iDance Cube DC100 User manual

Bluetooth KARAOKE System with Built in Light Show
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
Thank you for purchasing iDance Audio System.
Instrucon Manual
English ..................... E1-E10

WHAT’S IN THE BOX
Contents
1.
2.
3.
4.
5.
iDance BC100 main unit
Power Adaptor (12V DC / 2A)
Instrucon Manual
Microphone x 1
Shoulder Strap x 1

WARNINGS
FCC AND CANADIAN ICES
The lightning flash with arrow-
head symbol inside an equilateral
triangle is intended to alert User
of the presence of un-insulated "
hazardous voltage" within the
product’s enclosure, which may
be of sufficient magnitude to
induce a risk of electric shock to
persons.
The exclamaon mark inside an
equilateral triangle is intended to
alert user of the presence of
important operang and mainte-
nance (servicing) instrucons in
the literature accompanying the
product.
Please do not aempt to open the back cover or power adapter as opening or removing the covers
may expose you to dangerous voltage or other hazards, and it will also cause the restricted
servicing to be disabled. There are no user servicing components inside.
WARNING
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters
between the radiator and your body.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

Read these instrucons.
Keep these instrucons.
Heed all warnings.
Follow all instrucons.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any venlaon openings. Install in accordance with the manufacturer’s
instrucons.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or pinched parcularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use aachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use cauon when moving the cart/apparatus
combinaon to avoid injury from p-over. Portable Cart Warning
Unplug this apparatus during lightning storms or when unused for long periods of me.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
The baery shall not be exposed to excessive heat such as sunshine, fire or the like.
The MAINS plug is used as the disconnect device, which shall remain readily operable.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
IMPORTANT SAFETY INSTRUCTIONS

Supports Bluetooth wireless audio streaming
Supports A2DP profile(Advanced Audio Distribuon Profile)
Supports automac device pairing
Wireless range: 33 feet
USB charger for smart phone/tablet
3.5mm Aux input
6.3mm Microphones & Guitar input
Easy access knob for volume control
Audio output for external amplifier
ON/OFF Power standby buon
Build-in speaker
Ultra light weight for perfect mobility
15W RMS Power Output
FEATURES

CONTROL LOCATION
GENERAL OPERATIONS
BLUETOOTH OPERATIONS
AUX-IN OPERATIONS / USING SHOULDER STRAP
CHARGING YOUR PORTABLE DEVICE / ENERGY SAVING
TROUBLESHOOTING
SPECIFICATIONS
..................................................................
..................................................................
................................................................
.............................
...................
.......................................................................
.......................................................................
E1-E2
E3-E5
E6
E7
E8
E9
E10
CONTENTS

Light Cover Lens
BELT Clip
ECHO Control
Turn to adjust the echo up or down
MIC Level Control
Turn to adjust the MIC sound level up or down
Party Light Acvate
Press to turn on or off the light show
Volume Control
Turn to adjust up or down
STANDBY
Press to power the unit on or off
PAIRING Indicator
PAIRING
Press and hold to begin pairing a bluetooth device
Power Indicator
Main Speaker
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
CONTROL LOCATION (1.1)
E1
1
2
3
6
7
8
9
10
11
4
5
FRONT Panel

MIC Input 1, 2
GUITAR Input
AUDIO Output
Connect to external amplifier
AUX Input
DC Input
USB CHARGER
Connect to other portable device you wish to charge
1.
2.
3.
4.
5.
6.
CONTROL LOCATION (1.2)
E2
1
2
3
44
5
6
REAR Input & Control

GENERAL OPERATIONS
Power Connecon
Before using your Bluetooth wireless system, you should connect Power Adaptor to AC outlet.
1.
2.
3.
Firmly and securely insert the DC plug of the adaptor to the DC IN jack on the rear of the unit.
Plug the adaptor’s AC plugs into an AC outlet.
Power on the unit by press the STANDBY buon on the front of the unit, power indicator will
light up.
When the unit is not operated by the AC power or unused for long
periods of the me, please remove the power adaptor from the wall
outlet and unplug from the main unit.
E3
AC Adapter’s Plug
AC Outlet

GENERAL OPERATIONS
Mic Connecon
Plug the microphone into the MIC1 or MIC2 jack on the rear side of your unit. Their output is
mixed with playback from BLUETOOTH, USB PLAYER or AUX IN.
On the microphone, there is an ON/OFF switch. Ensure that you set the switch to ON posion
during the usage.
The volume of microphone can be adjusted by the MIC VOLUME knob on the rear side of the
unit together with the speaker volume at the same me. (There is no independent micro-
phone volume control)
You can start to sing-along with the music playback.
1.
2.
3.
4.
E4

Locate the RCA cables (not included).
Connect audio cable’s white and red plugs to the white and red AUDIO OUT jacks of the back
panel of your unit.
Connect the other ends of the audio cable’s white and red plugs to the external unit’s audio
input white and red jacks.
1.
2.
3.
GENERAL OPERATIONS
Guitar Connecon
Plug the 6.3mm Guitar plug (or other Hi-Z instrument) into the GUITAR IN jack on the rear side of
your unit. Their output is mixed with playback from BLUETOOTH, USB PLAYER or AUX IN.
ECHO control
Adjust the ECHO control to enhance the singers’ voice for a concert hall effect.
Party lighng
Press PARTY LIGHT ACTIVATE buon to switch on the party light show. Press again to turn off.
If you are change the mode of light show, press the PAIRING buon.
AUDIO OUTPUT Connecon
Please follow the steps below to connect audio signal from the unit to your home audio system.
E5

Power on the unit by press the STANDBY buon, power indicator will light up and Bluetooth
indicator will flash, press and hold the PAIRING buon for about 5 seconds.
When pairing, remain within 3 feet of the unit.
Using the nave controls on your Bluetooth device, select the BC100 in your Bluetooth
sengs to pair. If your device requests a password, enter the default password “0000”.
Refer to the user’s manual for your specific device for instrucons on pairing and connecng
Bluetooth devices.
When successfully paired and connected, a sound “Connected” will issue from the unit and
the Bluetooth indicator will remain lit.
Aer inial pairing, the unit will stay paired unless unpaired manually by the user or erased
due to a reset of the device. If your device should become unpaired or you find it is unable to
connect, repeat the above steps.
1.
2.
3.
Pairing a Bluetooth Device for the First Time
BLUETOOTH OPERATIONS
Playing Audio Wirelessly
Aer pairing to a Bluetooth device, use the nave controls on the connected Bluetooth Device
to select a track.
Play, pause or skip a selected track using the nave controls on the connected Bluetooth Device.
Audio played through the connected Bluetooth Device will now be heard through the speakers.
Adjust the VOLUME control to obtain the desired volume level.
Press STANDBY buon again to turn off the unit.
1.
2.
3.
4.
5.
E6

Plug one end of a 3.5mm audio input cable (not included) into the AUX IN input on the rear of
the unit, and plug the other end of the cable into the audio output on the external music
player or other source.
Note: Make sure your external music player is turn ON.
Press the STANDBY buon to power the unit on and Power indicator will light up.
Start playing the device you plugged into AUX IN input. Their output is mixed with playback
from BLUETOOTH, USB PLAYER or MIC IN.
Slowly adjust both the volume controls of the unit and the external device unl you reach a
comfortable listening level.
Press STANDBY buon again to turn off the unit. Remember to shut down the external player
power.
1.
2.
3.
4.
5.
AUX-in OPERATIONS
USING SHOULDER STRAP
You can play other music sources (iPod, MP3 or other digital audio players) through the speakers of this
unit by connecng the AUX IN JACK to your external player’s audio out jack or headphone jack
Use SHOULDER STRAP (included) to connect right and le BELT CLIP on top side of unit. You can easy to
carrying.
If you are connected to the Line Out Jack of your external device then you only need to adjust
the volume control on the unit. If you’re connected to the Headphone Jack of your external
device, then you may need to adjust both the volume control of your external device and the
BC10 to obtain the most desirable volume seng.
If you use AUX IN funcon when playing Bluetooth audio, AUX IN audio will be mixed when
the audio cable is plugged in. Unplugging the audio cable will resume Bluetooth audio. We
suggest you to stopped playback or disconnected the Bluetooth device when playing music
via Line In mode.
NOTE:
E7

1.
2.
3.
4.
Connecng a power adaptor (see “Power connecon”) into the main unit.
USB “CHARGER” port can’t control to off by STANDBY buon of the unit.
Plug one end of the USB cable (not included) into the USB ”CHARGER” Port located on the
back of the unit. Plug the other end of the cord into the device you wish to charge.
Observe the baery charge indicator on your device and the charging will start immediately.
Unplug the cable when your device is charged.
1.
2.
3.
4.
CHARGING YOUR PORTABLE DEVICE
Energy Saving (APS: Auto Power off System)
This unit features a USB “CHARGER” port for charging your portable device (iPod, iPhone, Android phone,
etc.) when used with the USB charging cord that came with your device.
Before charging, please refer to the user manual of the device you wish to charge to make sure the
charging current requested does not exceed 1A (1000mA) of charging current. Overloading the charge
The USB “CHARGER” port of this unit supplies a DC 5V output at 1000mA maximum current to
charge your portable device baery and it cannot support any other voltage range.
Make sure the device you want to charge has a baery charge rang of DC 5V only.
The USB “CHARGER” port of this unit is designed for smart phone or portable device baery
charging only and it cannot support data transfer or connect to computer.
Do not connect the USB port of this unit to other external power charger USB ports, it may
damage both units and void the warranty.
1.
2.
3.
The unit will automacally switch to Standby mode aer 15 minutes following situaons described as below:
In Bluetooth mode: if there is no connect or Bluetooth Device playback stops.
In MIC 1, 2 input: if microphones are switch to OFF.
In AUX input: external player playback stops.
Press STANDBY buon once again to turn on the unit. APS funcon is for energy saving
purpose
CAUTION:
1.
2.
3.
Some smart phones and portable devices use proprietary USB connecons and circuitry, so
they may not charge when plugged into the USB port. Please refer to your device user manual
before you aempt to charge them.
It is normal for the unit to be warm while the USB port is in use and charging your smart
phone or portable device.
Do not charge your smart phone over 12 hours connuously.
NOTE:
E8

TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE AND SOLUTION REMEDY
No Charging Portable device is not installed properly.
Portable device is locked up or frozen.
Portable device baery has problem.
Remove your portable device from the charging cord
and check for obstrucon on the connectors.
Please make sure your portable device is working
properly before plugging into the unit.
Please refer to your portable device manual for details.
Check the connecon or the Power Adaptor.
Try the unit on another outlet.
Turn the volume control to increase the sound level.
Pairing your Bluetooth device according to the
“Pairing a Bluetooth Device for the First Time”
secon.
Relocate the unit within Bluetooth operang range
(30 feet).
Increase the volume of your Bluetooth device.
Increase the volume of the unit to turn to your wish..
Adjust Mic Level control to max, and then re-adjust to
a comfortable level.
Switch Mic to the ON posion.
Securely connect the Mic to the Mic jack.
Adjust the volume knob.
Clear contacts pins and connect again.
No Sound Power Adaptor disconnected or loose.
The AC outlet has not power.
Volume set too low.
No sound from Mic.
No sound in AUX mode
Mic. Level control set at too low.
Mic Is off.
The Mic is not connected to the Mic jack
securely.
Volume at minimum.
External device not connected properly.
No sound when playing
audio via Bluetooth
Your Bluetooth device has been paired properly.
The unit placement out of range.
The volume control of your Bluetooth device is
set at too low.
The volume control of the unit is set at too low.
E9

All features and specificaons are subject to change without noce.
Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European
countries with separate collecon systems).
This symbol on the product or on its packaging indicates that this product shall not be treated as household
waste. Instead it shall be handed over to the applicable collecon point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potenal negave
consequences for the environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will help to conserve natural resources. For more detailed
informaon about recycling of this product, please contact your local Civic Office, your household waste disposal
service or the shop where you purchased the product.
SPECIFICATIONS
Power Requirement:
AC/DC Adaptor
AC Input 100-240V ~50/60Hz
DC Output DC 12V 2A
Bluetooth: Bluetooth Specificaon version 2.1
Support profile A2DP
USB Charging DC 5V 1A
Audio Power output: 15 W (RMS)
Speaker: 4 Ohms.
10.2 cm. x1
4.1 cm. x1
Dimensions: 26 cm(H) x 20.6 cm(W) x 20.6cm(D)
Weight: 1.7 Kg
E10
Microphone 600 Ohm Impedance w/6.3mm Dynamic microphone
