ICE AIR RSXC Operating instructions

RSXC
Durable High
Efficiency AC
Packaged Terminal Heat Pump
(PTHP) for New Construction
and Replacement/Retrofit
Operating and
Maintenance Manual

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
2
Welcome
Congratulations on your selection of the Ice Air Packaged Terminal
Air Conditioner (PTAC). PTAC units are thru-wall combination cooling
and heating units that provide an efficient, room-by-room source for
comfort conditioning of your living environment.
Ice Air PTAC units are built to a high standard of quality and reliability,
employing commercial grade components and heavy duty, galvanized
sheet metal casings. With proper maintenance and usage, Ice Air
PTACs should provide many years of efficient, quiet and trouble-free
comfort.
To enhance the use of your Ice Air equipment, you will want to
read and carefully follow all of the instructions contained in this
Operating and Maintenance Manual. We recommend that you pay
special attention to the Safety and Warning Information section at
the beginning of this Manual, and to the various safety advisories
throughout this Manual.
Please retain this Manual for your future reference. We suggest that
you retain it with other important documents and product manuals.
If your unit has optional features, they will be explained in a separate
instruction sheet specific to that option.
On behalf of Ice Air, and our network of distributors and dealers, we
are happy to welcome you to our base of satisfied customers!
Contents
Welcome........................................................ 2
Consumer Safety Information/Guidelines ... 3
Dimensions and Components ...................... 4
Maintenance ..............................................5-6
General Wiring .............................................. 7
Troubleshooting ............................................ 8
Warranty/Contact Information ................... 12
Location Model No. Serial No.
Living Room
Master Bedroom
Bedroom
Dining Room
Other
We recommend that you record the following
information about your Ice Air product(s).

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
3
Consumer Reference Information
For safe and optimal enjoyment of your Ice Air unit, please read
the following consumer safety and operating notes carefully before
operating your equipment!
p
! RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
p
!WARNING: Ice Air will not be responsible for any injury or
property damage arising from improper service or service
procedures. If you install or perform service on this unit, you
assume responsibility for any personal injury or property
damage which may result. Many jurisdictions require a license
to install or service heating and air conditioning equipment.
p
!WARNING HIGH VOLTAGE: Disconnect all power before
servicing or installing unit. Multiple power sources may be
present. Failure to do so may cause property damage,
personal injury or death.
Safety Guidelines
Read this entire manual before operating the unit.
p
!WARNING: This unit MUST be serviced only by professionally
trained and qualified technicians. Do NOT attempt to maintain or
service this unit on your own – severe injury and death can occur
from electric shock, moving parts, and other hazards.
• Your Ice Air unit must be properly installed and commissioned
to operate correctly. Improper unit installation, adjustment or
commissioning, and/or improper heating system installation and
connection can lead to equipment malfunction and hazardous
operating conditions, and may void your warranty. If you have
any doubt about the proper installation of your Ice Air unit,
please contact your property manager at once to have a qualified
technician inspect the equipment.
• Your Ice Air units must each be wired on an individual, dedicated
electrical circuit with the correct voltage and proper amperage
(capacity) to match the unit nameplate requirements.
• Each unit’s electrical circuit must have a proper overcurrent
protection device, employing an approved circuit breaker or fuse
of the proper rating under NEMA and local building codes.
p
!WARNING: Every unit contains refrigerant within a sealed and
pressurized refrigerant system. This system must not be opened
or tampered with and any refrigeration system repairs MUST be
carried out by trained technicians. Refrigerant must be properly
handled and recycled per EPA regulations and guidelines.
p
!WARNING: Do NOT operate the unit with frayed, burnt or
damaged electrical wires!
p
!WARNING: Do NOT operate the equipment when in doubt –
have it inspected first!
IMPORTANT: It is not the intent of this maintenance manual to
correct any installation deficiencies. If you have any doubt about the
proper initial installation (or re-installation after servicing) of your Ice
Air unit(s) – noisy or inefficient unit operation, frayed or damaged
electrical connections, improper unit appearance, etc. – please
contact a trained servicer or building maintenance staff immediately.
The following physical conditions must be maintained for
proper unit operation:
Air flow must be unobstructed into and out of the unit return air
opening.
• Have the unit filter properly cleaned and serviced to prevent air
blockage from dirt and dust within the filter media.
Intended for indoor use only.
Proper installation and operating environment must be maintained.
Therefore:
• Do not operate the unit in corrosive environments such as
chemical plants, refineries or salt spray areas.
• Operate only with proper electrical service and protective circuit
breakers or fuses in place.
• Operate only with all unit and enclosure sheet metal parts in
place and properly installed.
• In areas of high concentrations of dirt, dust, pet dander or
pollutants, clean the filter often (at least monthly).
• Do not clean the unit with any solvents or cleaning solutions that
may damage the equipment.
• Understand and follow the unit operating instructions before
using your Ice Air equipment.

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
4
48"
21"
10"
16-3/4 "
41-7/8 "
2-1/2 "
(MIN)
9-1/4 "
20-1/8 "
39-7/8 "
16-1/4 "
15 "
42"
A
ENCLOSURE
(OPTIONAL)
ENCLOSURE
FRONT COVER
RSXC CHASSIS
INTERIOR WALL
SLEEVE
LOUVER
(OPTIONAL)
HOLD DOWN
CLIPS
DRAIN PIPE
ELBOW
(BY OTHERS)
DRAIN PIPE
3/4"-14 NPT
(BY OTHERS)
ELECTRIC OUTLET
(BY OTHERS)
POWER
CORD
DETAIL A
SCALE 1 : 4
3/4"-14 NPT
SS MALE
FITTING
Dimensions and Components
NOTE: Pictures of components
and parts may vary depending
on your model.

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
5
Maintenance
Your Ice Air unit is designed to provide
many years of efficient, trouble-free comfort
conditioning service. To ensure equipment
longevity and efficiency, please make sure
that the following simple maintenance
procedures are followed. This manual
assumes that your unit has been installed
by a qualified installation professional, and
is operating properly prior to maintenance
service.
Have your unit periodically inspected by
a properly trained service professional or
building maintenance staff person. The unit
should be checked for the safe and proper
functioning of all of its systems at least
once a year. The following recommended
maintenance procedures should be carried
out only by trained personnel with strict
adherence to the Safety Guidelines outlined
at the beginning of this manual. These
procedures MUST be followed to ensure
your safety and the safety of the person
maintaining the equipment!
Indoor Air Filter
All units are equipped with a washable/
reusable filter. It is recommended that you
clean the indoor air filter after every 350
to 400 hours of unit operation – more
frequently if the unit is running in an
environment of high dust, pet dander or
other pollutants in the indoor atmosphere.
Condenser Coil
Clean the condenser coil at least once a year,
more frequently in an outdoor environment
with high levels of pollution – including
automobile traffic, smog or soot, etc. This
procedure is critical to proper unit function
and longevity. Clogged or dirty condenser
coils will cause unit failure and may void any
warranty coverage for the unit refrigeration
system.
Condensate Drain Pan And Drain Hoses
Check the unit condensate drain pan and
drain hoses annually to ensure proper
condensate drainage. If any foreign matter
build-up in the drain pan is found, clean the
drain pan and drain hoses – frequency of
cleaning depends on the level of dirt and
pollutants that may be present in the indoor
environment.
Evaporator Coil
Check and clean (if necessary) the unit
evaporator coil annually.
Line Cord
Check unit line cord (power connection) for
any fraying or deterioration of the plug and
cord.
With these simple maintenance procedures
carried out on a proper maintenance
schedule, your unit should provide many
years of trouble-free service. The procedures
are covered in greater detail on the following
pages and should be implemented by trained
personnel. But, there are certain items that
you, the apartment owner or tenant, can do
to ensure proper unit function:
• Keep the area around your unit clear of
objects that may block air flow into the
unit – furniture, carpets and rugs, etc.
may restrict air movement.
• Keep the top of your cabinet free of
objects that may block air flow out of the
unit – plants, paperwork and books, etc.
should not be placed on or above the
discharge grille area.
• Keep drapes, blinds and other window
treatments clear of the air discharge
area – any blockage of discharge air will
have a negative impact on the unit and
on its ability to properly condition the
room.
General Unit Inspection
Visually inspect unit at least once a month.
Pay special attention to hose assemblies and
connections. Repair any leaks and replace
deteriorated hose immediately to avoid
potential costly damage to your property due
to component failure.

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
6
Evaporator Coil
Check the coil for cleanliness and uniformity
of fins. If the coil is dirty, vacuum clean with
a soft brush attachment. This is the only form
of cleaning that should be carried out within
an apartment. If the coil requires additional
cleaning, the unit must be removed and
cleaned using compressed air and/ or
washed. These operations MUST be carried
out in a facility properly equipped to handle
this type of work in a safe and professional
manner.
Evaporator Motor and Blower Assembly
If there is evidence of dirt or dust build-up in
the evaporator motor or blowers, they should
be cleaned either by vacuum cleaning (if
working in an apartment) or by removing the
unit to a workshop location and cleaning with
compressed air.
p
!WARNING: Always obey safety
guidelines for using compressed air
in this latter case.
Your Ice Air PTAC has permanently lubricated
motor bearings that do not require additional
lubrication. Blowers and motor are factory
assembled for quiet performance – if there
is any excessive noise and vibration from this
assembly, it should be serviced by a qualified
technician.
Air Filter
1. Remove Permanent Air Filter from slides
at bottom of Cooling Chassis by sliding
the filter towards you.
2. Wash Air Filter in warm water and
biodegradable cleaner.
3. Rinse with clean water and allow to dry
completely.
4. Replace Air Filter.
5. As an alternate cleaning method, the
filter may be cleaned on both sides using
a vacuum cleaner and a soft brush type
attachment. On average, the filter should
be cleaned out every 6 months. However
this can vary with the presence of pets,
carpet, usage or air intake properties.
IMPORTANT: Do not operate unit without
filters.
Roomside Component Cleaning
IMPORTANT: In addition to the air filter, the
room side components can be cleaned with-
out removing the PTAC chassis from the wall
sleeve. The power cord MUST be disconnect-
ed from the electrical outlet before carrying
out any of the following cleaning!
To access the components within the chassis
of the unit:
1. Unit must be in OFF Position.
2. Disconnect unit from power source by
unplugging the line cord.
3. Remove the unit front cover/access door
by unscrewing the retaining screws
that hold it in place. You will then have
access to the unit components.
NOTE: Pictures of components and parts
may vary depending on your model.

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
7
General Wiring
WVU
U
W
V
WHITE
BLACK
AC-L
AC-N
H
M
L
CP11 CP9
CP10
CPN9
M1
BLUE
WHITE
EVAPORATOR
FAN MOTOR
GR
RED
BLACK
BROWN
CP2 ORANGE
CPN6
M2
CP1 WHITE
BROWN
FAN MOTOR CONDENSER
GR
BLACK
CP6
CPN4
CP4
REVERSING VALVE
BLUE BLUE
CPN2
CP2
HEAT ELEMENT
ROOM TEMP PROBE
EVAPORATOR
TEMP PROBE
CN14CN13CN7CN8CN10
CONDENSER
TEMP PROBE
OUTDOOR TEMP PROBE
Compressor Outlet TEMP PROBE
EXV
CN4
POWER SOURCE
GN
CP1 = CONDENSER MOTOR CAPACITOR
CP2 = EVAPORATOR MOTOR CAPACITOR
CP8
CPN8
Electromagnetic stop valve
WHITE
VRF BOARD
RC Y F1 RSTWF3
F2 ALA
7
4
1
8
5
2
9
6
3
COMMON
BLK1
NOT IN USE
ORN9
GRN
WHT
YEL
-
-
RED
8
7
6
5
4
3
2
FAN
NOT IN USE
HEAT
NOT IN USE
COOLING
24VAC
WIRE CHART
NOT IN USE
BLU
10
11
12
-NOT IN USE
-NOT IN USE
-NOT IN USE
CN11
HEAT ELEMENT TEMP PROBE
SWITCH
MD

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
8
Troubleshooting
IMPORTANT: It is not the intent of this maintenance manual to
resolve any problems with the operation of your Ice Air unit.
Please contact a trained servicer or building maintenance
staff immediately if your unit fails to perform properly.
1. Contact a trained service technician to conduct full unit
diagnostics and repair to equipment.
2. Record any unit that does not operate noting the unit serial
number on your report.
If unit is not operating, conduct the following checks:
1. Check the electrical connections.
2. Check the voltage and current against the electrical
specifications on the unit nameplate.
3. Look for wiring errors. Check for loose screw connections in both
line and low voltage terminals.
4. Check for dirty filters.
5. Check indoor fan for proper operation.
6. Check that unit did not cycle off due to improper thermostat
settings.
p
! RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
p
!WARNING: Ice Air will not be responsible for any injury or
property damage arising from improper service or service
procedures. If you install or perform service on this unit, you
assume responsibility for any personal injury or property
damage which may result. Many jurisdictions require a license
to install or service heating and air conditioning equipment.
p
!WARNING HIGH VOLTAGE: Disconnect all power before
servicing or installing unit. Multiple power sources may be
present. Failure to do so may cause property damage,
personal injury or death.

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
9
Notes or Technical Comments

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
10
Notes or Technical Comments

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
11
Notes or Technical Comments

Due to Ice Air’s ongoing product development programs, the information in this document is subject to change without notice.
12
Twelve (12) Month Warranty of entire
Packaged Terminal Equipment
Ice-Air, LLC (“Ice Air” or the “Company”) warrants, solely
to the person or entity that directly purchased the packaged
terminal system from the Company (the “Original Owner”), that
the entire packaged terminal system is free from defects in
material and workmanship for a period of twelve (12) months
from the date of delivery (the “Twelve Month Warranty”).
Any part or portion thereof which becomes defective under
normal use during the period of this warranty will be repaired
or replaced, provided Ice Air’s examination shall prove to
its satisfaction that the part was or became defective under
normal use. Ice Air’s obligations under this warranty are
subject to the satisfaction of the conditions set forth in the last
paragraph of this Section and are limited to: (a) repairing the
defective part or (b) furnishing a replacement part provided
the defective part is returned to Ice Air, without shipping
damage, transporting charges prepaid. No reimbursement will
be made for expenses incurred in making field adjustments or
replacements unless specifically authorized in writing by the
Company.
Except as otherwise provided in the last sentence of this
paragraph, the Company is not obligated under this warranty
for field labor such as service for inspection, removing,
packing and/or reinstalling water source unit, nor for the
return transportation charges. In addition, the Company is not
obligated under this warranty to make reimbursement of the
labor or service charges of any other party. Notwithstanding
the foregoing, labor provided by or at the direction of the
Company during the twelve (12) month period from the
date of delivery referred to in the initial paragraph above, in
connection with the Twelve Month Warranty of parts provided
in the initial paragraph above, is included in such warranty,
solely in the case in which a packaged terminal system is sold
by the Company to an Original Owner for use in a new facility
to be constructed and located in the greater New York City
metropolitan area. For the avoidance of doubt, except in the
case described in the preceding sentence, the Company has
no obligation under this warranty to provide for field labor or to
make reimbursement of the labor or services charges of any
other party, provided, however, that the Company, in its sole
and absolute discretion, may elect to do so, so long as (i) such
election is set forth in a writing signed by the Company and (ii)
the facility at which the applicable packaged terminal system
is or will be installed is located in the greater New York City
metropolitan area (the “Metropolitan Area”).
The obligations of the Company set forth in the preceding
paragraphs of this Section are in all cases subject to the
satisfaction of the following conditions: (x) the Company
shall have received proof, satisfactory to the Company, of
the purchase by the Original Owner from the Company of
the packaged terminal system that is the subject of the
Original Owner’s claim, (y) all amounts due and payable to
the Company on or prior to the date of such claim in respect
of such packaged terminal system shall have been paid in full
and (z) nothing shall exist or occur that relieves the Company,
in accordance with the terms of this agreement, from the
performance of its warranty obligations hereunder.
OPTIONAL Extended Refrigeration
Circuit Warranty
2nd – 5th year compressor parts only; labor not included
The Optional Extended Refrigeration Circuit Warranty MUST
be purchased from Ice Air within thirty (30) days from date of
delivery to be valid. The hermetically sealed refrigeration circuit
(consisting of the motor, compressor assembly, evaporator
coil, coaxial / condenser coil, and interconnecting tubing)
is warranted to the Original Owner for four additional years
from date of the expiration of the twelve-month Warranty.
Components under this warranty will be supplied at Ice Air’s
expense provided the failed component is returned to Ice Air.
This optional warranty does not include any other parts of the
equipment such as fans, fan motors, controls, cabinet parts,
electrical relays, capacitors, protective devices, or wiring. Ice
Air is not obligated under this warranty for field labor such as
service for inspection, removing, packing, and/or reinstalling
the refrigeration circuit, nor for return transportation charges.
In addition, the Company is not obligated under this warranty
to make reimbursement of the labor or service charges of any
other party. Ice Air reserves the right to make a handling and
inspection charge in the case of parts or equipment improperly
returned as defective and/or as being in warranty.
To obtain assistance under the parts warranty or to purchase
the optional extended warranty, simply contact Ice Air
Customer Service at 80 Hartford Avenue, Mount Vernon, New
York 10553 Phone [phone].
Additional warranty options include:
2nd – 5th year full unit parts only warranty
2nd – 5th year compressor parts and labor
warranty, so long as such labor is performed in the NY
Metropolitan Area
2nd – 5th year complete parts and labor warranty (Full
unit coverage), so long as such labor is performed in
the NY Metropolitan Area.
All Warranties (which must be purchased separately)
constitute the Original Owner’s sole remedy. They are given in
lieu of all other warranties. Ice Air is not liable for incidental or
consequential damages, whether the theory is breach of this
or any warranty, negligence, or strict tort. No person (including
any agent, salesman, dealer, or distributor) has authority to
expand Ice Air’s obligation beyond the terms of these express
warranties, or to state that the performance of the product
is other than that published by Ice Air. In addition, neither
the Original Owner nor any such person has the right to sell,
transfer or assign, or attempt to sell, transfer or assign, any
rights of the Original Owner in or to the warranties provided for
herein, no such sale, transfer or assignment shall be binding
upon Ice Air and any such sale, transfer or assignment is null
and void and of no force or effect.
General Conditions
The above warranties are void if Ice Air’s equipment has
been damaged, misused, subjected to abnormal use or
service or its serial number has been altered, defaced, or
removed, or payment for the equipment is in default. Ice Air
is not responsible for service to correct conditions due to
misapplication, faulty or improper installation, inadequate
wiring, incorrect voltage conditions or unauthorized opening
of the refrigeration circuit, nor forconsequential damages.
In case Ice Air’s equipment is installed in conjunction with
cabinets, grills, louvers, controls, or other parts manufactured
by others, these warranties shall apply only to Ice Air’s
manufactured portion of the equipment. The conditions of
the standard warranty plan are effective for 12 months from
the date of equipment delivery. Ice Air reserves the right to
make a handling and inspection charge in the case of parts or
equipment improperly returned as defective and/or as being
warranty.
Important Disclaimers
Ice Air Has No Responsibility For:
(A) Certain Damages
The following are the responsibility of the user. None of the
following constitutes a manufacturing defect, and each is
expressly excluded from the warranty plan:
1) Failure of unit to operate satisfactorily due to improper
amount of air on evaporator coil or air supply to air cooled
condensers.
2) Damage to unit or unsatisfactory operation due to improper
cleaning of evaporator coil or use of unit in corrosive
atmosphere locations such as chemical plants, refineries, or
salt spray areas.
3) Damage to unit from unsatisfactory operation due to blown
fuses, inadequate or interrupted electrical service, use of
improper electrical protective devices or operation of unit
on power supply other than covered by nameplate rating
of unit.
4) Damage due to failure to properly maintain unit.
5) Damage due to transportation or handling prior to and
during installation.
6) Damage due to accident or from alteration, improper
installation or tampering.
7) Failure to clean or replace filter timely.
8) Misapplication of equipment.
9) Damage due to deviation from original design and intended
use of equipment.
10) Damage due to use of additional accessories either
unapproved or approved but modified or manipulated.
(B) Installation
Ice Air is not responsible for the design, execution, and
performance of the installation method or any of the accessory
items used during installation such as seals, caulking,
weatherproofing, supporting structures, attachment means,
louvers and frames supplied by others.
(C) Check, Test and Start
Check, Test and Start of the air conditioners by an experienced
person is the responsibility of the installing contractor. This
consists of physically confronting each conditioner operating
in both heating and cooling modes and correcting any minor
deficiencies noted. After the equipment leaves the factory, it
may become damaged or maladjusted during transportation
or on the job. Sometimes wires are disconnected accidentally,
or fan motors move on their bases due to rough handling,
causing fans to strike; a component(s) may be inoperable.
The correction of such conditions is part of the Check, Test
and Start. Note that unless otherwise specifically agreed to
in writing, Ice Air has no obligation to perform, nor does the
price of its equipment include field labor in connection with
the performance of, these Check, Test, and Start procedures
(or the like).
80 Hartford Avenue, Mount Vernon, NY 10553
Tel: 877-ICE-AIR-1 (877-423-2471)
Fax: [phone]
email: [e-mail]
www.ice-air.com
© 2023 by Ice Air, LLC ICE6159 11/23
Limited Warranty
