IEI Technology WAFER-KBN-i1 User manual

3.5" SBC supports AMD® 28nm on-board SoC with VGA/LVDS,
Dual GbE, PCIe Mini, USB 3.2 Gen 1, SATA 6GB/s, iRIS-1010,
HD Audio and RoHS
WAFER-KBN-i1
Quick Installation Guide
Version 1.1
August 20, 2020
Package List
WAFER-KBN-i1 package includes the following items:
1 x WAFER-KBN-i1 single board computer with enclosure heatsink
1 x Audio cable
2 x SATA with 5V output cable kit
1 x RS-232 cable
1 x Power cable
©2020 Copyright by IEI Integration Corp.
All rights reserved.

1
Specifications
SoC:
AMD® G-Series 28nm low-power on-board SoC
GX-415GA on-board SoC (1.5GHz, quad-core, 2MB cache,
TDP=15W)
GX-210HA on-board SoC (1.0GHz, dual-core, 1MB cache,
TDP=9W)
GX-420CA on-board SoC (2.0GHz, quad-core, 2MB cache,
TDP=25W) (by request)
GX-217GA on-board SoC (1.65GHz, dual-core, 1MB cache,
TDP=15W) (by request)
Memory:
One 204-pin 1600/1333 MHz single-channel DDR3/DDR3L
SO-DIMM supported (system max. 8GB)
BIOS: UEFI BIOS
Ethernet:
One PCIe GbE by Intel®I210 (LAN1) for IPMI
One PCIe GbE by Intel®I211 (LAN2)
Graphics:
GPU frequency 500MHz(Radeon™ HD 8330E) for GX-415GA
GPU frequency 450MHz(Radeon™ HD 8310E) for GX-210HA
GPU frequency 600MHz(Radeon™ HD 8400E) for GX-420CA
GPU frequency 300MHz(Radeon™ HD 8280E) for GX-217GA
Support DX11.1, OpenGL 4.1 and OpenCL1.2
UVD4.2 decode for H.264, MPEG2/4, VC1 and MVC
VCE 2.0 encode for H.264 and VCE
Display Output:
1 x VGA (2048x1536@60Hz)
1 x 24-bit dual channel LVDS by CH7511B DP to LVDS
converter (1920x1200@60Hz)
1 x 20-pin (2x10) DisplayPort box header for display converter
board (2500x1600@60Hz)

2
Super IO: Fintek F81866
EC:iWDD
Digital I/O:8-bit digital I/O (4-bit input / 4-bit output)
Audio:
Realtek ALC892HD audio codec
1 x SPDIF by 4-pin (1x4) header for digital audio
1 x Analog audio by 10-pin (2x5) header
I/O Interface:
1 x RS-232 on rear I/O
2 x RS-232 by pin header
1 x RS-422/485
2 x USB 3.2 Gen 1 (5Gb/s) on rear I/O
4 x USB 2.0 by pin header
1 x 6-pin wafer for PS/2 KB/MS
2 x SATA 6Gb/s with 5V SATA power connector (No RAID)
Watchdog Timer:
Software programmable, supports 1~255 sec. system reset
Fan:
1 x 4-pin CPU fan connector
SMBus:1 x 4-pin (1x4) wafer
I2C: 1 x 4-pin (1x4) wafer
LAN LED:2 x 2-pin (1x2) header for LAN1 LED & LAN2 LED
Front Panel:
1 x 6-pin (1x6) wafer for power LED & HDD LED
1 x 2-pin (1x2) wafer for power button
1 x 2-pin (1x2) wafer for power reset button
Expansion:
1 x Full-size PCIe Mini card slot with mSATA support (SATA2
and mSATA shares SATA signal)
IPMI:1 x PCIe Mini slot supports iRIS-1010
Power Supply:
12V only, AT/ATX mode supported

3
1 x 4-pin (2x2) internal power jack
Operation Temperature: -10°C ~ 60°C
Storage Temperature:-20°C ~ 85°C
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 146mm x 102mm
Weight GW/NW: 600g / 250g
Ordering Information
WAFER-KBN-i1-4151-R11:
3.5" SBC supports AMD® 28nm Quad-Core GX-415GA 1.5GHz
(15W) on-board SoC with VGA/LVDS, Dual GbE, PCIe Mini, USB 3.2
Gen 1, SATA 6GB/s, iRIS-1010, HD Audio and RoHS
WAFER-KBN-i1-2101-R11:
3.5" SBC supports AMD® 28nm Dual-Core GX-210HA 1.0GHz (9W)
on-board SoC with VGA/LVDS, Dual GbE, PCIe Mini, USB 3.2 Gen 1,
SATA 6GB/s, iRIS-1010, HD Audio and RoHS
WAFER-KBN-i1-4201-R11:
3.5" SBC supports AMD® 28nm Quad-Core GX-420CA 2.0GHz
(25W) on-board SoC with VGA/LVDS, Dual GbE, PCIe Mini, USB 3.2
Gen 1, SATA 6GB/s, iRIS-1010, HD Audio and RoHS
WAFER-KBN-i1-2171-R11:
3.5" SBC supports AMD® 28nm Dual-Core GX-217GA 1.65GHz
(15W) on-board SoC with VGA/LVDS, Dual GbE, PCIe Mini, USB 3.2
Gen 1, SATA 6GB/s, iRIS-1010, HD Audio and RoHS
32001-008600-200-RS:Dual ports USB 2.0 cable
32205-003800-300-RS:RS-422/485 cable, 200mm
32006-001100-201-RS:PS/2 keyboard and mouse Y cable

4
Jumpers setting and connectors
LABEL
FUNCTION
J_ATX_AT1
AT/ATX mode select switch
J_CMOS1
Clear CMOS button
JP1
LVDS1 voltage selection
SW1
LVDS panel resolution selection
BAT1
Battery connector
FAN1
CPU fan connector
DIMM1
DDR3 SO-DIMM slot
DIO1
Digital I/O connector
DP1
Display port connector
AUDIO1
HD audio connector
M_IPMI1
IPMI iRIS-1010 module slot
KB_MS1
Keyboard and mouse connector
LVDS1
LVDS1 panel connector
INV1
LVDS1 panel backlight +12V power source
M_PCIE1
PCIe Mini card slot
CN5
Power & HDD LED connector
RST_BTN1
Reset button connector
PWR_BTN1
Power button connector
All the drivers and One Key Recovery
utility for the WAFER-KBN-i1 are
available on IEI Resource Download
Center. Type WAFER-KBN-i1 and press
Enter to find all the relevant software,
utilities, and documentation. To install
software from the downloaded ISO file,
mount the file as a virtual drive to view its
content.
IEI Resource Download Center
https://download.ieiworld.com

5
CN8
Power source connector
COM2, COM3
RS-232 serial port connectors
COM4
RS-422/485 serial port connector
SATA1, SATA2
SATA 6Gb/s drive connectors
SATA_PWR1, SATA_PWR2
SATA power connectors
CN6
SMBUS connector
CN7
I2C Connector
CN9
IPMI LED connector
CN10
Chassis intrusion connector
SPDIF1
SPDIF connector
USB2, USB3
Internal USB 2.0 connectors
LAN1, LAN2
RJ-45 LAN connectors
USB1
External USB 3.2 Gen 1 ports
COM1
External RS-232 serial port connector
VGA1
VGA connector
J_ATX_AT1: AT/ATX mode select switch
PIN NO.
DESCRIPTION
Short 1 - 2
ATX Mode (default)
Short 2 - 3
AT Mode
J_CMOS1: Clear CMOS button
PIN NO.
DESCRIPTION
Push
Clear CMOS Setup
JP1: LVDS1 voltage selection
PIN NO.
DESCRIPTION
Short 1 - 2
+3.3 V (Default)
Short 2 - 3
+5 V

6
SW1: LVDS panel resolution selection
* ON=0, OFF=1; Single=S, Dual=D
4-3-2-1
DESCRIPTION
0000
800x600 18bit S (default)
0001
1024x768 18bit S
0010
1024x768 24bit S
0011
1280x768 18bit S
0100
1280x800 18bit S
0101
1280x960 18bit S
0110
1280x1024 24bit D
0111
1366x768 18bit S
1000
1366x768 24bit S
1001
1440x960 24bit D
1010
1400x1050 24bit D
1011
1600x900 24bit D
1100
1680x1050 24bit D
1101
1600x1200 24bit D
1110
1920x1080 24bit D
1111
1920x1200 24bit D
BAT1: Battery Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+VBAT
2
GND
FAN1: CPU fan connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+12V
3
Rotation Signal
4
PWM Control Signal

7
DIO1: Digital I/O connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0
DP1: Display port connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
HPD
2
AUX+
3
GND
4
AUX-
5
CAD
6
GND
7
GND
8
Lane2+
9
Lane3+
10
Lane2-
11
Lane3-
12
GND
13
GND
14
Lane0+
15
Lane1+
16
Lane0-
17
Lane1-
18
VCC3
19
VCC5
20
N/C
AUDIO1: HD audio connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
SPK_R
2
LINE1_R
3
AUD_GND
4
AUD_GND
5
SPK_L
6
LINE1_L
7
AUD_GND
8
AUD_GND
9
MIC1_R
10
MIC1_L

8
KB_MS1: Keyboard and mouse connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
MSDATA
3
MSCLK
4
KBDATA
5
KBCLK
6
GND
LVDS1: LVDS connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
A_Y0
4
A_Y0#
5
A_Y1
6
A_Y1#
7
A_Y2
8
A_Y2#
9
A_CK
10
A_CK#
11
A_Y3
12
A_Y3#
13
GND
14
GND
15
B_Y0
16
B_Y0#
17
B_Y1
18
B_Y1#
19
B_Y2
20
B_Y2#
21
B_CK
22
B_CK#
23
B_Y3
24
B_Y3#
25
GND
26
GND
27
VCC
28
VCC
29
VCC
30
VCC
INV1: LVDS backlight connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LCD_BKLTCTL
2
GND
3
+12V
4
GND
5
BACKLIGHT ENABLE

9
M_PCIE1: PCIe Mini card slot
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
PCIE_WAKE#
2
VCC3
3
N/C
4
GND
5
N/C
6
1.5V
7
N/C
8
N/C
9
GND
10
N/C
11
PCIE_CLK#
12
N/C
13
PCIE_CLK
14
N/C
15
GND
16
N/C
17
N/C
18
GND
19
N/C
20
N/C
21
GND
22
PCIRST#
23
PCIE_RXN(SATA_RX+)
24
VCC3
25
PCIE_RXP(SATA_RX-)
26
GND
27
GND
28
1.5V
29
GND
30
SMBCLK
31
PCIE_TXN(SATA_TX-)
32
SMBDATA
33
PCIE_TXP(SATA_TX+)
34
GND
35
GND
36
USBD-
37
GND
38
USBD+
39
VCC3
40
GND
41
VCC3
42
N/C
43
GND
44
N/C
45
N/C
46
N/C
47
N/C
48
1.5V
49
N/C
50
GND
51
N/C
52
VCC3

10
CN5: Power & HDD LED connector
PIN
DESCRIPTION
PIN
DESCRIPTION
+5V
1
VCC
2
GND
Power LED
3
PWR_LED+
4
PWR_LED-
HDD LED
5
HDD_LED+
6
HDD_LED-
RST_BTN1: Reset button connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RESET+
2
RESET-
PWR_BTN1: Power button connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
PWR_BTN+
2
PWR_BTN-
CN3: Power source connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
+12V
4
+12V
COM2, COM3: RS-232 serial port connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
DSR
3
RXD
4
RTS
5
TXD
6
CTS
7
DTR
8
RI
9
GND
10
GND

11
COM4: RS-422/485 serial port connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RXD422-
2
RXD422+
3
TXD422+/TXD485+
4
TXD422-/TXD485-
SATA1, SATA2: Serial 6Gb/s connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
TX+
3
TX-
4
GND
5
RX-
6
RX+
7
GND
SATA_PWR1, SATA_PWR2: SATA power connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
2
GND
CN6: SMBUS connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
SMBUS DATA
3
SMBUS CLK
4
+5V
CN7: I2C connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
I2C DATA
3
I2C CLK
4
+5V

12
CN9: IPMI LED connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
ID_LED+
2
ID_LED-
CN10: Chassis Intrusion connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
Pull high to +3.3V_ALW
2
CHASSIS_OPEN
SPDIF1: SPDIF connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
2
NC
3
SPDIF OUT
4
GND
5
SPDIF IN
USB2, USB3: Internal USB 2.0 connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
USB_VCC
2
GND
3
DATA-
4
DATA+
5
DATA+
6
DATA-
7
GND
8
USB_VCC

13
USB1: External USB 3.2 Gen 1 (5Gb/s) ports
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
USB_VCC
2
USB2_D0-
3
USB2_D0-
4
GND
5
USB3_RXD0-
6
USB3_RXD0+
7
GND
8
USB3_TXD0-
9
USB3_TXD0+
10
USB_VCC
11
USB2_D1-
12
USB2_D1+
13
GND
14
USB3_RXD1-
15
USB3_RXD1+
16
GND
17
USB3_TXD1-
18
USB3_TXD1+
LAN1: RJ-45 LAN connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LAN1_MDI0+
7
LAN1_MDI2+
2
LAN1_MDI0-
8
LAN1_MDI2-
3
LAN1_MDI1+
9
LAN1_MDI3+
4
LAN1_MDI1-
10
LAN1_MDI3-
LAN2: RJ-45 LAN connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LAN2_MDI0+
7
LAN2_MDI2+
2
LAN2_MDI0-
8
LAN2_MDI2-
3
LAN2_MDI1+
9
LAN2_MDI3+
4
LAN2_MDI1-
10
LAN2_MDI3-

14
COM1: RS-232 serial port connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
VGA1: VGA connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RED
2
GREEN
3
BLUE
4
NC
5
GND
6
GND
7
GND
8
GND
9
VCC
10
GND
11
NC
12
DDCDAT
13
HSYNC
14
VSYNC
15
DDCCLK

15
Board Layout: Jumper and Connector Locations

16
（Unit: mm）
