ICT ICT240DB-8IRC User manual

Innovative Circuit
Technology Ltd.
Front Access Distribution
Panel Series
INSTRUCTION MANUAL
855-154-000
Model: ICT240DB-8IRC

2Innovative Circuit Technology Ltd.
WARNING
Risk of serious personal injury or damage to equipment and property! Always
observe the following:
Use an appropriately rated over-current protection device in line with the
main battery connections to the panel
Use an appropriately rated disconnect switch or circuit breaker in line with
the dc inputs to enable installation and service of the panel with the dc
source disconnected
Shut off or disconnect all dc power sources before connecting or
disconnecting wiring
Use wire and connectors rated for the maximum load current and size of
fuse or circuit breaker, and keep cable lengths as short as practical
Carefully observe wiring polarity when making input and output connections
Securely tighten all connections
Do not attempt to service any internal parts. Refer all product service to an
authorized ICT Ltd. service facility
CAUTION
Risk of personal injury or damage to equipment! Always observe the following:
Install unit in a restricted access location (such as an equipment rack) to limit
unintentional contact with terminals and wiring
Ensure the total power consumption of the loads does not exceed the 100A
(continuous) rated capacity of each power bus
Ensure load current through each output channel does not exceed 30A max,
25A continuous
Do not block air inlet or outlet openings in the panel sides and back

Innovative Circuit Technology Ltd. 3
Contents
PRODUCT DESCRIPTION .......................................................................4
INSTALLATION .....................................................................................5
OPERATION .........................................................................................9
Status Indicators and Alarms ......................................................9
TCP/IP WEB BASED INTERFACE........................................................... 10
Status and Control...................................................................... 11
Device Setup ............................................................................... 12
Bus Setup..................................................................................... 15
Output Setup............................................................................... 16
Network setup ............................................................................ 18
E-mail Setup................................................................................ 20
Alarm setup................................................................................. 22
User Setup................................................................................... 23
Maintenance................................................................................ 24
MOBILE WEB INTERFACE.................................................................... 24
PASSWORD RESET.............................................................................. 25
ROUTER CONFIGURATION.................................................................. 26
TEXT MESSAGE ALARM NOTIFICATIONS.............................................. 28
TROUBLESHOOTING........................................................................... 28
PRODUCT SPECIFICATIONS ................................................................. 30
LIMITED WARRANTY .......................................................................... 32

4Innovative Circuit Technology Ltd.
PRODUCT DESCRIPTION
The ICT Front Access Dual Bus Distribution Panel provides two 100A (continuous)
bus inputs with four independently controlled and monitored output channels
per bus in a compact 1U high chassis for 19 inch rack mounting. All connections
are located on the front panel for simple installation in tight cabinets, and over
current protection and manual on/off control for each output is provided by
65VDC user replaceable magnetic-hydraulic circuit breakers.
Each bus can accommodate a wide supply voltage from 10VDC to 60VDC, either
positive or negative polarity, with a peak input current of 120A to be distributed
at up to 30A peak on each of the 4 output channels. Each channel has
independent current sensing, over current protection, alarms, and output on/off
control.
Remote monitoring and control is available through the integrated security
protected Ethernet communications port on the front panel. The unit has a built-
in web server with an embedded web-based graphical user interface (GUI) that
can be accessed using any standard commercial web browser, such as Internet
Explorer or Google Chrome. The web server displays all panel information, allows
full access to channel configuration settings, provides remote channel on/off
control, and can be set up to send an alarm to user-defined email accounts in the
event a fault occurs. The web server can also be used to configure and down-
load a data log of up to 30 days of time stamped event information. Full
monitoring and control is also available using an SNMP (v2) based management
system for larger installations.
Form-C alarm output contacts (C/NO/NC) are provided for each bus to indicate
all distribution panel alarms, while 4 additional alarm inputs can be used to
monitor other dry-contact site sensors such as door/window opening, smoke
alarms, and water detectors etc. An optional remote temperature sensor (ICT-
TMP) can also be connected for remote monitoring of a battery pack or another
important temperature.
Model Numbers: (covered in this manual)
ICT240DB-8IRC Intelligent Dual 120A Bus Distribution Panel for +/-12, 24 or
48VDC Systems

Innovative Circuit Technology Ltd. 5
INSTALLATION
Inspect your distribution panel to ensure it was not damaged in shipping, and has
all accessories:
2 clear snap on covers to insulate main dc power connections (shipped
on unit)
4 clear snap on covers for the 4 position output terminal blocks (shipped
on unit)
2 seven pin alarm output, remote sensor input connector plugs (shipped
on unit)
Circuit Breaker label sheet (apply output number label below each
breaker rocker once breakers installed)
This Instruction Manual
To complete the installation you will also need to order circuit breakers
appropriately sized for your requirements, and blanking plugs for any un-used
positions. Order these separately from ICT per the following list:
Breakers:
ICT Model
Rating (65VDC)
Mfg. Part Number
ICT-CB5
5A
Carling MA1-B-14-450-1-A26-2-J
ICT-CB15
15A
Carling MA1-B-14-615-1-A26-2-J
ICT-CB25
25A
Carling MA1-B-14-625-1-A26-2-J
ICT-BLP
Blanking Plug
CBI “B” series rocker handle circuit breakers with 0.25” tab terminals and current
ratings up to 25A may also be used, consult ICT for suitable part numbers.
CAUTION
Risk of personal injury or damage to equipment! Always observe the following:
Install unit in a restricted access location (such as an equipment rack) to limit
unintentional contact with terminals and wiring
Ensure the total power consumption of the loads does not exceed the 100A
(continuous) rated capacity of each power bus
Channel output breakers must not exceed 30A max rating
Install only 65VDC rated breakers
Do not block air inlet or outlet openings in the panel sides and back

6Innovative Circuit Technology Ltd.
Figure 1: Front Panel Connections
Mount the Front Access Distribution Panel in a 19 inch equipment rack, using
standard rack mounting hardware. (Not provided)
Install appropriately rated circuit breakers in desired channel locations by
carefully inserting a breaker so that its mounting tabs securely snap into the
front panel (with “I/on”marking up). Install the breaker blanking plugs in any
unused locations. Breakers and plugs may be removed by using two small
screwdrivers or similar tools to press in the top and bottom mounting tabs
through the cover openings and gently prying out of the panel.
Label the output channel number of each breaker by applying one of the
supplied labels (A1 to A4, B1 to B4) below each breaker rocker.
WARNING
Risk of serious personal injury or damage to equipment and property! Always
observe the following:
Use an appropriately rated over-current protection device in line with the
main battery connections to the panel
Use an appropriately rated disconnect switch or circuit breaker in line with
the dc inputs to enable installation and service of the panel with the dc
source disconnected
Shut off or disconnect all dc power sources before connecting or
disconnecting wiring
Use wire and connectors rated for the maximum load current and size of
fuse or circuit breaker, and keep cable lengths as short as practical
Carefully observe wiring polarity when making input and output connections
Securely tighten all connections
Bus B Output
Breakers 1-4
Bus B Outputs
Channel 1-4
Bus B Return
(Common)
Bus A Return
(Common)
Site Alarm inputs
1-4, Temp Sense
Bus A, Bus B
Alarm out
C/NC/NO
LAN Port
10/100 Base-T
Bus A Output
Breakers 1-4
Bus A Outputs
Channel 1-4
Bus A Input
(100A cont)
Bus B Input
(100A cont)
Reset button
(recessed)

Innovative Circuit Technology Ltd. 7
Bond the panel chassis to the rack system ground, connecting a ground wire with
ring tongue to the front panel ground stud. (1/4-20 thread)
Connect Bus A loads to output channels A1 to A4 using suitably rated wire sized
for the breaker installed on the channel, with crimped on spade lug terminals
compatible with the output terminal block screws. Note which load is connected
to each channel, for future reference.
Repeat for the Bus B loads if required. The unit may be operated with either Bus
A or Bus B powered, or both.
NOTE!
All channel RTN lines, and the main high power Bus A and Bus B RTN terminals
are common, and tied to a single internal Return bus. Bus A and Bus B inputs can
be wired to a different dc voltage (10 to 60Vdc) of either polarity, but must share
a common RTN voltage, normally at earth potential.
Connect the main Bus A RTN line to the external battery or power supply return
using suitably sized wire and dual hole lug connector rated for up to 100A
continuous current. Connect the lug to the dual ¼-20 thread Bus A Rtn studs, and
then securely fasten with the supplied hardware.
Connect the Bus A Input through a suitably rated disconnect switch (set in the
open position) with a fuse or circuit breaker rated for 100A max continuous
operation to the external battery or power supply output, using suitably sized
wire and a dual-hole Lug connector rated for 100A continuous current. Connect
the Input lug to the dual ¼-20 thread Bus A Input studs, then securely fasten with
the supplied hardware. Snap the clear cover on to the Bus A input connector to
help prevent accidental contact with the input stud connections.
Repeat input wiring for the Bus B input, its power source and over current
protection device, if the Bus B outputs are to be used. Bus A and Bus B Input and
output Return lines are internally connected together, so will share a common
ground. The Bus A and Bus B Input terminals are isolated, and support operation
from separate + or –10 to 60V power sources, as long as they share a common
Return potential.
Connect the two form-C relay bus alarm outputs to an external monitoring
system if needed, by stripping and terminating 16-28AWG alarm wiring in the
Alarm 7-pin connector plug (lower), and installing in the front panel. Each Bus
Alarm output will trigger for any breaker open, or other alarm related to any
channel on that bus (Factory Default). Most alarm conditions can be masked off
so that they will not trigger the Alarm output if required, using the web based
graphical interface.

8Innovative Circuit Technology Ltd.
Bus Alarm Connector: (Lower connector plug)
Pin (L-R)
Alarm Function
1
Bus A - Alarm Output common
(0.5A 65Vdc max)
2
Bus A - Alarm Output normally
closed for alarm condition (NC)
3
Bus A - Alarm Output normally
open for alarm condition (NO)
4
No connection
5
Bus B - Alarm Output common
(0.5A 65Vdc max)
6
Bus B - Alarm Output normally
closed for alarm condition (NC)
7
Bus B - Alarm Output normally
open for alarm condition (NO)
Connect up to 4 dry contact type site sensors (such as door/window sensors,
smoke alarm, water detectors etc.) by stripping and terminating 16-28AWG
alarm wiring and connecting to the four Site Alarm Inputs on the 7 pin removable
Site Monitor Plug (upper), if desired. These inputs may be configured to activate
the panel Alarm outputs, or send an alarm e-mail on network connected units.
The external sensor contacts must be voltage free; as a small sense current is
supplied from the panel Alarm Input pins to detect the external contact open or
closed state. Refer to the Web Based Interface section for information on how to
configure and use the four Site Alarm inputs.
Connect an optional ICT external temperature sensor (ICT-TMP) to the two TMP
inputs if you need to remotely monitor the temperature of a battery pack or
enclosure.
Site Monitor Inputs: (Upper connector plug)
Pin (L-R)
Site Monitor Input Function
1
Contact Input 1
2
Contact Input 2
3
Contact Input 3
4
Contact Input 4
5
Monitor Return (common for
4 monitor inputs)
6
Remote Temperature Sense
7
Remote Temperature Sense

Innovative Circuit Technology Ltd. 9
Connect a standard 10/100 Base-T Ethernet cable to the RJ-45 LAN port on the
front panel to remotely monitor, control and reconfigure the panel settings from
a remote computer.
OPERATION
Ensure the correct circuit breakers are installed in each channel location that will
be used to power a load.
Energise each bus by closing the main external breaker or disconnect device on
the bus input lines. Switch on the front panel channel breakers for all connected
outputs, and check that the internal channel relays have closed by verifying that
the connected loads are energised. (Note that all output channels on a bus will
be disabled and network communication will be dropped if the bus voltage drops
below approximately 6V for more than 3s. Normal operation will be restored
once the bus voltage is above 8V)
Switch off any unused internal channel relays to reduce the power consumed by
the panel, using a networked computer and Web Browser. See the TCP/IP Web
Based Utility section, Output On/Off Buttons. (Each channel relay consumes
approximately 2W when closed; the factory default setting is for all outputs to be
on)
Status Indicators and Alarms
The Form-C Bus Alarm contacts are used to indicate an alarm condition.
Alarm
Trigger Condition
Channel Output
Bus Alarm
Contact
Breaker Off
Breaker opens or is
removed
Off
On
Bus Under-
voltage
Bus V drops below UV
threshold
No change1
On
Bus Over-
voltage
Bus V rises above the
OV threshold
No change
On
Bus Over-
current
Bus current exceeds
the OC threshold
(default 100A)
No change
On
Output Over-
current
Channel output current
exceeds OC threshold
Off2
On
No power to
Unit
Loss of bus input power
source
Off
On
1
All channel relays will be open if Bus Voltage is <6V, and recover for Bus Voltage >8V
2
The channel may be user configured to disable the output for an Over-current Alarm

10 Innovative Circuit Technology Ltd.
Alarm
Trigger Condition
Channel Output
Bus Alarm
Contact
Site Alarm
Input
Alarm contact on input
1 to 4
No change
On3
Remote Temp
Alarm
Adjustable over or
under temperature
threshold hit
No change
On3
The unit may also be configured to send an alarm e-mail to multiple user set e-
mail addresses for any of the alarm conditions, by enabling the e-mail function
on each alarm setup page on the web based interface. (no e-mail will be sent
when power is disconnected from the unit, due to loss of network control)
TCP/IP WEB BASED INTERFACE
These panels are equipped with a built in web server and Graphical User
Interface (GUI) to enable full remote monitoring and control using any standard
web browser, such as Microsoft Explorer, Google Chrome, or Mozilla Firefox. To
connect with your networked panel, do the following:
1. Start Your Browser.
2. Enter the IP address of the panel in the address field of your browser as
shown.
Typically your panel will be connected to a network with a DHCP server,
and will be assigned an IP address automatically. To find the current
address of your panel run the ICT IP Address Discovery tool, after
installing it on your Windows computer (tool available for download
from ICT http://www.ictcorporate.com/resources/tools/ ) otherwise the
panel will use the factory default IP address of 192.168.0.180, as shown
above.
3. Enter your user name and password. The default Administrator user
name is admin, with no password.
3
Use the web interface to configure each alarm input to trigger either Bus A, B or both
alarm contacts

Innovative Circuit Technology Ltd. 11
Once your browser is connected to the unit, the Status and Control page for the
panel will be displayed, as shown. See the following section for descriptions on
how to use the various monitoring, configuration, and control features available
through the panel’s graphical web interface.
Click on any one of the blue buttons in the menu bar on the left side of the
screen to select the desired page.
To log out of the ICT panel GUI close your browser session.
Status and Control
This page provides information on the voltage, current, and alarm status for each
bus, along with the status of each channel output and the current being provided

12 Innovative Circuit Technology Ltd.
to each load. Each bus, or an individual output may be manually enabled or
disabled by using the on screen buttons.
The status of any of the four Input Alarms that have been enabled (see Alarm
Setup page) will be shown in the Alarm Input box. A grey Alarm Input indicator
box shows that the sensor input is ready; a red box indicates that that external
sensor is in an alarm condition.
The Remote Temperature (in °C) of the optional ICT-TMP probe will be shown in
the top right corner, if a probe is installed.
Enable Bus Button: This button will close the four channel relays on that bus,
applying power to the external loads. The outputs will be enabled in a timed
sequence if the power-on sequencing is enabled on the Device Setup page.
Disable Bus Button: This button will open the four channel relays on that bus,
cutting power to the loads.
Output On/Off Buttons: Each button will toggle the internal relay for that
channel, enabling or disabling the power to the load on that output. The status of
each output channel is shown with a red (Disabled) or green (Enabled) bar next
to the ON/OFF button, along with an ammeter indicating the current through
that channel.
Device Setup
Use this page to configure the panel settings. Click on the Save Settings button
when finished to save and implement all new changes.
Device Info
Site Name: Enter a custom descriptive name for the panel
Model: Displays the ICT model number for the panel
Hardware: Displays the hardware version of the panel
Date and Time Settings
Current System Time: Displays the date and time used in the panel’s internal
clock for time stamping data entries in the data logs. This clock may be set
manually, or synchronized with a remote NTP Time Server over the Internet
(recommended).
Synchronize with NTP Server: Check this box to select automatic time
synchronization with the external server (recommended).
NTP Server: Enter the name or IP address of the NTP Server used for date
and time synchronization, such as “pool.ntp.org”.

Innovative Circuit Technology Ltd. 13
Time Zone: Select the appropriate time zone relative to GMT for your unit so
that the NTP server time can be converted to your local time zone. (e.g.:
Pacific Standard Time is GMT-8)
Set Time Manually: Checking this box will allow the unit’s clock and calendar
to be set manually by entering date and time in MM/DD/YY and HH:MM:SS
format.
Power-On Sequencing/Cycling
Sequence/Cycle Delay: Entering a time delay in this field (0-60s) will cause
the outputs on each bus to be enabled in sequence (1 to 4) with the set
delay time between each step, when the Enable Bus button for that bus is
pressed on the Status and Control page. This helps reduce the turn-on surge
that can occur when all connected loads are energized simultaneously.
Setting this time to 0 or leaving the box blank will cause all outputs to always
be enabled simultaneously. (Factory default)
Note the Sequence Delay time will also be used as the Power Cycling time
delay for each output that has the Power Cycling feature enabled on the
Output Setup page.

14 Innovative Circuit Technology Ltd.
Reverse Sequence Order: Checking this box will cause the power on
sequence to run in reverse order with output channel 4 on first, ending with
output 1, when the Enable Bus button is clicked on the Status and Control
page.
Network Watchdog:
Watchdog Enabled: Checking this box will enable the watchdog feature,
which will cause the unit to periodically ping up to two remote IP addresses
to verify the network connection status. If there is no response from either
address the unit will cycle the power on all outputs that have the Power
Cycling option enabled on the Output Setup page. This feature is useful for
re-booting a modem or other network device that is powered by one of the
distribution panel outputs, to help recover the network IP connection when
one of these devices has locked up. At least one channel must have the
Power Cycle option enabled, and a delay time entered in the
Sequence/Cycle Delay field for this function to work. Power for a cycled
channel will be held in the off state for the duration set by the
Sequence/Cycle delay time, then will be turned back on.
Primary IP Address: Enter the remote IP address you would like the panel to
monitor. If left blank the unit will monitor the Gateway IP address listed in
the Network Setup page.
Secondary IP Address: Enter an optional second IP address that the unit can
monitor to verify network status. The Network Watchdog will only trigger if
both the Primary and Secondary IP addresses fail to respond.
Watchdog Timeout: Enter the time (1 to 80 minutes) for which the remote
IP address must stop responding to ping requests from the panel, before the
Network Watchdog will trigger an output power cycle. Ensure this time is
greater than the normal start-up time for the network hardware to prevent
nuisance power cycle events at system start up.
Data Logging:
Data Logging rate: Enable this feature by selecting the sample rate. The data
logger will record the bus voltage, bus current, channel output currents,
breaker status, and alarm inputs at a rate of up to 1 sample per minute. View
this Comma Separated Values (CSV) format log by clicking the Download Log
button, and open in any Spreadsheet software, such as Microsoft Excel. The
log will store up to 30days of data, with the oldest entries at the top of the
file, newest at the bottom.
Log Start Date: Shows the date/time the most recent log began.

Innovative Circuit Technology Ltd. 15
Clear Log Now: Checking this box will cause the current log file to be cleared,
and a new logging sequence to begin.
Bus Setup
Use this page to configure each bus. Select Bus A, or Bus B in the Select a Bus to
Edit box to call up the settings for that bus. Click on the Save Settings button at
the bottom of the page to save any changes you make.
Bus A/B Settings:
Bus Name: Enter a descriptive name for the selected bus if desired
Bus A/B Under Voltage Alarm:
Under-Voltage Threshold: Enter the bus under voltage value. Bus voltage
dropping below this level will trigger a Bus Under-Voltage alarm.
Under-Voltage Recovery: Enter the bus voltage required to reset the alarm.
Bus voltage rising above this level will clear the alarm.
Activate Form-C Contact: Checking this box will cause the Alarm relay to
trigger for an under voltage condition. (default)
Send E-mail: Checking this box will cause the unit to send a Bus Under-
Voltage alarm e-mail to the assigned address entered on the E-mail Setup
page.
Bus A/B Over Voltage Alarm:
Over-Voltage Threshold: Enter the bus over-voltage value. Bus voltage rising
above this level will trigger a Bus Over Voltage alarm.
Activate Form-C Contact: Checking this box will cause the Alarm relay to
trigger for an over voltage condition. (default)
Send E-mail: Checking this box will cause the unit to send a Bus Over-Voltage
alarm e-mail to the assigned address entered on the E-mail Setup page.
Bus A/B Over-Current Alarm:
Over-Current Threshold: Enter the maximum total current level for the bus.
Current exceeding this level will trigger the Over-Current alarm.
Activate Form-C Contact: Checking this box will cause the Alarm relay to
trigger for an over-current condition. (default)
Send E-mail: Checking this box will cause the unit to send a Bus Over-Current
alarm e-mail to the assigned address entered on the E-mail Setup page

16 Innovative Circuit Technology Ltd.
Output Setup
Use this page to configure the settings for each output channel on Bus A and Bus
B. Select the output to be edited in the Select an Output to Edit box. Make any
required changes, and then click on the Save Settings button at the bottom of
the page to save any edits. Click on the Copy Settings to All button, to copy the
settings of the selected output to all other outputs on both buses.
Output Settings:
Output Label: Enter a descriptive label for the selected output channel if
desired.
Output State After Panel Reset: Sets the state for the output after an input
power failure, or soft reset of the panel. Select one of the following:
Restore last State: Will return the output contactor to the state
prior to the reset event (default)
Enable Output: Will enable the output contactor, regardless of
its previous state
Disable Output: Will disable the output contactor, regardless of
its previous state
Ignore Circuit Breaker Status: Will mask the circuit breaker open circuit
detection, to prevent false alarms on unused channels.
Enable Power Cycling: Check this box to enable output power cycling for the
selected output, so that the output will automatically be re-enabled after
the Sequence/Cycle Delay time whenever the output is disabled using the
Output Off button on the Status and Control page, or when the Network
Watchdog is triggered. This feature is useful for remotely resetting power to
hardware required for the network connectivity of the panel.
The Sequence/Cycle Delay time must be set on the Device Setup page with
duration long enough for the connected network hardware to fully reset for
this function to be effective. Multiple outputs that are disabled using Power
Cycling will be re-enabled in sequence.

Innovative Circuit Technology Ltd. 17
Output Load Shedding:
Enable Load Shedding: Check this box to disable this output when the bus
voltage drops below the load-shedding threshold for at least 30s. This
feature can be used to disconnect less critical loads to preserve back-up
battery power as the battery voltage drops.
Load-Shedding Threshold: Enter the voltage level at which the selected
output will be disconnected.

18 Innovative Circuit Technology Ltd.
Load-Shedding Auto Recovery: Check this box to allow the output to be
automatically reconnected when the bus voltage is above the Auto Recovery
Threshold for at least 60s. The output must be manually re-enabled using
the Output ON button on the Status and Control page if the Auto Recovery
function is not enabled.
Auto Recovery Threshold: Enter the voltage level at which the selected
output will automatically be reconnected. This value must be at least 0.5V
above the Load-Shedding Threshold voltage.
Output Over(Under)-Current Alarm:
Over-Current Threshold: Enter the over-current level. Output current above
this level for at least 5s will trigger the Over-Current Alarm, and disable the
output (if feature enabled). Disable this alarm by setting the threshold to 0A.
Under-Current Threshold: Enter the under-current level. Output current
below this level for at least 5s will trigger the Under-Current Alarm. Disable
this alarm by setting the threshold to 0A.
Activate Form-C Contact: Checking this box will cause the Alarm relay to
trigger for an over(under)-current condition.
Send E-mail: Checking this box will cause the unit to send an output Current
alarm e-mail to the assigned address entered on the E-mail Setup page.
Disable This Output: Check this box to automatically disable the output for
an Over-Current condition on the selected output. This function may be used
as an electronic circuit breaker which can then be remotely reset by clicking
the Output ON button on the Status and Control page.
Network setup
Use this page to configure the network settings for the panel. Click on the Save
Settings button at the bottom of the page to save any changes and re-boot the
panel.
NOTE:
Saving any changes to the network settings will cause the panel to re-boot,
cycling power to all outputs.
Network:
MAC Address: Displays the MAC address assigned to the panel
Enable DHCP: Turn on this setting if your network uses a DHCP server to
automatically assign IP addresses. (Enabled as default setting). To manually

Innovative Circuit Technology Ltd. 19
assign a static IP address to the unit uncheck this box, then set the following
parameters:
IP Address: Specify a unique IP address for the unit.
Subnet Mask: Specify the mask for the subnet the panel is located on
Gateway: Specify the IP address of the default router (Gateway) used
for connecting attached devices to different networks.
Primary DNS: Specify the IP address of the Primary DNS Server for your
network.
Secondary DNS: Specify the IP address of the Secondary DNS Server for
your network.
Web Server:
CAUTION:
Changing the web server port numbers may cause loss of communication with
the panel
The following ports may be changed within a range of 1 to 65565, if
required.
HTTP Port: This port is used for HTTP traffic between the panel and your
browser. The default HTTP port is 80, and if you change this the new HTTP
Port number must be appended to the URL used to access the panel. (e.g.
use URL http://192.168.0.180:8000 for IP address 192.168.0.180, port 8000)
HTTPS Port: The HTTPS (HTTP Secure) protocol uses encrypted data transfer
between web browsers and servers for higher security. The default HTTPS
port is 443. Append any changed HTTPS port to the end of the URL for the
panel.
To access the panel through a secure HTTPS connection, use https:// at the
start of the units URL. (e.g. https://192.168.0.180:8888 for IP address
192.168.0.180, HTTPS port 8888)
SNMP:
Configure these settings if you would like to use SNMP based monitoring. SNMP
(Simple Network Management Protocol) is an industry standard protocol for
network management software. Enabling the SNMP function on the panel will

20 Innovative Circuit Technology Ltd.
allow standard SNMP management software to connect to the SNMP agent
running on the panel and read real time system information such as bus voltage,
and channel currents. The panel can send SNMP traps to the external
management software when an alarm or fault occurs.
The information available from the SNMP agent is described in a MIB
(Management Information Base) file, which can be downloaded from the panels
Help page. The unique panel MIB file must then be imported into your external
SNMP management software.
Enable SNMP: Check this box to enable the SNMP agent
Read Community: Enter the community string/password for read-only SNMP
access. The default read community string is “public”.
Trap Community: Assign the community string/password that will be sent
with all traps. Some trap receivers are able to filter based on Trap
Community
Trap IP Addresses: Assign the IP address for up to two devices that will
receive SNMP traps from the panel.
Enable SNMP Write Access: Check this box to allow remote SNMP control of
individual panel power outputs. If this box is unchecked information from
the panel will be read-only.
Write Community: Enter the community string/password for read-write
SNMP access. The default write community is “write”.
NOTE:
The community strings should be changed to unique passwords before
enabling SNMP, as the defaults are well known.
SNMP Contact Information: Assign contact information, such as an operator
name and phone number for the panel, which can be read via SNMP queries.
This information is optional.
E-mail Setup
Configure these settings to enable automatic e-mail notifications directly
from the panel. The information required for this is available from your
Network Administrator, or Internet Service Provider. (ISP)
E-mail:
