Triflex®R
CLACK!
1 2
1 2
1 2
CLICK!
Phone +49- (0) 22 03-96 49-800 Fax +49- (0) 22 03-96 49-222 Triflex®R
Assembly Instruction Triflex®R - TRC
igus®GmbH
51147 Cologne
Internet: www.igus.de E-mail: [email protected]
Assembly instructions Version TRE and TRL page 2.6/2.7
Hold two pieces together at inner radius and move socket up against the ball´s wedged end
Assembly - TRC.40 · TRC.60 · TRC.70 · TRC.100
Bend Triflex®into its radius and twist apart, counter-clockwise
Separating - TRC.40
Insert screw driver into the opening of the socket from the top. Then twist apart, counter-clockwise.
Separating - TRC.60 · TRC.70 · TRC.100

2.6
Triflex®R
CLICK!
CLACK!
12
1 2
1 2
1 2
Assembly instructions Version TRC page 2.5
Phone +49- (0) 22 03-96 49-800 Fax +49- (0) 22 03-96 49-222
igus®GmbH
51147 Cologne
Internet: www.igus.de E-mail: [email protected] igus®E-ChainSystems®
Assembly Instruction Triflex®R - TRE
Hold two pieces together at inner radius and move socket up against the ball´s wedged end.
Push until a klicking sound indicates a secure fit of socket onto the ball.
Assembly - TRE.40 · TRE.60 · TRE.70 · TRE.100 (chain section exposed for the purpose of demonstration)
Insert screw driver into the opening of the socket from the top. Then twist apart, counter-clockwise.
Separating - TRE.60 · TRE.70 · TRE.100
Bend Triflex®into its radius and twist apart, counter-clockwise
Separating - TRE.40
Easy to fill - simply press cable in...
Filling - TRE.40 · TRE.60 · TRE.70 · TRE.100
...and easy to take the cables out

3
2.7
Triflex®R
CLACK!
12
12
1 2
1 2
Triflex®R
Easy to fill - simply press cable in...
Filling - TRL.40 · TRL.60 · TRL.70 · TRL.100
...and easy to take the cables out
Phone +49- (0) 22 03-96 49-800 Fax +49- (0) 22 03-96 49-222
Assembly Instruction Triflex®R - TRL
igus®GmbH
51147 Cologne
Internet: www.igus.de E-mail: [email protected]
Assembly instructions Version TRC page 2.5
Very easy to assemble - simply press the ball into the socket, ready!
Assembly - TRL.40 · TRL.60 · TRL.70 · TRL.100
Just twist the ball slightly to remove it from its socket
Separating - TRL.40 · TRL.60 · TRL.70 · TRL.100
Easy assembly - open the mounting bracket, install the chain and snap the mounting bracket shut again.
To open, push a screwdriver against one side and pry apart.
Mounting bracket installation - in this case, a "light" bracket with an intermediate connection
