IEI Technology WSB-Q354-R42 User manual

1
PICMG1.0 CPU Card supports Intel® 45nm LGA 775
Core™2 Quad/Duo Processor at FSB 800/1066/1333, VGA,
Dual PCIe GbE, 6 SATA 3Gb/s, FDD, LPT, USB 2.0
WSB-Q354-R42
Quick Installation Guide
Version 4.2
May 13, 2013
Package Contents
WSB-Q354 package includes the following items:
1 x WSB-Q354 single board computer
1 x Dual RS-232 cable
1 x KB/MS Y cable
1 x USB cable
3 x SATA power cable
6 x SATA cable
1 x mini jumper pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
© 2011 Copyright by IEI Technology corp.
All rights reserved.

2
Specifications
CPU: LGA775 45nm Intel® Core™2 Quad/ Duo, Celeron at FSB
800/1066/1333MHz processors
System Chipset: Intel® Q35+ICH9R
BIOS: AMI BIOS
System Memory: 4x 240-pin dual channel DDR2 at 800/667MHz
up to 8GB
Ethernet: Dual Realtek RTL8111E GbE controller with ASF2.0
I/O Interface:
2 x RS-232
7 x USB2.0 (1 on bracket, 6 by pin header)
6 x SATA 3Gb/s supports RAID 0,1,10, 5
1 x FDD
1 x LPT
1 x IrDA
1 x PS/2 KB/MS
1 x 5-pin wafer for KB
Super I/O: ITE IT8718F
Digital I/O: 8-bit Digital I/O (4-bit input / 4-bit output)
Display: VGA integrated in Intel® Q35
Audio: 10-pin on-board header support 7.1 channel HD Audio by
IEI AC-KIT888HD
TPM: 1x 20-pin on-board header for TPM
Watchdog Timer: Software programmable 1-255 sec. system
reset
Power Supply: ATX power supply
Power Consumption:
5V @5.97A, 5Vsb @0.07A, 12V @0.29A , Vcore @2.97A (Intel®
Core™2 Duo E8500 3.16 GHz,DDR2 800MHz 2GB x 4 running 3D
Mark 2001SE)
Temperature: 0 ~ 60C( 32 ~ 140F)

3
Ordering Information
WSB-Q354-R41
PICMG1.0 CPU Card support Intel® 45nm LGA 775 Core™2 Quad/ Duo,
Celeron CPU processor at FSB 800/1066/1333MHz, VGA, Dual GbE, 6
SATA 3Gb/s with RAID,FDD,LPT,USB 2.0
AC-KIT888HD-R10
7.1Channel HD Audio kit with Realtek ALC888 support dual audio streams
CF-775A-RS
High performance CPU cooler (115mmx115mmx67mm , 130W)
CF-520-RS-R11
High performance CPU cooler (115mmx115mmx67mm , 115W)
TPM-IN01-R11
Infineon 20-pin Trusted Platform Module with SW Management Tool,
firmware V3.17
Jumpers setting and Connectors
J_CMOS1 : Clear CMOS Setup
JSPI_SEL1
DESCRIPTION
1-2
Normal(Default)
2-3
Clear CMOS Data
KB1 : 5-pin Keyboard Connector
PIN
DESCRIPTION
1
KEYBOARD CLOCK
2
KEYBOARD DATA
3
N/C
4
GROUND
5
VCC
JLAN_PWR1 : WOL enable jumper(Optional)
DESCRIPTION
1-3
LAN 2 WOL Enable(Default)
2-4
LAN 1 WOL Enable(Default)
3-5
LAN 2 WOL Disable
4-6
LAN 1 WOL Disable

4
ATXCTL1 : Backplane
Power Connector
PIN
DESCRIPTION
1
Ground
2
PS_ON
3
5V Dual
TPM1: Trusted Platform Module connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
FWHPCLK
2
GND
3
LFRAME#
4
KEY
5
PCIRST#
6
VCC
7
LAD3
8
LAD2
9
VCC3
10
LAD1
COM1, COM2 : External Serial Port Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
DCD#
2
DSR#
3
RXD
4
RTS#
5
TXD
6
CTS#
7
DTR#
8
RI#
9
GND
10
NC
USB01, USB23, USB45: Internal USB Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
VCC
2
GND
3
DATA-
4
DATA+
5
DATA+
6
DATA-
7
GND
8
VCC
J_AUDIO1 : Audio Source Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
ACZ_SYNC
2
ACZ_BITCLK
3
ACZ_SDOUT
4
ACZ_PCBEEP
5
ACZ_SDIN
6
ACZ_RST#
7
ACZ_VCC(+5V)
8
ACZ_GND
9
ACZ_12V
10
ACZ_GND
IR1: IrDA connector
PIN
DESCRIPTION
1
VCC
2
NC
3
IR-RX
4
GND
5
IR-TX

5
11
LAD0
12
GND
13
SMBCLK
14
SMBDATA
15
3VDUAL
16
SERIRQ
17
GND
18
CLKRUN#
19
LPCPD#
20
LDRQ#
CPU_FAN1 : CPU Fan Connector
PIN
DESCRIPTION
1
Ground
2
+12V
3
Rotation Signal
4
Control
DIO1 : Digital Input / Output Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
Ground
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0
F_PANEL1 : External Switches and Indicators panel
PIN
DESCRIPTION
PIN
DESCRIPTION
Power LED
1
+5V
2
+5V
Speaker
3
N/C
4
N/C
5
GROUND
6
N/C
PWRBTN
7
PWRBTN+
8
Speaker
9
PWRBTN-
10
N/C
RESET
HDDLED
11
+5V
12
Reset-
13
HDLED-
14
GND
CPU12V1: ATX-12V1 (CPU)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
+12V
4
+12V

6
Board Layout: Jumper and Connector Locations
