Ignition Pico IR / Wireless User manual

M ANUAL
Pico IR / Wireless

2 / 9
PIC O IR/ WIRELESS
Table of contents
1. Safety instructions ........................................................................................................................... 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Commissioning................................................................................................................................ 4
2.1. Charging.................................................................................................................................. 4
3. Remote control ................................................................................................................................ 5
4. Wireless DMX.................................................................................................................................. 6
4.1. Setting the DMX address......................................................................................................... 6
5. Troubleshooting Pico....................................................................................................................... 7
6. Troubleshooting Flightcase ............................................................................................................. 7
7. Maintenance.................................................................................................................................... 8
8. Technical Data................................................................................................................................. 8

3 / 9
PIC O IR/ WIRELESS
1. Safety instructions
This device is suitable for indoor use only.
All modifications to the device will void the warranty.
Repairs are to carry out by skilled personnel only.
Use only fuses of the same type and original parts as spare parts.
Protect the unit from rain and humidity to avoid fire and electric shocks.
Make sure to unplug the power supply before opening the housing.
1.1. FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing, do not
open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to disconnect the
plug from the receptacle.

4 / 9
PIC O IR/ WIRELESS
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
- Before using: Make sure that there are no external damages.
- The minimum distance to flammable objects is 0,2m
- For vertical operation, the equipment complies with IP63 standard.
- There can be a maximum housing-temperature of tc=45°C.
- Don´t plug an audio or DMX device to the XLR plug. It can cause permanent damages of the
devices.
- Because of is lead gel battery you are not allowed to dispose it of in household waste.
- This battery is a high-quality product with approval of medical devices.
- The „Amptown“-Flightcase (optional) corresponds to the IP20 standard.
Important:
Every 3 weeks should be a regeneration charging to take place to avoid damaging the
battery.
2. Commissioning
Push the ON button on the IR remote control. The unit turns on and is ready for operation.
2.1. Charging
Connect the LED headlamp with the included power supplyIn the event you have bought a “Tourpack”
you can connect the device with pre-installed XLR connectors.
While charging the LED headlamp should be turned off, otherwise there can be no sufficient charge.
The loading process can take up to 10 hours, depending on the remaining charge of the battery.
If you turn the switch on the charging rail you can see the state of charge for every battery (only
possible with the “Tourpack”).

5 / 9
PIC O IR/ WIRELESS
3. Remote control
1
increase brightness
2
lower the brightness
3
red permanently
4
green permanently
5
orange permanently
6
lime permanently
7
dark yellow permanently
8
blue-green permanently
9
yellow permanently
10
light blue permanently
11
light yellow permanently
12
sky-blue permanently
13
red intensify
14
green intensify
15
red reduce
16
green reduce
17
custom setting 1
18
custom setting 2
19
custom setting 4
20
custom setting 5
21
color change with flash ( 3 colors)
22
color-change with flash (7 colors)
23
On/Off
24
Start/Pause
25
white permanently
26
blue permanently
27
beige permanently
28
dark blue permanently
29
white pink permanently
30
ultramarine permanently
31
green white permanently
32
purple permanently
33
blue white permanently
34
blackberry permanently
35
faster
36
blue intensify
37
slower
38
blue reduce
39
automatic change
40
custom setting 3
41
flash on/off
42
custom setting 6
43
smooth color change (7 colors)
44
smooth color change (3 colors)

6 / 9
PIC O IR/ WIRELESS
4. Wireless DMX
Only available if you bought the version “Pico IR Wireless“, otherwise you only can control the device
with the remote control.
LED display and its meaning
Permanently off = not connected to the transmitter
Permanently on = connected with the transmitter / DMX is transmitted
900ms on/ 100ms off = connected with the transmitter / No DMX signal
100ms on/ 100ms off = loose connection / Connection is perpared
4.1. Setting the DMX address
You can set the DMX address with the help of a binary system on the “Dipswitch“.In this cause the
“Dip” 10 is the set function. Switch the “Dip” 10 to on to release the connection to the wireless solution
transmitter. Switch the “Dip” then again to off.

7 / 9
PIC O IR/ WIRELESS
5. Troubleshooting Pico
The unit does not turn on.
Error
Failure of one color
Failure of the projection.
Light yield reduced
Possible causes
Check and reaction
x
No power supply.
Check the battery voltage
x
x
Defect LED.
Change the defect LED.
x
Empty battery of remote control.
Change the battery.
x
x
Defect optics.
Contact qualified personnel.
x
x
Dust or dirt.
Clean the device.
x
Defect remote control.
Change the defect remote control.
x
x
x
Fault in the electronics.
Contact qualified personnel.
x
x
Defect battery.
Contact qualified personnel.
6. Troubleshooting Flightcase
There is no charge
Error
No charge status indicator.
State of charge indicator does not reach max.
Possible causes
Check and reaction
x
No power supply.
Check the voltage
x
Defect power supply
Contact qualified personnel.
x
x
x
Fault in the electronics.
Contact qualified personnel.
x
x
Contact error of the XLR connectors.
Plug the XLR connector again.
x
Contact error.
Contact qualified personnel.
x
x
x
Defect battery.
Contact qualified personnel.
x
x
Switched on headlight.
Switch the headlight off.

8 / 9
PIC O IR/ WIRELESS
7. Maintenance
Opening the device may only be performed by technical personnel only!
- Remove the caps which are on the handle with a flat screwdriver.
- Among them are two screws, unscrew them and remove the handle.
- Now you can pull out the whole inner part down.
- .
-
8. Technical Data
Measures: 120 x 120 x 181mm
Weight: 3,5kg
Voltage: 100 –240V 50/60Hz via power supply
Lamp: LED (3x3W green, 3x3W blue, 4x3W red)
Radiation: 10°
Operating time: White 6h, single color 20h
Battery: 7,5A Lead-acid battery
Control: via IR remote control
Pico IR wireless Via Wireless Solution DMX
Housing: 4mm aluminum
Connections: XLR 3-pol for power supply

9 / 9
PIC O IR/ WIRELESS
Importeur:
B&K Braun GmbH
Industriestraße 2
D-76307 Karlsbad-Ittersbach
www.bkbraun.com
[email protected]
