves and accessories provided
by iCarsoft.
Make sure to program the sensors using iCarsoft-specific
TPMS tool prior to installation.
Do not install programmed TPMS sensors in damaged
wheels.
After installing the TPMS sensor, test the vehicle’s TPMS
following the steps described in the original manufacturer’s
user manual to confirm proper installation.
Safety Instructions Components & Controls
Technical Parameters
CAUTION
Caution: The bead loosener must be facing the valve.
Caution: Always observe this starting point during the whole
dismounting process.
Caution: Make sure that the nut and cap are installed on the
outside of the rim.
Caution: Strictly follow tire changer manufacturer’s instructions
to mount the tire.
Weight 29g
Dimension(L*W*H) About 77.5*40*15mm
IP Rating IP67
Cap
Valve core assembly
Sensor body
Screw
www.icarsoft.us
S2000

6. FCC Statement
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions (1)this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between
the radiator & your body
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the device.
The term “IC: “ before the certification/registration number only
signifies that the Industry Canada technical specifications were
met. This product meets the applicable Industry Canada
technical specifications.
Cet appareil contient des émetteurs / récepteurs exemptés de
licence conformes aux RSS (RSS) d'Innovation, Sciences et
Développement économique Canada. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
This equipment should be installed and operated with a
minimum distance of 20 centimetersbetween the radiator and
your body.
Cet équipement doit être installé et utilisé à une distance
minimale de 20 centimètres entre leradiateur et
votre corps.
7. IC Statement
