ICRealtime ICIPD1300VIR User manual

HD (IR) Vandal Proof Network Dome Camera User’s Manual
Version 1.5.1

i
Welcome
Thank you for purchasing our network camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!

ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction)
Please note: Do not connect two power supplying sources to the device at the same time; it may
result in device damage! The product must be grounded to reduce the risk of electronic shock.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding studs of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.

iii
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the
device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
Dome enclosure is the optical component, do not touch the enclosure when you are installing the
device or clean the enclosure when you are doing maintenance work. Please use professional optical
clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result
in poor IR effect of camera with IR function.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
Accessory Name
Amount
Network Camera
1
Quick Start Guide
1
Installation Accessories Bag
1
CD
1

iv
Table of Contents
1General Introduction ..................................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Specifications................................................................................................................2
1.3.1 Performance...........................................................................................................2
2Structure ......................................................................................................................................4
2.1 Dimensions....................................................................................................................4
2.2 Port Description ............................................................................................................4
2.3 Bidirectional talk..........................................................................................................10
2.3.1 Device-end to PC-end........................................................................................10
2.3.2 PC-end to the Device-end..................................................................................10
2.4 Alarm Setup.................................................................................................................11
3Installation..................................................................................................................................13
3.1 Device Installation Introduction ................................................................................13
3.2 Device Installation Steps...........................................................................................13
3.2.1 General Installation.............................................................................................13
3.2.2 Manual Zoom Lens Focus Operation...............................................................17
3.2.3 Side Cable Exit....................................................................................................18
3.2.4 Cable Connection................................................................................................18
3.3 Micro SD Card Installation ........................................................................................19
4Quick Configuration Tool.........................................................................................................21

v
4.1 Overview......................................................................................................................21
4.2 Operation.....................................................................................................................21
5Web Operation..........................................................................................................................23
5.1 Network Connection...................................................................................................23
5.2 Login and Main Interface...........................................................................................23
6FAQ ............................................................................................................................................25
Appendix Toxic or Hazardous Materials or Elements ...............................................................26

1
1General Introduction
1.1 Overview
This series network camera integrates the traditional camera and network video technology. It adopts
audio and video data collection, transmission together. It can connect to the network directly without any
auxiliary device.
This series network camera uses standard H.264 and MJPEG video compression technology and
G.711a audio compression technology, which maximally guarantee the audio and video quality.
This series network camera enclosure has the strong resistance capacity, which can guarantee the
proper work performance under heavy strike. It supports real-time monitor and listening at the same time.
It supports analog video output and dual-way bidirectional talk.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the network
and then use a network client-end. Due to its multiple functions and various uses, this series network
camera is widely used in many environments such office, bank, road monitor and etc.
1.2 Features
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Storage
Function
Support central server backup function in accordance with your configuration and
setup in alarm or schedule setting
Support record via Web and the recorded file are storage in the client-end PC.
Support built-in Micro SD card.
Support local Micro SD card hot swap, support short-time storage when
encounter disconnection.
Alarm
Function
Real-time respond to external local alarm input and video detect as user pre-
defined activation setup and exert corresponding message in screen and audio
prompt(allow user to pre-record audio file)
Real-time video detect: motion detect, tampering.
Can generate an alarm when network abnormal, Micro SD card abnormal event
occurred.
Network
Monitor
Network camera supports one-channel audio/video data transmit to network
terminal and then decode. Delay is within 270ms (network bandwidth support
needed)
Max supports 20 connections.
Adopt the following audio and video transmission protocol: HTTP, TCP, UDP,
MULTICAST, RTP/RTCP, RTSP and etc.
Support web access, widely used in WAN.
Network
Management
Realize network camera configuration and management via Ethernet.
Support device management via web or client-end.
Support various network protocols.
Peripheral
Equipment
Support the on-off alarm device to alarm via the sound or the light.
Power
External power adapter DC12V/AC 24V
Support PoE.
Warning！
Do not connect these two power supplying sources to the device at the same

2
time; it may result in device damage!
Assistant
Function
Log function
Support PAL/NTSC
Day/Night mode auto switch (electromagnetic ICR switch).
Support iris auto adjust.
Built-in IR light. Support IR night vision.
Backlight compensation: screen auto split to realize backlight compensation to
adjust the bright.
Support electronic shutter and gain setup.
Support video watermark function to avoid vicious video modification.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for network camera performance specification.
Model
Parameter
ICIP D1300VIR
System
Main
Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the same
time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Micro SD card status, bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
1280(H)*960(V)
Day/Night
Mode
Support day/night mode switch and electromagnetic IR-CUT at the same
time.
Auto Iris
DC drive
Gain Control
Manual/Auto
White Balance
Manual/Auto
BLC
On/Off
Electronic
Shutter
Manual/Auto
It ranges from 1/3 to 1/10000.
Motorized
Focus
Not support
Video
Compression
Standard
H.264 /H.264H/H.264B/MJPEG
Note: Some versions do not support H.264H.
Video Frame
Rate
PAL:
Main stream（1280*960@25fps）
Extra stream（704*576@25fps）
Main stream（1280*720@25fps）
extra stream（704*576@25fps）
NTSC:
Main stream（1280*960@30fps）
extra stream（704×480@30fps）
Main stream（1280*720@30fps）
extra stream（704×480@30fps）

3
Video Bit Rate
H.264: 56Kbps-8192Kbps. It is adjustable
MJPEG adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering.
Lens
φ14 interface, 2.8~12mm@F1.4
Lens Interface
CS. Lens is the default accessories.
Audio
Audio Input
1-channe, RCA audio input
Audio Output
1-channel RCA audio output
Bidirectional
Talk Input
Reuse the first audio input channel
Audio Bit Rate
16kbps 16bit
Audio
Compression
Standard
G.711a/G.711Mu
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100; area
threshold ranges from 0 to 100.
Activation event: alarm device, audio/video storage, image snapshot, log,
email function and etc.
Video Loss
Activation event, alarm device, audio/video storage, image snapshot, log,
email function and etc.
Alarm Input
1-channel input，1-channel output
Record and Backup
Record
Priority
Manual>External alarm >Video detect>Schedule
Storage
Management
Support Micro SD card storage, NAS storage
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network
Protocol
HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PP
POE,IPv4/v6,SNMP,QoS,UPnP,NTP, HTTPS, 802.1x, Bonjour
Protocol
PSIA (optional), ONVIF
Remote
Operation
Monitor, system setup, log information, maintenance , upgrade and etc
AUX
Interface
Video Output
1-channel analog video output，BNC port
Reset
Built-in RESET button
IR light
IR distance 10 to 20 meters (For IPC-HDBW series product only)
General Parameter
Power
Support AC24V/DC12V power. PoE
Power
Consumption
General series: below 3W.
IR series: below 5W.
Working
Temperature
-20℃~+60℃
Working
Humidify
≤95%
Dimensions(m
m)
¢151x119
Weight
1.25Kg
Installation
Support various installation modes

4
2Structure
2.1 Dimensions
You can refer to the following figures for dimension information. The Unit is mm. See Figure 2-1 and
Figure 2-2.
Figure 2-1 Dimension 1
Figure 2-2 Dimension 2
2.2 Port Description
For the non-IR series product, the interface is shown as in Figure 2-3 and Figure 2-4.
Note：
Figure in this chapter are all for reference only, and please refer to model 1-a and 1-b
according to actual product.

5
Figure 2-3 Camera internal without IR (1-a)
Figure 2-4 Camera internal without IR (1-b)
See Figure 2-5.

6
Figure 2-5 Camera internal without IR (2)
See Figure 2-6, Figure 2-7 and Figure 2-8.
Figure 2-6 Motorized focus camera internal with IR (1-a)

7
Figure 2-7 Motorized focus camera internal with IR (1-b)
Figure 2-8 Motorized focus camera internal with IR (2)
See Figure 2-9, Figure 2-10 and Figure 2-11.

8
Figure 2-9 Manual focus camera internal with IR (1-a)
Figure 2-10 Manual focus camera internal with IR (1-b)

9
Figure 2-11 Manual focus camera internal with IR (2)
Please refer to the following sheet for external connection port definition information.
SN
Port
Port Name
Connector
Function Description
1
POWER
AC 24V power
port
/
Connect to AC 24V power.
2
POWER
DC 12V power
port
/
Connect to DC 12V power.
3
Cable exit
of the
external
connected
cable
/
/
Cable exit.
4
LAN
RJ45 network
port
Ethernet port
Network cable port.
5
I/O
I/O port
/
It includes alarm input/output, audio
and analog output.
6
RESET
Reset button
/
Reset button. It is to restore factory
default setup.
7
AUTO
FOCUS
5-direction button
/
Adjust lens angle of view and
definition.
Note: Only some models have this
function.
8
Status
indicator
light
/
/
Display device running status.
9
Fan port
/
/
Connect to fan to reduce device
internal problem.
Please note this component is
optional.
10
Micro SD
Micro SD card
slot entry
Micro SD
card
Connect to Micro SD card to realize
local storage.
11
POWER
12V power port
/
The power port of the external
connected cable.

10
Default input is DC 12V.
12
LAN
Network port
Ethernet port
The network port of the
external connected cable.
Connect to standard Ethernet
port.
Support PoE.
Note:
Before making crystal head,
pull the anti-dust cover through
network cable.
Please refer to the following sheet for I/O port cable function information. Note: actual product may vary.
Port
Name
Cable SN
Cable Port Name
Function Description
I/O Port
1
ALARM_NO
Alarm output port. Output alarm signal to
alarm device.
NO: Normal open alarm output end.
2
ALARM_COM
Alarm output public end.
3
GND
Ground end.
4
ALARM_IN
Alarm input port. It is to receive the on-off
signal from the external alarm source.
5
GND
Ground end.
6
AUDIO_IN
Input audio signal. It is to receive the analog
audio signal from the devices such as
pickup.
7
AUDIO_OUT
Output audio signal to devices such as
sound box.
8
GND
Ground end.
9
VIDEO_OUT
Output analog video signal. It can connect
to TV monitor to view video.
2.3 Bidirectional talk
2.3.1 Device-end to PC-end
Device Connection
Please connect the speaker or the MIC to the audio input port of the device. Then connect the earphone
to the audio output port of the PC.
Login the Web and then click the Talk button to enable the bidirectional talk function.
You can see the button becomes orange after you enabled the bidirectional talk function.
Click Talk button again to stop the bidirectional talk function.
Listening Operation
At the device end, speak via the speaker or the pickup, and then you can get the audio from the
earphone or sound box at the pc-end.
2.3.2 PC-end to the Device-end
Device Connection
Connect the speaker or the MIC to the audio input port of the PC and then connect the earphone to the
audio output port of the device.

11
Login the Web and then click the Talk button to enable the bidirectional talk function.
You can see the button becomes orange after you enabled the audio talk function.
Click Talk button again to stop the bidirectional talk function.
Please note the on-site listening operation is null during the bidirectional talk process.
Listening Operation
At the PC-end, speak via the speaker or the pickup, and then you can get the audio from the earphone
or sound box at the device-end.
2.4 Alarm Setup
The alarm interface is shown as in Figure 2-12. Please follow the steps listed below for local alarm input
and output connection.
1) Connect the alarm input device to the alarm input port (No.4 pin) of the I/O cable.
2) Connect the alarm output device to the alarm output port (No.1 pin) and alarm output public port (No.2
pin). The alarm output port supports NO (normal open) alarm device only.
3) Open the Web, go to the Figure 2-12. Please set the alarm input 01 port for the first channel of the I/O
cable (No.4 pin). Then you can select the corresponding type (NO/NC.)
4) Set the WEB alarm output. The alarm output 01 is for the alarm output port of the device. It is the
No.1 pin of the I/O cable.
Figure 2-12 Alarm
Please refer to the following figure for alarm input information. See Figure 2-13.
Alarm input: When the input signal is idle or grounded, the device can collect the different statuses of the
alarm input port. When the input signal is connected to the 5V or is idle, the device collects the logic “1”.
When the input signal is grounded, the device collects the logic “0”.

12
Figure 2-13 Alarm input
Please refer to the following figure for alarm output information. See Figure 2-14.
Port ALARM_COM and Port ALARM_NO composes an on-off button to provide the alarm output.
If the type is NO, this button is normal open. The button becomes on when there is an alarm output.
If the type is NC, this button is normal off. The button becomes off when there is an alarm output.
Figure 2-14 Alarm output

13
3Installation
Important
Before you complete the installation and setup, do not remove the electrostatic attraction
film on the transparent enclosure. Otherwise it may result in injury.
After remove electrostatic attraction film, do not touch dome enclosure in case it may leave
stain.
Before the installation, please make sure the installation surface can sustain at least 3X
weight of the bracket and the camera.
3.1 Device Installation Introduction
Please refer to Figure 3-1 for device installation space information. You can use screws (diameter is less
than 4.5mm) to secure the device. You can see there are installation position map and installation
screws in the accessories bag for you to install the device conveniently.
Figure 3-1 Installation 1
3.2 Device Installation Steps
3.2.1 General Installation
The general interface is shown as in Figure 3-2.

14
IR Motorized Zoom Lens Series Non-IR Series IR Manual Zoom Series
Figure 3-2 General installation
Step 1
Take the installation position map from the accessories bag and then paste it on the installation ceiling
or the wall according to the monitor area. Please dig three bottom holes of the plastic expansion bolts
according to the map. Take three expansion bolts from the accessories bag and then insert them to the
holes you just dug and then fix firmly. If you need to dig a hole to pull through the cable, you need to dig
a cable exit hole (The diameter is more than 28mm) on the installation surface according to the
installation positioning map.
Step 2
Use the inner hex wrench from the accessories bag to unfasten the 3 hex screws on the dome camera
enclosure to open it.
Step 3
Please remove the device cable (Provided) network port and the power terminal. Use the inner hex
wrench (Provided) to remove the 2 inner hex screws from the dome driver module. Then please follow
the prompt on the device to push the metal hook to two sides. Remove the dome driver module from the
chassis. See Figure 3-3.
