Messoa NDR891 User manual

Mounting Installation Guide
NDF831/NDR891 Dome Camera
Rev A1

Mounting Installation Guide

Table of Contents
1. Introduction.............................................................................................3
Before Installation ....................................................................................3
2. Surface Mount.........................................................................................3
3. Cable Management Wall Mount.............................................................4
Dimensions – SAB755BP ........................................................................5

2

Mounting Installation Guide

1. Introduction
This mounting installation guide is intended to provide installers with basic
instructions of how to mount the NDF831/NDR891* dome camera (hereafter
referred to as the camera) using optional accessories from MESSOA. If you are using
other specialized mounting accessories or tools, always refer to the instruction
document supplied with that product.
Note: Always use the screws as instructed by this guide to ensure proper
installation.
*The appearance of the NDF831 and NDR891 are very similar. The NDF831 will be used as the
example in the illustration.
This guide will describe the following mounting methods:
Surface Mount
Cable Management Wall Mount
Before Installation
Before mounting the camera onto the bracket, please first secure the mount bracket
of your choice firmly at the desired position to a solid surface using appropriate
screws and plugs. Also make sure to route all the required cables properly.
2. Surface Mount
This mounting method requires no additional accessory. Refer to the user manual of
the camera for mounting instructions.
3

Mounting Installation Guide

3. Cable Management Wall Mount
Before beginning the following procedure, please make sure to have these items
ready:
Cable Management Wall Mount
Bracket (SAB755BP)
1. Use the appropriate metal
anchors/nuts (not provided) to
attach the SAB755BP to the
desired location.
2. Fasten the conduit adaptor to
the bracket. Then lock in the
adapter with the M4-0.7x15mm
screw provided with SAB755BP.
3. Pass the camera cables through
the conduit adapter and out of
the access hole of the wall
mount.
Note: Please do not connect the
cables at this point. It’s
suggested to make the
connection after step 4 is done.
4. Rotate the camera counter
clockwise to secure it onto the
conduit adapter.

M4-0.7x15mm screw
Conduit adapter
4

Mounting Installation Guide

5
Note: For waterproof it's suggested
to apply sealant to the conduit
adapter. You can do this before or
after you secure the camera to the
adapter.

Sealant
Dimensions – SAB755BP


