iDM AERO ILM 2-7 Guide

Modulation air-water-heat pumps
for Indoor Installation
DIE E
N
ER
G
IEFA
M
ILI
E
TECHNICAL DOCUMENTATION
INSTALLATION INSTRUCTIONS
HEAT PUMPS FROM AUSTRIA
www.idm-energie.at
812583 Rev.2 - Translation of original instructions
AERO ILM 2-7
AERO ILM 4-13
Additional Model:
HGL
with NAVIGATOR 2.0 Control

(C) IDM ENERGIESYSTEME GMBH
2.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
2
Contents
Contents
1. GENERAL DESCRIPTION 4
1.1. General information 4
1.2. Safety instructions 4
1.3. Transport and storage 4
1.4. Sound emission 4
1.5. Construction drying and floating screed heating 4
1.6. Service and maintenance 4
1.7. Cleaning 4
1.8. Ice-covering weather-shield grilles 5
1.9. Installation area 5
1.10. Information on environmental protection 5
1.11. Piping and pipe-wall-ducts 5
1.12. Installation of additional components 5
1.13. Standards and guidelines 5
1.14. Description 6
1.15. Application range 6
1.16. Scope of delivery 6
1.17. Accessories 6
2. TECHNICAL DATA 7
2.1. Dimensions of AERO ILM 2-7 and AERO ILM 4-13 7
2.2. Technical data 8
3. DIMENSIONING 10
3.1. Heating performance diagrams AERO ILM 2-7, according EN14511 12
3.2. Heating performance diagrams AERO ILM 4-13, according EN14511 14
3.3. Limitations of use 16
4. CONNECTIONS AND CABLE DUCTS 18
4.1. Cable and piping ducts 19
4.2. Hydraulic connections to the heat pump 19
5. INSTALLATION 20
5.1. Installation instructions 20
5.2. Heating connections 20
5.3. Condensation run-off 20
5.4. Air duct 21
5.5. Acoustic evaluation 21
5.6. Decoupling of buildings 24
5.7. Installation location 25
5.8. Space requirements and accessibility 25
5.9. Corner installation 26
5.10. Installation with a straight air duct 30
5.11. Installation with 90 ° air duct 33
5.12. Installation of flexible air hose - air outlet sideways 36
5.13. Installation of flexible air hose - air outlet to the top 40
5.14. Modification from the right-hand to left-hand outlet side 44
5.15. Opening front panel 44
5.16. Transport provisions 45

(C) IDM ENERGIESYSTEME GMBH Installation instruction AERO ILM 3
Contents
Contents
Important information on assembly and
operation of the heat pump. These in-
structions must be observed!
Space for the customer service
phone No.
6. HEATING CONNECTIONS 46
6.1. Requirements heating connections 46
6.2. Safety device 46
6.3. AERO ILM with unregulatet direct heating circuit and Hygienik without separating plate 47
6.4. AERO ILM with unregulated direct heating circuit and AQA 48
6.5. AERO ILM with Hygienic with separating plate and mixer circuits 49
6.6. AERO ILM with cooling buffer and hygienic with layer separate plate 50
6.7. AERO ILM with hygienic with layer separate plate and oil-/gas burner 51
6.8. AERO ILM HGL with unregulated direct heating circuit and Hygienik without separating plate 52
6.9. AERO ILM HGL with Hygienic with separating plate and mixer circuits 53
6.10. AERO ILM HGL with Hygienik without separating plate and heating buffer 54
6.11. AERO ILM HGL with Hygenik with separating plate and cockle stove 55
6.12. AERO ILM HGL with cooling and HGL usage in one step 56
6.13. Additional hydraulic connection for heat recovery 57
7. ELECTRICAL CONNECTION 58
7.1. Power supply 58
7.2. Feedthrough for wiring 59
7.3. Configuration of outputs and inputs 59
7.4. Connection diagram for the electric components 60
7.5. Configuration of sensors 61
7.6. Connecting the outputs 61
7.7. Grounding the system 61
7.8. Maximum delimitation in underfloor heating 61
7.9. Connecting external specifications 0-10V 62
7.10. Sum signal zone valves 62
7.11. EMC compatibility 62
8. START-UP 63
8.1. Information regarding the start-up 63
8.2. Errors 63
9. APPENDIX 64
9.1. AERO ILM 2-7 - Performance data heating - detailed 64
9.2. AERO ILM 2-7 - Performance data cooling - detailed 65
9.3. AERO ILM 4-13 - Performance data heating - detailed 66
9.4. AERO ILM 4-13 - Performance data cooling - detailed 67
9.5. AERO ILM 2-7 - Product data sheet 68
9.6. AERO ILM 4-13 - Product data sheet 69
9.7. Declaration of conformity 71
Subject to changes with regard to engineering and design!

(C) IDM ENERGIESYSTEME GMBH
1.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
4
1. General description
1.1. General information
By purchasing this system you have decided in favor
RIDPRGHUQDQGFRVWHႇHFWLYHKHDWLQJV\VWHP&RQ-
tinuous quality controls and improvements as well as
functional checks at our production facilities guaran-
tee technically error-free equipment.
Please read this documentation carefully. It con-
tains important instructions for a correct installa-
tion, for the reliable and an economical operation
of the system.
1.2. Safety instructions
Installation and maintenance operations can be as-
sociated with dangers resulting from high system
pressures, high temperatures and voltaged parts.
Heat pumps may only be installed by competent spe-
cialist and exclusively put into operation by a cus-
tomer service specialist trained for that purpose by
IDM-Energiesysteme GmbH.
If maintenance work is being done on the heat pump,
disconnect the system and ensure that it is volt-free
and provided with a safeguard to prevent unintention-
al restarting. Furthermore all safety instructions in the
respective documentation or on instruction plates af-
¿[HGWRWKHKHDWSXPSLWVHOIUHVSDOORWKHUSHUWLQHQW
safety regulations shall be observed.
1.3. Transport and storage
In transporting the heat pump ensure that it is never
tilted by more than 30°. Do not remove the transport
packaging until the heat pump has reached its instal-
lation location. Heat pump components must not be
stored outside. Heat pumps must not be stored in
humid rooms or dusty environments. The transport
¿[WXUHV DV GHVFULEHG LQ WKH IROORZLQJ DVVHPEO\
instructions are used to transport the heat pump
PDQXDOO\7KHWUDQVSRUW¿[WXUHVPXVWQRWEHXVHGIRU
transporting the components with a crane or similar
hoisting equipment.
1.4. Sound emission
AERO heat pumps run extremely smoothly due to
their construction. It is nevertheless important to
ensure that the heating room is located beyond the
noise-sensitive living area and furnished with a well-
closing door.
1.5. &RQVWUXFWLRQGU\LQJDQGÀRDWLQJVFUHHG
heating
Floor screed heating with the heat pump can only
take place if the air suction temperature continuously
OLHVRYHU&DVRWKHUZLVH DFRUUHFWGHIURVWLQJRI
the air evaporator cannot be guaranteed due to the
ORZ ÀRZ WHPSHUDWXUHV 2WKHUZLVH WKH ÀRRU VFUHHG
has to be heated with the electric heating element!
1.6. Service and maintenance
Regular maintenance as well as an inspection and
maintenance of all important system components
guarantees a reliable and low-price operation of the
system in the long term. We recommend you to sign
a maintenance contract with your competent cus-
tomer service.
1.7. Cleaning
If necessary, the AERO heat pump can be cleaned
using a moist cloth. The use of cleaning agents is not
recommended.
The air vent package in the air heat exchanger
has to be inspected regularly and cleared of any im-
purities (e.g. leaves,...), if necessary.
7KHFRQGHQVDWHUXQRႇKRVHFDQEHGLVFRQHFWHGE\
opening the tube clamp on the condensate bin. Now
the bin and the tube can be inspected and cleaned.
To prevent water damage, the conden-
sate bin and the condensate hose have
to be checked regularly for contamination.

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 5
General description
For the installation of the heat pump all
pertinent national and international lay-
ing, installation, accident prevention and
safety regulations in connection with the
installation of pipeline systems and elec-
tric components and equipment as well as
instructions in this assembly manual must
be observed.
1.8. Ice-covering weather-shield grilles
Depending on the weather and outdoor humidity, it
may happen that there will be formed an icy coverng
on the wheather-shield grilles of the heat pump. This
HႇHFW LV FRPPRQ RFFXULQJ LQ QDWXUH 7KLV FRYHULQJ
must be removed by the heat pump operator during
this weather periods.
1.9. Installation area
1.10. Information on environmental protection
- In order to minimize oscillations and sounds
within buildings, heat pumps should be decou-
pled as far as possible from the building mass.
It is principally recommended to avoid installing
KHDWSXPSVRQFHLOLQJVDQGÀRRUVLQOLJKWZHLJKW
FRQVWUXFWLRQ,QWKHFDVHRIÀRDWLQJÀRRUVFUHHG
ÀRRUVFUHHGDQGLPSDFWVRXQGLQVXODWLRQVKRXOG
be omitted around the heat pump.
- The installation in wet or damp environments or
in areas exposed to dust or explosion hazards is
non-permissible.
- If refrigerant escapes from the installation site,
this must not enter adjacent rooms, stairways,
yards, corridors or drainage systems and a
hazard-free drainage must be ensured.
- In the case of danger, leave the installation site
immediately.If the size of the installation site falls
below the requested minimum size, this has to
be designed as machinery room in compliance
with EN 378.
- ,I WKH HPHUJHQF\ YHQWLODWLRQ LV QRW VXႈFLHQW
mechanical ventilation must be provided. A
mechanical ventilation shall be installed with
an independent emergency control beyond the
installation site and near the door to that area.
- Heat pumps must not be installed in rooms with
KLJK(0&ORDG$LULQWDNHVDQGRXWOHWVKDYHWREH
safeguarded against theft by appropriate on-site
measures.
- The AERO ILM heat pump has to be
installed in a frost-proof room! (room
WHPSHUDWXUHPXVWOLHEHWZHHQ&DQG
&
Heat pumps are electronic devices of
high-quality material which must not be
disposed of in the same way as house-
hold waste. They must be disposed of in
a professional and appropriate manner
pursuant to the regulations of the local
authorities. Disposal contrary to the
regulations may lead damage the envi-
ronment and health with the exception
of sanctions imposed on law breakers.
1.11. Piping and pipe-wall-ducts
All pipelines and wall ducts must be discharged in
compliance with standards, according heat-insula-
tion, sound-decoupling and water-carrying pipes in a
frost-proof manner.
1.12. Installation of additional components
The installation of additional components which have
QRWEHHQYHUL¿HGZLWKWKHHTXLSPHQWPD\LPSDLUWKH
function. No warranty or liability shall be assumed for
any damage resulting therefrom.
1.13. Standards and guidelines
These comprise among others:
- the generally valid accident prevention and safety
regulations
- the provisions regarding environmental protection
- the regulations of the professional associations
- the pertinent laws, standards, regulations and pro-
visions, e.g. DIN, EN, DVGW, VDI and VDE.
- Provisions of the local public utilities.

(C) IDM ENERGIESYSTEME GMBH
1.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
6
General description
7KHORZHUWKHPD[LPXPÀRZWHPSHUDWXUH
LV WKH KLJKHU WKH FRHႈFLHQW RI SHUIRU-
PDQFH&23RIWKHKHDWSXPSZLOOEH
1.14. Description
AERO ILM is a compact air-water-heat pump with
modulating scroll capsule compressor with largely
GLPHQVLRQHGPXOWLURZ$O&X¿QQHGWXEHHYDSRUDWRU
By a special speed-controlled radial fan large volume
ÀRZVFDQEHDFKLHYHGDWORZVSHHGV
A copper-welded stainless steel plate heat exchanger
is used as condenser. The machine frame consists of
DVWURQJPHWDOSUR¿OH7KHFRYHUSDQHOVDUHLQVXODWHG
perfectly. The housing is thus completely without a
thermal bridge and thus features optimum sound in-
sulation values.
The heat pump is complete from a hydraulic view-
SRLQW DQG IHDWXUHV D KLJKHႈFLHQF\ ORDGLQJ SXPS
the safety device, an expansion container, the electric
heating rod, the priority valve respectively the HGL-
WHFKQRORJ\DÀRZVZLWFKDQGDOOQHFHVVDU\VHQVRUV
The heating controller (Navigator 2.0) developed es-
SHFLDOO\IRUWKLV V\VWHP RႇHUVDYDULHW\ RI DGGLWLRQDO
DSSOLFDWLRQVHJ6PDUW*ULG5HPRWH&RQWURORURS-
eration via a smart phone.
The heat pump is designed in compact construction,
the evaporator is mounted in the top part of the heat
SXPSFDVLQJ7KHKHDWSXPSLV¿OOHGZLWKUHIULJHUDQW
and is tested in the plant to ensure its perfect function.
1.15. Application range
For monovalent heating and cooling of detached and
semi-detached houses in appropriate climatic envi-
ronments. The building should be furnished with a
ORZWHPSHUDWXUHKHDWLQJHJXQGHUÀRRUKHDWLQJZDOO
heating, low-temperature radiator heating ...).
The heat pump must be used only for domestic, but
not for commercial operation, eg production of pro-
cess heat.
AERO ILM heat pumps function with the safety re-
frigerant R410A which, if in the event of a proper as-
sembly and installation circulates in a closed circuit,
represents practically no environmental impact.
1.16. Scope of delivery
- Heat pump aggregate with modulating scroll cap-
sule compressor (AERO ILM 4-13) or rolling piston
compressor (AERO ILM 2-7)
- ,QYHUWHUZLWKSDWHQWHG&,&WHFKQRORJ\
- &RSSHUZHOGHGVWDLQOHVVVWHHOSODWHKHDWH[FKDQJHU
as condenser
- HGL-plate heat exchanger (only ILM HGL type)
- )LQQHGWXEH$O&XHYDSRUDWRUSDFNDJH
- Speed-controlled radial fan
- Refrigerant collection and dehydration
- Liquid separator
- 2 pcs. electronic expansion valves
- Refrigerant level indicator
- Pressure sensors for high and low-pressure moni-
toring
- &DUWULGJHSUHVVXUHFRQWUROVZLWFKIRUKLJKSUHVVXUH
monitoring
- Installed switching valve for cooling/defrosting
- Suction air sensor
- +LJKHႈFLHQF\ORDGLQJSXPS
- 3-way valve for priority mode (ILM type) orHGL-
valve for HGL-mode (ILM HGL type)
- Flow switch
- Electrical heating rod 6 kW for possible subsequent
heating
- Heat and sound-insulated cover panels
- colored 7” touch display
- SFVÀH[LEOHFRQQHFWLRQKRVHV
- &RQGHQVDWHGUDLQWXEH
- nonreturn valve (loose)
- 2 pcs. sound reduction mats to place below the
heat pump
- network connector for myIDM integration
1.17. Accessories
see IDM price list

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 7


 

















ZLWKRXWIURQW
outlet
inlet
front
from above
Technical data
2. Technical data
2.1. Dimensions of AERO ILM 2-7 and AERO ILM 4-13

(C) IDM ENERGIESYSTEME GMBH
2.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
8
Technical data
Heatpump type AERO ILM 2-7 AERO ILM 4-13
Additional model -
without HGL
HGL
without HGL
Energy efficiency class
35 °C 55 °C
35 °C 55 °C
Performance data heating with nominal speed Unit
+HDWLQJFDSDFLW\DW$&:& kW 3.87 7.11
+HDWLQJFDSDFLW\$&:& kW 4.51 8.28
+HDWLQJFDSDFLW\$&:& kW 2.84 5.50
3RZHUFRQVXPSWLRQDW$&:& kW 0.89 1.73
3RZHUFRQVXPSWLRQDW$&:& kW 0.89 1.74
3RZHUFRQVXPSWLRQDW$&:& kW 0.86 1.68
&23DW$&:& - 4.32 4.11
&23DW$&:& - 5.06 4.76
&23DW$&:& - 3.28 3.27
Performance data cooling with nominal speed
&RROLQJFSDFLW\DW$&:& kW 5.09 9.48
&RROLQJFSDFLW\DW$&:& kW 3.44 6.76
3RZHUFRQVXPSWLRQDW$&:& kW 1.13 2.31
3RZHUFRQVXPSWLRQDW$&:& kW 1.09 2.23
((5DW$&:& - 4.50 4.10
((5DW$&:& - 3.16 3.03
Sound data according EN12102 1
Outside air inlet - nominal dB(A) 48 55
Outside air inlet - maximum dB(A) 55 59
Outside air outlet - nominal dB(A) 48 53
Outside air outlet - maximum dB(A) 53 57
Night mode dB(A) -2 -2
Indoor - nominal dB(A) 44 42
Indoor - maximum dB(A) 49 53
The sound pressure level can be calculated with the iDM-sound calculation tool
Dimensions HxWxD mm 1850/910/830 1850/910/830
Tilt hight mm 2028 2028
Weight kg 280 295
1
Sound data with weather shield-grilles, without air hose and without air duct. If the fan speed will be raised, the sound power level raises too.
:LWKWKH+*/0RGHOWKHVSHFL¿HGKHDWRXWSXWLVFRPSRVHGRIWKHKHDWLQJDQGWKH+*/KHDWLQJRXWSXW
'HWDLOHGGDWDDFFRUGLQJWKHHQHUJ\HႈFLHQF\DUHVKRZQLQWKHDSSHQGL[
2.2. Technical data
A+A+ A+ A+

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 9
Technical data
Heatpump type unit AERO ILM 2-7 AERO ILM 4-13
Maximum heatpump flow temperature & 62 60
1RPLQDOIORZUDWHKHDWLQJZDWHU$&:&ǻ7 . m³/h 0.8 1.42
)ORZUDWHKHDWLQJZDWHU$&:&ǻ7 . m³/h 0.42 0.77
Integrated loading pump Yonos Para 7.0 Stratos Para 25/1-9
Free residual pressure loading pump at nominal flow rate kPa 49 77
Pressure loss heating side kPa 15 11
Flow- and return connections heating side R 1“ AG 1“ AG
Flow domestic hot water heater or HGL-flow R 1“ AG 1“ AG bzw. 5/4“ AG
&RQGHQVDWHUXQRIIFRQQHFWLRQ R 35 mm 35 mm
Maximum operating pressure heating side bar 3 3
Integrated fan-type Radialventilator Radialventilator
Residual pressure at maximum speed ¹ Pa 150 110
1RPLQDODLUIORZUDWH$&:&
DQGQRPLQDO&RPSUHVVRUVSHHG m³/h 1,250 2,200
diameter flexible air outlet hose (accessory) mm 560 560
Refrigerant R410A (GWP3 2088) R410A (GWP3 2088)
Quantity of refrigerant 2kg 3.2 6.2
&22-Equivalent 3t 6.7 12.9
Minimum size of installation room m³ 7.3 14.1
Quantity of compressor oil (FV50S) lt. 0.35 1.9
Quantity of compressors qty 1 1
1
If the fan speed will be raised, the sound power level raises too
ð$(52,/0KHDWSXPSVZRUNZLWKWKHE\WKH.\RWRSURWRFROGHWHFWHGVDIHW\UHIULJHUDQW5$ZLWKDJOREDOZDUPLQJSRWHQWLDORI
3
&22-equivalent filling quantity (GWP x refrigerant filling quantity)
Electrical data unit AERO ILM 2-7 AERO ILM 4-13
Electrical power supply compressor V/Hz
1~ 230/50 3~ 400/50
Electrical power supply heating element V/Hz
3~ 400/50 or
1~ 230/50
3~ 400/50
Electrical power supply controller V/Hz 1~ 230/50 1~ 230/50
Maximum operating (starting) current of compressor A 15.8 19.0
Maximum power consumption electric heating element A 8.7 8.7
Fuse of control supply A B/Z 13 B/Z 13
Fuse of electrical heating element A if
3~ 400/50 B/Z 13
if
1~ 230/50 B/Z 32
B/Z 13
Fuse of main power supply compressor A &. &.
Maximum operating current of fan A 0.24 0.5
Maximum power consumption fan W 56 115

(C) IDM ENERGIESYSTEME GMBH
3.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
10
0
2
4
6
8
10
12
14
16
-20-15-10-5 0 5 101520
MAX
NOMINAL
MIN
W35 EN14511
W35 EN14511
W35 EN14
{
outside temperature [°C]
heating capacity [kW]
bivalence point of the
particular heatpump type
standard external temperature
domestic hot water required
building- characteristic line
required heating capacity at
standard external temperature
incl. domestic hot water required
Bivalence
part
heating limit
Dimensioning
An air/water-heat pump should be dimensioned in
such a way that the bivalence point lies between -3
DQG&7KLVJXDUDQWHHVWKDWPRUHWKDQRI
the annual heating requirement (Austria, Germany,
Switzerland) will be covered by the heat pump.
In dimensioning the system the maximum heating
output of the house including the water for domestic
use is calculated.
The standard outside temperature is additionally re-
quired. This is determined by the geographical loca-
tion and can be found on the IDM homepage and ob-
tained from various institutions.
Example:
Detached single-family house in Germany
4 person-household
'RPHVWLFZDWHUUHTXLUHPHQWV [N: N:
Heating output requirements 11 kW
Standard outside temperature
*HUPDQ\  &
2ႇSHULRGIDFWRU  
Heating energy required:
GRPHVWLFZDWHUUHTXLUHPHQWVKHDWLQJRXWSXWUHTXLUHPHQWV[RႇSHULRGIDFWRU N:
Heating performance diagram AERO ILM 4-13
3. Dimensioning

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 11
Dimensioning
Notizen:
Notes

(C) IDM ENERGIESYSTEME GMBH
3.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
12
0
2
4
6
8
10
12
-20-15-10-5 0 5 101520
MAX
NOMINAL
MIN
heating capacity [kW]
outside temperature [° C]
0
2
4
6
8
10
12
-20-15-10-5 0 5 101520
MAX
NOMINAL
MIN
heating capacity [kW]
outside tem
p
erature
[
° C
]
Dimensioning
3.1. Heating performance diagrams AERO ILM 2-7, according EN14511
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 13
0
2
4
6
8
10
12
-20 -15 -10 -5 0 5 10 15 20
MAX
NOMINAL
MIN
heating capacity [kW]
outside tem
p
erature
[
° C
]
0
2
4
6
8
10
12
-10-5 0 5 101520
MAX
NOMINAL
MIN
heating capacity [kW]
outside temperature [° C]
Dimensioning
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&

(C) IDM ENERGIESYSTEME GMBH
3.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
14
0
2
4
6
8
10
12
14
16
-20 -15 -10 -5 0 5 10 15 20
MAX
NOMINAL
MIN
heating capacity [kW]
outside temperature [° C]
0
2
4
6
8
10
12
14
16
-20-15-10-5 0 5 101520
MAX
NOMINAL
MIN
heating capacity [kW]
outside temperature [° C]
Dimensioning
3.2. Heating performance diagrams AERO ILM 4-13, according EN14511
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 15
0
2
4
6
8
10
12
14
16
-20 -15 -10 -5 0 5 10 15 20
MAX
NOMINAL
MIN
heating capacity [kW]
outside temperature [° C]
0
2
4
6
8
10
12
14
16
0 2 4 6 8 101214161820
MAX
NENN
MIN
heating capacity [kW]
outside temperature [° C]
Dimensioning
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&
+HDWRXWSXWZLWKÀRZWHPSHUDWXUHVRI&

(C) IDM ENERGIESYSTEME GMBH
3.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
16
-20 -15 -10 -5 0 5 10 15 20 25 30 35
20
25
30
35
40
45
50
55
60
10
[°C]
[°C]
40
45
62
R410A
AERO ILM 2-7 - heating
outdoor temperature
flow temperature
0 5 101520253035404550
4
6
8
10
12
14
16
18
20
2
[°C]
[°C]
R410A
0
flow temperature
outdoor temperature
AERO ILM 2-7 - cooling
Dimensioning
3.3. Limitations of use
The heating of liquids other than heating water is not permitted (see heating water quality). Heat pumps
are naturally subject to pressure or temperature-dependent operating limits (see diagram below). Operation
outside these limits is not permitted.

(C) IDM ENERGIESYSTEME GMBH Installation instructions AERO ILM 17
If the outside temperatures falls below or exceeds the application range , the heat pump turns
Rႇ,IDELYDOHQFHV\VWHPH[LVWVDQGLVFRQ¿JXUHGLQWKH1DYLJDWRUWKHELYDOHQFHZLOOVWDUW
-18-15 -10 -5 0 5 10 15 20 25 30 35
20
25
30
35
40
45
50
55
60
10
[°C]
R410A
[°C]
40
45
AERO ILM 4-13 - heating
flow temperature
outdoor temperature
0 5101520253035404550
4
6
8
10
12
14
16
18
20
2
[°C]
[°C]
R410A
0
AERO ILM 4-13 - cooling
flow temperature
outdoor temperature
Dimensioning

(C) IDM Energiesysteme GmbH
4.
G
e
n
eral descriptio
n
Installation instructions AERO ILM
18
9
12
9
11 11
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
10
1
2
3
4
5
6
7
8
13
9
9
4. Connections and cable ducts
ducts AERO ILM HGL
 +*/ÀRZIRUdomestic hot water heater
ÀH[FRQQHFWLRQKRVH
2 HGL-return
(only for HGL-usage in cooling mode)
3 not used
 &RQGHQVDWHUXQRႇ
+HDWSXPSÀRZ
ÀH[FRQQHFWLRQKRVH
6 Heat pump return
ÀH[FRQQHFWLRQKRVH
7 Main current
8 Sensor and control lines
9 height-adjustable feet (50 mm)
ducts AERO ILM
1 not used
2 Flow domestic hot water heater
ÀH[FRQQHFWLRQKRVH
3 not used
 &RQGHQVDWHUXQRႇ
+HDWSXPSÀRZ
ÀH[FRQQHFWLRQKRVH
6 Heat pump return
ÀH[FRQQHFWLRQKRVH
7 Main current
8 Sensor and control lines
9 height-adjustable feet (50 mm)

(C) IDM Energiesysteme GmbH Installation instructions AERO ILM 19
1
3
2
1
4
2
Connections and cable ducts
4.1. Cable and piping ducts
The hydraulic and electric connections can be ac-
complished on the left-hand side or on the right-hand
side.
7KH  ÀH[LEOH FRQQHFWLRQ KRVHV HQFORVHG DUH FRQ-
nected as shown in the diagram and led through the
protective sleeve provided. The electric cables are
also connected as shown in the diagram.
4.2. Hydraulic connections to the heat pump
AERO ILM HGL AERO ILM (without HGL)
KHDWSXPSÀRZ
2 ... heat pump retur
+*/ÀRZ
(backside of HGL-condenser)
KHDWSXPSÀRZ
2 ... heat pump retur
ÀRZGRPHVWLFKRWZDWHUKHDWHU

(C) IDM Energiesysteme GmbH
5.
General description
Installation instructions AERO ILM
20
To prevent water damage, the conden-
sate bin and the condensate hose have
to be checked regularly for contamination.
Even when installing with light shaft, the
condensate drain must be checked for
contamination. The discharge hose can
EHVHSDUDWHGIURPWKHUXQRႇELQE\RSHQ-
ing the hose clamp. This allows to inspect
and clean the bin and the hose.
In coastal installation, a minimum dis-
tance of 5 km from the coast must be
observed. If this safety distance is not
observed, there could occur increased
corrosion. These cases are excluded from
the guarantee.
5.
5.
Interior installation
G
e
n
er
a
l descriptio
n
General description
Installation
5. Installation
5.1. Installation instructions
The AERO ILM (HGL) is only designed for interior
installation. By installing this system in the interior the
expenses for frost protection and condensation run-
RႇKHDWLQJFDQEHUHGXFHG7KHUHDUHYDULRXVLQVWDO-
lation options to ensure that the inlet air / outlet air is
fed to the heat pump with a minimum loss. These are
described in detail in the following chapters.
All components of the heat pump are insulated in
such a way to ensure that even in the event of outlet
WHPSHUDWXUHVRI&QRFRQGHQVHGZDWHUGHYHORSV
on the outer parts. It is nevertheless recommended to
ventilate the room regularly.
The heat pump is decoupled by a vibration dampers.
The installation location must have a solid surface.
The heat pump can be leveled by the 4 height adjust-
able feet (up to 50 mm).
2 pieces of insulating mat are also included in the
delivery contents with the heat pump in order to avoid
noise. These 2 mats are placed under the heat pump.
They are both furnished with 2 openings for the ad-
justable feet of the heat pump.
7KHHႇHFWLYHQRLVHSUHVVXUHOHYHOat the installation
location depends on various factors, such as room
VL]H DEVRUSWLRQ FDSDFLW\ UHÀHFWLRQ XQREVWUXFWHG
sound propagation etc. It is therefore important to
ensure that the heat pump is installed, if possible,
beyond the noise-sensitive area. The heating room
should be furnished with a sound-insulating door.
5.2. Heating connections
7KHKHDWLQJFRQQHFWLRQVPXVWEHLQVWDOOHGZLWKDÀH[-
ible hoses which are included as a standard.
5.3. &RQGHQVDWLRQUXQRႇ
Air source heat pumps generate condense water
during operation. Per defrosting cycle, i.e. within 2
minutes up to 10 l of condensate can accumulate.
The factory-provided and pre-mounted condensate
UXQRႇPXVWEHODLGRQVLWHLQWRWKHVHZDJHGUDLQDQG
must be checked regularly for contamination. See
chapter connections and cable ducts
,I WKH UXQRႇ RI WKH FRQGHQVDWLRQ ZDWHU LV QRW SRV-
sible properly, damage to the heat pump itself and
water damage to the building can occur.
