1. Introduction
The ID Lock Z-Wave Module is a security enabled Z-Wave Plus product which is able
to use encrypted Z-Wave Plus messages in order to communicate to other Z-Wave
Plus products with enabled security.
The module is created for the ID Lock 150 and is also backwards compatible with the
ID Lock 101 (note that some functionallity is not available on ID Lock 101).
The ID Lock Z-Wave Module must be used in conjunctioin with a Security Enabled
Z-Wave Controller in order to fully utilize its full capability. Other nodes in the Z-
Wave network can function as repeaters.
The ID Lock Z-Wave Module can be included and operated in any Z-Wave network
containing other certified Z-Wave products regardless of manufacturer.
Using the Z-Wave Module on the ID Lock will affect the battery life of the door lock.
The ID Lock Z-Wave Module does not support the Basic Set Command Class.
2. Overview
Z-Wave Module is a Z-Wave interface device of ID Lock and is used to connect a to Z-
Wave Controller using the Z-Wave protocol.
This document decribes the spesifics for Z-Wave command classes used when ID
Lock Z-Wave Module is interfacing with a Z-Wave controller.
Front Side of Z-Wave Module
Back Side of Z-Wave Module Sales box and Z-Wave module

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
4
3. Getting started
3.1. Identify your model type (101 or 150)
The keypads on 101 and 150 are different. Whilst the 101 has a * (star) and # (hash)
left and right of digit “0” the 150 has open and closed padlocks (see pictures below).
Note: FW v1.6 of ID Lock Z-Wave Module has reduced compatibility for ID Lock 101.
The Z-Wave Module fits only one way below
the batteries on both 101 and 150. The slot
is marked “Remote control”.
IMPORTANT!
Always remove batteries before inserting or
removing the Z-Wave Module.

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
5
3.2. ID Lock 101
3.2.1. Inclusion and Exclusion (Adding or removing)
For inclusion (puts your device in inclusion mode) of ID Lock 101 first set your
designated Z-Wave controller in inclusion mode then press and hold the
Key Button [A] until keypad is activated whilst the door lock is open and unlocked.
Release button [A] and press digit [8] on keypad.
Inclusion mode starts immediately and is indicated by flashing blue LEDs.
3.2.2. Z-Wave module device reset
For Z-Wave local reset follow same procedure except use digit [0].
Reset starts immediately and is indicated by flashing blue LEDs.
Warning!
After Z-Wave local reset the device might have to be excluded before a new inclusion.
This function is made available by design only to be used if your module
does no longer function properly or if your Z-Wave controller is lost.

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
6
3.3. ID Lock 150
3.3.1. Inclusion and Exclusion (Adding or removing)
For inclusion (puts your device in inclusion mode) of ID Lock 150 first set your
designated Z-Wave controller in inclusion mode then press and hold the
Key Button [A] until keypad is activated whilst the door lock is open and unlocked.
1. Release button [A] and enter Master PIN [1234], followed by [*] on keypad.
2. Press digit [2], followed by [*] to enter settings menu.
3. Press digit [5] to start inclusion or exclusion.
Inclusion/exclusion mode starts immediately and is indicated by flashing blue LEDs.
3.3.2. Z-Wave module device reset
For Z-Wave local reset follow same procedure except use digit [0] instead of [5].
Take notice that if the Z-Wave module is included in a Z-Wave network the door lock
will return to factory settings when performing a local reset.
Reset starts immediately and is indicated by flashing blue LEDs.
Warning!
After Z-Wave local reset the device might have to be excluded before a new inclusion.
This function is made available by design only to be used if your module
does no longer function properly or if your Z-Wave controller is lost.

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
7
4. Z-Wave firmware version
This chapter contains the release for the Z-Wave Module firmware.
ID Lock 150 firmware can and must be updated with the app ID Lock 150 Updater
which is available for iOS and Android devices (idlock.no/updater).
4.1. Firmware version 1.6
Firmware version 1.6 is compatible with ID Lock 150 firmware 1.4.7 and newer.
•Configuration parameters
oChanged how ID lock 150 handles configuration parameter 2 “RFID
Registration mode”.
oAdded configuration report for Door audio volume (configuration parameter
4) and service pin mode (configuration parameter 7)
oAdded values 0x07 “always mode” and 0xFE “disable mode” to configuration
parameter 7 service pin mode.
oChanged configuration parameter 8 “updater mode” and 9 “Master pin
mode”.
•Notification parameters
oAdded serveral new notification events for “Access Control” (0x06).
Notifications for different lock types, add and delet credensials and lock
jammed alarm added.
oMoved remote unlock from “keypad unlock operation” with identifier 0x00, to
“RF unlock operation” with identifier 0x00.
•Version parameter
oChanged how a version report descibes ID lock 150 firmware version.
•Credensials of Z-Wave index
oChanged Z-Wave identifiers for master PIN, service PIN, user PINs and RFID.
•Battery
oBugfixes related to CC battery.

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
8
5. Z-Wave Specifications
○Device Type: Secure Keypad Door Lock
○Role Type: LSS (Listening Sleeping Slave)
5.1. Supported Command Classes
◼Non Secure Mode
CLASS
Value (Hex)
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
5E
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
72
COMMAND_CLASS_SECURITY_V1
98
COMMAND_CLASS_DEVICE_RESET_LOCALLY_V1
5A
COMMAND_CLASS_POWERLEVEL_V1
73
COMMAND_CLASS_CONFIGURATION_V1
70
◼Secure Mode (S0)
CLASS
Define Value (Hex)
COMMAND_CLASS_VERSION_V2
86
COMMAND_CLASS_DOOR_LOCK_V2
62
COMMAND_CLASS_USER_CODE_V1
63
COMMAND_CLASS_ASSOCIATION_V2
85
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V1
59
COMMAND_CLASS_NOTIFICATION_V4
71
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
7A
COMMAND_CLASS_BATTERY_V1
80

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
9
6. Configuration Parameters
These configuration parameter numbers and values are specific for the different
applications.
COMMAND_CLASS_CONFIGURATION
Name
Parameter
Number
Size
Parameter
Values
Description
Configuration
Set parameter
1
1
0-3
Door Lock Mode
2
1
5,9
RFID Mode (only IDL-150)
3
1
0-1
Door Hinge Position Mode
4
1
0-5
Audio Volume
5
1
0-1
Door Relock Mode
6
1
0-9, FE
Service Pin Mode
7
1
150
Door Lock Model Type
(read only, only IDL-150)
8
1
0-3
Updater Mode (only IDL-150)
9
1
0-1
Master PIN Mode

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
10
Name
Parameter
Size
Value
Description
Remarks
Lock Mode
1
1
0
Manual lock
Away off
1
Auto lock
Away off
Default value
2
Manual lock
Away on
After unlock value 0
3
Auto lock
Away on
After unlock value 1
RFID Mode
2
1
5
RFID
activated
Default value
9
RFID
deactivated
Hinge
Direction
3
1
0
Right hinged
operation
Default value
1
Left hinged
operation
Audio
Volume
4
1
0-6
0 = OFF
1-6 = Level
Default value: 5
ReLock
Mode
5
1
0
ReLock OFF
1
ReLock ON
Default value

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
11
Name
Parameter
Size
Value
Description
Remarks
Service PIN
Mode
(Index 108)
6
1
0
Deactivated
Default value
1
1x use
Returns to value 0
2
2x uses
Returns to value 0
3
5x uses
Returns to value 0
4
10x uses
Returns to value 0
5
Not used
For future use
6
Not used
For future use
7
Always valid
8
12 hours
Returns to value 0
9
24 hours
Returns to value 0
FE
Disabled
Disables both PIN and
Service PIN menu on
door lock
Model Type
7
1
101 (65)
ID Lock 101
Ready only
150 (96)
ID Lock 150
Ready only
Updater
Mode
8
1
0
Off (no sound)
Default value
1
On (no sound)
Enables use of
Updater app
2
Off
3
On
Enables use of
Updater app
Master PIN
Unlock Mode
(Index 109)
9
1
0
Off
1
On
Default value

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
12
7. Notification Parameter
These Notification parameters are specific for the applications. ID Lock supports
Notification Class (V4) to report events of ID Lock.
The type and event is described in table below.
COMMAND_CLASS_NOTIFICATION (V4)
Notification Type
Event
Event
Parameter
Description
Access Control
(0x06)
Manual Lock Operation
(0x01)
Manual lock and key button
lock
Manual Unlock Operation
(0x02)
Manual unlock and key
button unlock
RF lock Operation
(0x03)
Remotely locked (Z-Wave)
ID = 0
or
Locked by RFID
ID = RFID identifier
RF Unlock Operation
(0x04)
RF unlock (0x00)
or
RFID Index Info.
Remotely unlocked
(Z-Wave) ID = 0
or
Unlocked by RFID
ID = RFID index
Keypad Lock Operation
(0x05)
User ID = PIN index
Keypad Unlock Operation
(0x06)
User ID of User
Code Report
User ID = PIN index
Auto lock locked
Operation (0x09)
Auto lock and Relock
Lock jammed (0x0B)
All user code deleted
(0x0C)

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
13
Single user code
deleted (0x0D)
Single user code added
(0x0E)
New user code not
added due to duplicate
code (0x0F)
Unlock By RF with invalid
user code (0x14)
Unknown
Credential
Information
Unknown PIN
Or
Unknown RFID
Lock by RF with invalid
user code (0x15)
Unkown
Credensial
information
Unknown PIN
Or
Unknown RFID
Home
Security(0x07)
Tampering,
Product covering
Removed (0x03)
Door Forced Open
(Idle after PIN input)
Idle (0x00)
Emergency (0x0A)
Contact Fire Service
(0x02)
Fire Sensor
(Idle after PIN input)
Idle (0x00)

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
14
7.1. Use Case of Manual Lock Notification
⚫Example: Lock the door by thumb turn switch or open/close button
Notification
Type
Notification
Event
Para
Length
0x06
0x01
0
7.2. Use Case of Manual Unlock Notification
⚫Example: Unlock the door by thumb turn switch or open/close button
Notification
Type
Notification
Event
Para
Length
0x06
0x02
0
7.3. Use Case of RF Lock Operation
⚫Example : lock the door by remote unlock (Z-Wave)
The value of para1 refers to a reseved value
Notification
Type
Notification
Event
Para
Length
Para1
0x06
0x03
0x01
0x00

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
15
7.4. Use Case of RF Unlock Operation
⚫Example : Unlock the door by remote unlock (Z-Wave) or RFID Card
The value of para1 refers to user identifier for RFID or remote unlock (0x00)
Notification
Type
Notification
Event
Para
Length
Para1
0x06
0x04
0x01
0x00
7.5. Use Case of Keypad Lock Operation
⚫Example: Lock the door by Keypad by thouching panel
The value of para1 refers to a reseved value
Notification
Type
Notification
Event
Para
Length
Para1
0x06
0x05
0x01
0x00
7.6. Use case of Keypad Unlock Operation
⚫Example: Unlock the door by Keypad using PIN Code.
The value of para1 refers to User Identifier of User PIN
Notification
Type
Notification
Event
Para
Length
Para1
0x06
0x06
0x01
0x00
7.7. Use case of Auto lock locked operation
⚫Example: Locked automaticly by auto lock or relock
Notification
Type
Notification
Event
Para
Length
Para1
0x06
0x09
0
0x00

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
16
7.8. Use case of Lock Jammed
⚫Example: unsucsessfull lock or unlock
Notification
Type
Notification
Event
Para
Length
0x06
0x0B
0
7.9. Use case of All User Code Deleted
⚫Example: Delete all user pins either throug Z-Wave or locally on lock
Notification
Type
Notification
Event
Para
Length
0x06
0x0C
0
7.10. Use case of Single User Code Deleted
⚫Example: Delete single user pin either throug Z-Wave or locally on lock
Notification
Type
Notification
Event
Para
Length
0x06
0x0D
0
7.11. Use case of New User Code Added
⚫Example: Add single user pin either through Z-Wave or locally on lock
Notification
Type
Notification
Event
Para
Length
0x06
0x0E
0

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
17
7.12. Use case of User Code Not Added Due to Duplicate Code
⚫Example: pin not added due to duplicate pin code
Notification
Type
Notification
Event
Para
Length
0x06
0x0F
0
7.13. Use case of Unlock by RF with invalid user code
⚫Example: Invalid PIN code Notification Report
PIN Type is 1 value and Invalid PIN code is 12121212
Notification
Type
Notification
Event
Para
Length
Para1
Para2
Para3
Para4
0x06
0x14
0x04
0x12
0x12
0x12
0x12
⚫Example: Invalid RFID Notification Report
RFID Type is 2 value and Invalid RFID UID is 0x89AE939C
Notification
Type
Notification
Event
Para
Length
Para1
Para2
Para3
Para4
Para5
0x06
0x14
0x05
0x02
0x89
0xAE
0x93
0x9C

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
18
7.14. Use case of lock by RF with invalid user code
Reserved, not implemented on door lock firmware version 1.4.7 (for future use)
⚫Example: Invalid PIN code Notification Report
PIN Type is 1 value and Invalid PIN code is 12121212
Notification
Type
Notification
Event
Para
Length
Para1
Para2
Para3
Para4
0x06
0x14
0x04
0x12
0x12
0x12
0x12
⚫Example: Invalid RFID Notification Report
RFID Type is 2 value and Invalid RFID UID is 0x89AE939C
Notification
Type
Notification
Event
Para
Length
Para1
Para2
Para3
Para4
Para5
0x06
0x14
0x05
0x02
0x89
0xAE
0x93
0x9C
7.15. Use case of Tampering (Door Forced Open)
⚫Example: The door is forced opened by burglar (Alarm).
To deactivate: Enter valid PIN followed by #.
Notification
Type
Notification
Event
Para
Length
0x07
0x03
0x00
7.16. Use case of Emergency (Fire Sensor)
⚫Example: Extreme heat is detected by heat sensor on door lock inside.
To deactivate: Enter valid PIN followed by #.
Notification
Type
Notification
Event
Para
Length
0x0A
0x02
0x00

ID Lock Z-Wave Module Technical manual for FW 1.6 June 20th 2019
idlock.no
idlock.no/zwave
ID Lock
19
8. Manufacturer Parameter
The ID Lock support the Manufacturer Specific Command Class with the following
parameters.
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
Name
Value
Description
Manufacture ID
0x0373
ID Lock AS
Product Type ID
0x03
PRODUCT_TYPE_ID_ZWAVE_PLUS
Product ID
0x01
PRODUCT_ID_DoorLockKeyPad
