iCentral 10.2 Premium User manual

iCentral 10.2 Premium Video Intercom System
REV2
Installation & Operation Manual
Intelligent Central Systems
TM

COPYRIGHT NOTICE
All rights reserved. No part of this publication may be reproduced, transmitted or stored in a retrieval system in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Ness.
Ness reserves the right to make changes to features and specifications at any time without prior notification in the interest of ongoing
product development and improvement.
© 2012 Ness Corporation ABN 28 069 984 372
Sales, Service, Spares consumer enquiries 1300 050 333
www.icentralsystems.com.au
www.ness.com.au
iCENTRAL TRADE & DEALER ENQUIRIES
HEAD OFFICE
Ness Corporation Pty Ltd
ABN 28 069 984 372
Ph [phone] Fax [phone]
[email protected]

Features / Specifications / Cable Specifications ....................4
Room Station Description......................................5
Monitor Rear Description ......................................6
Monitor Connections .........................................7
System Schematic ...........................................8
Connection Diagram 1 Door Station / 1 Room Station ...............9
Connection Diagram 2 Door Stations / 1 Room Station .............10
Connection Diagram 2 Door Stations / 2 Room Stations ............11
Switch Settings .............................................12
Room Station Installation Guide ................................13
Door Station Installation Guide.................................14
Operating Instructions ....................................15-19
Contents

4
ROOM STATION
■Slimline surface mounted Monitor/Room Station
■10 inch colour LCD display
■Touch sensitive glass buttons
■Supports up to two video Door Stations and up to two video Room Stations
■Make intercom calls between two Room Stations
■Transfer door calls between Room Stations
■Monitor up to two optional CCTV cameras or other audio/video inputs
■Do Not Disturb function
■Electric door lock release from Room Stations
■Adjustable Colour/Contrast/Brightness/Ring Volume
■Choice of 12 door bell chimes
■Master/Slave selectable
■Part No. 100-974
Room Station Display Screen ........................................................ 10.2” TFT
Horizontal Resolution ................................................................420TVL
Input Voltage ......................................................................13.8VDC
Video Channel Qty........................................................................ 4
Room Stations Supported Qty .............................................................. 2
Power Consumption .............................................................1.5W ~ 16W
Wiring Requirements .........................................4 core screened cable + RG59 coax*
Operating Temperature .......................................................... -10°C ~ 50°C
Room Station Dimensions (W x H x D) .......................................... 334 x 210 x 25mm
Door Station Dimensions (W x H x D) ............................................ 98 x 173 x 25mm
In some installations the 100-958 Video Door Station may have audio feedback when used with a weathershield.
A simple modification to the microphone gain is available - please ask when ordering.
DOOR STATION
■Zinc Alloy, surface mount
■1/4 inch colour CCD camera
■Resolution: 420TV Lines
■Waterproof Vandal Resistant alloy housing
■Built-in automatic 3 x LED lighting for night vision / Minimum illumination 1.0 lux
■68 degree wide angle field of view
■Compatible with Four Plus & 10.2 intercom systems
■Part No. 100-958
Features
Specifications
Cable Specifications
*MINIMUM WIRING REQUIREMENTS BETWEEN DOOR AND ROOM STATIONS
UP TO 15m DISTANCE OVER 15m DISTANCE
4 CORE SCREENED CABLE for
PWR, GND, AD and VD.
4 CORE SCREENED CABLE for PWR & AD (only 1 pair required)
RG59 COAX for GND & VD.
Maximum cable distance.
Master Station to Slave Station: 60m
Door Station/s to Master Station: 80m
NOTE - 4 CORE SCREENED CABLE
Connect outer screen to GND at the
master station end only.
RECOMMENDED CABLE
100-960 4 Core Screened cable 100m reel
100-353 RG59 Coax cable 100m reel

5
Room Station Description
1Monitor button
2Answer / Call / Transfer / Intercommunication button
3Door release button
4Off / Save button
5Adjust Left/Right buttons
6Menu: Brightness/Contrast/Colour button
7Chime Select button
8Microphone
910” Colour Screen
1
5
6
7
9
2
3
4
8

6
6
DESCRIPTIONS OF MONITOR-REAR: (10.2 inch TFT Power voltage:DC 13.8V)
DIMENSION:
Room Station Rear Description
12 Speaker
13 Door Station 1 connection
14 Door Station 2 connection
15 Slave Room Station connection
16 Optional Audio/Video Input 1 connection
17 Optional Audio/Video Input 2 connection
18 Master/Slave selector dipswitches
19 Door 1 lock release output, 12VDC
20 Power input 13.8VDC

7
9
DESCRIPTIONS OF MONITOR CONNECTIONS: (10.2 inch TFF, Power voltage:DC 13.8V)
Room Station Connections
SLAVE STATION
VD: Video Input
AD: Audio Input
GND: Ground
DATA: Data
POWER INPUT
13.8VDC
DOOR LOCK OUTPUT
13.8VDC
A/V INPUT 1
VD3: Video Input
PWR3: 13.8VDC Output
GND: Ground
AD3: Audio Input
A/V INPUT 2
VD4: Video Input
PWR4: 13.8VDC Output
GND: Ground
AD4: Audio Input
DOOR STATION 1
PWR1: Power
GND: Ground
AD1: Audio
VD1: Video
DOOR STATION 2
PWR2: Power
GND: Ground
AD2: Audio
VD2: Video

8
100-974 ROOM STATION (max. 2)
Selected as
MASTER
Selected as
SLAVE
100-958 DOOR STATION (max. 2)
13.8VDC supply
13.8VDC supply
Optional
electric locks
Optional CCTV cameras,
TV tuner or other A/V
inputs. Max 2.
System Schematic

9
VD
AD
GND
DATA
13.8V-
13.8V+
GND
LOCK1
PWR1
GND
AD1
VD1
VD3
PWR3
GND
AD3
VD4
PWR4
GND
AD4
PWR2
GND
AD2
VD2
PW
GND
AD
VD
KEY1
NOT
USED
100-974
10.2 ROOM STATION
100-958
DOOR STATION
12VDC ELECTRIC
DOOR STRIKE
MASTER Setting
Both switches ON
MASTER Setting
Both switches ON
12VDC ELECTRIC
DOOR STRIKE
KEY2
840-003
POWER SUPPLY
13.8VDC
VD
AD
GND
DATA
13.8V-
13.8V+
GND
LOCK1
PWR1
GND
AD1
VD1
VD3
PWR3
GND
AD3
VD4
PWR4
GND
AD4
PWR2
GND
AD2
VD2
PW
GND
AD
VD
KEY1
POWER SUPPLY
840-003
100-974
10.2 ROOM STATION
100-958
DOOR STATION
KEY2
DOOR STRIKE
POWER SUPPLY
840-003 or equivalent
Door Lock Connection, Method 2
Door Lock Connection, Method 1
Connection Diagram 1 Door Station / 1 Room Station
Notes
1. The Room Station provides power for the electric door strike.
2. One extra pair of wires is required between the door and the Room Station.
This method eliminates the need to provide a dedicated power supply for the electric
door strike.
Notes
1. The electric door strike is unlocked by a pair of dry relay contacts at the Door Station.
2. A dedicated power supply is required for the electric door strike.
3. If the door strike power supply is located near the front door then only 4 wires are
required between the door and the Room Station.
4. This method provides lower security as the door strike can be operated by short-
circuiting the KEY1 & KEY2 wires at the back of the door station.
Up to 15m cable length use 4 core screened cable for audio,
video and power. Over 15m cable length, use RG59 coax cable
for VD and GND.
Max. cable distance: Master-Slave: 60m / Door-Master: 80m
See page 4 for further detail.

10
VD
AD
GND
DATA
13.8V-
13.8V+
GND
LOCK1
PWR1
GND
AD1
VD1
VD3
PWR3
GND
AD3
VD4
PWR4
GND
AD4
PWR2
GND
AD2
VD2
PW
PW
24/020 FIG8 CABLE
GND
GND
AD
AD
VD
VD
KEY1
KEY1
100-974
10.2 ROOM STATION
100-958
DOOR STATION 1
100-958
DOOR STATION 2
MASTER Setting
Both switches ON
KEY2
KEY2
840-003
POWER SUPPLY
13.8VDC
12VDC ELECTRIC
DOOR STRIKE
12VDC ELECTRIC
DOOR STRIKE
DOOR STRIKE
POWER SUPPLY
840-003 or equivalent
DOOR STRIKE
POWER SUPPLY
840-003 or equivalent
Connection Diagram
2 Door Stations / 1 Room Station
Up to 15m cable length use 4 core screened cable for audio,
video and power. Over 15m cable length, use RG59 coax cable
for VD and GND.
Max. cable distance: Master-Slave: 60m / Door-Master: 80m
See page 4 for further detail.

11
VD
AD
GND
DATA
VD
AD
GND
DATA
13.8V-
13.8V+
13.8V-
13.8V+
GND
LOCK1
GND
LOCK1
PWR1
GND
AD1
VD1
PWR1
GND
AD1
VD1
VD3
PWR3
GND
AD3
VD3
PWR3
GND
AD3
VD4
PWR4
GND
AD4
VD4
PWR4
GND
AD4
PWR2
GND
AD2
VD2
PWR2
GND
AD2
VD2
PW
24/020 FIG8 CABLE
PW
GND
GND
AD
AD
VD
VD
KEY1
KEY1
100-974
10.2 ROOM STATION 1
selected as MASTER
100-974
10.2 ROOM STATION 2
selected as SLAVE
NOTE:
A single 840-003 13.8VDC power supply can be used to
power both room stations.
If the distance between room stations is over 30m install
one power supply at each room station.
100-958
DOOR STATION 1
100-958
DOOR STATION 2
MASTER Setting
Both switches ON
SLAVE Setting
Both switches OFF
KEY2
KEY2
840-003
POWER SUPPLY
13.8VDC
12VDC ELECTRIC
DOOR STRIKE
12VDC ELECTRIC
DOOR STRIKE
DOOR STRIKE
POWER SUPPLY
840-003 or equivalent
DOOR STRIKE
POWER SUPPLY
840-003 or equivalent
Connection Diagram
2 Door Stations / 2 Room Stations
Up to 15m cable length use 4 core screened cable for audio,
video and power. Over 15m cable length, use RG59 coax cable
for VD and GND.
Max. cable distance: Master-Slave: 60m / Door-Master: 80m
See page 4 for further detail.

12
Switch Settings
When connecting two room stations to the system, set the dipswitches on the rear
panel of each station as follows.
Switch 1. Enables video load impedance
Switch 2. Master/Slave setup
Please disconnect power to each station before changing switch settings.
MASTER STATION
OR SINGLE STATION
Set both switches ON
SLAVE STATION
Set both switches OFF
ON ON
OFF OFF

13
19
MONITOR INSTALLATION GUIDE:
Installation Instructions:
 Please select relevant wire diagram for your chosen system
 Make sure you use correct cable for system required.
Single Monitor Installations:
 Select correct height of indoor monitor ，usually installation height is between
150~160CM（See below Figure 1）
 After determine the monitor bracket position and run cable through the bracket，fix
locating screws in bracket.
 Finally, install the indoor monitor on the wall as below Figure 2.
19
MONITOR INSTALLATION GUIDE:
Installation Instructions:
 Please select relevant wire diagram for your chosen system
 Make sure you use correct cable for system required.
Single Monitor Installations:
 Select correct height of indoor monitor ，usually installation height is between
150~160CM（See below Figure 1）
 After determine the monitor bracket position and run cable through the bracket，fix
locating screws in bracket.
 Finally, install the indoor monitor on the wall as below Figure 2.
1. Use the recommended cable between all stations.
2. Determine the correct height for the Room Station/s. Typical installation height is
between 150-160cm. See figure 1.
3. Run the cable through the bracket and mount the bracket to the wall using screws.
4. Terminate the cable at the monitor following the relevant wiring diagram in this
manual.
5. Fit the Room Station on the bracket. See Figure 2.
Room Station Installation Guide
FIG. 1 FIG. 2

14
20
DOOR BELL INSTALLATION GUIDE:
Doorbell Installation:
 Please take some time to select the most suitable position for doorbell.
 Please consider the factors of day time, night time and likely weather condition impact.
 Direct sunlight on the camera and direct contact with rain should be avoided.
 Determine Camera Position: we recommend the door bell and the camera should be at
the same height ( Average Height from 1.5 to 1.6 meters )
1. Please take care to select the most suitable position for the Door Station.
2. Consider all factors which may affect audio and video performance such as likely
sun position in daytime, shadows, blindspots, avoid backlighting, and the likely
weather impact.
3. Direct Sunlight on the camera and expose to rain should be avoided.
4. Determine the best Door Station height for your premises. Typical installation height
is 150 - 160cm.
Door Station Installation Guide

15
Operating Instructions

16
Operating Instructions
HOW TO ANSWER THE DOOR STATION AND RELEASE THE DOOR LOCK
When a visitor presses the call button at the front door/s the room station/s will chime and the
monitor will display the video from the front door which called.
Press
Answer
Intercom
to answer. You have 60 seconds to talk with the visitor
Press to hang up.
Press to release the door lock (if fitted).
If the system has two door stations, the door lock which made the call is released.
HOW TO TRANSFER A CALL (If two room stations are installed)
To transfer a call from the door station to the other room station.
Press the Answer
Intercom button again. The call will be transferred to the other room station. Your
room station will hang up once the call has been transferred. Conversation time is 60
seconds.

17
Operating Instructions
HOW TO MONITOR AUDIO & VIDEO INPUTS
Your 10.2 Intercom System has four Audio/Video inputs that can be viewed at any room
station.
Inputs 1 & 2 provide audio and video signals from Door1 and Door2.
Inputs 3 & 4 provide audio and video signals from two optional A/V sources such as CCTV
cameras, TV tuners, MP3 players and many other types of devices for surveillance or
entertainment.
Press Monitor
to display video from Door1. The image will display for 30 seconds.
Press Monitor
again to display video from Door2. The image will display for 30 seconds.
Press Monitor
again to display video and audio from A/V Input 1.
Press Monitor
again to display video and audio from A/V Input 2.
Note 1. The image and audio (if connected) from A/V1 & A/V2 will remain on until another
input is activated or is pressed.
Note 2. If a call is made from a door station while an A/V input is being monitored, the display
will switch to allow the call from the front door. When the call is completed the display will
return to the previous A/V input.

18
Operating Instructions
HOW TO MAKE AN INTERCOM CALL BETWEEN TWO ROOM STATIONS
In standby mode press Answer
Intercom
at your room station.
The other room station will chime.
Press
Answer
Intercom
on the other room station to take the call.
HOW TO ADJUST BRIGHTNESS/CONTRAST/COLOUR
At any time with an image on the display:
Press
Video/set
RGB
The monitor will display the “Brightness” level.
Use the <or >button to adjust the image brightness.
Press
Video/set
RGB
again. The monitor will display “Contrast” level.
Use the <or >button to adjust the image contrast.
Press
Video/set
RGB
to save the settings and return to the main menu.
Press to exit.

19
Operating Instructions
HOW TO CHOOSE THE CALL CHIME TUNE
To choose one of the 12 available chime tunes.
Have one person press the call button on the door station.
At a room station press Chime/set to change the tune.
Press repeatedly to play each tune in turn.
Press Off/Save to save the selected chime tune.
HOW TO ADJUST ROOM STATION VOLUME
During a front door call or when listening to an optional audio source from A/V1 or A/V2:
Use the <or >buttons to adjust speaker volume at the room station.
HOW TO USE THE “DO NOT DISTURB” FUNCTION
The “Do Not Disturb” function can be activated when you don’t want to be disturbed by
calls from the front door or another room station.
TO ACTIVATE Do Not Disturb mode
In standby mode press Chime/set for 2 seconds. The button will light up red.
In Do Not Disturb mode you will still see video from a front door call and you can
answer the call, but the chime will be silent. Intercom calls from another room station will
be ignored.
TO CANCEL Do Not Disturb mode
Press Chime/set for 2 seconds. The red lit button will turn off.
