ICRealtime ICIP360L6 User manual

IC REALTIME SECURITY SOLUTIONS
ICIP360L6: 360 Degree Series IP Camera
Instruction Manual
Cameras:
HD-IP

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
ICIP360L6 IP Camera Instruction Manual
IC Realtime
3050 N Andrews Ave Ext
Pompano Beach, FL33064
Phone [phone] • Fax [phone]

Table of Contents
1. Features and Specifications.......................................................................1
a. Overview..........................................................................................1
b. Features............................................................................................1
c. Specifications...................................................................................3
d. Dimensions......................................................................................4
2. Camera Installation ....................................................................................6
a. General Overview...........................................................................6
b. Step by Step Guide .........................................................................7
c. SD Card Installation.......................................................................8
3. Web Operation ...........................................................................................9
a. Network Connection......................................................................9
b. Logging In, and Main Interface ..................................................10
c. EPTZ Controls .............................................................................11
4. Appendices................................................................................................13
a. Toxic or Hazardous Elements ....................................................13

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
1
Features and Specifications
This section outlines the primary features of the ICRealtimeICIP360L6 IP Camera. It
also outlines basic Architectural and Engineering specifications.
1.a Overview
his IC Realtime series product is an excellent situational awareness IP Camera designed for the security
field. It adopts an embedded Linux operating system to maintain reliable, 24/7 operation. Utilizing
both H.264 video compression and G.711/AAC audio compression technology enables the highest
quality of recorded audio/video, while maintaining the lowest bitrate utilization.
The ICIP360L6 support 6 MegaPixel with an integrated microphone. This IPC is fully suited for full operation
as a standalone device, or can be paired to one of our ICR Network Video Recorders to add a great duration of
recorded video.
The high recording resolution and extreme wide angle lens design makes this IPC well equipped for installation
in various institutions ranging from residential, commercial, governmental, and enterprise environments.
1.b Features
IC Realtime ICIP360L6 IP Cameras all support the following features:
Real-time Monitoring
ICIP360L6 supports 3072*2048 @25FPS (P)/ 3072*2048 @26FPS (N) in Max FPS.
Protection
This product fully supports IK10 and IP66.
Secure Archiving
Chapter
1
T

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
2
Audio Video data is compressed and packaged into a secure and proprietary video format (.dav files). This
bolsters archived video integrity, and prevents vicious data manipulation. Video is also watermarked with
special data for evidentiary purposes.
Compression Format
H.264 video and G.711/AAC audio enables high quality video recording while maintaining the lowest file sizes
possible.
SD Card Storage
As a standalone device, the IPC can hold a 64GB micro SD card suitable for storing video direct from the
camera.
Network Operation
Full system control (including live view, playback, backup, PTZ control, and system configuration) is available
with over the network. Client software is available for both Mac and PC systems.
EPTZ Control
This IPC includes a special de-warping algorithm, enabling users to „Virtually‟ Pan/Tilt/Zoom across a high
resolution image, in order to get the highest visibility and situational awareness from the camera.
1.c Specifications
Model
ICIP360L6 (PAL)
ICIP360L6 (NTSC)
Camera
Image Sensor
1/8” 6 Megapixel CMOS
Effective Pixels
3072(H)x2048(V)
Scanning System
Progressive
Electronic Shutter
Speed
Auto/Manual 1/3~1/10000
Auto/Manual 1/4~1/10000
Min. Illumination
Color: 0. 1LUX/F2.0
S/N Ratio
>52dB
Camera Features
Day/Night
Electromagnetic type IR-CUT, Support day/night mode
switch
Backlight Compensation
BLC
White Balance
Auto/ Manual

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
3
Gain Control
Auto/Manual
Noise Reduction
3D
Privacy Masking
Up to 4 areas
Lens
Focal Length
1.55mm
Max Aperture
F2.0
Angle of View
185°/185°/185°
Mount Type
Wall-mount, In-ceiling and bracket
Video
Compression
H.264/H.264H/H.264B/MJPEG
Resolution
3072*2048 25FPS
2048*2048 25FPS
2048*1536 25FPS
1600*1200 25FPS
3072*2048 26FPS
2048*2048 26FPS
2048*1536 26FPS
1600*1200 30FPS
Frame
Rate
Main Stream
3072*2048@25fps
Sub Stream
704*576@25fps
Bit Rate
H.264: 24K ~ 12288Kbps, MJPEG: 64K ~ 65536 Kbps
Network
Ethernet
RJ-45 (10/100/1000 Base-T)
Protocol
HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHC
P,DNS,DDNS,PPPOE,IPv4/v6,SNMP,QoS,UpnP,NTP
ONVIF
ONVIF Profile S
Max. User Access
10 users
Smart Phone
iPhone, iPad, Android, Windows Phone
General
Power Supply
DC12V, PoE(802.3af)
Memory Slot
Micro SD
Power Consumption
<11W
Working Environment
-40°C~+60°C, Humidity≤95%
Dimensions
Φ150×50.7mm
Weight
<1kg
Protection
IK10, IP66

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
4
1.d Dimensions

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
5
1.e External Cable
NO.
Port
Port Name
Connector
Function Description
1
AUDIO
OUT
Audio output
port
RCA
Output audio signal to the speakers.
2
AUDIO IN
Audio input
port
RCA
Input audio signal, receive the analog audio signal from
the sound pick-up.
3
LAN
Network port
Ethernet
port
Connect to standard Ethernet cable.
4
I/O
I/O port
-
Connect I/O port
5
POWER
Power input
port
-
Connect DC 12V power, input power.
Port Name
Cable
Number
Cable Port
Name
Function Description
I/O port
1
ALARM_NO
Alarm output port. It is to output the alarm signal
to the alarm device.
NO：Normal open alarm output port.
This port needs to be used with ALARM_COM
port
2
ALARM_COM
Alarm output public port.

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
6
Port Name
Cable
Number
Cable Port
Name
Function Description
3
ALARM_IN1
Alarm input port 1. It is to receive the on-off signal
from an external alarm source.
4
ALARM_IN2
Alarm input port 2. It is to receive the on-off signal
from an external alarm source.
5
GND
Ground port

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
7
Camera Installation
This section outlines the proper way to mount and install an ICIP360L6 IP Camera.
Suitable methods of installing the IPC include either Ceiling installation, Ground
Installation, or Wall installations. Note that hardware including screws and anchors are
included for the camera installation.
2.a General Overview
Chapter
2

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
8
2.b Step by Step Guide
Step 1: Remove the cameras dome cover
Using the included hex wrench from the accessories kit, unfasten the 3 hex screws on the dome camera
enclosure and then remove it.
Step 2: Place mounting template
Included with the camera is a mounting template that can be adhered to the target installation surface for ease
of installation. Following the diagram, bore 3 small holes as indicated on the diagram, around the perimeter of
the template. Once you‟ve created your holes, insert the plastic anchors securely and firmly.
If you need to pass the cameras cable through the mounting plate, be sure to bore out the template area marked
„Cable Exit‟ to allow for the female RJ-45 plug to pass through.
If you need to pass the cameras cable through the side of the cameras enclosure, be sure to snip out the U-
shape knock out in order to allow the cable a wire path.
Step 3: Mount camera base
Adjust the cameras base plate, and pull the cable through your exit hole. Match the ”TOP” direction of the
camera with that from the installation template. Align the 3 base plate holes with the plastic anchors from Step
2. Using (3) ST3.0 self tapping screws from the accessories kit, fix the camera base plate onto the installation
surface by screwing the ST3.0 screws through the holes, and into the plastic anchors.
Step 4: Replace dome cover
Lastly, take the dome cover and align it with the base plate that is now fixed to the installation surface. Using
the hex key from step 1, replace the 3 hex screws, securing the dome back in place.
Note: If connect the host GND to ground lead, may improve device reliability. The GND locates next to exit hole on the rear side
of the chassis and the GND screw is M3.

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
9
2.c SD Card Installation
Step 1: Disconnect power source from the IP Camera
SD cards shall not be installed or removed while the camera is powered and operational. Doing so can
potentially result in damage to the camera, and any data stored on the SD card.
Step 2: Remove the cameras dome cover
Using the included hex wrench from the accessories kit, unfasten the 3 hex screws on the dome camera
enclosure and then remove it..
Step 3: Insert SD card
Look on the base plate of the camera to see the section labeled “SD Card”. Insert your micro SD card (Pin
side down) until it clicks securely into place. At this point you can restore power to the camera, and attache the
dome cover again.

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
10
Web GUI Operation
This section outlines how to assign an IP address to the camera, and how to access and
control the IPC via it’s built inWeb Ineterface.
3.a Network Connection
Step 1: Ensure the Camera is physically connected to your Network, and Powered ON.
Patch the IP Camera into your network with a standard Ethernet cable. Provide the camera with power either
via PoE or with the separate 12VDC power input jack.
Step 2: Assign an IP address to the IP Camera.
The ICIP360L6 Series camera (and all ICR IP Cameras) have a factory default static IP address of
192.168.1.108. If this matches the same subnet as your LAN, you will be able to login to the camera by typing
this address into your browser (assuming that the IP address does not conflict with another device on your
network).
Alternatively, you can use our IP Auto Search utility to rapidly find and change IP addresses for IC Realtime
series IP Cameras. The utility is available on our support page at :
http://www.icrealtime.com/docs/IPAutoSearch.zip
3.b Logging In, and Main Interface
Step 1: Open up your Web Browser (Safari, Chrome, Firefox, or IE) and input the IP address
of your IP camera.
In Example, open Safari and browse to http://192.168.1.108
Chapter
3

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
11
Step 2: Follow the on screen prompts to install the plugin
When you first access the IP Camera over your web browser, you will be prompted to install the plugin. See
below:
Step 3: Login to the camera with the default credentials
By default, the username is „admin‟ and the password is „admin‟. It is always strongly recommended to change
the default passwords after the initial setup. The cameras login page should appear as below:

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
12
3.c EPTZ Controls
One of the primary features and functions of this series IP Cameras is its virtual Pan/Tilt/Zoom Capabilities. Read on for a step-
by-step guide on how to control the multiple viewing options of the ICIP360L6.
Before Using the EPTZ function, you must configure the Installation Mode.
When logged into the camera and click the “fish-eye control function”on the bottom-left of live view window,
you‟ll see options at the top right to choose the Installation mode. Refer to the image below:
The installation mode has 3 options:
oCeiling: Use this option when the camera has been installed in the ceiling, and the camera is
facing down.
oWall: Use this option when the camera has been installed onto a Wall Surface

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
13
oGround: Use this option when the camera is mounted or laying on the ground, and the camera
is facing up.
Set your desired display mode next. There are several options:
o1O: A 360°Omni view. Fisheye original image mode. It does not offer EPTZ control.
o1P: One-picture panorama, it takes the whole panorama with 360°view. It does not offer
EPTZ control.
o2P: It split s 1P into 2 separate 180°field of vision views. It does not offer EPTZ control.
o1O+3P: Display one fisheye original image plus three local region images. You can click the
EPTZ controls at the top right to drive around the image virtually.
o1R: 1 Region default in center. It is to display one of the four windows. It can show the video
around the 360 degrees panorama. You can select video and then implement corresponding
operation. EPTZ control is available.
Where you can:
1. Adjust camera direction via arrow keys. Click OK to restore default position.
2. Step length is mainly used for speed adjustment as the longer the step, the higher the
speed. Zoom step length is to adjust zoom speed; movement step length is to adjust
rotation speed per step; rotation step length is to adjust clockwise/counterclockwise
rotation speed.
o4R: 90°x4 Regions. Panorama 360 degree is divided into four windows. Each window has 90
degrees and totally displayed in four channels. It can be operated in a similar way with 1-
window. EPTZ control is available.

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
14

I C R E A L T I M E S E C U R I T Y S O L U T I O N S
15
Appendix: Toxic or Hazard Materials
Report
Note
This user manual is intended for reference only. Slight differences may be found in the user interface as
products continually develop.
All designs and software herein are subject to change without prior written consent.
All trademarks and registered trademarks mentioned are the properties of their respective owners.
Please visit http://www.icrealtime.com for more information.
Chapter
4
