IdeaWorks Shirt Butler User manual

© 2019 Jobar International, Inc.
Carson, CA 90745
Made in China
For additional assistance or trouble-shooting help,
please email [e-mail]
Instructions
*8328 [040119]
TM

2. 3.
Intended Use
• This device is intended to be used to dry and press
textiles, for example blouses and shirts. Delicate textiles
such as wool or similar fabrics must not be pressed on
the presser. Always follow the care labels for the textiles!
Explanation of the Symbols
DANGER
WARNING
CAUTION
NOTE
Danger symbols: These
symbols indicate risks
of injury
(e.g. from electricity or
re).
Read through the
associated safety
instructions carefully
and follow them.
Caution: hot surfaces!
Protection class II
Read operating
instructions before use!
Supplementary
information
Warns of serious
injuries and danger
to life.
Warns of possible
serious injuries and
danger to life.
Warns of slight to
moderate injuries.
Warns of damage
to property
Explanation of the Signal Words
WARNING: This device is intended only for drying
textiles washed in water.
• The device is for indoor use only.
• The device is for household use only and is not intended for commercial
applications.
• The device should only be used as described in these instructions.
Safety Instructions
The device is equipped with safety features. Nevertheless, the
device may still present dangers if it is not used as intended.
CAUTION: hot surfaces! The motor unit / telescopic rod
will become hot during use. You should therefore not touch
it during or shortly after use.
• This product is not a toy. Keep away from children.
• The device must always be switched o and disconnected from
the main power when it is not being used and before assembling,
disassembling or cleaning the device.
• Do not make any modi cations to the device.

4. 5.
• Allow the device to cool down completely before it is cleaned
and stored away. before it is cleaned
NOTE – Risk of Damage to Material and Property
• Never cover up the ventilation slots and do not insert any objects
into them.
• Lay the power cable in such a way that it does not become squashed
or bent and does not come into contact with hot surfaces (also
applies to the hot surfaces of the device!).
• Never pull or carry the device by the power cable. When you pull it out
of the plug socket, always pull on the power plug and never the
power cable!
Parts & Device Overview
WARNING – Danger of Suffocation! Keep children and animals away
from the packaging material.
• Never remove the rating plate and any warning lables!
DANGER – Danger of Electric Shock from
WARNING – Danger of Electric Shock from Damage
and Inappropriate Use
CAUTION – Danger of Injury
1Hanger
2Telescopic rod
3Drip protection
(premounted on the telescopic rod)
4Fan Opening
5Motor unit
6Ventilation slots
7Timer Knob (5 – 30 minutes)
Not shown:
• Nylon balloon
• 5 x clamps with integrated
weight
• Mains cable with mains plug
WARNING – Danger of Fire
• Use the device only in closed rooms.
• Do not use the device in rooms with high humidity.
• Never immerse the device, cable or plug in water or other liquids.
• Should the device fall into water, switch o the power supply
immediately. Do not attempt to pull it out of the water while it is still
connected to the mains power!
• Steam may rise up during operation. For this reason, do not place the
device under other electronic devices.
• Always switch o the device  rst before unplugging from the outlet.
• Do not use the device in conjunction with extension cables.
• The device must not be moved during use.
• Do not use the device in rooms containing combustible materials
• Do not connect the device with other high wattage products to a
mul-tiple socket in order to prevent overloading and a possible
short circuit.

6. 7.
Assembly
Use
1. Insert telescopic rod (2) into the recess on the top of the motor unit (5).
2. Place the hanger (1) onto the telescopic rod (2). When you do this,
make sure that the slight bend in the hanger (1) points forward. The
drip protection (3) must be located directly above the fan (4). It
prevents any water that may drip down from being able to get into
the fan (4).
3. Attach the nylon balloon:
– Pull it over the hanger (1). When you do this, make sure that the side
with the hole line points forward.
– Pull the small elastic cord at the top over the collar section on the
hanger (1).
– Pull the large elastic cord at the bottom over the motor unit.
• Always place the device with clear space above it and on all sides on a
dry, at, solid and heat-resistant surface.
• It is essential that you follow the care labels for the textiles to be dried!
NOTE!
1. Set the height you want. To
do this, open the clip
underneath the hanger and
pull out the telescopic rod
(2) and then close the clip.
3. Pull the garment which is to be pressed over
the nylon balloon and the hanger (1) and
button up the buttons if necessary. Make sure
that
– the collar is tted over the collar section
– the arms of the nylon balloon t properly
in the sleeves of the garment and are not
twisted or scrunched up,
– all buttons on the garment (including on the
sleeves) are button up.
2. The nylon balloon should
wrap around the motor
unit so that it can fully inate
4. Spread the clamps along the bottom of the garment so that it is
evenly weighed down and will not go out of shape when the nylon
balloon is inated.
5. Plug the unit into an electrical outlet.
6. Turn the timer knob (7) clockwise and set it to the length of time you
want. Each LED light represents 5 minutes.
7. Once the nylon balloon has in ated, straighten out the garment
and smooth it down.
8. When the set time is completed, the device switches o
automatically. The drying /pressing process can be interrupted at any
time by turning the timer knob (7) to the starting position.
9. Remove the garment from the nylon balloon and hanger (1).
10. Unplug the unit from the electrical outlet and allow the device to
cool down completely.

8. 9.
Cleaning and Storage
NOTE!
Do not attempt to repair a defective electrical device yourself!
• Before cleaning, read the safety instructions in the “Safety
Instructions”chapter!
• Never immerse the device, or electrical cables in water or other liquids!
• Do not use any corrosive or abrasive cleaning agents or cleaning pads
to clean the device. These can damage the surface.
• Clean the device and the nylon balloon if necessary with a slightly
damp cloth and a little mild detergent if required. Then wipe down fully
with a dry cloth.
• Allow all parts to dry completely before you put them away.
• Store the device in a clean, dry place that is protected from sunlight and
is not accessible
to children and animals.
Troubleshooting
If the device does not work properly, check whether you are able to
rectify the problem yourself. If the problem cannot be solved with the
steps that are listed.
Tips
• The device is intended primarily for machine-spun laundry! If hand-
washed or nonmachine-spun laundry is to be pressed, rst allow it to
dry out a little rst.
• The drying / pressing process takes around 10 minutes for a
spun-dried shirt. However, the length of time can vary depending on
the material and thickness of the material. We recommend that you
start with a shorter time and extend it if necessary.
• The nylon balloon can be enlarged or reduced in size with the aid
of the zip fasteners. For smaller sizes, the zip fasteners should be closed.
For larger sizes, the zip fasteners should be opened on both sides.
• Wide-spaced buttons may result in the button strip crimping
slightly during pressing. This area will need to be smoothed down by
hand immediately after the pressing process.

10. 11.
Disposal
Technical Data
Article number:
Model number:
Voltage supply:
Power:
Protection class:
00384
EL17001-00100
120 V ~ 60 Hz
1800W
II
The packaging material is recyclable. Dispose of the packaging in an environmentally
friendly manner and take it to a recycling centre.
Dispose of the device in an environmentally friendly manner. It should not be disposed of
in the normal domestic waste. Dispose of the device at a recycling centre for used electrical
and electronic devices. More information is available from your local authorities.
Problem
The device does
not work. The
LEDs do not
light up.
• Is the plug socket defective? Try another plug
socket.
• Is the device switched on? Set the timer knob (7)
to a time.
• Are the ventilation slots (6) covered up or blocked?
Free up the ventilation slots (6).
• The device has an automatic safety switch-o
function. It switches o automatically if it overheats.
Allow the device to cool down and switch it on
again.
• Has the device fallen over? The device has a pro-
tective switch that is activated if the device falls
over. Set the device up again and switch it back on.
• Are the ventilation slots (6) covered up or blocked?
Free up the ventilation slots (6).
• You might notice a slight odor caused by produc-
tion residues the rst time you use the device.
However, this is harmless and will cease as you use
the device.
The device
switches
o suddenly.
Unusual noises
Odor produced
Possible cause / solution
