ICT Distribution 3 Series User manual

i
Distribution Series 3 Dual Bus (Breaker)
Instruction Manual
855-314-002

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
ii
SAFETY GUIDELINES
Principles of Safe Operation and Maintenance
Safety must always be the top priority of all personnel involved in the
installation, operation, and maintenance of this unit as it operates at high
voltages that could be potentially lethal. Technicians must adhere to the
appropriate standards and manufacturer’s recommendations to minimize
hazards.
Do not attempt to perform the tasks described in this manual if you are not
a qualified professional.
It is essential that all safety devices and emergency response systems be
fully operational and within their certification periods before starting any
service.
Visual Communication
This manual uses extensive visual aids and tries to adhere to ANSI and ISO
safety symbol standards. These symbols describe the following situations:
WARNING
WARNING indicates a hazardous situation that, if not avoided,
may result in death or severe injury or damage to equipment and
property.
CAUTION
CAUTION indicates a hazardous situation that, if not avoided,
may result in minor or moderate injury or damage to equipment
and property.
NOTICE
NOTICE indicates practices not related to physical injury but may
result in equipment damage, environmental hazards, loss of data,
and other undesirable consequences.
General Alerts
WARNING
Risk of serious personal injury or damage to equipment and
property. Always observe the following:
•Installation must be done by qualified technicians.
•Shut off or disconnect all DC power sources before
connecting or disconnecting wiring.
•Carefully observe wiring polarity when making input and
output connections.
•Securely tighten all connections.
•Do not attempt to service any internal parts. Refer all product
service to an authorized ICT Ltd. service facility.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
iii
CAUTION
Risk of personal injury or damage to equipment and
property. Always observe the following:
•Use wire and connectors rated for the maximum load
current and size of fuse or circuit breaker in accordance with
NEC Section 210.20(A) and keep cable lengths as short as
practical.
•Install unit in a restricted access location (such as an
equipment rack) to limit unintentional contact with terminals
and wiring.
•Keep sources of moisture away from unit.
•Ensure all breakers are in the "OFF" position before
connecting or disconnecting wiring.
•Do not energize the unit before the chassis ground is
connected.
•DC-AC Inverters should not be connected to the outputs of
any ICT Distribution Series panel. DC-AC Inverters create
significant inrush current and may damage the circuitry or
interfere with the operation of power distribution panels that
they are connected to. Connecting an inverter in this way
may void the product warranty. ICT recommends connecting
a DC-AC inverter to the battery bank.
NOTICE
Risk of damage to equipment, environmental hazards, loss
of data and other undesirable consequences. Always
observe the following:
•The unit must be properly handled, mounted, and installed.
•Do not block air inlet or outlet openings.
•Due to environmental factors which are common at outdoor
communications sites, power surges from lightning strikes,
electrostatic discharge, and utility power feeds can occur.
These surges can damage connected equipment.
•Third-party surge suppression devices must be utilized to
protect AC input power feeds, and exposed DC power
conductors and data cables. To provide optimal protection,
these protection devices should be installed at both ends of
the exposed conductor, in close proximity to installed
equipment.
•Consult with manufacturers of surge suppression devices to
select appropriately rated protection device(s) and proper
installation methods.
•ICT’s product warranty does not cover damage caused by
power surges and electrostatic discharge events including
lightning.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
iv
NOTE: Due to the breaker-detection circuitry internal to the unit, it may be
possible to measure a voltage on the terminal(s) with no load
connected, even if that terminal’s breaker is open circuit. This is
normal operation. The breaker-detection circuitry is a high-
impedance circuit, and while a voltage may be present on the output
terminal, it is a signal voltage and does not support loading. A load
device connected to the output will immediately pull this voltage to
zero volts.
Product Alerts
CAUTION
Risk of personal injury or damage to equipment and
property. Always observe the following:
•Ensure the total power consumption of the loads does not
exceed the 100 amps (peak) rated capacity of each power
bus.
•Ensure continuous load current through each output
channel does not exceed the 80% of the maximum output
ratings in accordance with NEC Section 210.20(A).

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
v
GENERAL INFORMATION
Document Number: 855-314-002
Model: ICT200DB-12IRC (Breaker)
Date and Revision: February 2024, Revision 2.0
Copyright © 2024 Innovative Circuit Technology Ltd. All rights reserved. No
part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written consent of
Innovative Circuit Technology Ltd.
Disclaimer
ICT shall not be held liable for any damage or injury involving this product if
it has been subjected to misuse and exposure to environmental conditions
not conforming to the product’s limits of operation, improper installation, or
maintenance.
The illustrations in this manual are for illustrative purposes only. Review the
drawings before proceeding. If there are questions and concerns regarding
the product, refer to the FAQs section or contact ICT.
Contact Information
•North America toll-free: +1 877.930.0717 ext. 810
•International: +1 604.856.6303 ext. 810
•E-mail: [email protected]m

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
vi
ICT LIMITED WARRANTY
The warranty period on ICT products is two (2) years from date of purchase
from an authorized ICT reseller or OEM with valid proof of purchase, or from
date of shipment from the ICT manufacturing facility. The warranty period
for a repaired product or part is ninety (90) days or the remainder of the
unexpired term of the new product warranty period, whichever is greater.
Repair or replacement of a defective product or part does not extend the
original warranty coverage period.
The ICT Limited Warranty is only intended for the benefit of the original
purchaser and user of this product. This Warranty is not transferable or
assignable without the prior written permission of ICT. ICT’s sole obligation
and liability under this warranty is limited to either repairing or replacing
defective products at the sole discretion of ICT. When repairing or replacing
the products, ICT may use products or parts that are new, equivalent to new
or re-conditioned. Parts repaired or replaced during the warranty period will
be under warranty for the remainder of the warranty period.
No claim will be accepted unless written notice of the claim is received by
ICT in accordance with ICT’s Return Material Authorization (RMA)
procedure, as soon as reasonably possible after the defect is discovered. A
valid product serial number must be provided with the RMA claim to prove
eligibility. The RMA procedure is available on the ICT website at www.ict-
power.com/support/warranty-repair/.
The Purchaser shall at their own risk and cost return the defective product
to ICT’s factory or designated repair center once an RMA is issued by ICT.
Return of the products to the customer after repair is completed shall be
prepaid by ICT unless otherwise mutually agreed between the parties.
Products shipped to ICT which have incurred freight damage will not be
covered by this Warranty and any repairs or replacement parts, components
or products needed will be invoiced in the full current price amount and
returned freight collect to the Purchaser. It is the Purchaser’s responsibility
to check the product upon receipt for any damage during shipping and to
contact the carrier or shipper regarding such damage. Product that is
returned as defective, which is determined to operate within published
specifications will be returned to the Purchaser freight collect.
ICT assigns to the Purchaser any warranties which are made by
manufacturers and suppliers of components of, or accessories for, the ICT
product and which are assignable. ICT makes no representations as to the
effectiveness or extent of such warranties, assumes no responsibility for any
matters which may be warranted by such manufacturers or suppliers and
extends no additional coverage under this Warranty to such components or
accessories.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
vii
In no event shall ICT be liable for any special, indirect, or consequential
damages such as, but not limited to, loss of use, business or goodwill, loss
of revenue, or loss of profits, which may result, either directly or indirectly,
from defects in products provided by ICT.
This Warranty will be void if the product has been subjected to misuse,
neglect, accident, exposure to environmental conditions not conforming to
the products’ limits of operation, improper installation or maintenance,
improper use of an electrical source, defects caused by sharp items or by
impact pressure, a force majeure event, has been modified or repaired by
anyone other than ICT or its authorized representative, has been subjected
to unreasonable physical, thermal or electrical stress, improper
maintenance, or causes external to the unit including but not limited to
general environmental conditions such as rust, corrosive atmospheres,
sustained temperatures outside the specified operating range of the
equipment, exposure to power surges and/or electrical surges, improper
grounding, mold or dust, animal or insect damage, water damage or
immersion in liquid of any kind, or if the serial number has been altered,
defaced, or removed.
ICT does not control the installation and use of any ICT product.
Accordingly, it is understood this does not constitute a warranty of
performance or a warranty of fitness for a particular purpose. This Warranty
represents the entire agreement between ICT and Purchaser with respect
to the subject matter herein and supersedes all prior verbal or written
communications, representations, understandings, or agreements relating
to this subject.
Return Material Authorization Procedure
1. Request RMA number from ICT through telephone, e-mail, or website
from Monday to Friday between 8:00am and 4:30pm Pacific Time.
•North America toll-free: +1 877.930.0717 ext. 810
•International: +1 604.856.6303 ext. 810
•E-mail: [email protected]m
•ICT website: https://ict-power.com/support/warranty-repair
2. Provide the following information when requesting an RMA:
•ICT model number
•Serial number
•Return ship-to address
•The preferred shipping courier and account number, if applicable
•An estimate of what the possible failure cause might be

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
viii
TABLE OF CONTENTS
1.0 INTRODUCTION................................................................................... 1
1.1 Common Features ............................................................................ 2
1.2 Intelligent Models .............................................................................. 2
2.0 INSTALLATION .................................................................................... 2
2.1 Quick Install Guide ............................................................................ 3
2.2 Unpacking and Inspection................................................................. 3
2.3 Package Contents ............................................................................. 4
2.3.1 Tools and Parts Needed ............................................................. 4
2.3.2 Other Requirements................................................................... 4
2.4 Rack Mounting .................................................................................. 4
2.5 Ground Connection ........................................................................... 5
2.6 Sensor and Alarm Connections......................................................... 5
2.7 Load Connections ............................................................................. 6
2.8 Installation of Breakers...................................................................... 7
2.9 System Wiring Final Verification........................................................ 8
2.10 Input Connections ........................................................................... 9
2.11 Software Configuration.................................................................... 9
2.12 Energize Loads ............................................................................... 9
2.13 Mixed Polarity or Voltage Installation .............................................. 9
3.0 OPERATION: FRONT DISPLAY PANEL ........................................... 10
3.1 Graphic Display ............................................................................... 10
3.2 Menu Structure................................................................................ 10
3.2.1 Main Screen ..............................................................................11
3.2.2 Network Screen........................................................................ 12
3.2.3 Output Screen (1A to 6A or 1B to 6B) ...................................... 12
3.2.4 Site Alarm Input Screen (1 to 5) ............................................... 13
3.3 Password Reset .............................................................................. 13
3.4 Status Indicators and Alarms .......................................................... 13
4.0 OPERATION: GRAPHICAL USER INTERFACE............................... 14
4.1 Log In/Log Out ................................................................................ 14
4.2 Status & Control .............................................................................. 15
4.3 Alarm Status .................................................................................... 17
4.4 Device Setup ................................................................................... 18
4.5 Bus Setup........................................................................................ 21
4.6 Output Setup ................................................................................... 23
4.7 Network Setup................................................................................. 26
4.8 E-mail Setup.................................................................................... 30
4.9 Alarm Setup..................................................................................... 32
4.10 User Setup .................................................................................... 33
4.11 Maintenance .................................................................................. 36
4.12 Help ............................................................................................... 39
5.0 OPERATION: MOBILE VERSION...................................................... 39
5.1 Log In/Log Out ................................................................................ 39
5.2 Status & Control .............................................................................. 40

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
ix
6.0 FAQs ................................................................................................... 41
6.1 How do I access the web-based configuration utility? .................... 41
6.2 How do I reset the password? ........................................................ 42
6.3 How do I receive e-mails from the unit?.......................................... 42
6.4 How do I configure a router?........................................................... 42
6.5 How do I receive text message alarm notifications?....................... 42
6.6 How do I upgrade the firmware? ..................................................... 43
6.7 How can I access the MIB file? ....................................................... 43
6.8 What type and maximum rating of breakers can be installed in the
unit?....................................................................................................... 43
6.9 How do I properly wire the unit? ..................................................... 43
6.10 How do I configure mixed polarity or voltage? .............................. 43
6.11 How do I log out of the GUI? ......................................................... 44
7.0 PRODUCT SPECIFICATIONS ........................................................... 44
7.1 Electrical Specifications .................................................................. 44
7.2 Physical Specifications.................................................................... 44
7.3 Regulatory Specification ................................................................. 45
7.4 Mechanical Specifications............................................................... 45
8.0 GLOSSARY ........................................................................................ 46
LIST OF FIGURES
Figure 1. Front Panel .................................................................................. 1
Figure 2. Typical Rear View ........................................................................ 5
Figure 3. Installing breaker with even pressure .......................................... 8
Figure 4. Installing breaker with uneven pressure ...................................... 8
Figure 5. Front Control Interface ............................................................... 10
Figure 6. Menu Structure ...........................................................................11
Figure 7. Unit Dimensions......................................................................... 45
LIST OF TABLES
Table 1. Breakers ........................................................................................ 4
Table 2. Bus Alarm Connector..................................................................... 5
Table 3. Site Alarm Inputs ........................................................................... 6
Table 4. Bus Output Capacity...................................................................... 7
Table 5. Distribution Unit Alarms ............................................................... 14
Table 6. Electrical Specifications............................................................... 44
Table 7. Physical Specifications ................................................................ 44
Table 8. Regulatory Compliance ............................................................... 45
Table 9. Dimension and Weight ................................................................ 45

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 1 of 46
1.0 INTRODUCTION
The ICT Distribution Series 3 dual-bus DC distribution panel provides two
100 amps (peak) bus inputs; with six independently controlled and
monitored output channels per bus in a compact 1RU chassis for 19-inch
rack mounting. Overcurrent protection for each output is available on the
front panel with 65-volt DC rated, user-insertable, magnetic-hydraulic circuit
breakers that are orderable separately.
Each bus can accommodate a supply voltage from 10- to 60-volt DC, either
positive or negative polarity, with a peak input current of 100 amps to be
distributed at 25 amps continuous (16 amps continuous for 48-volt systems)
on each of the six output channels. Each channel has independent current
sensing, overcurrent protection, alarms, and output on/off control.
Remote monitoring and control are available through the integrated
security-protected Ethernet communications port on the back of the unit.
The unit has a built-in web server with an embedded web-based graphical
user interface (GUI) that can be accessed using any standard commercial
web browser. The GUI displays all panel information; allows full access to
channel configuration settings; provides remote channel on/off control; and
can be set up to send an alarm to user-defined e-mail accounts in the event
a fault occurs. The GUI can also be used to configure and download a data
log of up to 30 days of time-stamped event information. Full monitoring and
control are also available using an SNMP-based management system for
larger installations.
System voltage, system current, output channel current, breaker status, and
alarm input status can also be monitored onsite through the front display
panel. Breaker trip status is indicated locally by the rocker handle position
and front Bus Alarm LEDs. Form-C alarm output contacts (C/NO/NC) are
provided on the back panel for each bus to indicate all distribution panel
alarms, while five additional alarm inputs can be used to monitor other dry-
contact site sensors such as door/window opening, smoke alarms, water
detectors, etc.
Figure 1. Front Panel
Front panel Display
Bus A Output 1-6 Circuit Breakers
Bus B Output 1-6 Circuit Breakers
LCD Output
Selection Buttons
Bus A Alarm
Bus B Alarm

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 2 of 46
1.1 Common Features
•200 amps peak system current rating / 100 amps per bus
•Six independently controlled and monitored output channels per
bus
•Independent form-C alarm contacts for each bus
•High-quality, reliable hydraulic/magnetic breakers support 12-, 24-
and 48-volt DC applications
•Mixed voltages and polarities can be supported in one panel
•−30 to +60 °C operating temperature range
•2-year warranty
1.2 Intelligent Models
•TCP/IP remote management and power control of system and
individual outputs
•On-board web server means no software to maintain
•Easy to use GUI
•Remote firmware update capability
•HTTPS, SMTP, SNMP (v1, v2c, v3), TLS 1.2 protocols supported
•Monitoring and alarm reporting of each output
•Alarms can be sent to multiple e-mail accounts
•Each output has adjustable load-shedding settings
•Network watchdog
•Five digital inputs for site monitoring sensors
•Data logging
•Password protection
2.0 INSTALLATION
WARNING
Risk of serious personal injury or damage to equipment and
property. Always observe the following:
•Shut off or disconnect all DC power sources before
connecting or disconnecting wiring.
•Carefully observe wiring polarity when making input and
output connections.
•Securely tighten all connections.
CAUTION
Risk of personal injury or damage to equipment and
property. Always observe the following:
•Use wire and connectors rated for the maximum load
current and size of fuse or circuit breaker in accordance with
NEC Section 210.20(A) and keep cable lengths as short as
practical.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 3 of 46
CAUTION
•Channel output breakers must not exceed 30 amps max
rating for 12- and 24-volt DC systems, 20 amps max rating
for 48-volt DC systems.
•Install unit in a restricted access location (such as an
equipment rack) to limit unintentional contact with terminals
and wiring.
•Keep sources of moisture away from unit.
•Ensure all breakers are in the "OFF" position before
connecting or disconnecting wiring.
•Do not energize the unit before the chassis ground is
connected.
•Ensure the total power consumption of the loads does not
exceed the 100 amps (peak) rated capacity of each power
bus.
The following is the recommended sequence for the installation process.
2.1 Quick Install Guide
•Unpack and check that the unit and all materials have been
delivered.
•Obtain the recommended tools.
•Mount the unit.
•Connect the ground according to the site design, and in
accordance with local electrical code standards.
•Connect the sensors and alarms.
•Connect the loads.
•Insert the breakers.
•Verify system wiring.
•Connect and energize the DC inputs.
•Configure the software settings.
•Energize the loads.
2.2 Unpacking and Inspection
Perform a physical check of the unit as it is being taken out of the box to
ensure it has not been damaged during shipping. Check that the
accessories under the package contents section were shipped with the unit.
NOTE: In case of shipping damage, your freight carrier should be notified
immediately.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 4 of 46
2.3 Package Contents
•Distribution panel
•Instruction manual (in bag)
•Four black plastic boots to insulate main DC power connections (in
bag)
•Two 3-pin alarm output connector plugs (in bag)
•One 10-pin site monitor alarm input connector plug (in bag)
•Six ICT-BLP breaker blanking plugs for installation in unused
breaker locations (in bag)
2.3.1 Tools and Parts Needed
•1/2-inch wrench
•3/8-inch wrench
•Wire stripper
•Four #10-32 Phillips screws (length to be decided by installer) to
connect rack ears to rack
•#2 Phillips screwdriver for the rack ear connections
•3/32-inch flathead screwdriver for the form-C alarm relay
connector, alarm and sensor wire connection
2.3.2 Other Requirements
To complete the installation, appropriate circuit breakers (available from
ICT) are needed for each output channel that the user plans to use. Circuit
breakers must be ordered separately from the following list for use on the
ICT200DB-12IRC unit.
Table 1. Breakers
ICT Model
Rating (65 VDC)
ICT-CB5
5 A
ICT-CB10
10 A
ICT-CB15
15 A
ICT-CB25
25 A
ICT-CB30
30 A
ICT-BLP
Blanking Plate
NOTE: "C" series rocker handle circuit breakers with 0.25-inch tab terminals
and current ratings up to 30 amps may also be used. Consult ICT
for suitable part numbers.
2.4 Rack Mounting
Mount the unit in an enclosed standard 19-inch equipment rack or other
restricted access location, using rack mounting screws (not supplied).
Support the rear of the unit with rack shelf supports or back rail if required.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 5 of 46
2.5 Ground Connection
NOTICE
All DC inputs and outputs of ICT’s DC distribution panels are
isolated from chassis ground (floating). DC input and output
returns can remain isolated from ground (DC-I) or can be
grounded (DC-C), as per site grounding requirements and/or
local or national electrical codes. Ensure that all relevant electrical
code standards are followed.
Connect an 8 AWG ground bonding wire from the chassis ground stud to a
nearby common grounding point.
Figure 2. Typical Rear View
2.6 Sensor and Alarm Connections
1. Connect the two form-C relay Bus Alarm outputs to an external
monitoring system if needed, by stripping and terminating 16–28
AWG alarm wiring in the alarm 3-pin connector plugs and installing
in the back panel. Each Bus Alarm output will trigger for any breaker
open, or other alarm related to any channel on that bus (factory
default). If required, using the Graphical User Interface (GUI), some
alarm conditions may be muted so that they will not trigger the form-
C alarm output.
Table 2. Bus Alarm Connector
Alarm Pin (Bus A or B)
Function
C
Alarm Output common (0.5 A 65 VDC max)
NC
Alarm Output normally closed for alarm condition
NO
Alarm Output normally open for alarm condition
2. Connect up to five dry contact type site sensors (such as
door/window sensors, smoke alarm, water detectors, etc.) by
Bus B Input
(100 amps max)
Bus B Outputs
Channel 6–1
Bus A/B RTN Connectors
(common)
Chassis Ground
Bus A Outputs
Channel 6–1
Bus A Input
(100 amps max)
Bus B Alarm out
C/NC/NO
LAN Port
10/100Base-T
Bus A Alarm out
C/NC/NO
Site Alarm
Inputs 1–5

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 6 of 46
stripping and terminating 16–28 AWG alarm wiring and connecting
to the five Site Alarm Inputs on the 10-pin removable Alarm Input
Plug, if desired. These inputs may be configured to activate the
panel Alarm outputs or send an alarm e-mail on network connected
units. The external sensor contacts must be voltage free as a small
sense current is supplied from the panel Alarm Input pins to detect
the external contact open or closed state. Refer to Section 4.9 for
more information on how to configure and use the five Site Alarm
inputs.
Table 3. Site Alarm Inputs
Pin (L-R)
Site Alarm Input Function
1
Input 1
c
Common
2
Input 2
c
Common
3
Input 3
c
Common
4
Input 4
c
Common
5
Input 5
c
Common
2.7 Load Connections
CAUTION
Risk of personal injury or damage to equipment and
property. Always observe the following:
•DC-AC Inverters should not be connected to the outputs of
any ICT Distribution Series panel. DC-AC Inverters create
significant inrush current and may damage the circuitry or
interfere with the operation of power distribution panels that
they are connected to. Connecting an inverter in this way
may void the product warranty. ICT recommends connecting
a DC-AC inverter to the battery bank.
•Ensure that the combined current draw on the outputs does
not exceed the output capacity of the bus (100 amps).
•Leave breakers turned off until the software has been
configured (see Section 4).
Make connections to the load using wire and connectors appropriately rated
for the maximum output current capability of the unit.
An output (labelled OUT) and return (labelled RTN) are provided for each
channel.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 7 of 46
Each bus provides six remotely controlled and monitored outputs, with front
panel overcurrent protection provided by hydraulic-magnetic circuit
breakers (see Section 2.8 for the installation instructions for the breakers).
The maximum current rating for each bus is 100 amps. Each output can
accept maximum current based on the bus voltage (see Table 4).
Table 4. Bus Output Capacity
Bus Voltage
Output Capacity
12 or 24 VDC
Up to 6 x 30 A peak output (25 A cont.)
48 VDC
Up to 6 x 20 A peak output (16 A cont.)
The unit may be operated with either Bus A or Bus B powered, or both.
Each bus may have independent polarity and bus voltage.
CAUTION
All output return (RTN) lines and the main Bus A and Bus B RTN
terminals are common and are referenced to a single internal bus
(RTN). Bus A and Bus B inputs can be wired to a different DC
voltage (10- to 60-volt DC) of either polarity. When used with
mixed-polarity voltages, e.g., positive 12 volts on Bus A and
negative 48 volts on Bus B, the two voltage sources must be
electrically isolated from each other. Not isolating the two voltage
sources for mixed-polarity applications will short circuit and
potentially damage connected equipment.
For each bus that is being used:
1. Locate the six outputs on the bus rear panel connector block.
2. Ensure that the breakers on the bus are turned off until the software
has been configured (see Section 4).
3. Verify the polarity of the bus.
4. Connect up to six external loads using appropriately rated wire
inserted and secured into the six cage-clamp output connector pairs
on the bus rear panel. The terminal will accept wires from 10–22
AWG.
NOTE: The outputs use normally closed relays.
2.8 Installation of Breakers
Install breakers in the 12 front locations of the panel by inserting into the
breaker openings ("On" or "I" facing up, "Off" or "0" facing down), ensuring
the breaker connector tabs securely seat in the breaker sockets. Leave the
breakers turned off until the software has been configured (see Section 4).

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 8 of 46
CAUTION
If the breakers are not fully installed or are not installed "square"
they may cause intermittent power loss or unexpected behavior
for the load devices.
When installing load breakers, apply even pressure to the top and bottom
of the breaker to ensure proper engagement of the breaker with the rear
contacts (see Figure 3).
Figure 3. Installing breaker with even pressure
Applying pressure unevenly may result in misalignment of the contacts (see
Figure 4).
Figure 4. Installing breaker with uneven pressure
2.9 System Wiring Final Verification
1. Connect a 10/100 Base-T Ethernet cable to the RJ45 LAN port on
the rear panel to allow for remote monitoring and control of the unit.
NOTE: See the Network Monitoring and Control section for information on
configuring and using the built in GUI, e-mail, or SNMP functions
(see Section 4.7).

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 9 of 46
2. Check that all connections to the power distribution panel are
correct and properly tightened.
2.10 Input Connections
1. De-energize the DC source.
2. Connect the main Bus A RTN line to the power supply return using
wire and ring connectors rated for up to 100 amps continuous
current. Feed the wire through the supplied rubber insulating boot
and connect the ring terminal to the M8 RTN stud, then securely
fasten with supplied hardware. Slip the insulating boot over the high
current ring terminal and RTN stud on the back panel to help
prevent accidental contact with the stud connection.
3. Connect the Bus A INPUT through a suitably rated disconnect
switch (set in the open position) and a fuse or circuit breaker rated
for 100 amps max continuous operation to the power supply output,
using wire and connectors rated for 100 amps continuous current.
Feed the wire through the supplied rubber insulating boot and
connect the input ring terminal to the M8 Bus A INPUT stud, then
securely fasten with supplied hardware. Slip the boot over the ring
terminal and INPUT stud to help prevent accidental contact with the
stud connection.
4. Repeat input wiring for the Bus B INPUT, its power source and
overcurrent protection device, if the Bus B outputs are to be used.
5. Energize the DC source and close any disconnect switches.
2.11 Software Configuration
Configure the software (see Section 4).
2.12 Energize Loads
Switch on the output breakers 1 to 12 (if installed) to energize any loads
connected to the distribution panel outputs.
2.13 Mixed Polarity or Voltage Installation
All output return (RTN) lines and the main Bus A and Bus B RTN terminals
are common and are referenced to a single internal bus (RTN). Bus A and
Bus B inputs can be wired to a different DC voltage (10- to 60-volt DC) of
either polarity. When used with mixed-polarity voltages, e.g., positive 12
volts on Bus A and negative 48 volts on Bus B, the two voltage sources must
be electrically isolated from each other. Not isolating the two voltage
sources for mixed-polarity applications will short circuit and potentially
damage connected equipment.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 10 of 46
3.0 OPERATION: FRONT DISPLAY PANEL
Energize each bus by closing the main external breaker or disconnect
device on the bus input lines. Check that the distribution panel front graphic
display powers up. The Distribution Series 3 will start up and operate at the
factory default settings when DC power is connected, generally requiring no
further set up or adjustment for basic operation.
3.1 Graphic Display
Use the front display screen and two interface buttons on the front panel to
monitor the bus voltage, total bus current, network status, channel output
status of the selected bus and the alarm status of the external monitored
devices.
Figure 5. Front Control Interface
NOTE: The LCD backlight will activate when pressing either "Output Select"
button and will turn off after approximately 15 minutes of inactivity.
Bus A "Output Select" Button: Use to scroll through the Bus A display
screens; or to switch to the Bus A main screen from Bus B.
Bus B "Output Select" Button: Use to scroll through the Bus B display
screens; or to switch to Bus B main screen from Bus A.
Holding either "Output Select" button for 2 seconds will return the display to
the main screen for that bus. Holding either "Output Select" button for 20
seconds will reset the password to the factory default (see Section 3.3).
3.2 Menu Structure
See the complete menu structure in the following diagram. Navigate through
the various screens using the two interface buttons.

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 11 of 46
Figure 6. Menu Structure
NOTE: While navigating using the A button, pressing B will take the user to
the Bus B main screen. Similarly pressing A while navigating using
the B button will take the user to the Bus A main screen.
3.2.1 Main Screen
The main screen will show the name of the unit — user configurable through
the graphic user interface (GUI), the bus being monitored (Bus A or Bus B),
the bus voltage, and the total bus current.
Other information will be shown depending on the operating state of the unit:
•The bus voltage will blink if the voltage exceeds the undervoltage
or overvoltage alarm thresholds.
•The total bus current will blink if the current exceeds the
overcurrent alarm threshold.
Press either "Output Select" button to move to the
Network Screen.
MAIN SCREEN
ICT Dual Bus Panel PRESS "A" ICT Dual Bus Panel
BUS : " A" BUS : " B"
VOLTAGE: 13.7V VOLTAGE: −13.7V
CURRENT: 0.0A PRESS "B" CURRENT: 0.0A
PRESS "A" PRESS "B"
Network Connected Network Connected
HOLD "A" 100 Base-Tx PRESS "B" 100 Base-Tx HOLD "B"
192.168.0.68 PRESS "A" 192.168.0.68
e8:eb:1b:e8:6b:99 e8:eb:1b:e8:6b:99
PRESS "A" PRESS "B"
OUTPUT #A OUTPUT #B
HOLD "A" STATUS: ENABLED PRESS "B" PRESS "A" STATUS: DISABLED HOLD "B"
VOLTAGE: 13.8V VOLTAGE: 13.8V
CURRENT: 0.0A CURRENT: 0.0A
PRESS "A" PRESS "B"
(if enabled) (if enabled)
PRESS/HOLD ALARM INPUT # ALARM INPUT # PRESS/HOLD
"A" PRESS "B" PRESS "A" "B"
STATUS: READY STATUS: ALARM
ICT Dual Bus Panel
BUS: "X"
VOLTAGE: 13.8V
CURRENT: 0.0A
