ICS RZ60C User manual

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
RZ60C
OPERATOR’S MANUAL

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
3
TABLE OF CONTENTS
SYMBOLS & LABELS 4
SAFETY 6
TECHNICAL SPECIFICATIONS 9
SET UP 10
ADJUST GUARD 12
REVERSE ARM 13
FUELING 15
OPER ATION 16
MAINTENANCE 20
ADDITIONAL MAINTENANCE 25
TROUBLESHOOTING 28
REFERENCE 29

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb22
TITLE ICS®RZ60C OPERATOR’S MANUAL
4
SYMBOLS & LABELS
THE FOLLOWING SYMBOLS & DEFINITIONS ARE FOUND THROUGHOUT THIS MANUAL AND
ARE DESIGNED TO MAKE YOU AWARE OF POTENTIAL HAZARDS OR UNSAFE PRACTICES.
A potentially hazardous situation exists which, if not avoided,
could result in death or serious injury.
A potentially hazardous situation exists which, if not avoided,
may result in moderate or minor injury or property damage.
A potential situation exists which, if not avoided, may result in
product or property damage.
THE FOLLOWING SYMBOLS & LABELS MAY BE FOUND IN THIS MANUAL OR ON THE SAW
Read the operator’s manual carefully and understand the
contents before you use this equipment.
Always use:
• Hard hat
• Ear protection
• Protective glasses or full face protection
• Respiratory protection
Wear hand protection
IMPORTANT
WARNING
CAUTION
Hazardous dust and gas emissions

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
5
max
5100 rpm
Fire risk due to sparks
Reactive forces
Maximum spindle speed
SYMBOLS & LABELS

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
6
WARNING A potentially hazardous situation exists which, if not avoided,
could result in death or serious injury.
The items listed below are critical to minimizing the risk of injury
or equipment damage.
• DONOT operate this machine unless you have read and understand this operator’s manual.
• DONOToperatethesawwithdamaged,modified,broken,ormissingguards.
• DONOTallowbladeexposurefromtheguardtobemorethan180degrees.
• Readallsafetymaterialsandinstructionsthataccompanyanybladeusedwiththissaw.
• Useonlyabrasivebladesorhigh-speeddiamondbladesmarkedforusewithgasoline-powered,
hand-held,portable,abrasivecutting-offmachines.
• DONOTuseabrasivebladesthatarelessthan1/8”(3.17mm)thick.
• DONOTuseabrasivebladesthatarenotreinforced.
• DONOTuseabrasivebladesordiamondbladesthatarenotspecificallyratedforatleast5100
rpmon14”(350mm)or6200rpmon12”(300mm).Excessivespeedcouldresultinblade
breakage.
• DONOTusedamagedblades.Alwaysinspectthebladethoroughly.
• DONOTuseanabrasivebladethathasbeendropped.
• DONOTusecarbide-tippedortoothedtypebladesofanykind.
• DONOTgrindonthesideofablade.
• DONOTcock,jamorwedgethebladeinthecut.
• Inspectthesawflangesandshaftsfordamagebeforeinstallingtheblade.DONOTuseif
damagedorworn.
• Verifythebladearborholematchesthemachinespindlebeforemountingtheblade.
• Mountthebladesolidlyandfirmly.Wrenchtightenthearborscrew.
• Makesurethebladeandflangesarecleanandfreeofdirtanddebrisbeforemountingtheblade
onthesaw.
• DONOTinsertthebladeintoaslotnarrowerthantheblade.Rapidpushbackmayoccur.
• DONOTrunthesawupside-down.Debriscanflybackintotheoperator’sface.
• AlwaysturnthesawOFFbeforeperformingmaintenanceonthesaw.
• DONOTuseequipmentthatisnotfunctioningproperly.
• TurnengineOFFbeforerefuelingandallowtheenginetocool.
• Keepfuelawayfromopenflame.
• Alwaysprovideadequateventilationwhenhandlingfuel.
• Makesurethegascaponthesawandthefuelcanareproperlytightened.
• Movethesawatleast10feet(3m)awayfromrefuelingareabeforestarting.
SAFETY

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
7
• DONOTtrytostopamovingbladewithyourhand.
• DONOToperatethismachinewhenyouaretiredorfatigued.
• Alwayswearprotectiveclothing,includinghardhat,eyeprotection,hearingprotection,respiratory
protection,andgloves.
• Avoidloosefittingclothing.
• Besuretherearenoobstructionsinthecuttingarea(plumbing,electricalconduit,
airducts).
• DONOToperatethismachineinanenclosedareaunlessitisproperlyventilated.
• DONOToperatethemachineinthevicinityofanythingthatisflammable.Sparkscouldcause
afireoranexplosion.
• DONOToperatethesawwhileusingdrugsoralcohol.
• Keepallpartsofyourbodyawayfromthebladeandallothermovingparts.
• Knowhowtostopthemachinequicklyincaseofemergency.
A potentially hazardous situation exists which, if not avoided,
may result in minor or moderate injury or property damage.
CAUTION
• DONOTtouchadrycuttingdiamondbladeimmediatelyafteruse.Thesebladesrequireseveral
minutestocoolaftereachcut.
• DONOTleavethismachineunattendedwhiletheengineisrunning.
• DONOToperateacuttingmachineifthebladedoesnotstoprotatingwhenthethrottletrigger
is released.
• Usethecorrectbladeforthetypeofworkbeingdone.Checkwithblademanufacturerifyoudo
notknowifbladeiscorrect.
• Performsafetychecksbeforestartingeachday.
• DONOToperatethissawwithoutbothhandsonthehandles.Useafirmgripwiththumbsand
fingersencirclingthehandles.
• Keepthehandlesdry,cleanandfreeofoilorfuel.
• DONOToperatethissawwithoutsolidfooting.
• Removeorcontrolslurrytopreventslipperyconditionswhilecutting.
• Setupawell-markedsafetyzonewitharopedboundaryandclearsigns.
• Alwayscarrythemachinewiththeenginestoppedandthemufflerawayfromthebody.
• Usecautionandfollowinstructionswhensettinguportransportingthemachine.
• Makesurethebladeisnotcontactinganythingbeforestartingtheengine.
• DONOTstandinthebladepathwhiletheengineisrunning.
SAFETY
WARNING A potentially hazardous situation exists which, if not avoided,
could result in death or serious injury.

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
8
A potential situation exists which, if not avoided, may result in
product or property damage.
IMPORTANT
FUEL
• FailuretouseICS®brandoilmayresultinprematureenginefailureand/orupto90%reductionin
enginelife.
NOTE:1bottleofICS® two-strokeengineoilisprovidedwiththissaw.
• AlwaysrunthissawwithamixtureofgasolineandICS® two-strokeengineoil.
• AlwaysuseICS® brandtwo-strokeengineoil.Ifnotavailable,usehigh-qualityoilformulated
specificallyforair-cooledtwo-strokeengines.
• Neverusetwo-strokeoilformulatedforwater-cooledtwo-cycleengines,suchasoutboard
motor oil.
• Neverusemotoroilintendedforfour-strokeengines.
• Usehighquality,unleadedgasolinewithaminumumoctaneratingof90.Loweroctanegasoline
willcausetheenginetemperaturetoincreaseresultinginpistonseizure.
• Alwaysmeasuretheamountofgasolineandoilaccurately.Smallinaccuraciescandrastically
affecttheratioofthemixture.
ENGINE BREAK-IN
• Itisveryimportanttobreak-inanewengineto“seat”allmovingparts,especiallythepistonrings.
• Tobreak-intheengine,runonefulltankof25:1fuelatidle,cyclingthethrottleevery5to10
minutestopreventloading.
• Failuretobreak-inanenginemayresultinpistonseizure.
OTHER
• Cleanthemachineaftereachday'suse.
• Havethesawrepairedbyqualifiedservicepersonnel.
• Alwaystiedownthemachinewhentransporting.
SAFETY

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
9
Engine Type 2-strokesinglecylinderaircooled
Displacement 3.8cu-in(64cc)
Horsepower 4.2HP(3.1kW)@9,500rpm
Torque 32in-lbs(3.6Nm)
Engine Speed 10,000+/-200rpm
2,400-2,800rpmidle
Blade Speed Incut=4,500sfm
Noload=5,100sfm
Weight 23lbs.(10.4kg)withoutbladeand
26.8lbs.(12.2kg)withblade(14x.110)
Cut Depth Upto4.5inches(11.4cm)
Dimensions
25inches(63.5cm)length
16.125inches(41cm)height
8.125inches(20.6cm)width
Air Filter Paperfordrycutting
Polyester(optional)forwetcutting
Carburetor WalbroHDA207,throttleshaftsealed,
pressurecompensating
Starter Standard recoil
Ignition Specialwaterresistantelectronic
ignition
Clutch Three-weight,singlespring
Fuel ratio 25:1gasoline-to-oil
Fuel Capacity 24oz(0.7Liter)
15-18minutesruntimepertank
Water Supply Minimum20psi(1.5bar)
Noise Level 101dBat3ft(1m)
Vibration Level 9.2m/s2(fronthandle)
Engine Break-in Period Onetank,withoutcutting,cycling
throttle
Spark Plug ChampionCJ7Y,BoschBWS7F,or
NGKBPMR7A
TECHNICAL SPECIFICATIONS

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
10
• Insertflangestoptoolinthebeltcover,
rotatebladeflangesuntiltoolengages
beltpulley.
ASSEMBLING THE SAW
• Placeinnerflangeonthedriveshaft.
• Mountbladeinproperdirectionof
rotation.
• Insertflangestoptoolinthebeltcover
andtightenflangebolt18.4ft-lbs
(2.5Nm).
• Loosentheflangeboltandremovebolt
andbladeflanges.
• Checkbladearborholediameter.
SET UP
• Chooseappropriatesideoftheinner
flagetouseforyourblade.
• NOTE:Onesideoftheinnerflangeis
1inch(25.4mm)theotheris20mm.
INNER
FLANGE
OUTER
FLANGE
1 2
3 4

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
11
WATER KIT INSTALLATION
• Pressthefittingintotheholeson
oppositesidesofthebladeguard.
• Usesmallscrewstoretainfittings.
• Fastenthewatertubetofronthandle
withcableties.
• Makesurethebladeguardcanbe
adjustedbeforetighteningthecableties.
SET UP
• Assembleclamptothesparkguard.
1 2
3 4

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
12
ADJUST GUARD
• Loosenguardadjustmentknob. • Moveguardtoappropriateplace.
• Tightenguardadjustmentknob.
1 2
3

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
13
REVERSE ARM
• Removeguardadjustmentknoband
wavewasher.
• Removebeltcoverscrewsandbelt
cover.
• Removethreebladearmnuts.
• Removethethreeholetriangularplate.
• Removethebeltfrompulleyandblade
arm.
• Rotatebladearmtotherightand
remove spacer.
• Rotatebladearmleftandalignspacer
over nut clip.
• Makesurearmhole,spacerandnutclip
arealigned.
• Replacebladearmonreversesideand
pullbeltontopulley.
• Replacetriangularplateandnuts.
1 2
3 4
5 6

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
14
REVERSE ARM
• Tensionbelt. • Installbeltcoverandscrews.
• Installguardadjustmentknob.
BLADE ARM REVERSED
OUT OF BOX REVERSED
7 8

F/N 51873 Feb22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
15
FUELING
CAUTION
FUEL HANDLING
Always run this saw with a mixture of gasoline and
ICS®two-stroke engineoil.
GASOLINE OIL
US
Gallon
US
Floz
1 5.2
2 1/2 12.8
5 25.6
GASOLINE OIL
Liters ml
1 40
5 200
10 400
20 800
• Usepremiumunleadedgasolinewithaminimumoctaneratingof90.Ifloweroctanegasolineis
used,enginetemperaturewillincreasewhichcanresultinapistonseizureanddamagetothe
engine.
• Alwaysprovideadequateventilationwhenhandlingfuel.
• Usecautionwhenhandlinggasoline.Avoiddirectcontactwithskinorinhalingfuelvapor.
FUEL MIXING
• Alwaysmixgasolineandoilinacleancontainerintendedforusewithfuel.
• Keepfuelcontainerclosedtightlytopreventmoisturefromgettingintothefuel.
• Alwaysbeginmixingfuelbyaddinghalftheamountofgasolinetobeused.Thenaddthe
correctamountoftwo-strokeoilfor25:1mixtureandfinishfillingthecontainerwithgasoline.
• Donotmixmorethanonemonth’ssupplyoffuel.Thishelpspreventtheseparationofthe
two-strokeoilfromthegasoline(varnishing).
• Ifthesawisnotusedforanextendedperiodoftime(3months)thefueltankshouldbeemptied
and cleaned.
Fuel Cap
FUELING
• Alwaysshutoffthesawbeforefueling.
• Beforefueling,cleantheareaaroundfuelcaptoprevent
dirtfromcontaminatingthefuel.Contaminationofthe
fueltankcanleadtosawmalfunction.
• Thoroughlymixthefuelinit’scontainerbeforefueling.
• Slowlyopenthefuelcaptoreleaseanypressurethat
mayhavebuilt-upinthetank.
• Afteraddingfuel,tightenthefuelcapcarefullyand
securewithawrench.

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
16
CAUTION
OPER ATION
STARTING AND STOPPING THE SAW
Always move the saw at least 10 feet (3 m) away from the fueling
area before starting.
Place the saw on clear ground. Ensure that secure footing is
established and blade is not contacting any objects.
IMPORTANT
• Pullthechokeleverout.
A
B
• Lockthethrottleinthestartpositonbydepressing
andholdingthethrottlelockbuttonwhilereleasingthe
trigger(A)andtriggerinterlock(B)insuccession.
• Toggletheignitionswitchto"ON".
1
2
3

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
17
OPER ATION
• Pullthestarterropeuntilenginestarts–couldbeas
many as 5 to 7 pulls.
• Whentheenginestarts,releasethrottlefromstarting
position.
• Allowenginetoidleforatleastoneminute;squeeze
throttletriggerseveraltimesduringthisperiod.
• Pressdecompressionvalveonsubsequentstartups.
AS MANY AS
15 PULLS
• Placethesawonthegroundmakingsurethebladeis
freeofanyobstructions.
• Placerightfootonthebaseoftherearhandle.
• Placelefthandonthefronthandle.
• Withrighthand,slowlypullstarterhandleuntilthe
starterpawlsengage.
• Pullthestarterrope(hard, fast, short pulls)until
enginefires–couldbeasmanyas15pullsonvery
firststart-upofsaw.
• Aftertheenginefiresitwillbenecessarytopushthe
chokeleverin.
• Pushthedecompressionvalvein.
5 TO 7 PULLS
4
5
6
7

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
18
OPER ATION
PRE-CUT CHECKLIST
• Ensureproperbelttension.
• Ensurethebladeismountedcorrectly.
• Ensureallsafetydevicesareproperlymountedandfunctionalandthatallcontrolsareinproper
workingorder.
• Besuretherearenoobstructions(plumbing,electricalconduit,airducts).
• Alwayswearprotectiveclothing,includinghardhat,eyeprotection,hearingprotection,non-slip
safetyboots,gloves,andavoidwearingloosefittingclothing.
PLANNING THE CUT
• Outlinethecutwithapermanentmarkerforavisualcuttingguide.
• Avoidpinchingtheblade.Alwayscutthebottomofanopeningfirst,thentop,andthenthesides.
Savetheeasiestcutforlast.
• Forthestraightestcutsusethe“StepCut”method.Firstscoretheentirecutlineapproximatelya
half-inchdeep.Next,deepenthecutbyabouttwoinches.Thencompletethecut.
• Besurecutconcretecannotfallandinjureoperatororbystanders.Concreteisveryheavy,one
cubicfoot=12”x12”x12”=150lbs.(30cmx30cmx30cm=68kg).
WARM ENGINE STARTING PROCEDURE
Usethesameprocedureasstartingcoldengine,butDO NOT pull choke lever out.Ifchokeis
used,thecarburetorwillfloodwithgas.
Iftheenginedoesnotstartin3hard,fastpullswiththethrottlelocked,unlockthethrottleandpull
the starter cord 3 more times.

F/N 51873 Feb 22 © 2022 ICS, Oregon Tool Inc.
TITLEICS®RZ60C OPERATOR’S MANUAL
19
CUTTING WITH THE RZ60C CHOP SAW
Tostartacut,holdtriggeronfullthrottleandslowlyplungethebladestraightintothewall.
CUTTING TIPS
• Alwaysoperatethesawatfullthrottle.ApplyenoughfeedforcesothatthefreerunningRPM
drops20to30%.Iftoomuchforceisapplied,thesawwilllugorstall.Thebladewillnothave
enoughspeedtocuteffectively.Iftoolittlefeedforceisapplied,thediamondswillskidandglaze
over.
• Forstraightercutsusethe“stepcut”method.Firstscoretheentirecutlinewiththeblade
approximately1/2inch(12mm)to1inch(25mm)deep.Next,deepenthecutbyabout2inches
(50mm).Thisgroovewillhelpguidethebladeforastraightcut.Thencompletethecut.
• Plungecutinsteadofstartingatthetopofthewall.Thiswillreducechatter,extendbladelife,
createastraightercut.
• Whencuttingheavyrebar,movethebladeinandoutofthesteelsothatthebladeisalways
cuttingconcreteaswellassteel.Thiswillhelpkeepthediamondsexposed.Also,expectless
diamondbladelifewhencuttingheavyrebar.
OPER ATION

© 2022 ICS, Oregon Tool Inc. F/N 51873 Feb 22
TITLE ICS®RZ60C OPERATOR’S MANUAL
20
MAINTENANCE
Follow these simple maintenance guidelines
and your RZ60C Chop Saw will keep running at its very best.
• Removethecoverandprefilter.
• Cleanbyshakingpre-filtervigorously.
• Donotusecompressedair.
• Washpre-filterwithwarmsoapywater.
• Drythoroughly.
• Re-oilwithfoamfilteroil.
NOTE: Itisrecommendedtokeepspare
pre-filtersonhand.Regularexchangewill
prolongthelifeoftheprimaryairfilter.
AFTER EACH USE
FollowthedirectionsontheDailyMaintenanceLabel,
locatedontheairfiltercover.
• Cleanthesawwithwaterifcuttingwet
andwipeoff. • Blowoffthesawwithairifcuttingdry.
