Ideal Warehouse COBALT User manual

COBALT (SCA14000)
INSTALLATION MANUAL
Read the manual thoroughly before
operation and retain for future
reference.
REV SCA14000-IM-01

1
DISCLAIMER -------------------------------------------------------------------- 2
SAFETY PRECAUTIONS -------------------------------------------------- 3-6
FEATURES AND SPECIFICATIONS -------------------------------------- 7
WHAT’S INCLUDED ----------------------------------------------------------- 8
INSTALLATION BOM LIST --------------------------------------------------- 9
INSTALLATION REMARKS -------------------------------------------- 10-12
ELECTRICAL SUPPLY REMARKS -------------------------------------- 13
INSTALLATION INSTRUCTIONS ------------------------------------ 14-19
CONCRETE CEILING --------------------------------------- 14-17
I-BEAM CEILING --------------------------------------------- 18-19
CARE AND MAINTENANCE ----------------------------------------------- 20
TROUBLESHOOTING -------------------------------------------------- 21-22
SCA14000 Cobalt Installation Guide

SCA14000 Cobalt Installation Guide
2
DISCLAIMER
A printed copy of all the electronic materials is included in the unit packaging.
The ceiling installation of the unit should be performed by a certified professional.
Read the label on the unit, operation and installation manuals before use and make sure you follow all the
precautions outlined in the manuals.
The manufacturer disclaims all liability for damage or injury incurred by disregarding the instructions in this
document, negligence in the installation, use, maintenance, or repair of the product identified in this document, or
by failure to strictly abide by these safety precautions and instructions.
The product's user is always totally responsible for adhering to any local safety laws and regulations that may be
in effect.
INTENDED USE
The SCA14000 Air Purifier is intended to remove particles from the air.
Using attachments, filters and/or any other components not recommended and approved by Surgically Clean Air™
will void the warranty.
For Commercial or Industrial Use Only.
DIRECTIONS FOR USE
Follow the instructions to ensure proper installation. The display panel will turn on and the “Surgically Clean Air™”
LED will light up if the unit is powered on.
DISPOSAL INSTRUCTIONS
Dispose of filters according to local regulations based on the location of use (e.g., medical waste if used in a medical
setting such as dental clinics, laboratories, etc.).

3
SAFETY PRECAUTIONS
FIRST AID INSTRUCTIONS
In case of injury, clean the area using soap and warm water, apply antibiotic ointment and a bandage, and seek
immediate medical attention.
OPERATING ENVIRONMENT CAUTIONS
•DO NOT place in rooms with high heat, damp, or wet places.
•DO NOT use outdoors.
•DO NOT use extension cord with this fan.
•Not for use in kitchens.
•DO NOT remove (or attempt to remove) any part of the unit except for the filters.
•Best operating environment is 50 -104 °F or 10 – 40 °C.
•Ensure the unit is level. Never use when it is tilted.
•Use only a 120-volt outlet with a grounding wire receptacle.
•To reduce the risk of electric shock, this equipment has a grounding-type plug that has a third (grounding) pin.
This plug will only fit into a grounding-type power outlet. If the plug does not fit into the outlet, contact qualified
personnel to install the proper outlet. DO NOT alter the plug in any way.
WARNING
–TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the service disconnecting means cannot be locked,
securely fasten a prominent warning device, such as a tag, to the service panel.
SCA14000 Cobalt Installation Guide

4
SAFETY PRECAUTIONS
WARNING
–THIS DEVICE SHOULD NOT BE USED IN A CONSTRUCTION ZONE. Extensive amounts of particulates such
as construction dust and debris will clog up the filter and impact the efficiency of the unit. If construction needs to
be conducted in an area where Cobalt units are installed, it is recommended that the unit is turned off. After the
construction is concluded in the area, units are to be vacuumed and filters replaced.
UNIT OPERATION CAUTIONS
•This manual's contents must be thoroughly understood by anyone working on or with the product. Operators and
personnel must adhere to the contents of this manual.
•Never change the sequence of the operations to be carried out.
•Always keep the manual in the vicinity of the product.
•DO NOT insert fingers or foreign objects into the intake or air outlet.
•Keep hair, loose clothing, fingers, and all parts of your body away from openings and moving parts.
•In the event the machine starts to make excessive vibrations or noise, overheats, or starts to smell, stop using the
equipment immediately. Turn off the machine and disconnect the power and contact the manufacturer.
•DO NOT use the air purifier if the power cord or plug is damaged or the connection to the outlet is loose.
•When removing the plug, always hold the plug and never pull by the cord.
•DO NOT use the unit near hot objects, or where it may be exposed to steam or open flame.
•DO NOT obstruct the air inlets or outlets of the unit.
•To avoid the risk of fire, shock, and injury, DO NOT disassemble the unit. Contact a certified technician for service.
SCA14000 Cobalt Installation Guide

5
SAFETY PRECAUTIONS
WARNING
–TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT expose to water or rain.
–RISK OF FIRE OR ELECTRIC SHOCK, DO NOT use this equipment with any solid-state speed control device.
–TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, DO NOT use replacement parts
that have not been recommended by the manufacturer.
–TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, AND INJURY TO PERSONS, Cobalt unit must be installed
with brackets and screws that are marked in the installation manual to indicate the suitability with this model. Other
types of brackets and fasteners cannot be substituted.
–TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT bend the blade brackets when installing the brackets,
balancing the blades, or cleaning the fan. DO NOT insert foreign objects in between rotating fan blades.
–This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they DO
NOT play with the appliance.
–If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons
in order to avoid a hazard.
SCA14000 Cobalt Installation Guide

6
SAFETY PRECAUTIONS
CARE AND MAINTENANCE/ SERVICING CAUTIONS
WARNING
–RISK OF FIRE. Never operate the air purifier in a space that contains flammable gases. Never use the equipment
to extract or filter flammable, blazing or burning particles, chemicals, or liquids. Never use the unit to extract or filter
hostile vapors or sharp particles.
–RISK OF ELECTRIC SHOCK. These servicing instructions are for use by qualified personnel only. DO NOT perform
any servicing other than that contained in the operating instructions unless you are qualified to do so.
–HIGH VOLTAGE INSIDE. Disconnect power before installation, servicing or replacing filters.
CAUTION – AUTOMATICALLY OPERATED DEVICE –To reduce the risk of injury disconnect from power supply
before servicing.
SCA14000 Cobalt Installation Guide

7
FEATURES AND SPECIFICATIONS
The device features:
-Automatic Proximity Sensor On/Off
-Automatic Timer
-Remote Control
Model No . SCA14000–2x4
Power Requirement 120V, 60 Hz
Rated Power 250 W, 2.1A
Fan Motor 310 VDC, 0.98 A, 113 W
Dimensions (L) 1245.0 mm x (W) 636.0 mm x (H) 360.0 mm
Weight 45 kg
Model No . SCA14000–2x2
Power Requirement 120V, 60 Hz
Rated Power 75 W, 1.1 A
Fan Motor 24 VDC, 1.14 A, 27.5 W
Dimensions (L) 636.0 mm x (W) 636.0 mm x (H) 255.0 mm
Weight 20.5 kg
SCA14000 Cobalt Installation Guide

8
WHAT’S INCLUDED
Below items are included with the SCA14000 air purifier:
1. Cobalt Unit
2. H13 Filters (x2), included in the unit
3. Mount Bracket (x4)
4. ¼” Screws (x8)
5. Remote Control
6. Remote Control AAA Battery (x2)
SCA14000 Cobalt Installation Guide

9
INSTALLATION BOM LIST (NOT INCLUDED IN PACKAGING)
Below items are required for the SCA14000:
NO. NAME QTY REMARK
INSTALLATION
TYPE
1 Hanging Bar 4 ¼” Threaded Rod
100+ lbs. rated
Concrete Ceiling/
I-Beam Ceiling
2 Expansion Bolt 4 ¼” Expansion Bolt
100+ lbs. rated
Concrete Ceiling/
I-Beam Ceiling
3 Washer 4 ¼” Fender Washer
Concrete Ceiling/
I-Beam Ceiling
4 Rubber Washer 4 ¼” Rubber Washer
Concrete Ceiling/
I-Beam Ceiling
5 Nut 4 ¼” Nut
*Lock Nut Recommended
Concrete Ceiling/
I-Beam Ceiling
6
Metal-Clad Jacket for
power cord, Plenum
Rated
As
Required
For plenum installation,
power cord MUST be rated
to local codes and
requirements.
Concrete Ceiling/
I-Beam Ceiling
SCA14000 Cobalt Installation Guide

10
INSTALLATION REMARKS
The SCA14000 is designed to be installed as a fixed built-in unit by a qualified installer. In addition to the following
instructions the SCA14000 shall be installed:
•In the United States, in accordance with the National Electric Code/State, ANSI/NFPA 70 and Municipal codes
and/or local codes.
•In Canada, in accordance with the Canadian Electric Code C22.1 - latest edition/Provincial and Municipal codes
and/or local codes.
UNPACKING
While unpacking the product please follow the instructions and markings on the packaging.
INSPECTION
After unpacking the air purifier and prior to installation, thoroughly inspect the unit for freight or cosmetic damage.
Report any damage immediately.
REQUIRED TOOLS
•Ladder/ Lift
•Work gloves and safety glasses
•Wire Stripper
•Screwdriver (Manual or Impact)
•Allen Key
•Level
•Hammer Drill
SCA14000 Cobalt Installation Guide

11
INSTALLATION REMARKS
•The Cobalt unit can be hoisted from the concrete ceiling or the I-beam.
•Ensure the unit is being installed level in both directions.
•Follow ceiling tile system manufacturer instructions for integration
compatibility.
•Install the filters after the building is completely clean of construction
debris and dust.
•Be sure to remove any plastic wrapping from the HEPA filters prior to
installing them in the unit and operating the equipment.
•If lift assist equipment is being used to lift the equipment to position,
ensure padding is placed under the unit to prevent damage and
unwanted scratches to the front mesh panel. Padding is available inside
the packaging.
•It is recommended that installation is performed by two people.
•Ensure the equipment is adequately supported at all 4 corners to
support the weight of the unit. If needed install supplementary hanger
rods on the existing supports (not supplied).
•A lubricant should not be used on any mounting screw.
SCA14000 Cobalt Installation Guide

12
INSTALLATION REMARKS
CHOOSING THE LOCATION
•Choose a location with the following conditions:
A. Indoor Space
B. Operating Temperature: 50 -104 °F (10 – 40 °C), Relative Humidity: <75%
•Built-in fixed units must be unobstructed from the front.
•For new installation, the installation work must be done by a qualified installer before the air purifier is moved
into place.
•It is recommended that Cobalt unit is positioned centrally within a room. It is important that the intake side of
the unit is away from the supply of the HVAC system. To improve air quality in the room, the unit should circulate
and filter the existing air in the room, not the fresh air supplied by the HVAC system. Likewise, the position of
the exhaust side of the unit should be away from the return ducts of the HVAC system. This is to ensure that
the clean air coming from the unit is not immediately taken out of the room by the HVAC system.
WARNING
–SUPPORT DIRECTLY FROM THE BUILDING STRUCTURE IF INSTALLED IN THE CEILING.
–TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS OBSERVE THE
FOLLOWING:
a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes
and standards, including fire-rated construction.
b) When cutting or drilling into a wall or ceiling, DO NOT damage electrical wiring and other hidden utilities.
–MAKE SURE THE POWER IS OFF BEFORE ATTEMPTING INSTALLATION.
SCA14000 Cobalt Installation Guide

13
ELECTRICAL SUPPLY REMARKS
•The customer has the responsibility to ensure that the unit installation is in compliance with all national and
local electrical and building codes and ordinances. The electrical supply which the unit is designed for is
120VAC, 60 Hz.
•All wiring and materials must comply with all National/ State/ Municipal and/or local codes and ordinances
including but not limited to ANSI/NFPA 70 and Canadian Electric Code C22.1.
•The receptacle shall be accessible and connected to an electrical supply circuit with a fuse or breaker rated for
15.0 Amps. Receptacles shall be located to avoid physical damage to the flexible cord.
•No other appliances should be connected to the air purifier supply circuit.
WARNING – If the maximum ampere rating is more than 50 percent of the rating of the branch circuit,
connect only to a dedicated branch circuit. Do not use an extension cord with this equipment.
SCA14000 Cobalt Installation Guide

14
INSTALLATION INSTRUCTIONS
CONCRETE CEILING
1. Determine the installation location;
the reinforced concrete ceiling must be
selected for installation.
2. Draw rectangles at the installation
position with dimensions as follows：
-SCA14000–2x4: 1037mm*490mm
-SCA14000–2x2: 490mm*490mm
The four vertices of the rectangle are
the anchor points for installing the
expansion screw.
SCA14000 Cobalt Installation Guide

15
3. Use an electric hammer to drill holes
in four anchor points, ensuring a
minimum depth of two inches into the
slab and install expansion screws.
SCA14000 Cobalt Installation Guide

16
4. Drive the expansion screw, screw in
the threaded rod, and then screw in the
four Nuts, where nut 3 is next to nut 4.
The position of each screw should be
at the same height from the ceiling.
5. Load all the four cabinet hangers into
nut 3.
SCA14000 Cobalt Installation Guide

17
6. Using a level in both directions,
adjust nut 3 and nut 4 to ensure the
machine is leveled horizontally. Finally
tighten nuts 3 and 4 to fix the machine
in place, connect the power to
complete the installation.
SCA14000 Cobalt Installation Guide

18
CEILING INSTALLATION
I-BEAM CEILING
1. Determine the installation location;
the I-Beam structure must be directly
under the suspended ceiling opening
or desired area.
2. Draw rectangles at the installation
position with dimensions as follows：
-SCA14000–2x4: 1037mm*490mm
-SCA14000–2x2: 490mm*490mm
The four vertices of the rectangle are
the anchor points for installing the
expansion screw.
SCA14000 Cobalt Installation Guide

19
3. Load all the four cabinet hangers into
nut 3.
4. Secure the threaded rod to the I-
Beam as shown.
5. Using a level in both directions,
adjust nut 3 and nut 4 to ensure the
machine is leveled horizontally. Finally
tighten nuts 3 and 4 to fix the machine
in place, connect the power to
complete the installation.
SCA14000 Cobalt Installation Guide
