IEI Technology KINO-DH110 User manual

KINO-DH110 Mini-ITX Motherboard
Page i
User Manual
MODEL:
KINO-DH110
Mini-ITX Motherboard Supports 6th/7th Gen. LGA1151
Intel® Core™ i7/i5/i3, Pentium® or Celeron® CPU,
Intel® H110 Chipset, DDR4, HDMI, DP++, iDP, Dual GbE, M.2,
USB 3.0, SATA 6Gb/s, RS-232/422/485, HD Audio and RoHS
Rev. 1.00 – May 21, 2018

KINO-DH110 Mini-ITX Motherboard
Page ii
Revision
Date Version Changes
May 21, 2018 1.00 Initial release

KINO-DH110 Mini-ITX Motherboard
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-DH110 Mini-ITX Motherboard
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.

KINO-DH110 Mini-ITX Motherboard
Page v
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 KINO-DH110 Layout....................................................................................... 16
3.1.1 Peripheral Interface Connectors ..................................................................... 18
3.1.2 External Interface Panel Connectors............................................................... 19
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 20
3.2.1 Audio Connector.............................................................................................. 20
3.2.2 Battery Connector............................................................................................ 21
3.2.1 Buzzer Connector............................................................................................. 22
3.2.2 Chassis Intrusion Connector............................................................................ 23
3.2.3 DDR4 SO-DIMM Sockets................................................................................ 24
3.2.4 Digital I/O Connector...................................................................................... 25
3.2.5 EC Debug Connector....................................................................................... 26
3.2.6 Fan Connector (CPU)...................................................................................... 27
3.2.7 Fan Connector (System) .................................................................................. 28
3.2.8 Front Panel Connector .................................................................................... 29

KINO-DH110 Mini-ITX Motherboard
Page vi
3.2.9 I2CConnector.................................................................................................. 30
3.2.10 Internal DisplayPort Connector.................................................................... 31
3.2.1 Internal Power Connector ............................................................................... 32
3.2.2 Keyboard and Mouse Connector ..................................................................... 33
3.2.3 LAN LED Connectors...................................................................................... 34
3.2.1 M.2 Slot............................................................................................................ 35
3.2.2 PCIe x16 Slot ................................................................................................... 35
3.2.3 PCIe Mini Slot.................................................................................................. 36
3.2.4 RS-232 Serial Port Connectors........................................................................ 38
3.2.5 SATA 6Gb/s Drive Connectors......................................................................... 39
3.2.1 SATA Power Connectors.................................................................................. 40
3.2.2 SMBus Connector ............................................................................................ 41
3.2.3 SPI Flash Connector........................................................................................ 42
3.2.4 SPI Flash Connector, EC................................................................................. 43
3.2.5 USB 2.0 Connectors......................................................................................... 44
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 45
3.3.1 Audio Connector.............................................................................................. 45
3.3.2 Ethernet and USB 3.0 Connectors................................................................... 46
3.3.1 RS-232/422/485 Serial Port Connectors ......................................................... 47
3.3.1 HDMI and DP++ Connector........................................................................... 48
3.3.1 Power Connector (Power Adapter) ................................................................. 49
4 INSTALLATION ......................................................................................................... 50
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 51
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 51
4.3 SOCKET LGA1151 CPU INSTALLATION ................................................................... 53
4.4 SOCKET LGA1151 COOLING KIT INSTALLATION ..................................................... 56
4.5 SO-DIMM INSTALLATION ....................................................................................... 58
4.6 FULL-SIZE PCIE MINI CARD INSTALLATION............................................................. 59
4.7 M.2 MODULE INSTALLATION.................................................................................... 61
4.8 SYSTEM CONFIGURATION......................................................................................... 62
4.8.1 AT/ATX Power Mode Setting ........................................................................... 62
4.8.2 Clear CMOS Button......................................................................................... 62
4.8.3 Flash Descriptor Security Override Jumper.................................................... 63
4.8.4 USB Power Selection....................................................................................... 64

KINO-DH110 Mini-ITX Motherboard
Page vii
4.9 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 65
4.9.1 SATA Drive Connection ................................................................................... 65
4.10ADDING USB 3.0 DRIVERS TO A WINDOWS 7INSTALLATION IMAGE...................... 68
4.11AVAILABLE DRIVERS .............................................................................................. 66
4.11.1 Driver Download............................................................................................ 67
5 BIOS.............................................................................................................................. 72
5.1 INTRODUCTION......................................................................................................... 73
5.1.1 Starting Setup................................................................................................... 73
5.1.2 Using Setup...................................................................................................... 73
5.1.3 Getting Help..................................................................................................... 74
5.1.4 Unable to Reboot after Configuration Changes.............................................. 74
5.1.5 BIOS Menu Bar................................................................................................ 74
5.2 MAIN........................................................................................................................ 75
5.3ADVANCED............................................................................................................... 76
5.3.1 CPU Configuration .......................................................................................... 77
5.3.2 PCH-FW Configuration................................................................................... 79
5.3.3 ACPI Settings................................................................................................... 80
5.3.4 F81866 Super IO Configuration...................................................................... 81
5.3.4.1 Serial Port n Configuration....................................................................... 82
5.3.4.2 Serial Port 1 Configuration....................................................................... 82
5.3.4.3 Serial Port 3 Configuration....................................................................... 83
5.3.4.4 Serial Port 4 Configuration....................................................................... 84
5.3.5 iWDD H/W Monitor......................................................................................... 85
5.3.5.1 Smart Fan Mode Configuration................................................................ 86
5.3.6 RTC Wake Settings........................................................................................... 87
5.3.7 Serial Port Console Redirection ...................................................................... 88
5.3.7.1 Legacy Console Redirection Settings....................................................... 91
5.3.8 NVMe Configuration........................................................................................ 92
5.3.9 USB Configuration........................................................................................... 93
5.3.10 iEi Feature ..................................................................................................... 94
5.4 CHIPSET ................................................................................................................... 95
5.4.1 System Agent (SA) Configuration .................................................................... 96
5.4.1.1 Memory Configuration ............................................................................. 97
5.4.1.2 Graphics Configuration............................................................................. 97

KINO-DH110 Mini-ITX Motherboard
Page viii
5.4.1.3 PEG Port Configuration............................................................................ 99
5.4.2 PCH-IO Configuration .................................................................................. 101
5.4.2.1 PCI Express Configuration..................................................................... 103
5.4.2.2 SATA Configuration................................................................................ 105
5.4.2.3 HD Audio Configuration......................................................................... 106
5.5 SECURITY............................................................................................................... 107
5.6 BOOT...................................................................................................................... 108
5.7 SAVE &EXIT ...........................................................................................................110
A REGULATORY COMPLIANCE.............................................................................111
B PRODUCT DISPOSAL.............................................................................................113
C BIOS OPTIONS.........................................................................................................115
D DIGITAL I/O INTERFACE......................................................................................118
D.1 INTRODUCTION.......................................................................................................119
D.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 120
D.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 120
E WATCHDOG TIMER............................................................................................... 121
F HAZARDOUS MATERIALS DISCLOSURE........................................................ 124

KINO-DH110 Mini-ITX Motherboard
Page ix
List of Figures
Figure 1-1: KINO-DH110.................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: KINO-DH110 Dimensions (mm) .................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Peripheral Interface Connectors (Front Side)........................................................16
Figure 3-2: Peripheral Interface Connectors (Solder Side)......................................................17
Figure 3-3: Audio Connector Location.......................................................................................20
Figure 3-4: Battery Connector Location.....................................................................................21
Figure 3-5: Buzzer Connector Location.....................................................................................22
Figure 3-6: Chassis Intrusion Connector Location...................................................................23
Figure 3-7: DDR4 SO-DIMM Socket Locations ..........................................................................24
Figure 3-8: Digital I/O Connector Location................................................................................25
Figure 3-9: EC Debug Connector Location................................................................................26
Figure 3-10: CPU Fan Connector Location................................................................................27
Figure 3-11: System Fan Connector Location...........................................................................28
Figure 3-12: Front Panel Connector Location...........................................................................29
Figure 3-13: I2C Connector Location..........................................................................................30
Figure 3-14: Internal DisplayPort Connector Location.............................................................31
Figure 3-15: Internal Power Connector Pinout Location..........................................................32
Figure 3-16: Keyboard and Mouse Connector Location...........................................................33
Figure 3-17: LAN LED Connector Locations .............................................................................34
Figure 3-18: M.2 Slot Location ....................................................................................................35
Figure 3-19: PCIe x16 Slot Location ...........................................................................................36
Figure 3-20: PCIe Mini Slot Location..........................................................................................36
Figure 3-21: RS-232 Serial Port Connector Locations..............................................................38
Figure 3-22: SATA 6Gb/s Drive Connector Locations..............................................................39
Figure 3-23: SATA Power Connector Locations .......................................................................40
Figure 3-24: SMBus Connector Location...................................................................................41
Figure 3-25: SPI Flash Connector Location...............................................................................42
Figure 3-26: SPI EC Flash Connector Location.........................................................................43

KINO-DH110 Mini-ITX Motherboard
Page x
Figure 3-27: USB 2.0 Connector Locations ...............................................................................44
Figure 3-28: External Peripheral Interface Connector..............................................................45
Figure 3-29: Audio Connector.....................................................................................................45
Figure 3-30: LAN Connector........................................................................................................47
Figure 3-31: HDMI Connector......................................................................................................48
Figure 3-32: HDMI Connector......................................................................................................49
Figure 3-33: 4-pin Power Mini-DIN Connector...........................................................................49
Figure 4-1: Disengage the CPU Socket Load Lever..................................................................53
Figure 4-2: Remove Protective Cover.........................................................................................54
Figure 4-3: Insert the Socket LGA1151 CPU..............................................................................55
Figure 4-4: Close the Socket LGA1151 ......................................................................................55
Figure 4-5: Cooling Kit Support Bracket....................................................................................57
Figure 4-6: SO-DIMM Installation (DDR4)...................................................................................58
Figure 4-7: Removing the Retention Screw...............................................................................59
Figure 4-8: Inserting the Full-size PCIe Mini Card into the Slot at an Angle..........................60
Figure 4-9: Securing the Full-size PCIe Mini Card ....................................................................60
Figure 4-10: Inserting the M.2 Module into the Slot at an Angle .............................................61
Figure 4-11: Securing the M.2 Module........................................................................................61
Figure 4-12: AT/ATX Power Mode Switch Location..................................................................62
Figure 4-13: Clear CMOS Button Location.................................................................................63
Figure 4-14: Flash Descriptor Security Override Jumper Location ........................................63
Figure 4-15: SATA Drive Cable Connection...............................................................................65
Figure 4-16: IEI Resource Download Center..............................................................................66
Figure 4-17: Windows 7 USB 3.0 Creator Utility........................................................................69
Figure 4-18: Update Process is Complete .................................................................................70

KINO-DH110 Mini-ITX Motherboard
Page xi
List of Tables
Table 1-1: KINO-DH110 Specifications.........................................................................................9
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................14
Table 3-1: Peripheral Interface Connectors...............................................................................19
Table 3-2: External Peripheral Connectors................................................................................19
Table 3-3: Audio Connector Pinouts ..........................................................................................20
Table 3-4: Battery Connector Pinouts........................................................................................22
Table 3-5: Buzzer Connector Pinouts.........................................................................................22
Table 3-6: Chassis Intrusion Connector Pinouts......................................................................23
Table 3-7: Digital I/O Connector Pinouts....................................................................................25
Table 3-8: EC Debug Connector Pinouts...................................................................................26
Table 3-9: CPU Fan Connector Pinouts......................................................................................27
Table 3-10: System Fan Connector Pinouts..............................................................................28
Table 3-11: Front Panel Connector Pinouts...............................................................................29
Table 3-12: I2C Connector Pinouts..............................................................................................30
Table 3-13: Internal DisplayPort Connector Pinouts ................................................................31
Table 3-14: Internal Power Connector Pinouts..........................................................................32
Table 3-15: Keyboard and Mouse Connector Pinouts..............................................................33
Table 3-16: LAN LED Connector Pinouts...................................................................................34
Table 3-17: PCIe Mini Slot Pinouts..............................................................................................37
Table 3-18: RS-232 Serial Port Connector Pinouts...................................................................38
Table 3-19: SATA 6Gb/s Drive Connector Pinouts....................................................................39
Table 3-20: SATA Power Connector Pinouts.............................................................................40
Table 3-21: SMBus Connector Pinouts ......................................................................................41
Table 3-22: SPI Flash Connector Pinouts..................................................................................42
Table 3-23: SPI EC Flash Connector Pinouts ............................................................................43
Table 3-24: USB 2.0 Connector Pinouts.....................................................................................44
Table 3-25: USB 3.0 Port Pinouts................................................................................................46
Table 3-26: LAN Pinouts..............................................................................................................46
Table 3-27: DB-9 RS-232/422/485 Pinouts..................................................................................47

KINO-DH110 Mini-ITX Motherboard
Page xii
Table 3-28: HDMI Connector Pinouts .........................................................................................48
Table 3-29: DP++ Connector Pinouts .........................................................................................49
Table 4-1: AT/ATX Power Mode Switch Settings.......................................................................62
Table 4-2: Flash Descriptor Security Override Jumper Settings.............................................63
Table 4-3: BIOS Options and Configured USB Ports................................................................64
Table 4-4: USB Power Source Setup..........................................................................................64
Table 5-1: BIOS Navigation Keys................................................................................................74
Table 5-2: BIOS Options and Configured USB Ports..............................................................103

KINO-DH110 Mini-ITX Motherboard
Page xiii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................75
BIOS Menu 2: Advanced..............................................................................................................76
BIOS Menu 3: CPU Configuration...............................................................................................77
BIOS Menu 4: PCH-FW Configuration........................................................................................79
BIOS Menu 5: ACPI Configuration..............................................................................................80
BIOS Menu 6: F81866 Super IO Configuration..........................................................................81
BIOS Menu 7: Serial Port n Configuration Menu.......................................................................82
BIOS Menu 8: iWDD H/W Monitor ...............................................................................................85
BIOS Menu 9: Smart Fan Mode Configuration ..........................................................................86
BIOS Menu 10: RTC Wake Settings............................................................................................87
BIOS Menu 11: Serial Port Console Redirection.......................................................................88
BIOS Menu 12: Legacy Console Redirection Settings .............................................................91
BIOS Menu 13: NVMe Configuration...........................................................................................92
BIOS Menu 14: USB Configuration.............................................................................................93
BIOS Menu 15: iEi Feature...........................................................................................................94
BIOS Menu 16: Chipset................................................................................................................95
BIOS Menu 17: System Agent (SA) Configuration....................................................................96
BIOS Menu 18: Memory Configuration.......................................................................................97
BIOS Menu 19: Graphics Configuration.....................................................................................97
BIOS Menu 20: PEG Port Configuration.....................................................................................99
BIOS Menu 21: PEG Port Feature Configuration.....................................................................100
BIOS Menu 22: PCH-IO Configuration......................................................................................101
BIOS Menu 23: PCI Express Configuration .............................................................................103
BIOS Menu 24: MPCIE1 Slot......................................................................................................104
BIOS Menu 25: SATA Configuration.........................................................................................105
BIOS Menu 26: HD Audio Configuration..................................................................................106
BIOS Menu 27: Security.............................................................................................................107
BIOS Menu 28: Boot...................................................................................................................108
BIOS Menu 29: Save & Exit........................................................................................................110

KINO-DH110 Mini-ITX Motherboard
Page 1
Chapter
1
1 Introduction

KINO-DH110 Mini-ITX Motherboard
Page 2
1.1 Introduction
Figure 1-1: KINO-DH110
The KINO-DH110 is a Mini-ITX motherboard. It accepts a Socket LGA1151 Intel® Core™
i7/i5/i3, Pentium® or Celeron® processor and supports two 260-pin 2133 MHz
dual-channel DDR4 SO-DIMM modules for up to 32 GB of memory.
The KINO-DH110 provides two GbE interfaces through the Intel® PCIe Ethernet
controllers. The integrated Intel® H110 chipset supports two SATA 6Gb/s drives and one
M2. B-key slot for storage. In addition, the KINO-DH110 includes HDMI, DP++ and iDP
interfaces for dual independent display.
Expansion and I/O include one PCIe x16 slot, one PCIe Mini slot, four USB 3.0 on the rear
panel, four USB 2.0 by pin headers, two RS-232 and one RS-232/422/485. High Definition
Audio (HDA) support ensures HDA devices can be easily implemented on the
KINO-DH110.

KINO-DH110 Mini-ITX Motherboard
Page 3
1.2 Features
Some of the KINO-DH110 motherboard features are listed below:
Mini-ITX form factor
6th/7th generation LGA1151 Intel® Core™ i7/i5/i3, Pentium® or Celeron®
processor supported
Intel® H110 chipset
Two 260-pin 2133 MHz dual-channel unbuffered DDR4 SO-DIMMs supported
(system max. 32 GB)
Two GbE connectors via Intel® I219LM and Intel® I211 PCIe controllers
Dual independent display by HDMI, DP++ and iDP interfaces
Two SATA 6Gb/s connectors
One M.2 2242 B-key slot for SATA storage module installation
One PCIe x16 slot
One full-size PCIe Mini slot
Four USB 3.0 ports on the rear I/O
Four USB 2.0 ports via internal pin headers
Two RS-232 serial ports via internal pin headers
One RS-232/422/485 serial port on the rear I/O
High Definition Audio
RoHS compliant

KINO-DH110 Mini-ITX Motherboard
Page 4
1.3 Connectors
The connectors on the KINO-DH110 are shown in the figure below.
Figure 1-2: Connectors

KINO-DH110 Mini-ITX Motherboard
Page 5
1.4 Dimensions
The main dimensions of the KINO-DH110 are shown in the diagram below.
Figure 1-3: KINO-DH110 Dimensions (mm)

KINO-DH110 Mini-ITX Motherboard
Page 6
1.5 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram
