IEI Technology KINO-HM551 User manual

KINO-HM551
Page I
IEI Technology Corp.
User Manual
KINO-HM551
MODEL:
Mini-ITX SBC Supports Socket G1 for Intel® mobile Core™ i7/i5/i3 and
Intel® Celeron®, VGA/DVI/LVDS/HDMI Display, Dual GbE, Eight USB
2.0, Dual PCIe Mini, Four SATA 3Gb/s, Audio, RoHS
Rev. 1.02 - 15 February, 2012
)zKINO-HM551 CPU Card

KINO-HM551
Page II
Revision
Date Version Changes
15 February, 2012 1.02 Updated Table 3-6: Fan Connector Pinouts
15 September, 2011 1.01 Modified Chapter 3 Connectors
17 November, 2011 1.00 Initial release

KINO-HM551
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-HM551
Page IV
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 CONNECTORS ............................................................................................................. 3
1.3 DIMENSIONS............................................................................................................... 4
1.4 DATA FLOW................................................................................................................ 5
1.5 TECHNICAL SPECIFICATIONS ...................................................................................... 6
2 UNPACKING................................................................................................................. 8
2.1ANTI-STATIC PRECAUTIONS........................................................................................ 9
2.2 UNPACKING PRECAUTIONS......................................................................................... 9
2.3 PACKING LIST........................................................................................................... 10
2.3.1 Optional Items...................................................................................................11
3 CONNECTORS ........................................................................................................... 12
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 13
3.1.1 KINO-HM551 Layout ...................................................................................... 13
3.1.2 Peripheral Interface Connectors ..................................................................... 14
3.1.3 External Interface Panel Connectors............................................................... 15
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 15
3.2.1 Audio Connector .............................................................................................. 15
3.2.2 Digital I/O Connector...................................................................................... 16
3.2.3 Fan Connector (CPU)...................................................................................... 17
3.2.4 Fan Connector (System) .................................................................................. 17
3.2.5 Front Panel Indicators..................................................................................... 18
3.2.6 Half PCIe Mini Card Slot ................................................................................ 19
3.2.7 Infrared Connector .......................................................................................... 20
3.2.8 Inverter Connector........................................................................................... 21
3.2.9 Keyboard/Mouse Connector ............................................................................ 22
3.2.10 LVDS Connector ............................................................................................ 22
3.2.11 PCIe Mini Card Slot....................................................................................... 23
3.2.12 Power Supply Connector ............................................................................... 25

KINO-HM551
Page V
3.2.13 RS-232/422/485 Serial Port Connector......................................................... 25
3.2.14 RS-232 Serial Port Connector....................................................................... 26
3.2.15 SATA Drive Connectors ................................................................................. 27
3.2.16 SATA Power Connectors................................................................................ 28
3.2.17 SMBus Connector .......................................................................................... 29
3.2.18 SPDIF Connector........................................................................................... 30
3.2.19 TPM Connector.............................................................................................. 31
3.2.20 USB Connectors............................................................................................. 31
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 32
3.3.1 Adapter Connector........................................................................................... 33
3.3.2 Audio Connector .............................................................................................. 34
3.3.3 Ethernet/USB Connector ................................................................................. 34
3.3.4 HDMI Connector............................................................................................. 35
3.3.5 Serial Port DB-9 Connector ............................................................................ 36
3.3.6 VGA and DVI Connector ................................................................................. 37
4 INSTALLATION ......................................................................................................... 39
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 40
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 41
4.2.1 Installation Notices.......................................................................................... 41
4.3 UNPACKING.............................................................................................................. 42
4.4 CPU, CPU COOLING KIT AND SO-DIMM INSTALLATION........................................ 42
4.4.1 Socket G1 CPU Installation............................................................................. 43
4.4.2 Socket G1 Cooling Kit Installation.................................................................. 45
4.4.3 SO-DIMM Installation..................................................................................... 47
4.5 JUMPER SETTINGS .................................................................................................... 47
4.5.1 AT/ATX Power Select Jumper Settings ............................................................ 48
4.5.2 Clear CMOS Jumper........................................................................................ 49
4.5.3 ME RTC Register Jumper................................................................................ 50
4.5.4 LVDS Voltage Selection.................................................................................... 51
4.5.5 LVDS Screen Resolution Selection................................................................... 52
4.5.6 Serial Port Select Jumper ................................................................................ 53
4.6 CHASSIS INSTALLATION............................................................................................ 54
4.6.1 Airflow.............................................................................................................. 54
4.6.2 Motherboard Installation................................................................................. 54

KINO-HM551
Page VI
4.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 54
4.7.1 Dual RS-232 Cable with Slot Bracket.............................................................. 54
4.7.2 SATA Drive Connection ................................................................................... 55
4.8 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 57
4.8.1 Audio Connector .............................................................................................. 58
4.8.2 HDMI Display Device Connection.................................................................. 58
4.8.3 LAN Connection............................................................................................... 59
4.8.4 USB Connection............................................................................................... 60
4.8.5 Serial Device Connection ................................................................................ 61
4.8.6 VGA Monitor Connection ................................................................................ 62
4.8.7 DVI Display Device Connection...................................................................... 63
4.9 SOFTWARE INSTALLATION ........................................................................................ 64
5 BIOS SCREENS........................................................................................................... 66
5.1 INTRODUCTION......................................................................................................... 67
5.1.1 Starting Setup................................................................................................... 67
5.1.2 Using Setup...................................................................................................... 67
5.1.3 Getting Help..................................................................................................... 68
5.1.4 Unable to Reboot After Configuration Changes.............................................. 68
5.1.5 BIOS Menu Bar................................................................................................ 68
5.2 MAIN........................................................................................................................ 69
5.3ADVANCED............................................................................................................... 70
5.3.1 ACPI Configuration......................................................................................... 71
5.3.2 Trusted Computing........................................................................................... 72
5.3.3 CPU Configuration.......................................................................................... 72
5.3.4 SATA Configuration ......................................................................................... 74
5.3.5 USB Configuration........................................................................................... 75
5.3.6 Super IO Configuration ................................................................................... 76
5.3.7 H/W Monitor.................................................................................................... 77
5.3.7.1 Serial Port Console Redirection................................................................ 82
5.3.7.2 Console Redirection Settings.................................................................... 83
5.4 CHIPSET ................................................................................................................... 84
5.4.1 Northbridge Configuration.............................................................................. 85
5.4.2 Southbridge Configuration .............................................................................. 85
5.4.3 Intel IGD SWSCI OpRegion............................................................................. 87

KINO-HM551
Page VII
5.5 BOOT........................................................................................................................ 89
5.6 SECURITY................................................................................................................. 90
5.7 EXIT......................................................................................................................... 92
A BIOS MENU OPTIONS............................................................................................. 94
B ONE KEY RECOVERY............................................................................................. 97
B.1 ONE KEY RECOVERY INTRODUCTION ...................................................................... 98
B.1.1 System Requirement......................................................................................... 99
B.1.2 Supported Operating System......................................................................... 100
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 101
B.2.1 Hardware and BIOS Setup ............................................................................ 101
B.2.2 Create Partitions ........................................................................................... 102
B.2.3 Install Operating System, Drivers and Applications..................................... 106
B.2.4 Build-up Recovery Partition.......................................................................... 106
B.2.5 Create Factory Default Image....................................................................... 109
B.3 SETUP PROCEDURE FOR LINUX...............................................................................114
B.4 RECOVERY TOOL FUNCTIONS .................................................................................117
B.4.1 Factory Restore ..............................................................................................119
B.4.2 Backup System............................................................................................... 120
B.4.3 Restore Your Last Backup.............................................................................. 121
B.4.4 Manual........................................................................................................... 122
B.5 OTHER INFORMATION ............................................................................................ 122
B.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 122
B.5.2 System Memory Requirement ........................................................................ 125
C TERMINOLOGY ..................................................................................................... 126
D WATCHDOG TIMER .............................................................................................. 131
E HAZARDOUS MATERIALS DISCLOSURE ....................................................... 134
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 135

KINO-HM551
Page VIII
List of Figures
Figure 1-1: KINO-HM551 ................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................3
Figure 1-3: KINO-HM551 Dimensions (mm).................................................................................4
Figure 1-4: Data Flow Block Diagram...........................................................................................5
Figure 3-1: Connector and Jumper Locations...........................................................................13
Figure 3-2: Audio Connector Location.......................................................................................16
Figure 3-3: Digital I/O Connector Location ................................................................................16
Figure 3-4: Fan Connector Locations.........................................................................................17
Figure 3-5: Fan Connector Locations.........................................................................................18
Figure 3-6: Front Panel Indicator Location................................................................................18
Figure 3-7: Half PCIe Mini Card Slot Connector Location........................................................19
Figure 3-8: Infrared Connector Locations..................................................................................21
Figure 3-9: Inverter Connector Location....................................................................................21
Figure 3-10: Keyboard/Mouse Connector Location..................................................................22
Figure 3-11: LVDS Connector Locations....................................................................................23
Figure 3-12: PCIe Mini Card Slot Connector Location..............................................................24
Figure 3-13: +12V Power Supply Connector Location..............................................................25
Figure 3-14: RS-232/422/485 Serial Port Location.....................................................................26
Figure 3-15: RS-232 Serial Port Connector Location................................................................27
Figure 3-16: SATA Drive Connector Locations .........................................................................28
Figure 3-17: SATA Power Connector Locations .......................................................................29
Figure 3-18: SMBus Connector Pinout Locations.....................................................................30
Figure 3-19: SPDIF Connector Pinout Locations......................................................................30
Figure 3-20: TPM1 Connector Location......................................................................................31
Figure 3-21: USB Connector Pinout Locations.........................................................................32
Figure 3-22: KINO-HM551 External Peripheral Interface Connector .......................................33
Figure 3-23: 4-pin Power Mini-DIN Connection .........................................................................33
Figure 3-24: Audio Connector.....................................................................................................34
Figure 3-25: Ethernet Connector.................................................................................................35
Figure 3-26: Serial Port DB-9 Male Connector...........................................................................36
Figure 3-27: VGA Connector .......................................................................................................37

KINO-HM551
Page IX
Figure 4-1: Make sure the CPU socket retention screw is unlocked ......................................44
Figure 4-2: Lock the CPU Socket Retention Screw...................................................................45
Figure 4-3: Cooling Kit Support Bracket....................................................................................46
Figure 4-4: SO-DIMM Installation................................................................................................47
Figure 4-5: Jumper Locations.....................................................................................................47
Figure 4-6: AT/ATX Power Select Jumper Location..................................................................49
Figure 4-7: AT Auto Button Select Jumper Settings.................................................................50
Figure 4-8: ME RTC Register Jumper Location.........................................................................51
Figure 4-9: LVDS Voltage Selection Jumper Locations ...........................................................52
Figure 4-10: LVDS Panel Resolution Jumper Pinout Locations..............................................53
Figure 4-11: Serial Port Jumper Location..................................................................................53
Figure 4-12: Dual RS-232 Cable Installation ..............................................................................55
Figure 4-13: SATA Drive Cable Connection...............................................................................56
Figure 4-14: SATA Power Drive Connection..............................................................................57
Figure 4-15: Audio Connector.....................................................................................................58
Figure 4-16: LAN Connection......................................................................................................60
Figure 4-17: USB Connector........................................................................................................61
Figure 4-18: Serial Device Connector.........................................................................................62
Figure 4-19: VGA Connector .......................................................................................................63
Figure 4-20: DVI Connector .........................................................................................................64
Figure 4-21: Introduction Screen................................................................................................65
Figure 4-22: Available Drivers.....................................................................................................65
Figure B-1: IEI One Key Recovery Tool Menu ...........................................................................98
Figure B-2: Launching the Recovery Tool.............................................................................. 103
Figure B-3: Recovery Tool Setup Menu .................................................................................. 103
Figure B-4: Command Mode..................................................................................................... 104
Figure B-5: Partition Creation Commands.............................................................................. 105
Figure B-6: Launching the Recovery Tool.............................................................................. 107
Figure B-7: System Configuration for Windows .................................................................... 107
Figure B-8: Build-up Recovery Partition................................................................................. 108
Figure B-9: Press any key to continue.................................................................................... 108
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 109
Figure B-11: Recovery Tool Menu ........................................................................................... 109
Figure B-12: About Symantec Ghost Window........................................................................ 110
Figure B-13: Symantec Ghost Path ......................................................................................... 110

KINO-HM551
Page X
Figure B-14: Select a Local Source Drive ............................................................................... 111
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 111
Figure B-16: File Name to Copy Image to ............................................................................... 112
Figure B-17: Compress Image.................................................................................................. 112
Figure B-18: Image Creation Confirmation............................................................................. 113
Figure B-19: Image Creation Complete................................................................................... 113
Figure B-20: Image Creation Complete................................................................................... 113
Figure B-21: Press Any Key to Continue ................................................................................ 114
Figure B-22: Partitions for Linux.............................................................................................. 115
Figure B-23: System Configuration for Linux......................................................................... 116
Figure B-24: Access menu.lst in Linux (Text Mode).............................................................. 116
Figure B-25: Recovery Tool Menu ........................................................................................... 117
Figure B-26: Recovery Tool Main Menu.................................................................................. 118
Figure B-27: Restore Factory Default...................................................................................... 119
Figure B-28: Recovery Complete Window.............................................................................. 119
Figure B-29: Backup System.................................................................................................... 120
Figure B-30: System Backup Complete Window ................................................................... 120
Figure B-31: Restore Backup ................................................................................................... 121
Figure B-32: Restore System Backup Complete Window..................................................... 121
Figure B-33: Symantec Ghost Window ................................................................................... 122

KINO-HM551
Page XI
List of Tables
Table 1-1: Technical Specifications..............................................................................................7
Table 3-1: Peripheral Interface Connectors...............................................................................15
Table 3-2: Rear Panel Connectors..............................................................................................15
Table 3-3: Audio Connector Pinouts ..........................................................................................16
Table 3-4: Digital I/O Connector Pinouts....................................................................................17
Table 3-5: Fan Connector Pinouts..............................................................................................17
Table 3-6: Fan Connector Pinouts..............................................................................................18
Table 3-7: Front Panel Indicator Pinouts....................................................................................19
Table 3-8: Half PCIe Mini Card Slot Pinouts ..............................................................................20
Table 3-9: Infrared Connector Pinouts.......................................................................................21
Table 3-10: Inverter Connector Pinouts .....................................................................................22
Table 3-11: Keyboard/Mouse Connector Pinouts .....................................................................22
Table 3-12: LVDS Connector Pinouts.........................................................................................23
Table 3-13: PCIe Mini Card Slot Pinouts ....................................................................................25
Table 3-14: +12V Power Supply Connector Pinouts.................................................................25
Table 3-15: RS-232/422/485 Serial Port Connector Pinouts.....................................................26
Table 3-16: RS-232 Serial Port Connector Pinouts...................................................................27
Table 3-17: SATA Drive Connector Pinouts...............................................................................28
Table 3-18: SATA Power Connector Pinouts.............................................................................29
Table 3-19: SMBus Connector Pinouts ......................................................................................30
Table 3-20: SPDIF Connector Pinouts........................................................................................30
Table 3-21: TPM1 Connector Pinouts.........................................................................................31
Table 3-22: USB Connector Pinouts...........................................................................................32
Table 3-23: Adapter Connector Pinouts.....................................................................................33
Table 3-24: LAN Connector Pinouts...........................................................................................35
Table 3-25: USB Connector Pinouts...........................................................................................35
Table 3-26: HDMI Connector Pinouts .........................................................................................36
Table 3-27: USB Connector Pinouts...........................................................................................37
Table 3-28: VGA Connector Pinouts...........................................................................................38
Table 3-29: DVI Connector Pinouts.............................................................................................38
Table 4-1: Jumpers.......................................................................................................................48

KINO-HM551
Page XII
Table 4-2: AT/ATX Power Select Jumper Settings....................................................................48
Table 4-3: Clear CMOS Jumper Settings....................................................................................50
Table 4-4: ME RTC Register Jumper Settings ...........................................................................50
Table 4-5: LVDS Voltage Selection Jumper Settings................................................................51
Table 4-6: LVDS Screen Resolution Jumper Settings..............................................................52
Table 4-7: Serial Port Jumper Settings.......................................................................................53
Table 5-1: BIOS Navigation Keys................................................................................................68

KINO-HM551
Page XIII
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................69
BIOS Menu 2: Advanced..............................................................................................................70
BIOS Menu 3: ACPI Configuration..............................................................................................71
BIOS Menu 4: TPM Configuration...............................................................................................72
BIOS Menu 5: CPU Configuration...............................................................................................73
BIOS Menu 6: IDE Configuration.................................................................................................74
BIOS Menu 7: USB Configuration...............................................................................................75
BIOS Menu 8: Super IO Configuration........................................................................................76
BIOS Menu 9: Hardware Health Configuration..........................................................................77
BIOS Menu 10: Serial Port Console Redirection Menu.............................................................82
BIOS Menu 11: Console Redirection Settings...........................................................................83
BIOS Menu 12: Chipset................................................................................................................84
BIOS Menu 13:Northbridge Chipset Configuration...................................................................85
BIOS Menu 14:Southbridge Chipset Configuration..................................................................86
BIOS Menu 15: Intel IGD SWSCI OpRegion ...............................................................................87
BIOS Menu 16: Boot.....................................................................................................................89
BIOS Menu 17: Security...............................................................................................................90
BIOS Menu 18:Exit........................................................................................................................92

KINO-HM551
Page 1
1 Introduction
Chapter
1

KINO-HM551
Page 2
1.1 Introduction
Figure 1-1: KINO-HM551
The KINO-HM551 motherboard is a Socket G1 32nm Intel® Core™ i3, i5 and i7 processor
platform. One 4.0 GB 800 MHz or 1066 MHz DDR3 SDRAM SO-DIMM is supported by
the KINO-HM551.
The integrated Intel® HM55 Express Chipset supports two GbE LAN ports through dual
Realtek RTL8111E Ethernet controllers (ASF 2.0 support on LAN1). The KINO-HM551
also supports four SATA 3Gb/s drives and provides 5 V SATA power.
The KINO-HM551 supports dual display via VGA, HDMI and an internal LVDS connector.
Eight USB 2.0 channels and two PCIe Mini expansion sockets provide flexible expansion
options. High Definition Audio (HDA) support ensures HDA devices can be easily
implemented on the KINO-HM551. Serial device connectivity is provided by three internal
RS-232, one external RS-232, and two internal RS-232/422/485 connectors.

KINO-HM551
Page 3
1.2 Connectors
The connectors on the KINO-HM551 are shown in the figure below.
Figure 1-2: Connectors

KINO-HM551
Page 4
1.3 Dimensions
The dimensions of the board are listed below:
Length: 170 mm
Width: 170 mm
Figure 1-3: KINO-HM551 Dimensions (mm)

KINO-HM551
Page 5
1.4 Data Flow
5Figure 1-4 shows the data flow between the two on-board chipsets and other components
installed on the motherboard and described in the following sections of this chapter.
Figure 1-4: Data Flow Block Diagram

KINO-HM551
Page 6
1.5 Technical Specifications
KINO-HM551 technical specifications are listed in table below.
Specification KINO-HM551
Form Factor Mini-ITX
Socket Socket G1 (rPGA989)
Socket 988A
CPU Supported 32 nm Intel® Core™ i3 processor
32 nm Intel® Core™ i5 processor
32 nm Intel® Core™ i7 processor (i7 processors without
integrated graphics)
Intel® Celeron® processor
Express Chipset Intel® HM55
Memory Two 204-pin SO-DIMM sockets support 800/1066 MHz
4.0 GB (max.) dual-channel DDR3 SDRAM SO-DIMM
(system max. 8GB)
Audio Realtek ALC888 HD 7.1 channel audio codec
LAN Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0
support on LAN1
Super I/O Fintek F81865
BIOS AMI uEFI BIOS label
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCIe Two PCIe Mini slot
I/O Interface Connectors
Audio Connector One internal audio connector (10-pin header)
