IEI Technology WAFER-PV-N4552 User manual

WAFER-PV-D5252/D4252/N4552 SBC
Page i
User Manual
3.5" SBC with Intel
®
AtomProcessor
Up to 2.0 GB DDR3, VGA, LVDS, PCIe Mini, RS-232/422/485,
SATA 3Gb/s, CompactFlash®, Eight USB, RoHS
WAFER-PV-D5252/D4252/N4552
MODEL:
Rev. 1.11 – December 17, 2014

WAFER-PV-D5252/D4252/N4552 SBC
Page ii
Revision
Date Version Changes
December 17, 2014 1.11 Added WAFER-PV-D4252 information
November 24, 2014 1.10 Updated for R11 version
- Changed audio controller from ALC888 to ALC662
- Updated Chapter 5: BIOS
November 7, 2014 1.03 Modified COM port information to
- RS-232 serial port: COM2~COM5
- RS-232/422/485 serial port: COM6
March 20, 2013 1.02 Modified supported memory specifications (Table 1-1)
March 4, 2011 1.01 Modified LVDS connector pinouts (Table 3-11)
Modified LVDS resolution select jumper settings
(Table 4-5)
January 11, 2011 1.00 Initial release

WAFER-PV-D5252/D4252/N4552 SBC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

WAFER-PV-D5252/D4252/N4552 SBC
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 BENEFITS ................................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 3
1.5 DIMENSIONS............................................................................................................... 4
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST............................................................................................................. 9
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.4 OPTIONAL ITEMS...................................................................................................... 12
3 CONNECTOR PINOUTS........................................................................................... 13
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 14
3.1.1 Layout .............................................................................................................. 14
3.1.2 Peripheral Interface Connectors ..................................................................... 15
3.1.3 External Interface Panel Connectors............................................................... 16
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 16
3.2.1 ATX Power Connector ..................................................................................... 16
3.2.2 Audio Connector .............................................................................................. 17
3.2.3 Battery Connector............................................................................................ 18
3.2.4 CompactFlash® Slot........................................................................................ 19
3.2.5 Digital I/O Connector...................................................................................... 20
3.2.6 Fan Connectors................................................................................................ 21
3.2.7 Keyboard/Mouse Connector ............................................................................ 22
3.2.8 LED and +5 V Power Output Connector......................................................... 23
3.2.9 LVDS Connector .............................................................................................. 24
3.2.10 LVDS Backlight Connector............................................................................ 25

WAFER-PV-D5252/D4252/N4552 SBC
Page v
3.2.11 PCIe Mini Card Slot....................................................................................... 26
3.2.12 Power Button Connector................................................................................ 28
3.2.13 Reset Button Connector ................................................................................. 28
3.2.14 RS-232/422/485 Serial Port Connector (COM6) .......................................... 29
3.2.15 RS-232 Serial Port Connector (COM2~COM5)............................................ 30
3.2.16 SATA Drive Connectors ................................................................................. 31
3.2.17 SATA Power Connectors................................................................................ 32
3.2.18 SMBus Connector .......................................................................................... 33
3.2.19 SO-DIMM Connector..................................................................................... 33
3.2.20 SPI Flash Connector...................................................................................... 34
3.2.21 USB Connectors............................................................................................. 35
3.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 36
3.3.1 Ethernet Connectors ........................................................................................ 36
3.3.2 Serial Port Connector...................................................................................... 37
3.3.3 USB Ports......................................................................................................... 38
3.3.4 VGA Connector................................................................................................ 38
4 INSTALLATION ......................................................................................................... 40
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 41
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 42
4.3 SO-DIMM INSTALLATION ....................................................................................... 43
4.4 COMPACTFLASH®INSTALLATION ............................................................................ 44
4.5 JUMPER SETTINGS .................................................................................................... 45
4.5.1 AT/ATX Mode Selection ................................................................................... 45
4.5.2 Clear CMOS Jumper........................................................................................ 46
4.5.3 LVDS Voltage Selection.................................................................................... 47
4.5.4 LVDS Resolution Selection .............................................................................. 48
4.5.5 CompactFlash® Master/Slave Selection......................................................... 49
4.5.6 COM6 RS-232/422/485 Selection.................................................................... 50
4.5.7 COM 1 Pin 9 Setting Jumper........................................................................... 51
4.6 CHASSIS INSTALLATION............................................................................................ 52
4.6.1 Airflow.............................................................................................................. 52
4.6.2 Motherboard Installation................................................................................. 52
4.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 52
4.7.1 AT Power Connection ...................................................................................... 52

WAFER-PV-D5252/D4252/N4552 SBC
Page vi
4.7.2 Audio Kit Installation....................................................................................... 53
4.7.3 Keyboard/Mouse Connector ............................................................................ 55
4.7.4 Four Serial Port Connector............................................................................. 57
4.8 SOFTWARE INSTALLATION ........................................................................................ 58
5 BIOS.............................................................................................................................. 60
5.1 INTRODUCTION......................................................................................................... 61
5.1.1 Starting Setup................................................................................................... 61
5.1.2 Using Setup...................................................................................................... 61
5.1.3 Getting Help..................................................................................................... 62
5.1.4 Unable to Reboot After Configuration Changes.............................................. 62
5.1.5 BIOS Menu Bar................................................................................................ 62
5.2 MAIN........................................................................................................................ 63
5.3ADVANCED............................................................................................................... 64
5.3.1 ACPI Configuration......................................................................................... 65
5.3.2 RTC Wake Settings........................................................................................... 66
5.3.3 CPU Configuration.......................................................................................... 67
5.3.4 IDE Configuration........................................................................................... 68
5.3.5 USB Configuration........................................................................................... 70
5.3.6 Super IO Configuration ................................................................................... 71
5.3.6.1 Serial Port n Configuration....................................................................... 72
5.3.7 H/W Monitor.................................................................................................... 77
5.3.8 Serial Port Console Redirection ...................................................................... 78
5.3.9 IEI Feature....................................................................................................... 80
5.4 CHIPSET ................................................................................................................... 81
5.4.1 Host Bridge...................................................................................................... 82
5.4.2 South Bridge..................................................................................................... 83
5.4.3 Intel IGD SWSCI OpRegion............................................................................. 85
5.5 BOOT........................................................................................................................ 87
5.6 SECURITY................................................................................................................. 89
5.7 EXIT......................................................................................................................... 89
A BIOS OPTIONS .......................................................................................................... 91
B TERMINOLOGY........................................................................................................ 94
C DIGITAL I/O INTERFACE....................................................................................... 98

WAFER-PV-D5252/D4252/N4552 SBC
Page vii
C.1 INTRODUCTION........................................................................................................ 99
C.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 100
C.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 100
D HAZARDOUS MATERIALS DISCLOSURE....................................................... 101
D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 102

WAFER-PV-D5252/D4252/N4552 SBC
Page viii
List of Figures
Figure 1-1: WAFER-PV-D5252/D4252/N4552................................................................................2
Figure 1-2: Connectors ..................................................................................................................3
Figure 1-3: Dimensions without Heatsink (mm)..........................................................................4
Figure 1-4: Dimensions with Heatsink (mm)................................................................................5
Figure 1-5: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................14
Figure 3-2: ATX Power Connector Location..............................................................................17
Figure 3-3: Audio Connector Location.......................................................................................17
Figure 3-4: Battery Connector Location.....................................................................................18
Figure 3-5: CompactFlash® Slot Location.................................................................................19
Figure 3-6: Digital I/O Connector Location ................................................................................21
Figure 3-7: Fan Connector Locations.........................................................................................22
Figure 3-8: Keyboard/Mouse Connector Location....................................................................23
Figure 3-9: LED and +5 V Power Output Connector Location.................................................24
Figure 3-10: LVDS Connector Location......................................................................................25
Figure 3-11: Backlight Inverter Connector.................................................................................26
Figure 3-12: PCIe Mini Card Slot Location.................................................................................27
Figure 3-13: Power Button Connector Location........................................................................28
Figure 3-14: Reset Button Connector Location.........................................................................29
Figure 3-15: RS-232/422/485 Serial Port Connector Location..................................................29
Figure 3-16: RS-232 Serial Port Connector Location................................................................30
Figure 3-17: SATA Drive Connector Location ...........................................................................31
Figure 3-18: SATA Power Connector Locations .......................................................................32
Figure 3-19: SMBus Connector Location...................................................................................33
Figure 3-20: SO-DIMM Connector Location...............................................................................34
Figure 3-21: SPI Flash Connector Location...............................................................................34
Figure 3-22: USB Connector Location........................................................................................35
Figure 3-23: External Interface Connectors...............................................................................36
Figure 3-24: Ethernet Connector.................................................................................................37
Figure 3-25: Serial Port Pinout Locations..................................................................................38

WAFER-PV-D5252/D4252/N4552 SBC
Page ix
Figure 3-26: VGA Connector .......................................................................................................39
Figure 4-1: SO-DIMM Installation................................................................................................43
Figure 4-2: CompactFlash® Card Installation ...........................................................................44
Figure 4-3: AT/ATX Mode Selection Jumper Location..............................................................46
Figure 4-4: Clear CMOS Jumper Location .................................................................................47
Figure 4-5: LVDS Voltage Selection Jumper Location .............................................................48
Figure 4-6: LVDS Resolution Selection Jumper Location........................................................49
Figure 4-7: CompactFlash® Master/Slave Selection Jumper Location ..................................50
Figure 4-8: COM6 RS-232/422/485 Selection Jumper Location...............................................50
Figure 4-9: COM 1 Pin 9 Setting Jumper Location....................................................................51
Figure 4-10: Power Cable to Motherboard Connection............................................................53
Figure 4-11: Audio Kit Cable Connection ..................................................................................54
Figure 4-12: Connect Power Cable to Power Supply................................................................55
Figure 4-13: Keyboard/mouse Y-cable Connection..................................................................56
Figure 4-14: Four Serial Port Connector....................................................................................57
Figure 4-15: Serial Device Connector.........................................................................................58
Figure 4-16: Introduction Screen................................................................................................59
Figure 4-17: Available Drivers.....................................................................................................59

WAFER-PV-D5252/D4252/N4552 SBC
Page x
List of Tables
Table 1-1: Technical Specifications..............................................................................................8
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................12
Table 3-1: Peripheral Interface Connectors...............................................................................16
Table 3-2: Rear Panel Connectors..............................................................................................16
Table 3-3: ATX Power Connector Pinouts .................................................................................17
Table 3-4: Audio Connector Pinouts ..........................................................................................18
Table 3-5: Battery Connector Pinouts........................................................................................18
Table 3-6: CompactFlash® Slot Pinouts....................................................................................20
Table 3-7: Digital I/O Connector Pinouts....................................................................................21
Table 3-8: Fan Connector Pinouts..............................................................................................22
Table 3-9: Keyboard/Mouse Connector Pinouts .......................................................................23
Table 3-10: LED and +5 V Power Output Connector Pinouts...................................................24
Table 3-11: LVDS Connector Pinouts.........................................................................................25
Table 3-12: Backlight Inverter Connector ..................................................................................26
Table 3-13: PCIe Mini Card Slot Pinouts ....................................................................................28
Table 3-14: Power Button Connector Pinouts...........................................................................28
Table 3-15: Reset Button Connector Pinouts............................................................................29
Table 3-16: RS-232/422/485 Serial Port Connector Pinouts.....................................................30
Table 3-17: Serial Port Connector Pinouts ................................................................................31
Table 3-18: SATA Drive Connector Pinouts...............................................................................32
Table 3-19: SATA Power Connector Pinouts.............................................................................32
Table 3-20: SMBus Connector Pinouts ......................................................................................33
Table 3-21: SPI Flash Connector Pinouts ..................................................................................34
Table 3-22: USB Port Connector Pinouts...................................................................................35
Table 3-23: Ethernet Connector Pinouts....................................................................................36
Table 3-24: RJ-45 Ethernet Connector LEDs.............................................................................37
Table 3-25: Serial Port Pinouts....................................................................................................37
Table 3-26: USB Connector Pinouts...........................................................................................38
Table 3-27: VGA Connector Pinouts...........................................................................................39

WAFER-PV-D5252/D4252/N4552 SBC
Page xi
Table 4-1: Jumpers.......................................................................................................................45
Table 4-2: AT/ATX Mode Selection .............................................................................................46
Table 4-3: Clear CMOS Jumper Settings....................................................................................47
Table 4-4: LVDS Voltage Selection.............................................................................................48
Table 4-5: LVDS Resolution Selection........................................................................................48
Table 4-6: CompactFlash® Master/Slave Selection..................................................................49
Table 4-7: COM6 RS-232/422/485 Selection...............................................................................50
Table 4-8: COM 1 Pin 9 Setting Jumper Settings......................................................................51
Table 5-1: BIOS Navigation Keys................................................................................................62

WAFER-PV-D5252/D4252/N4552 SBC
Page xii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................63
BIOS Menu 2: Advanced..............................................................................................................64
BIOS Menu 3: ACPI Configuration..............................................................................................65
BIOS Menu 4: RTC Wake Settings..............................................................................................66
BIOS Menu 5: CPU Configuration...............................................................................................67
BIOS Menu 6: IDE Configuration.................................................................................................68
BIOS Menu 7: USB Configuration...............................................................................................70
BIOS Menu 8: Super IO Configuration........................................................................................71
BIOS Menu 9: Serial Port n Configuration Menu.......................................................................72
BIOS Menu 10: Hardware Health Configuration........................................................................77
BIOS Menu 11: Serial Port Console Redirection.......................................................................79
BIOS Menu 12: IEI Feature...........................................................................................................80
BIOS Menu 13: Chipset................................................................................................................81
BIOS Menu 14:Host Bridge Configuration.................................................................................82
BIOS Menu 15:Southbridge Chipset Configuration..................................................................83
BIOS Menu 16: Intel IGD SWSCI OpRegion ...............................................................................85
BIOS Menu 17: Boot.....................................................................................................................87
BIOS Menu 18: Security...............................................................................................................89
BIOS Menu 19:Exit........................................................................................................................90

WAFER-PV-D5252/D4252/N4552 SBC
Page 1
Chapter
1
1 Introduction

WAFER-PV-D5252/D4252/N4552 SBC
Page 2
1.1 Introduction
Figure 1-1: WAFER-PV-D5252/D4252/N4552
The WAFER-PV-D5252/D4252/N4552 is a 3.5" SBC with a Intel® AtomD525, D425 or
N455 CPU.
The WAFER-PV-D5252/D4252/N4552 is designed for fanless operation. The low power
CPUs don't require active cooling and stay within specified heat range using the included
heatsink.
Storage on the board is handled by a SATA 3Gb/s port for connecting a hard drive, optical
drive or SSD. The CompactFlash® slot allows a Type II CompactFlash® card to be
installed.
The board has two graphics outputs. A VGA output connects to a traditional VGA monitor
and one LVDS connector supports 18-bit single-channel display.
Other slots and connectors include a PCIe Mini cards slot, RS-232, RS-232/422/485,
Gigabit Ethernet, USB ports, and digital I/O.
1.2 Benefits
Some of the WAFER-PV-D5252/D4252/N4552 motherboard benefits include:
Low power consumption
Wide range of I/O interfaces
Dual display support

WAFER-PV-D5252/D4252/N4552 SBC
Page 3
1.3 Features
Some of the WAFER-PV-D5252/D4252/N4552 motherboard features are listed below:
3.5" form factor
Fanless design
RoHS compliant
Eight USB 2.0 ports
Six serial ports
PCIe Mini card slot
CompactFlash® Type II slot
Gigabit Ethernet
1.4 Connectors
The connectors on the WAFER-PV-D5252/D4252/N4552 are shown in the figure below.
Figure 1-2: Connectors

WAFER-PV-D5252/D4252/N4552 SBC
Page 4
1.5 Dimensions
The main dimensions of the WAFER-PV-D5252/D4252/N4552 are shown in the diagram
below.
Figure 1-3: Dimensions without Heatsink (mm)

WAFER-PV-D5252/D4252/N4552 SBC
Page 5
Figure 1-4: Dimensions with Heatsink (mm)

WAFER-PV-D5252/D4252/N4552 SBC
Page 6
1.6 Data Flow
Figure 1-5 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-5: Data Flow Diagram

WAFER-PV-D5252/D4252/N4552 SBC
Page 7
1.7 Technical Specifications
WAFER-PV-D5252/D4252/N4552 technical specifications are listed in Table 1-1.
Specification WAFER-PV-D5252/D4252/N4552
Form Factor 3.5"
Socket Embedded
CPU Supported 1.8 GHz Intel® AtomD525 dual-core CPU with 1 MB L2 cache
1.8 GHz Intel® AtomD425 single-core CPU with 512 KB L2 cache
1.66 GHz Intel® AtomN455 single-core CPU with 512 KB L2 cache
System Chipset Intel® ICH8M
Memory One 204-pin 800 MHz DDR3 SDRAM SO-DIMM
D525/D425: system max. 4.0 GB
N455: system max. 2.0 GB
Graphic Engine Intel® GMA3150
D525/D425: Gen 3.5 DX9, 400 MHz
N455: Gen 3.5 DX9, 200 MHz
Integrated Graphics Analog CRT (CRT hot plug supported)
D525/D425: up to 2048 x 1536
N455: up to 1400 x 1050
18-bit single-channel LVDS
BIOS UEFI BIOS
Digital I/O 8-bit, 4-bit input/4-bit output
Ethernet Controllers Two Realtek RTL8111E PCIe GbE controllers
(LAN1 supports ASF2.0)
Audio Realtek ALC662 HD Audio codec
Super I/O Controller Fintek F81865F
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion PCIe Mini slot (PCIe + USB + SATA signal) supports IEI PCIe Mini disk
on module (DOM) cards

WAFER-PV-D5252/D4252/N4552 SBC
Page 8
I/O Interface Connectors
Fan connector Two 3-pin wafer for system fan
Keyboard/Mouse One internal 6-pin wafer connector
Serial Ports Five RS-232 COM connectors
One RS-232/422/485 COM connector
USB 2.0/1.1 ports Six internal via pin header
Two external USB ports
SMBus One 4-pin wafer connector
Storage
IDE CompactFlash® Type II slot
SATA Two independent SATA channels with 3.0 Gb/s data transfer rates
Environmental and Power Specifications
Power Supply AT or ATX, 12 V only
Power Consumption 12 V @ 1.79 A (1.8 GHz Intel® AtomD525 dual-core CPU with one
1 GB DDR3 SO-DIMM)
Operating temperature D525: -20ºC ~ 60ºC with free air; -20ºC ~ 70ºC with force air
D425: -20ºC ~ 65ºC with free air; -20ºC ~ 70ºC with force air
N455: -20ºC ~ 70ºC with free air; -20ºC ~ 75ºC with force air
Humidity 0% ~ 95% (non-condensing)
Physical Specifications
Dimensions 102 mm x 146 mm
Weight GW/NW 600 g/250 g
Table 1-1: Technical Specifications
