ICE 1506 on a
Beverage Dispenser
Problem
Harvest Assist
Provides consistent ICE production 24/7 for the life of the
machine, while reducing operating costs
PURE ICE ®- Exclusively by ICE-O-Matic
®
Built-in antimicrobial protection for the life of the machine
prevents bacteria and slime fungus growth. ICE-O-Matic’s®
optional water filteration system provides protection
against unpleasant tastes, odors and scale formation.
Sea Salt Corrosion Proctection
All remote condensers are coated with a salt air corrosion
protection – FREE
ICE-O-Matic ®is the Best ICE Making Solution for:
Hard Water, Food Safety and Tight Spaces
ICE 1506 Series
Cube ICE Maker
Solution
Hard Water
Scaling due to hard water slows ICE
Making production
Food Safety
Food safety concerns about slime- and
odor-causing bacteria
Corrosion
Salt air corrosion of outdoor equipment
located in coastal regions
✓Produces up to 1431 lbs. (650 Kgs.)* of ICE per day
✓Constructed from sturdy, corrosion-resistant
300 series stainless steel
✓Only 30” wide
✓Available with a remote condenser
*Rated at 70 °Air / 50° Water
Dirty Air Filter
Forget to change the air filter?
Filter-Free Air
No air filter to change

ICE 1506HR Remote 1431 (650) 1202 (546) 20.26 (76) n/a 5.5 20050 208-230/60/1 3 27.4 30 300 (136)
LRC-2661 Remote Condenser for 1 model ICE 1506R (208-230/60/1 voltage) 100 (46)
RT-325-404 25 ft. (7.6m) Precharged Tubing Kit for R-404A models 13 (6)
RT-340-404 40 ft. (12m) Precharged Tubing Kit for R-404A models 18 (8)
RT-345-404 45 ft. (13.7m) Precharged Tubing Kit for R-404A models 19 (9)
RT-360-404 60 ft. (18.2m) Precharged Tubing Kit for R-404A models 23 (12)
ICE 1506
Conds. Air Temp. Water Temp. °F (°C)
Unit °F (°C) 80°(27°) 70°(21°) 50°(10°)
90° (32°) 1118 (508) 1202 (546) 1294 (588)
80° (27°) 1152 (523) 1238 (563) 1362 (619)
70° (21°) 1210 (550) 1301 (591) 1431 (650)
1. 90°/70° figures are rated in accordance with
ARI Standard 810. All remaining points are
mathematical estimates.
2. All specifications and performance data are
subject to normal manufacturing variances.
ICE-O-Matic 11100 E. 45th Avenue, Denver, CO 80239
Tel. [phone] Fax. [phone] www.iceomatic.com
We reserve the right to make changes in design and construction at any time
without obligation.
2004© ICE-O-Matic Rev Code: 1019B-05/04-SS
Remote
Cooled
Water Used-Gals. (Lits.) Kilowatts
ICE Production ICE Production per 100 lbs. of ICE Used per
per 24 hrs. at per 24 hrs. at 90° Air/70° Water 100 lbs. of Ice Min. Max. Shipping
Model Cond. 70° Air/50° Water 90° Air/70° Water 90° Air Voltage No. of Circuit Fuse Weight
No. Unit lbs. (Kgs.) lbs. (Kgs.) 70° Water Btuh Characteristics Wires Amp. Size lbs. (Kgs.)
ICE Prod. Cond.
Use Use
60 Hz
ORDERING AND SPECIFICATION INFORMATION
OPERATING LIMITS
Ambient Temp. Range
Remote -20° - 120°F (-29° - 49°C) 60Hz
Water Temp. Range 40° - 80°F (4.5° - 27°C)
Water Pressure ICE Maker Min. 20 psi (1.4 bar)
Water in Max. 60 psi (6.9 bar)
ICE PRODUCTION CHART POUNDS
(KILOGRAMS) PER 24 HOURS
Ice Cube Dispense Area
7/8" Holes For Electrical
Connections
Ice Maker Potable
Water In 3/8" FPT
Ice Maker Water
Out 3/4" FPT
2.41 11.58 1.09
10.06
13.06
15.56
22.06
Discharge Line 1/2" Male Quick Connect Coupling For
Use With RT-325-404 or RT-340-404 Precharge Line Set
Liquid Line 3/8" Male Quick Connect Coupling For
Use With RT-325-404 or RT-340-404 Precharge Line Set
Rear of Machine
2 x 3.29
2 x 1.10
2 x 1.10
2 x 2.00
2 x 19.50 Ice Maker Potable
Water In 3/8"
Ice Maker Potable Water In 3/8"
(Optional)
Ice Maker Water Out 3/4" FPT
(Optional)
Minimum Wall Clearance
6.00
2 x 4.50
Top View
30.28
Rear of Machine
5.12 20.00
22.05
Hardware For Strap
Mounting To Bin Located
Underside Of Ice Maker
Ice Cube Dispense Area
R.H. Side View
25.61
28.36
22”
(589 mm)
30”
(762 mm)
28 1/2”
(724 mm)
Dimensions
I
S
O
9
0
0
1
C
E
R
T
I
F
I
E
D
®
NOTES
The ICE 1506 must be ordered with the LRC 2661
Remote Condenser. The ERC 2661 is not compatible.
Half Cube
7/8" x 7/8" x 3/8"
(22mm x 22mm x 10mm)
Full Cube
7/8" x 7/8" x 7/8"
(22mm x 22mm x 22mm)
