ICS SB586TCP/166 User manual

Product Manual
MANUAL NO. 8705347
Revision F
SB586TCP/166
SB586TCP/150
SB586TCP/133
SB586TCP/120
SB586TCP/100
SB586TCP/90
9950 Barnes Canyon Road, San Diego, CA 92121 [phone] (FAX) 619-677-0895
INDUSTRIAL COMPUTER SOURCE EUROPE TEL [phone] FAX [phone]
INDUSTRIAL COMPUTER SOURCE (UK) LTD TEL [phone] FAX [phone]

This page intentionally left blank.

INDUSTRIAL COMPUTER SOURCE
GUARANTEE, LIMITED WARRANTY AND RETURN POLICY
* LIMITED WARRANTY: One year limited warranty on all products sold
with the exception of the "Performance Series" I/O products, which are war-
ranted to the original purchaser for as long as they own the product, subject
to all other conditions below, including those regarding neglect, misuse and
acts of God. Within one year of purchase, we will repair or replace, at our
option, any defective product sold by us. At any time after one year, we
will repair or replace, at our option, any defective "Performance Series" I/O
product sold by us. This does not include products damaged in shipment, or
damaged through customer neglect or misuse.
The Return Procedure below must be followed to assure repair or re-
placement. We will normally return your replacement or repaired item
via UPS Blue. Overnight delivery or delivery via other carriers is avail-
able at additional charge.
The limited warranty is void if the product has been subjected to altera-
tion, neglect, misuse, or abuse; if any repairs have been attempted by
anyone other than Industrial Computer Source or its authorized agent;
or if the failure is caused by accident, acts of God, or other causes
beyond the control of Industrial Computer Source or the manufacturer.
Neglect, misuse, and abuse shall include any installation, operation, or
maintenance of the product other than in accordance with the owners’
manual.
No agent, dealer, distributor, service company, or other party is
authorized to change, modify, or extend the terms of this Limited War-
ranty in any manner whatsoever. Industrial Computer Source reserves
the right to make changes or improvements in any product without in-
curring any obligation to similarly alter products previously purchased.
* GUARANTEE: Thirty day money-back guarantee on all standard
products sold. Special order products are covered by our Limited Warranty,
however they may not be returned for refund or credit.
REFUNDS: In order to receive a full refund of product purchase
price, the product must not have been damaged by the customer or by
the common carrier chosen by the customer to return the goods, and the
product must be returned complete (meaning all manuals, software,
cables, etc.) within 30 days of receipt and in as-new and resalable con-
TECHNICAL REFERENCE

dition. RETURN PROCEDURE below must be followed to assure
prompt refund.
RESTOCKING CHARGES: Product returns after 30 days, and
before 90 days, after purchase will be subject to a minimum 20% res-
tocking charge and any charges for damaged or missing parts.
Products not returned within 90 days of purchase, or products
which are not in as-new and resalable condition, are not eligible
for credit return and will be returned to the customer.
RETURN PROCEDURE: For any Limited Warranty or Guarantee return,
every product returned to Industrial Computer Source for service or credit
must be accompanied by a Return Material Authorization (RMA) Number,
obtained from Industrial Computer Source Customer Service, (800) 480-
0044, prior to its return. Freight on all returned items must be prepaid by
the customer and customer is responsible for any loss or damage caused by
common carrier in transit. Returns for warranty must include a failure
report for each unit by serial number, as well as a copy of the original in-
voice showing date of purchase.
To reduce risk of damage, returns of product must be in an Industrial
Computer Source shipping container. If the original container has been
lost or damaged, new shipping containers may be obtained from In-
dustrial Computer Source Customer Service at a nominal cost.
SHIPMENTS NOT IN COMPLIANCE WITH THIS GUARANTEE
AND LIMITED WARRANTY RETURN POLICY WILL NOT
BE ACCEPTED BY INDUSTRIAL COMPUTER SOURCE
LIMITATION OF LIABILITY: In no event shall Industrial Computer
Source be liable for any defect in hardware or software or loss or inade-
quacy of data of any kind, or for any direct, indirect, incidental, or conse-
quential damages in connection with or arising out of the performance or
use of any product furnished hereunder. Industrial Computer Source
liability shall in no event exceed the purchase price of the product pur-
chased hereunder. The foregoing limitation of liability shall be equally ap-
plicable to any service provided by Industrial Computer Source or its
authorized agent.
* Some sale items and custom systems are not subject to the
guarantee and limited warranty above, however in these instances
any deviations will be disclosed prior to sale and noted on the
original invoice. We reserve the right to refuse returns or refunds
on software or special order items.
TECHNICAL REFERENCE

FOREWORD
This instruction manual provides the necessary user information for the ref-
erenced product(s) manufactured or distributed by Industrial Computer
Source for the user to install, operate and/or program the product properly.
Please refer to the preceding pages for information regarding the warranty
and repair policies.
Technical assistance is available at [phone].
Manual Errors, Omissions and Bugs: A Bug Sheet is included as the last
page of this manual. Please use it if you find a problem with the manual
you believe should be corrected.
NOTICE
The information in this document is provided for reference only. Industrial
Computer Source does not assume any liability arising out of the applica-
tion or use of the information or products described herein. This document
may contain or reference information and products protected by copyrights
or patents and does not convey any license under the patent rights of In-
dustrial Computer Source, nor the rights of others.
Printed in the U.S.A. Copyright 1996 by Industrial Computer Source, a
California corporation, 9950 Barnes Canyon Road, San Diego, CA 92121.
All rights reserved.
TECHNICAL REFERENCE

TRADEMARKS
IBM, PC/AT, VGA, EGA, OS/2 and PS/2 are trademarks of
International Business Machines Corp.
AMI, AMIBIOS and WinBIOS are trademarks of American
Megatrends Inc.
Intel, 486, 386, DX and SX are trademarks of Intel Corporation.
Pentium is a registered trademark of Intel Corporation.
MS-DOS and Microsoft are trademarks of Microsoft Corp.
PICMG and the PICMG logo are trademarks of the PCI Industrial
Computers Manufacturers Group.
SCSI-2 is a trademark of Symbios Logic.
All other brand and product names are trademarks or registered
trademarks of their respective companies.
LIABILITY DISCLAIMER
This manual is as complete and factual as possible at the time of
printing; however, the information in this manual may have been up-
dated since that time. Industrial Computer Source reserves the right
to change the functions, features, or specifications of their products
at any time, without notice.
TECHNICAL REFERENCE

TABLE OF CONTENTS
Specifications . . . . . . . . . . . . . . . . . .1-1
Model Numbers . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . 1-1
Processor Block Diagram . . . . . 1-3
Processor Board Layout . . . . . . . 1-4
Processor . . . . . . . . . . . . . . . 1-5
CPU Clock . . . . . . . . . . . . . . 1-5
Bus Speed . . . . . . . . . . . . . . . 1-5
On-Board Features . . . . . . . . . . 1-5
RAM Memory . . . . . . . . . . . . 1-6
ROM Memory . . . . . . . . . . . . 1-6
Performance . . . . . . . . . . . . . 1-7
Power Requirements . . . . . . . . . 1-7
Environment . . . . . . . . . . . . . 1-7
Configuration Jumpers . . . . . . . . 1-8
System BIOS . . . . . . . . . . . . 1-10
Watchdog Timer . . . . . . . . . 1-10
Connectors . . . . . . . . . . . . . 1-12
ISA/PCI Reference . . . . . . . . . . . . . . . .2-1
ISA Bus . . . . . . . . . . . . . . . . 2-1
I/O Address Map . . . . . . . . . . 2-8
Interrupt Assignments . . . . . . . . 2-8
PCI Local Bus . . . . . . . . . . . . 2-9
System BIOS . . . . . . . . . . . . . . . . . .3-1
BIOS Operation . . . . . . . . . . 3-1
Password Entry . . . . . . . . . 3-3
BIOS Errors . . . . . . . . . . 3-5
Running WinBIOS Setup . . . . . 3-7
TECHNICAL REFERENCE

TABLE OF CONTENTS
System BIOS (continued)
Utility Functions . . . . . . . . . . . 3-15
Security Functions . . . . . . . . . 3-17
Default Settings . . . . . . . . . . . 3-21
Key Conventions . . . . . . . . . 3-23
Mouse Conventions . . . . . . . . . 3-24
Standard Setup/Drive Types . . . . . . . . . 4-1
Advanced Setup . . . . . . . . . . . . . . . . . 5-1
Advanced Setup . . . . . . . . . . . .5-1
Chipset Setup . . . . . . . . . . . . 5-13
Power Management Setup . . . . . . . . . . . 6-1
Peripheral Setup . . . . . . . . . . . . . . . . . 7-1
Appendix A - BIOS Messages . . . . . . . . . A-1
Appendix B - SCSI Driver License Agreement B-1
CE Declaration of Conformity
TECHNICAL REFERENCE

INTRODUCTION
The SB586TCP full-featured ISA/PCI processors are single board
computers which feature PentiumCPU, DRAM, PCI Local Bus,
cache, floppy controller, EIDE interface, PCI SCSI controller, two
serial ports, parallel port, speaker port and keyboard port on a single
ISA card. These single-slot, high performance processors plug into
ISA Bus passive backplanes and PICMG ISA/PCI passive back-
planes and provide 100% PC compatibility for the system expansion
slots.
MODEL NUMBERS
SB586TCP/166 Pentium CPU at 166MHz
SB586TCP/150 Pentium CPU at 150MHz
SB586TCP/133 Pentium CPU at 133MHz
SB586TCP/120 Pentium CPU at 120MHz
SB586TCP/100 Pentium CPU at 100MHz
SB586TCP/90 Pentium CPU at 90MHz
FEATURES
•Pentium microprocessor at 166MHz, 150MHz, 133MHz,
120MHz, 100MHz or 90MHz
•256KB write-back cache memory, 64 bits wide with burst
read and write
•PCI Local Bus supports off-board PCI option cards and
on-board PCI SCSI controller - Symbios Logic 53C810
•Compatible with PCI Industrial Computer Manufacturers
Group (PICMG) 2.0 Specification
•Supports up to 256MB of DRAM on-board
•Two serial ports and one parallel port
•Floppy drive and EIDE drive interface
SPECIFICATIONS
TECHNICAL REFERENCE 1-1

FEATURES (continued)
•Automatic or manual peripheral configuration
•Watchdog timer
•On-board 3.3V regulator
•Supports 256K x 36, 512K x 36, 1M x 36, 2M x 36,
4M x 36, 8M x 36 and 16M x 36 SIMM’s
•Shadow RAM for System BIOS and peripherals increases
system speed and performance
•Full PC compatibility
•Intel Neptune chip set
SPECIFICATIONS
1-2 TECHNICAL REFERENCE

SPECIFICATIONS
TECHNICAL REFERENCE 1-3

P2 Keylock
P4 KeyboardP5 Speaker
JU82 Watchdog
JU81 Password Clear JU80 CRT Type
P10 Reset
P3-Floppy
P12-Hard Drive LED
P11-IDE
BIOS
P8
Parallel
P6
Serial 1
P7-Serial 2
Timer
JU101-Serial 2 Int JU100-Serial 1 Int JU102-Parallel Int
Processor PCI Local Bus ISA Bus
P13 PCI SCSI
Cache
1 0 SIMM Bank Extension
1.1
P5A Combo IO
JU104
JU103
JU90-
IOCHRDY
JU83-
CMOS Clear
JU84
JU85
Pentium
CPU
P9 CPU Fan
SPECIFICATIONS
1-4 TECHNICAL REFERENCE

PROCESSOR
•Pentium at 166MHz, 150MHz, 133MHz, 120MHz, 100MHz
or 90MHz operation
CPU CLOCK
•166MHz, 150MHz, 133MHz, 120MHz, 100MHz or 90MHz
BUS SPEED
•8.33MHz for 166MHz, 133MHz or 100MHz
•7.5MHz for 150MHz, 120MHz or 90MHz
ON-BOARD FEATURES
•Speaker port
•Keyboard port
•Keylock port
•Floppy disk controller supports two floppy drives. Drives
can be 3-1/2" or 5-1/4" or one of each.
•Two serial ports
•Parallel printer port - bidirectional
•EIDE interface supports two integrated drive electronics
hard drives. Supports drives larger than 528MB.
•On-board 3.3V regulator
•PCI SCSI controller, which is a Symbios Logic 53C810 on
the PCI Local Bus, is a fast SCSI-2 implementation support-
ing asynchronous and synchronous transfers with single-
ended drivers and passive termination. Software drivers for
most major PC operating systems are provided.
SPECIFICATIONS
TECHNICAL REFERENCE 1-5

RAM MEMORY - 2 MB to 256 MB
Processor Board RAM Memory:
•The RAM memory array consists of two banks of 72-pin
SIMM sockets. Bank 0 consists of sockets 1 and 2 (U52 &
U53); bank 1 consists of sockets 3 and 4 (U62 & U63).
•Supported SIMM’s are:
•256K x 36
•512K x 36
•1M x 36
•2M x 36
•4M x 36
•8M x 36
•16M x 36
NOTE: Two SIMM’s of the same memory capacity must be used to
fill a memory bank. All SIMM’s must have gold contacts.
•RAM Speed
•< 70 nanoseconds fast page mode
ROM MEMORY
•BIOS ROM memory on the processor board is 1 27C010
(128K x 8)
SPECIFICATIONS
1-6 TECHNICAL REFERENCE

PERFORMANCE
•Norton SI Version 8.0
•166MHz - 523
•150MHz - 476
•133MHz - 419
•120MHz - 380
•100MHz - 316
•90MHz - 288
POWER REQUIREMENTS
Voltage:
+5V @ 3.7 Amps typical
+12V @ < 100 mAmps typical
-12V @ < 100 mAmps typical
ENVIRONMENT
Operating Temperature: 0°C to 60°C.
Storage Temperature: - 40°C to 70°C.
HumidityMaximum: 90% non-condensing
SPECIFICATIONS
TECHNICAL REFERENCE 1-7

CONFIGURATION JUMPERS
The setup of the configuration jumpers on the processor is described
below. * indicates the default value of each jumper.
NOTE: For two-position jumpers (3-post), "RIGHT" is toward the
bracket end of the board; "LEFT" is toward the memory sockets.
Jumper Description
JU80 CRT Type Select
Install on the TOP for a color CRT. *
Install on the BOTTOM for a monochrome CRT.
JU81 Password Clear
Install for one power-up cycle to reset the password to
the default (null password).
Remove for normal operation. *
JU82 Watchdog Timer
Install on the LEFT for normal reset operation. *
Install on the RIGHT to enable watchdog timer
operation.
JU83 CMOS Clear
Install to clear.
Remove to operate. *
JU84 P5A Speaker Connect
Install to connect speaker data signal to pin 8 of the
Combo IO connector (P5A). *
Remove to disconnect.
SPECIFICATIONS
1-8 TECHNICAL REFERENCE

CONFIGURATION JUMPERS (continued)
Jumper Description
JU85 P5A Reset Connect
Install to connect reset data signal to pin 1 of the
Combo IO connector (P5A). *
Remove to disconnect.
JU90 IDE IOCHRDY
Install to connect the IOCHRDY signal to the IDE
drive connector. *
Remove to disconnect the IOCHRDY signal from
the IDE drive connector.
JU100 On-Board Serial Port 1 Interrupt Select
Install on the LEFT for IRQ3.
Install on the RIGHT for IRQ4. *
JU101 On-Board Serial Port 2 Interrupt Select
Install on the LEFT for IRQ3. *
Install on the RIGHT for IRQ4.
JU102 On-Board Parallel Port 1 Interrupt Select
Install on the LEFT for IRQ7. *
Install on the RIGHT for IRQ5.
JU103 Parallel Port DACK Pins
DACK #7 1-2
DACK #6 3-4
DACK #5 5-6
DACK #3 7-8
SPECIFICATIONS
TECHNICAL REFERENCE 1-9

CONFIGURATION JUMPERS (continued)
Jumper Description
JU104 Parallel Port DREQ Pins
DREQ #7 1-2
DREQ #6 3-4
DREQ #5 5-6
DREQ #3 7-8
SYSTEM BIOS
The System BIOS is an AMI WinBIOS with ROM-resident setup
utilities. The main WinBIOS Setup screen displays four windows
which contain selectable Setup options. These windows are:
•Setup
•Utility
•Security
•Default
WATCHDOG TIMER
The watchdog timer is a hardware timer which resets the processor
board if the timer is not refreshed by software periodically. The
timer is typically used to restart an application which becomes hung
on an external event. When the application is hung, it can no longer
refresh the timer. The watchdog timer then times out and resets the
processor board.
The watchdog timer has two levels of enable. First, the watchdog
timer jumper must be moved to the "enabled" position, which puts
the watchdog timer under software control. Second, user-supplied
software must start the watchdog timer via Keyboard Controller
SPECIFICATIONS
1-10 TECHNICAL REFERENCE

(8042) Port 2, bit 3 (P23). P23 is set high from reset. Setting P23
low starts the watchdog timer timeout of 1.2 seconds (nominal).
Before the end of the timeout , P23 must be toggled high then low to
restart the timeout. If P23 is left low until the end of the timeout, the
watchdog timer issues a hardware reset to the processor board. The
timer should be refreshed by the software every 1.0 seconds to
prevent a timeout.
A set of watchdog timer software is available from Technical Sup-
port. The software includes sample C code which can be embedded
in a user program and demo software to demonstrate and test the
watchdog timer.
SPECIFICATIONS
TECHNICAL REFERENCE 1-11

CONNECTORS
NOTE: Pin 1 on the connectors is indicated by the square pad on
the PCB.
P2 - Keylock Connector
5 pin single row header, Amp #640456-5
PIN SIGNAL
1 LED Power
2 Key
3 Gnd
4 Keylock Data
5 Gnd
P3 - Floppy Drive Connector
34 pin dual row header, Molex #10-89-1341
PIN SIGNAL PIN SIGNAL
1 Gnd 2 N-RPM
3 Gnd 4 NC
5 Gnd 6 NC
7 Gnd 8 P-Index
9 Gnd 10 N-Motoron 1
11 Gnd 12 N-Drive Sel2
13 Gnd 14 N-Drive Sel1
15 Gnd 16 N-Motoron 2
17 Gnd 18 N-Dir
19 Gnd 20 N-Stop Step
21 Gnd 22 N-Write Data
23 Gnd 24 N-Write Gate
25 Gnd 26 P-Track 0
27 Gnd 28 P-Write Protect
29 Gnd 30 N-Read Data
31 Gnd 32 N-Side Select
33 Gnd 34 Disk Chng
SPECIFICATIONS
1-12 TECHNICAL REFERENCE
