IEI Technology IMBA-XQ354-R11 User manual

1
ATX Motherboard with Intel LGA775 Core 2 Quad, Celeron
with a 1333/1066/800Mhz FSB, PCIe x16, PCIex4, PCIe
GbE, SATAII and Audio, ROHS
IMBA-XQ354-R11
Quick Installation Guide
Version 1.0
Mar.2, 2011
Package Contents
IMBA-XQ354-R11 package includes the following items:
l1 x IMBA-XQ354 Single Board Computer
l1 x Mini jumper pack
l6x SATA cables
l2x Dual RS-232 Cable
l1 x RS-232 Cable
l1 x Utility CD
l1 x QIG (Quick Installation Guide)
l1 x IO Shielding
©2011 Copyright by IEI Technology corp.
All rights reserved.

2
Specifications
lCPU:
LGA775 Intel®CoreTM 2 Duo(45nm and 65nm), Intel®CoreTM 2
Quad(45nm and 65nm), Intel®Celeron(65nm)
lSystem Chipset: Intel®Q35 + ICH9DO
lBIOS: AMI BIOS
lSystem memory:
4 x 240 pin Dual channel DDR2 SDRAM DIMM 667/800MHz up to 8GB
lEthernet:
One Intel®82566DM (PHY) and Intel®ICH9DO (MAC)
One PCIe x1 Intel®82573L (MAC+PHY)
lI/O Interface:
12 x USB 2.0 (4x External, 8x on board)
6x SATAII
6x RS-232
1 x keyboard/mouse PS/2 connector
lSuper I/O: ITE IT8718F
lDigital I/O: 8-bit digital I/O,4-bit input/ 4-bit output
lIrDA:1x IrDA by pin header
lAudio: Realtek ALC888 HD audio codec
lDisplay:
VGA integrated in Q35
Analog VGA display through external DB-15 connector
lWatchdog timer: Software programmable supports 1~255 sec.system reset
lPower Supply: ATX POWER support
lPower consumption :
3.3V@2.96A,[email protected],5Vsb@1.61A,12V@2.77A,(2.66GHz E6850 Intel®
CoreTM 2 Duo CPU with 1333MHz FSB and 8GB 800 MHz DDR2 DIMM,
running --3D Mark 2001 )
lTemperature: 0 ~ 60°C( 32 ~ 140°F)
lHumidity: Operation: 5% ~ 95%
lDimension: 338mm x 126mm
lWeight: GW:1.1 Kg

3
Ordering Information
IMBA-XQ354-R10:
ATX Motherboard with Intel LGA775,Core 2 Quad,Celeron with a
1333/1066/800Mhz FSB,PCIe x16,PCIex4,PCIe GbE,SATAII and
Audio;ROHS
CB-USB02-RS:Dual USB cable
CB-USB14-RS:Four USB cable
CF-775A-RS/CF-520-RS:CPU cooler
TPM-WI01-R10: 20-pin WINBOND TPM Module, S/W Management
TPM-IN01-R10: 20-pin INFINEON TPM Module, S/W Management
SDVO-100VGA-R10: PCIe x16 VGA Output SDVO card supports dual
display (IEI CPU board only)
SDVO-100DVI-R10: PCIe x16 DVI Output SDVO card supports dual display
(IEI CPU board only)

4
Jumpers setting & Connector
J_CMOS1: Clear CMOS Setup (1*3 pin header, pitch 2.54mm)
J_COMS1 DESCRIPTION
1-2Normal (default)
2-3Clear CMOS Setup
J_COM_F3~J_COM_F6 : Set the function of pin9 as signal or voltage
J_COM_F3~F6 DESCRIPTION
1-2Pin9 of COM3~COM6 as voltage
2-3Pin9 of COM3~COM6 as signal (RING)
CPU_FAN1:
CPU Fan Connector
PIN DESCRIPTION
1Ground
2+12V
3Rotation Signal
4Control
CPU12V1 : CPU Power Connector
PIN DESCRIPTION PIN DESCRIPTION
1GND 2GND
3+12V 4+12V
J_COM_V3~J_COM_V6 : Set the voltage level of pin9 at COM3 ~ COM6
J_COM_V2~V4 DESCRIPTION
1-2+5V
2-3+12V
JP1: SPDIF_OUT Connector Selection
J_COM_F3~F6 DESCRIPTION
1-2RCA Connector (default)
2-3Optical Connector
SYS_FAN1~2:
CPU Fan Connector
PIN DESCRIPTION
1Ground
2+12V
3Rotation Signal

5
FPAUDIO1 : Front audio connector
PIN DESCRIPTION PIN DESCRIPTION
1MIC_L 2GND
3MIC_R 4Audio Detect
5LINE2-R6GND
7Jack Detection 8N/C
9LINE2-L10 GND
CD_IN1: Internal CD IN connector
PIN DESCRIPTION
1CD-L
2CD-GND
3CD-GND
4CD-R
COM2~6 : Internal Serial Port Connector
PIN DESCRIPTION PIN DESCRIPTION
1. DCD 2. RXD
3. TXD 4. DTR
5. GND 6. DSR
7. RTS 8. CTS
9. RI 10. N/C
SPDIF1: Internal SPDIF connector
PIN DESCRIPTION
15V
2N/C
3SPDIFOUT
4GND
5SPDIFIN
USB45,67,89,1011: Internal USB Connector
PIN DESCRIPTION PIN DESCRIPTION
1VCC 2GND
3DATA-4DATA+
5DATA+ 6DATA-
7GND 8VCC

6
DIO1: 8-bit Digital I/O Connector
PIN DESCRIPTION PIN DESCRIPTION
1Ground 2VCC
3Output 3 4Output 2
5Output 1 6Output 0
7Input 3 8Input 2
9Input 1 10 Input 0
JSPI1 : SPI FLASH Connector
PIN DESCRIPTION PIN DESCRIPTION
1VCC 2GND
3CS# 4CLOCK
5SO 6SI
7NC 8NC
TPM1 : Trusted Platform Module connector
PIN DESCRIPTION PIN DESCRIPTION
1TPMPCLK 2GND
3LFRAME# 4KEY
5PCIRST# 6VCC
7LAD3 8LAD2
9VCC3 10 LAD1
11 LAD0 12 GND
13 SMBCLK 14 SMBDATA
15 3VDUAL 16 SERIRQ
17 GND 18 CLKRUN#
19 LPCPD# 20 LDRQ#
IR1 : IrDA connector
PIN DESCRIPTION
1VCC
2NC
3IR-RX
4GND
5IR-TX

7
FDD1: FDC Connector
PIN DESCRIPTION PIN DESCRIPTION
1GND 2DENSEL-
3GND 4N/C
5N/C 6N/C
7GND 8INDEX#
9GND 10 MOTOR ENABLE A#
11 GND 12 DRIVE SELECT B#
13 GND 14 DRIVE SELECT A#
15 GND 16 MOTOR ENABLE B#
17 GND 18 DIRECTION#
19 GND 20 STEP#
21 GND 22 WRITE DATA#
23 GND 24 WRITE GATE#
25 GND 26 TRACK 0#
27 GND 28 WRITE PROTECT#
29 GND 30 READ DATA#
31 GND 32 SIDE 1 SELECT#
33 GND 34 DISK CHANGE#
F_PANEL1: External Switches and Indicators panel
PIN DESCRIPTION PIN DESCRIPTION
1PWR_LED+ 2SPKR+
3N/C 4N/C
5PWR_LED-6N/C
7PWRBTN+ 8SPKR-
9PWRBTN-10 N/C
11 HDD_LED+ 12 RESET+
13 HDD_LED-14 RESET-
1-3-5 : Power LED
2-4-6-8 : Speaker
7-9 : PWRBTN
11-13 : HDDLED
12-14 : RESET

8
BoardLayout
(Unit : mm)
