Idis DC-B1001 User manual

Powered by
DC-B
Series
Operation Manual
DC-B1001 / DC-B1101
DC-B1103 / DC-B1203

2
This is a basic operation manual for installation and use of an IDIS network camera. Users who are using this
product for the first time, as well as users with experience using comparable products, must read this operation
manual carefully before use and heed to the warnings and precautions contained herein while using the product.
Safety warnings and precautions contained in this operation manual are intended to promote proper use of the
product and thereby prevent accidents and property damage and must be followed at all times. Once you have
read this operation manual, keep it at an easily accessible location for future reference.
•The manufacturer will not be held responsible for any product damage resulting from the use of unauthorized parts
and accessories or from the user's failure to comply with the instructions contained in this operation manual.
•It is recommended that first-time users of this network camera and individuals who are not familiar with its use seek
technical assistance from their retailer regarding product installation and use.
•If you need to disassemble the product for functionality expansion or repair purposes, you must contact your retailer
and seek professional assistance.
•Both retailers and users should be aware that this product has been certified as being electromagnetically compatible
for commercial use. If you have sold or purchased this product unintentionally, please replace with a consumer
version.
Safety Symbols
Symbol Type Description
Warning An important instruction or set of important instructions that can lead to severe injury or
even death if not followed.
Caution An instruction or set of instruction that can lead to personal injury and/or property
damage if not followed.
In-Text
Symbol Type Description
Caution Important information concerning a specific function.
Note Useful information concerning a specific function.
Before reading this manual

Before reading this manual
3
Safety Precautions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future
reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not
use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval
of the manufacturer as such additions may result in the risk of fire,
electric shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Placing and Accessories
Do not place this equipment on an wall or ceiling that is not strong
enough to sustain the camera. The equipment may fall, causing
serious injury to a child or adult, and serious damage to the
equipment. Wall or shelf mounting should follow the manufacturer's
instructions, and should use a mounting kit approved by the
manufacturer.
This equipment and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
equipment and cart combination to overturn.
Do not place this equipment in an enclosed space. Sufficient
ventilation is required to prevent an increase in ambient temperature
which can cause malfunction or the risk of fire.
7. Power Sources
This equipment should be operated only from the type of power
source indicated on the marking label. If you are not sure of the
type of power, please consult your equipment dealer or local power
company.
8. Power Cord
Operator or installer must remove power and TNT connections before
handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm,
or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the equipment due to lightning
and power-line surges. If thunder or lightning is common where the
equipment is installed, use a surge protection device.
10. Overloading
Do not overload wall outlets and extension cords as this can result in
the risk of fire or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this equipment
as they may touch dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill liquid of any kind on
the equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all servicing
to qualified service personnel.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have hit the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the
operating instructions, adjust only those controls that are covered
by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work
by a qualified technician to restore the equipment to its normal
operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance —
this indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service technician
has used replacement parts specified by the manufacturer or that
have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask the
service technician to perform safety checks to determine that the
equipment is in proper operating condition.
16. Field Installation
This installation should be made by a qualified service person and
should conform to all local codes.
17. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
18. Tmra
A manufacturer’s maximum recommended ambient temperature
(Tmra) for the equipment must be specified so that the customer and
installer may determine a suitable maximum operating environment for
the equipment.

Before reading this manual
4
FCC Compliance Statement
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE,
PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN WHICH
CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. THIS CLASS OF DIGITAL APPARATUS
MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE CAUSING EQUIPMENT REGULATIONS.
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.
Copyright
© 2013 IDIS Co., Ltd.
IDIS Co., Ltd. reserves all rights concerning this operation manual.
Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly
prohibited.
Contents of this operation manual are subject to change without prior notice for reasons such as functionality
enhancements.
Registered Trademarks
IDIS is a registered trademark of IDIS Co., Ltd.
Other company and product names are registered trademarks of their respective owners.
This product contains software built partially on open-source content. Codes for the corresponding open-
source content are available for download. For more information, refer to the software CD (OpenSourceGuide\
OpenSourceGuide.pdf) or the open source guide accompanying this operation manual.

5
1
2
3
Part 1 – Introduction .................................7
Product Features ...............................................7
Accessories ...................................................8
Overview .....................................................9
Front ................................................................9
Side .................................................................9
Top .................................................................10
Back ...............................................................12
Installation ...................................................14
Manual Iris Lens .......................................................14
DC Type Auto Iris Lens ..................................................14
CS-Mount Lens .......................................................15
C-Mount Lens ........................................................15
Dimensions ..........................................................15
Part 2 - Camera Connection..........................16
With DirectIP™ NVR-based Layout.................................16
With non DirectIP™ NVR-based Layout .............................17
Part 3 - Remote Setup ..............................18
Camera Protocol ..............................................18
Switching Protocols ....................................................18
Remote Setup ................................................19
Quick Setup ..................................................19
System ......................................................20
General .............................................................20
Date/Time ...........................................................21
User/Group ..........................................................21
Network .....................................................22
IP ADDRESS .........................................................22
FEN ................................................................23
Port/QoS ............................................................24
Bandwidth Control .....................................................25
Table of Contents

Table of Contents
6
Security .............................................................26
IEEE 802.1X ..........................................................26
Video .......................................................27
Camera .............................................................27
Streaming............................................................30
Webcasting ..........................................................31
MAT ................................................................32
Privacy Masking .......................................................32
Audio DC-B1103 / DC-B1203 only .................................33
In/Out...............................................................33
Event Action ..................................................33
Alarm Out DC-B1103 / DC-B1203 only .....................................34
Email ...............................................................34
Remote Callback ......................................................34
Audio Alarm
DC-B1103 / DC-B1203 only ....................................35
FTP Upload ..........................................................35
Record
DC-B1103 / DC-B1203 only .......................................36
Event .......................................................38
Alarm In DC-B1103 / DC-B1203 only .......................................39
Motion Detection ......................................................39
Trip-Zone ............................................................41
Audio Detection
DC-B1103 / DC-B1203 only .................................42
Tampering ...........................................................42
System Event .........................................................43
Part 4 - IDIS Web ...................................45
Web Live Mode ...............................................46
Web Search Mode
DC-B1103 / DC-B1203 only .......................49
Part 5 - Appendix...................................51
Setup Menu Tree (Remote Setup) ..................................51
DC-B1001 / DC-B1101 .................................................51
DC-B1103 / DC-B1203 .................................................51
Troubleshooting ...............................................52
Specifications .................................................53
Index .......................................................56
4
5

7
Product Features
DC-B1001 / DC-B1101/DC-B1103/DC-B1203
is an IP-based network camera that compresses
and transmits video over ethernet. You can use the
IDIS Discovery program to change network camera
settings or the IDIS Solution Suite Compact program
to manage multiple network cameras. In addition, the
embedded web server (IDIS Web) lets you remotely
view live video or scan recorded video using a web
browser. Alternatively, you can use the provided
remote access program to manage network cameras
and view/record video.
In this operation manual, the term Remote System
refers to the computer on which the remote program
(IDIS Solution Suite Compact or IDIS Web) is
running.
•Supports DirectIP mode working with a DirectIP™
NVR that allows users to simply set up all required
configurations without a PC
•Supports ONVIF protocol (Profile S)
•Multi-streaming for high-resolution and high-quality
video monitoring and simultaneous recording in real-
time as well as flexible configurations for those
•Supports H.264 video compression and M-JPEG
still image compression algorithms
•Supports 4-stage video compression rate and
multiple compression resolutions
•Bidirectional audio communication support for
remote audio dialog
DC-B1103 / DC-B1203 only
•Video stream buffering to counter pre-/post-event
buffering and network delays for improved network
recording reliability
•Remote monitoring via web browser or remote
software
•Automatic web casting code (HTML) generation
•Up to 10 simultaneous remote monitoring
connections
•IP filtering, HTTPS, SSL, IEEE 802.1X, and
configurable user authority levels for greater security
•Network bandwidth limitation and MAT features for
more efficient use of network bandwidth
•Easy network access via UPnP (Universal Plug and
Play) function and embedded mDNS (Multicast
DNS) protocol
•Wide dynamic range compensation (Digital WDR)
for improved video quality in high-contrast situations
•Slow shutter support for improved low-lighting video
capture performance
•Day & Night feature (built-in IR cut filter changer)
DC-B1103 / DC-B1203 only
•Quick and easy firmware upgrade over the network
•Redundant firmware and auto recovery features for
improved system stability
•Network-based integrated management of multiple
network cameras
•Multiple event detection modes: Alarm-in, motion
detection, trip zone, audio detection, and tampering
(alarm-in and audio detection modes are available
for
DC-B1103 / DC-B1203 models only)
•Backup storage on a microSD card as a safeguard
against data loss during network interruptions
DC-
B1103 / DC-B1203 only
•Supports 12 VDC and PoE (Power over Ethernet)
•Supports pan/tilt driver control via RS485 interface
DC-B1103 / DC-B1203 only
•Supports C/CS mount lens connection
•Video out feature (selectable NTSC and PAL)
•Features a built-in microphone
DC-B1103 / DC-
B1203 only
Remote monitoring and recording via multistreaming
are available using the IDIS Solution Suite Compact
program. For more information on using IDIS
Solution Suite Compact, refer to its operation
manual.
There is a limit to the number of users allowed to
connect remotely via the Internet at the same time.
Part 1 – Introduction

Part 1 – Introduction
8
Accessories
Upon purchasing the product, check inside the box to make sure all the following accessories are included.
External appearances and colors of the accessories may vary depending on the model.
Network Camera C-Mount Ring
Installation Parts Protective Cover (attaches to camera)
DC Adapter (12V) / Ferrite Core Operation Manual CD
Quick Guide

Part 1 – Introduction
9
Overview
Product color and design may vary depending on
the model.
Front
1
2
1Built-in Microphone
DC-B1103 / DC-B1203
only
2Image Sensor
1Built-in Microphone
Receives audio.
DC-B1103 / DC-B1203 only
2Image Sensor
Converts optical data into electronic signals.
If the lens is not attached to the camera, use the
protective cover to cover up the image sensor.
Side
1
2
3
4
5
1Protective Cover
2C-Mount Ring
3Back Focus Adjustment Ring
4Mount Bracket
5SD Card Slot
DC-B1103 / DC-B1203 only
1Protective Cover
If the lens is not attached to the camera, use the
protective cover to protect the image sensor.
2C-Mount Ring
Attach the c-mount ring to the camera if using a
c-mount lens.
3Back Focus Adjustment Ring
Undo the screw and turn the ring clockwise or
counterclockwise to adjust the back focus. Once
finished, tighten the screw to lock the back focus
in place.
4Mount Bracket
This bracket can be installed on either top
or bottom of the camera. Use 1/4–20 UNC
(20-thread), 2.5mm +/- 0.2mm (ISO standard) or
0.197 (ASA standard) screws to attach the mount.

Part 1 – Introduction
10
5SD Card Slot
DC-B1103 / DC-B1203 only
Pull on the connection cover and then insert a
microSD card into the slot. (An SLC (Single Level
Cell) or MLC (Multi Level Cell) card by SanDisk or
Transcend is recommended)
•Do not remove the SD card while the system
is in operation. Removing the card while the
system is in operation can cause the system
to malfunction and/or corrupt data stored on
the SD card.
•An SD card is a consumable product with a
finite service life. Prolonged use will damage
the card's memory sectors and result in data
loss or memory card failure. Test the SD card
regularly and replace it whenever necessary.
Top
Alarm
GND 3
2
1
OUT
IN
RS485
-
8
9
+
Audio
GND
GND
3
2
2
1
OUT
IN
1
2
3
4
1RS485 Port
DC-B1103 / DC-B1203 only
2Audio I/O
DC-B1103 / DC-B1203 only
3Alarm I/O
DC-B1103 / DC-B1203 only
4Factory Reset Switch
1RS485 Port
DC-B1103 / DC-B1203 only
Connect a pan/tilt driver to this port. Connect the
driver's TX+/RX+, TX-/RX- to the network camera's
+/—. For more information on RS485 connections,
refer to the pan/tilt driver manufacturer's operation
manual.
2Audio I/O
DC-B1103 / DC-B1203 only
•Out: Connect an amplifier to this port (line out).
This device does not feature a built-in audio
amplifier unit and therefore requires the user to
purchase a separate speaker system with a built-
in amplifier.
•In: Connect an audio source (line in). A built-in
microphone is featured on the front.

Part 1 – Introduction
11
3Alarm I/O
DC-B1103 / DC-B1203 only
•Out: Connect an alarm out device's mechanical
or electrical switch to the alarm out port and
the GND (ground) connector. (Supported Types:
Active Low (open collector output), Electrical
Specs: 30mA sync current at 5 VDC)
•In: Connect an alarm-in device to this port.
(Mechanism: Choose between an NC (Normally
Closed) type or an NO (Normally Open) type)
Connect a mechanical or electrical switch to the
alarm in port and the GND (ground) connector.
Alarm in range is 0V to 5V. In order to detect
alarm input from an electrical switch, the signal
must be higher than 4.3V from an NC switch or
less than 0.3V from an NO switch and must last
for longer than 0.5 seconds.
4Factory Reset Switch
Restores the camera's default factory settings. For
more information, refer to the Factory Reset.
When inserting an , audio in/out, or RS485
connector, hold down the button and push the
connector in through the exposed hole. ( and audio
in/out apply to DC-B1103 / DC-B1203 models only)
Release the button and then gently pull on the wire
to ensure a secure connection. To disconnect the
cable, press down on the button again and pull the
cable out.
•Check your local laws and regulations on making
video or audio recordings. The user will be held
liable for any violation of the law. (Article 25-5 of
the Personal Information Protection Act: Operators
of image data processing devices may not
operate such devices for purposes other than as
originally intended during device installation, place
such devices at locations other than as originally
intended, or use such devices to record audio.)
•The network connector is not designed to be
connected directly with cable or wire intended for
outdoor use.
Factory Reset
Only use the factory reset switch to restore the
camera to its factory default settings.
A factory reset will clear all camera settings
configured by the user.
1 Shut off the power supply, insert a straight pin
into the switch hole, and press down on the reset
switch.
2 Hold the switch down and reconnect the power
adapter.
3 Once the device turns back on and its LEDs start
blinking, wait 5 seconds and then remove the pin.
4 The device will go through the resetting process
and reboot. All camera settings will be restored to
their factory defaults after the reboot.
It's also possible to do a factory reset by pressing and
releasing the reset switch while the camera is turned
on or using the IDIS Discovery program from a remote
location. A factory reset will reboot the system. For
more information on factory reset, refer to the IDIS
Discovery operation manual.

Part 1 – Introduction
12
I/O Connector
DC-B1103 / DC-B1203 only
Alarm
GND 3
2
1
OUT
IN
RS485
-
8
9
+
Audio
GND
GND
3
2
2
1
OUT
IN
Audio
GND Grounding
Out Audio Out
GND Grounding
In Audio In
Alarm
GND Grounding
Out
Alarm Out (Active
Low - Open Collector
Output)
In Alarm In
RS485 Connector
DC-B1103 / DC-B1203 only
Alarm
GND 3
2
1
OUT
IN
RS485
-
8
9
+
Audio
GND
GND
3
2
2
1
OUT
IN
Master Device Slave Device
+ →To →TX+/ RX+
- →To →TX-/RX-
Back
1
2
3
4
5
6
VIDEO
OUT
DC 12V
FGND NETWORK+
-
1Auto Iris Lens Connector
2Video Out
3Power
4Network Port
5Network LED
6Power LED
1Auto Iris Lens Connector
If using a DC type auto iris lens, connect the auto
iris jack.
The lens must have a long auto iris jack.
2Video Out
Connect he monitor.
Use these ports for previewing video and not
monitoring video.
3Power
•DC12V -/+: Connect the two wires of the power
adapter to these ports. Be careful not to cross
the + and - wires. Booting will commence once
connected to a power supply.
•FGND (Frame Ground): Used to ground the
device.

Part 1 – Introduction
13
4Network Port
Connect a network cable with an RJ-45 connector
to this port. If using a PoE switch, you can supply
power to the camera using an ethernet cable. For
more information on PoE switch use, refer to the
switch manufacturer's operation manual. You can
configure, manage, and upgrade this camera and
monitor its images from a remote computer over
the network. For more information on network
connection setup, refer to the IDIS Discovery
operation manual.
5Network LED
Indicates the network connection status. For more
information, refer to the LED Status Indications.
6Power LED
Indicates the system's operating status. For more
information, refer to the LED Status Indications.
Press down on the button and insert the video out/
power connector cable into the opening. Release the
button and then pull on the cable slightly to ensure it
is held securely in place. To disconnect, press down
on the button again and pull the wire out.
•When switching over from 12 VDC to PoE as the
power source, the system will be rebooted once
the power adapter is disconnected.
•Ground the power port's frame ground terminal
before use.
•Organize the power cable so that it will not cause
people to trip over or become damaged from
chairs, cabinets, desks, and other objects in the
vicinity. Do not run the power cable underneath
carpet or a rug or plug the cable into a power
outlet shared by a number of other devices.
•Wrap the camera-end of the network cable twice
around the provided ferrite core (28A2024-0A2,
Laird Technologies) to subdue electromagnetic
wave generation.
Ferrite Core
LAN Cable
LED Status Indications
LED Status Description
Power LED
Off Power not
connected
Flashing Booting
On Powered on
Network LED On Not connected to
network
Power LED/
Network LED
Flashing
(sequentially)
Software upgrade
in progress
Power Connector
DC12V + Power connection (Check + and -
markings)
DC12V -
FGND Frame grounding

Part 1 – Introduction
14
Installation
The lens must be purchased separately. If you'd like
to purchase a lens, contact your camera retailer. This
camera supports manual iris lenses and DC type auto
iris lenses in either CS-mount or C-mount format.
•Product color and design may vary depending on
the model.
•We recommend megapixel lenses for clearer and
higher resolution images.
•Video type auto iris lenses are not supported.
•Use a lens that weighs less than 450g. Heavier
lenses can cause the camera to lose its balance.
Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall off if the wall or
ceiling is not strong enough to support its weight.
Manual Iris Lens
1 Remove the protective cover from the camera.
2 Turn the lens in clockwise direction and mount it
on the camera.
3 Rotate the lens' iris ring to open up the iris and
then adjust accordingly.
DC Type Auto Iris Lens
1 Solder on the lens connection line to the connector
socket, if necessary. For more information about
soldering on the lens control wire, refer to the lens
manufacturer's operation manual.
1Connector
Socket Cover
2Iris Control Cable
3Connector
Socket
4Heat-Shrinkable
Tube
1Brake (Damp)
Coil -
2Brake (Damp)
Coil +
3Drive Coil +
4Drive Coil -
2 Remove the protective cover from the camera.
3 Turn the lens in clockwise direction, mount it on to
the camera, and connect the auto iris jack to the
auto iris lens connector.
The auto iris jack must be at least 20cm long in
order to connect it to the camera.

Part 1 – Introduction
15
CS-Mount Lens
1 Remove the protective cover from the camera.
2 Turn the lens in clockwise direction and mount it
on the camera.
C-Mount Lens
1 Remove the protective cover from the camera.
2 Turn the mount ring in clockwise direction and
mount the ring on to the camera.
3 Turn the C-mount lens in clockwise direction and
mount it on to the C-mount ring.
Dimensions
Front
75.62 mm
61.02 mm
70.90 mm
Side
129.32 mm
125.82 mm

16
Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite
Compact.
With DirectIP™ NVR-based Layout
DirectIP™ NVR
DirectIP™ Switch
Audio Out
Network Camera
Power
Power
IDIS Center
Remote Monitoring
VGA/HDMI
Monitor Out
Alarm Out
Sensor In
Audio In
DirectIP NVR makes it easy to use cameras without extra network configurations.
Each camera can be controlled via the DirectIP™ NVR setup menu, without any PC.
For detailed camera settings, please see the camera setting pages of DirectIP™ NVR manual.
Alarm In/Out, Audio In/Out and SD card recording are supported by TYPE 1 models only.
For users using the camera with DirectIP™ NVR connection, do not need to consider contents after page 16.
Part 2 - Camera Connection

Part 2 - Camera Connection
17
With non DirectIP™ NVR-based Layout
Network Camera
Network
Remote Monitoring
(IDIS Solution Suite
Compact or IDIS Web)
Remote Recording (IDIS
Solution Suite Compact)
microSD Card
Alarm Out
Sensor In
Audio Out
Audio In
Control the camera over the network from software installed on a computer.
Ideal for using the camera over the network from a remote location.
Alarm In/Out, Audio In/Out and SD card recording are supported by TYPE 1 models only.
The contents after page 17 are only for users using the camera with non DirectIP™ NVR connection or VMS
connection such as IDIS Solution Suite Compact.

18
Configure basic network camera settings and all other
system settings.
Screen images may vary depending on the model.
Camera Protocol
Camera supports DirectIP™ and IDIS protocols.
•DirectIP™ protocol:
- Using with a DirectIP™ NVR enables camera use
without the need to configure network settings.
- The DirectIP™ NVR also allows you to control all
camera settings directly from the NVR, without
the need for a computer.
For more information on configuring camera settings
from a DirectIP™ NVR, refer to the DirectIP™'s
operation manual.
•IDIS protocol:
- Control the camera over the network from
software installed on a computer or a separate
NVR.
- Ideal for using the camera over the network from
a remote location.
Switching Protocols
1 Launch the IDIS Discovery program and from the
list, select a camera whose protocol you wish to
change.
2 Click on the Setup icon and then select Setup
→ Protocol Setup.
•Alternatively, you can right-click on the mouse
and select Protocol Setup.
3 From the Protocol Setup screen, select the
desired protocol and then click OK.
4 This will activate the selected protocol. You
can check each camera's protocol on the IDIS
Discovery program.
This operation manual has been composed based
on IDIS protocol use.
Part 3 - Remote Setup

Part 3 - Remote Setup
19
Remote Setup
1 Launch the IDIS Discovery program and then from
the main screen, select a network camera whose
settings you wish to change.
2 Click on the Setup icon.
3 Select Remote Setup from the Setup menu to
load the Remote Setup screen. Alternatively,
you can select Network Camera from the main
screen and then right-click to access the Remote
Setup screen.
System settings can also be changed using a remote
program.
From the Remote Setup screen, select the
menu on the left to display the current settings.
Select an option under the menu to change the
corresponding settings. Once you have changed
the settings, click OK to apply the settings and
exit from the Remote Setup screen.
Quick Setup
DC-B1001 / DC-B1101
DC-B1103 / DC-B1203
Quick Setup allows you to set up System, Network,
Video, Audio, and other basic settings needed for
camera use. Audio feature is supported in
DC-B1103
/ DC-B1203
models only.

Part 3 - Remote Setup
20
System
Change the camera's system information, add users/
groups, and/or import/export settings.
General
•SYSTEM/GENERAL
- Language: Select the language you wish to use
for remote setup.
- Name: Enter a name for the camera. (Up to 31
alphanumeric characters, including spaces)
- Note: Enter a description for the camera.
- HW Version/SW Version: Indicates the camera's
hardware and software versions.
•Miscellaneous
- ONVIF Protocol: Select to enable ONVIF
protocol use. However, ONVIF Protocol is
available only to users belonging to the standard
user groups (Administrator, Operator, and
User).
•Setup
- Load Default Setup: Restores all settings other
than Date/Time to their factory defaults. Select
Include Network Setup to load default network
settings as well. For more information on network
setup, refer to the Network on page 22.
- Import Setup: Open a setup file and apply its
settings to the camera. Click on the button and
then select a setup file. Select Include Network
Setup to apply the file's network setup settings
(exc. FEN). For more information on network
setup, refer to the Network on page 22.
- Export Setup: Export the current settings as a
.dat file. Click on the button and then enter a file
name.
•Load Default Setup and Import Setup
options are available only to users belonging to
the Administrator group.
•When applying the settings of a setup file, do
not select the Include Network Setup option
if the network settings contained in the selected
file is currently being used by a different camera.
Doing so can interfere with establishing a
connection with the other camera.
•If IP Address, Admin Port, and/or SSL settings
have been changed, Remote Setup will
terminate after applying the current settings.
