Iiyama ProLite TF6537UHSC-B1AG User manual

ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the monitor.
Please keep this manual in a safe place for
your future reference.
USER MANUAL

ENGLISH
 We reserve the right to change specifi cations without notice.
 All trademarks used in this user manual are the property of their respective owners.
We recommend recycling of used product. Please contact your dealer or iiyama
service center. Recycle information is obtained via the Internet, using the
address: http://www.iiyama.com
You can access the Web page of diff erent countries from there.
CE MARKING DECLARATION OF CONFORMITY
This LCD monitor complies with the requirements of the EC/EU Directive 2014/30/EU “EMC
Directive”, 2014/35/EU “Low Voltage Directive”, 2009/125/EC “ErP Directive” and 2011/65/EU
“RoHS Directive”.
Warning
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands
Model No. : PL6537

ENGLISH
TABLE OF CONTENTS
FOR YOUR SAFETY ............................................................................1
SAFETY PRECAUTIONS................................................................1
SPECIAL NOTES ON LCD MONITORS .........................................3
CUSTOMER SERVICE ...................................................................5
CLEANING ......................................................................................5
BEFORE YOU OPERATE THE MONITOR ..........................................6
FEATURES......................................................................................6
CHECKING THE CONTENTS OF THE PACKAGE ........................6
UNPACKING ...................................................................................7
SPECIAL NOTES ON ......................................................................7
CONTROLS AND CONNECTORS : MONITOR ..............................8
INSTALLATION ...............................................................................9
CONTROLS AND CONNECTORS :
REMOTE CONTROL (For maintenance) ...................................... 11
PREPARING THE REMOTE CONTROL.......................................12
BASIC OPERATION ......................................................................13
CONNECTING YOUR MONITOR .................................................16
COMPUTER SETTING .................................................................18
OPERATING THE MONITOR .............................................................19
ADJUSTMENT MENU CONTENTS ..............................................21
POWER MANAGEMENT FEATURE .............................................33
TROUBLE SHOOTING ......................................................................34
RECYCLING INFORMATION .............................................................35
APPENDIX ........................................................................................36
SPECIFICATIONS .........................................................................36
DIMENSIONS ................................................................................37
COMPLIANT TIMING ....................................................................38

ENGLISH
FOR YOUR SAFETY 1
FOR YOUR SAFETY
WARNING
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the
monitor and contact your dealer or iiyama service center immediately. Further use may be
dangerous and can cause fi re or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of
fi re or electric shock.
DO NOT PUT ANY OBJECT INTO THE MONITOR
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug
your monitor immediately and contact your dealer or iiyama service center. Using the monitor with
any object inside may cause fi re, electric shock or damage.
INSTALL THE MONITOR ON A FLAT, STABLE SURFACE
The monitor may cause an injury if it falls or is dropped.
DO NOT USE THE MONITOR NEAR WATER
Do not use where water may be splashed or spilt onto the monitor as it may cause fi re or electric
shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the monitor only with the specifi ed power supply. Use of an incorrect voltage will
cause malfunction and may cause fi re or electric shock.
PROTECT THE CABLES
Do not pull or bend the power cable and signal cable. Do not place the monitor or any other heavy
objects on the cables. If damaged, the cables may cause fi re or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in
power may cause malfunction. It is also advised not to touch the plug in these circumstances as it
may cause electric shock.
SAFETY PRECAUTIONS

ENGLISH
2 FOR YOUR SAFETY
CAUTION
INSTALLATION LOCATION
Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or
smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the
sun shines directly on the monitor.
DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION
The monitor may topple and cause injury if not suitably located. Please also ensure that you do not
place any heavy objects on the monitor, and that all cables are routed such that children may not
pull the cables and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause
fi re. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls.
Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the
cabinet will be blocked and the monitor may overheat if the stand is removed. This may cause fi re
or damage. Operating the monitor on its back, side, upside down or on a carpet or any other soft
material may also cause damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR
When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal
cable is disconnected. If you do not disconnect them, it may cause fi re or electric shock.
UNPLUG THE MONITOR
If the monitor is not in use for a long period of time it is recommended that it is left unplugged to
avoid accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable
itself as this may cause fi re or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may
damage your computer.
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room.
For optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches)
away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour
is recommended as looking at the screen continuously can cause eye strain.
OTHERS

ENGLISH
FOR YOUR SAFETY 3

The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE - When you fi rst turn on the LCD monitor, the picture may not fi t in the display area
because of the type of computer that is used. In this case, adjust the picture position to
the correct position.
- You may fi nd slightly uneven brightness on the screen depending on the desktop
pattern you use.
- Due to the nature of the LCD screen, an afterimage of the previous screen may remain
after switching the image, when the same image is displayed for hours. In this case, the
screen is recovered slowly by changing the image or turning off the Power Switch for
hours.
SPECIAL NOTES ON LCD MONITORS

This LCD cannot be used outdoors.

If you use a cable longer than the supplied one, the picture quality is not guaranteed. Touch
function can be disrupted if the USB cable length exceeds 3m.

ENGLISH
4 FOR YOUR SAFETY
USAGE CONFIRMATION
This product is designed for optimum usage at 24hours per day.
The display is compatible for usage in Landscape/Portrait and Tabletop (face-up) applications. If
being used in Tabletop application, please utilise the Fan-on function.
IMAGE PERSISTENCE / IMAGE STICKING
Please be aware that all LCD screens can experience Image Persistence or Image Sticking. This
occurs when a residual image remains visible on a screen when static images are displayed for long
periods of time. LCD Image Persistence is not permanent but constant images being displayed for a
long period of time should be avoided.
To counteract Image Persistence, turn off the monitor for as long as the previous image was
displayed, so if an image was on the monitor for 1 hour and there is evidence of a residual or “ghost”
image, you should turn off the monitor for 1 hour in order to clear the residual image.
For all LFD products, iiyama recommends displaying moving images and utilising a moving screen
saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not
in use to assist the prevention.
Other ways to reduce the risk of Image Persistence will be to utilise the FAN-on function (if
available), Low Backlight and Low Brightness settings.
FOR EXTENDED USE AS A PUBLIC DISPLAY

Image Sticking on LCD Panel
When a static image is displayed for hours, an electric charge trace remains near the electrode
inside the LCD producing a “ghost” image. (Image Persistence).
Image Persistence is not a permanent feature.

Recommendations
To prevent Image Sticking and promote longer life expectancy of display, we recommend the
following:
1. Avoid static images displayed for long periods – change static images on continuous loop.
2. Turn off monitor when not in use, either by remote control or use Power Management or Schedule
functions.
3. When monitor is installed in high ambient temperature environment(s) or in an enclosed position,
utilise the Cooling Fan, Screen Saver and Low Brightness functions.
4. Suitable ventilation for any monitor is an expectation of any installation – climate control systems
may need to be employed.
5. We strongly recommend utilisation of active cooling with fans for long operation times or high
ambient temperature environments.

ENGLISH
FOR YOUR SAFETY 5
NOTE 
If you have to return your unit for service and the original packaging has been
discarded, please contact your dealer or iiyama service center for advice or
replacement packaging.
WARNING 
If you drop any materials or liquids such as water into the monitor when cleaning,
unplug the power cable immediately and contact your dealer or iiyama service center.
CAUTION 
For safety reasons, turn off the power switch and unplug the monitor before you
clean it.
NOTE 
To protect the LCD panel, do not scratch or rub the screen with a hard object.

Never use any of the following strong solvents. These will damage the cabinet and
the LCD screen.

Touching the cabinet with any product made from rubber or plastic for a long time
may cause degeneration or loss of paint on the cabinet.
Thinner Benzine Abrasive cleaner
Spray-type cleaner Wax Acid or Alkaline solvent
CABINET Stains can be removed with a cloth lightly moistened with a mild detergent solvent.
Then wipe the cabinet with a soft dry cloth.
LCD
SCREEN
Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.
CUSTOMER SERVICE
CLEANING

ENGLISH
6 BEFORE YOU OPERATE THE MONITOR
The following accessories are included in your package. Check to see if they are enclosed with
the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional
iiyama offi ce.
* The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using
a power supply higher than this rating, then a power cable with a rating of 10A/
250V must be used. However, all guarantees and warranties are void for any
problems or damage caused by a power cable not supplied by iiyama.
BEFORE YOU OPERATE THE MONITOR
CHECKING THE CONTENTS OF THE PACKAGE
CAUTION
FEATURES
 Pixel format 3840 × 2160 (RGBW)
 High Contrast 1000:1 (Typical) / Brightness 500cd/m2 (Typical: without Touch
panel)
 Digital Character Smoothing
 Automatic Set-up
 Stereo Speakers
2 × 8W Stereo Speakers

Plug & Play VESA DDC2B Compliant
Windows® XP/Vista/7/8/8.1/10 Compliant
 Power Management (VESA DPMS Compliant)
 VESA Mounting Standard (600mm×400mm) Compliant
 Support 24hrs/day usage (by moving picture condition)
 IPX1 Standard Compliant (Only front face)
 Power Cable*
HDMI Cable  DisplayPort Cable
 USB Cable  IR Extender Cable  Remote Control (For maintenance)
 Button Battery CR2025 (for Remote Control)  Clamper (For tying cables)
 Cable Cover  Safety Guide  Quick Start Guide

ENGLISH
BEFORE YOU OPERATE THE MONITOR 7
UNPACKING
Before unpacking your monitor, prepare a stable, level, and clean surface near a wall outlet.
Set the LCD Monitor box in an upright position and open from the top of the box before removing
the top cushions.
Remove the carton holders.
Remove the top cushion and take
the accessories box and the Monitor out.
CAUTION
Moving the monitor requires at least two people. If not, it may drop
and could result in a serious injury.
When moving/shipping the monitor, please hold by the carton holders.
SPECIAL NOTES ON
Permanent damage can occur if Sharp Edged, Pointed or Metal items are used to activate Touch.
This could invalidate any remaining warranty.
We recommend to use a conductive rubber pen (tip ø7.0 or over) or fi nger.
CAUTION
Pinch and Pull the Knob.

ENGLISH
8 BEFORE YOU OPERATE THE MONITOR
CONTROLS AND CONNECTORS : MONITOR
<Front> <Back>
POWER Power Button
LEFT Left/Volume + Button
RIGHT Right/Volume - Button
AUTO / EXIT Auto/Exit Button
SOURCE / OK Input Select/OK Button
MENU Menu Button
LED Green Normal Operation
Orange Power Management
IR Remote Sensor
SPEAKERS Speakers
AC IN AC-INLET AC Connector( : Alternating current) (AC-IN)
AC SWITCH
(ON) / (OFF) MAIN POWER Main Power Switch
HDMI4
HDMI3
HDMI2
HDMI1
HDMI
HDMI Connector
DP IN DisplayPort DisplayPort Connector
DP OUT DisplayPort DisplayPort Connector
USB USB Touch USB Connector
RS232 OUT RS232C 9pin RS232C Connector
RS232 IN RS232C 9pin RS232C Connector
IR Mini Jack IR Extender Connector
LAN RJ45 RJ45 Connector
AC IN
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR
USB
HDMI4 HDMI3 HDMI2 HDMI1 DP
IN IN IN IN IN
DP
OUT
RS232 LAN A/SIR
OUT
RS232
IN
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR

ENGLISH
BEFORE YOU OPERATE THE MONITOR 9
INSTALLATION
CAUTION
 Follow the manual instructions for the type of mount you have selected. Refer all servicing to
qualifi ed service personnel.
 Moving the monitor requires at least two people.
 Before installing, please make sure the wall is strong enough to hold the necessary weight of the
display and the mount.
[WALL MOUNTING]
When using the wall mounting, consideration of thickness of the mounting stage needs to be taken.
Tighten the M8 Screw with washer which “L” length is 10mm to fasten the monitor. Using a screw
longer than this may cause electric shock or damage because it may contact with the electrical parts
inside the monitor.
CAUTION
L
Mounting Stage Screw
Chassis
[FAN]
If the screen is used in face-up position, please be sure to turn on the FAN function.
If you do not use the FAN, the internal temperature rises and the product life cycle may get shorter.
If the screen is built into an external cabinet, please be sure to implement a cooling unit inside of the
cabinet.
Dirt and dust may stick to the FAN, reducing the cooling eff ect which may result in a shorter life
cycle of the product. Please clean regularly.
CAUTION

ENGLISH
10 BEFORE YOU OPERATE THE MONITOR
[ROTATING THE DISPLAY]
A
A
Not Available
A
A
Landscape
Portrait
Available
It is designed to be compatible in both landscape and portrait modes.

ENGLISH
BEFORE YOU OPERATE THE MONITOR 11
CONTROLS AND CONNECTORS : REMOTE CONTROL (For maintenance)
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT
POWER Turns the monitor ON and OFF.
MENU
Opens the monitor’s on-screen menu systems.
When the menu system is already open, pressing
this button will select the previous submenu.
Navigates through submenus and settings.
: Up Button
: Down Button
: Left Button
: Right Button
OK Confi rms your selection or save changes.
PLAY Not available on this model.
EXIT Returns to a previous menu or closes the OSD
Menu.
STOP Not available on this model.
MUTE Turns on or off the mute function when the Menu is
not displayed.
AUTO Adjust H. / V. Position, Clock and Phase
automatically.
VOL : Increases the sound volume.
: Decreases the sound volume.
SELECT Selects the source.
To use the remote control we advise you to position it at the back of the monitor (left side) where the
remote sensor is located. It might not work if you use it standing in front of the monitor.
NOTE

ENGLISH
12 BEFORE YOU OPERATE THE MONITOR
To use the remote control, insert the button battery.
PREPARING THE REMOTE CONTROL
CAUTION
Do not use any other batteries other than those specifi ed in this manual for the Remote Control.
Burst batteries or the electrolyte from these batteries may cause stains, fi re or injury.
Push Lock to right and remove the battery case in the
direction of the arrow.
Put it in face up the + side of the button battery (CR2025).
Replace the battery case in the direction of the arrow.
NOTE  Replace with new batteries when the Remote Control does not work close to the
monitor. Use the button battery (CR2025).
 Operate the Remote Control by pointing it toward the Remote Sensor on the monitor.
 Other manufacturers remote control will not work with this monitor. Use the provided
Remote Control ONLY.
 Used batteries needed to follow the local rules to be discarded. (Suggestion: to dispose
of used batteries please follow correct policy as per your local regulations.)
Button Battery

ENGLISH
BEFORE YOU OPERATE THE MONITOR 13
BASIC OPERATION
 Turning the monitor ON
The monitor is on and the Power Indicator turns Green when you press the Power Button on the
monitor or the Remote Control. The monitor is off and the Power Indicator turns Orange when you
press the Power Button on the monitor or the Remote Control. Press again to turn the monitor on.
NOTE
Even when using the power management mode or turning OFF the Power Switch, the monitor
will consume a small amount of electricity. Disconnect the Power Cable from the power supply
whenever the monitor is not in use or during the night, to avoid unnecessary power consumption.
[Remote Control]
 Display the adjustment menu page
The menu page appears on the screen when you press the MENU Button on the monitor or the
Remote Control.
The menu page disappears when you press the EXIT Button on the Monitor or the Remote
Control.
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR
[Monitor]
[Remote Control][Monitor]
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR

ENGLISH
14 BEFORE YOU OPERATE THE MONITOR
 Move the cursor horizontally
Select menu or setting, or perform the adjustment by pressing the / Button on the Remote
Control while the menu page is displayed on the screen.
 Move the cursor vertically
Select adjustment by pressing the UP / DOWN Button on the monitor or the / Button on the
Remote Control while the menu page is displayed on the screen.
[Remote Control]
[Monitor]
[Remote Control]
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT

ENGLISH
BEFORE YOU OPERATE THE MONITOR 15
 Adjust the volume of sound
Press the UP / DOWN Button on the Monitor or the VOL / Button on the Remote Control to
adjust the volume of sound when the menu page is not displayed on the screen.
 Switch the input signal
This is activated when you successively press the SOURCE Button on the monitor or SELECT
Button on the Remote Control.
[Remote Control][Monitor]
[Remote Control][Monitor]
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT
POWER
LEFT
RIGHT
AUTO/EXIT
SOURCE/OK
MENU
LED
IR
POWER MUTE
MEMU AUTO
OK
PLAY
EXIT STOP
VOL
SELECT

ENGLISH
16 BEFORE YOU OPERATE THE MONITOR
CONNECTING YOUR MONITOR
Ensure that both the computer and the monitor are switched off .
Connect the computer to the monitor with the signal cable.
Connect the computer to the monitor with the USB Cable.
Connect the IR Extender Cable to the monitor, peel off the double-sided tape in the back of the
IR Receiver and stick it to your preferred location.
Connect the Power Cable to the monitor fi rst and then to the power supply.
Turn on your monitor (Main Power Switch and Power Switch) and computer.
 The signal cables used for connecting the computer and monitor may vary with the
type of computer used. An incorrect connection may cause serious damage to both
the monitor and the computer. The cable supplied with the monitor is for a standard
connector. If a special cable is required please contact your local iiyama dealer or
regional iiyama offi ce.
 Make sure you tighten the fi nger screws at each end of the Signal Cable.
 When USB cable connected than wait for 5 seconds and the touch function is ready to
go. It can be activated by pen, fi nger or any other pointer.
[Example of Connection]
<Back>
NOTE
[ Cable Cover ]
Place the cable cover and fi x it fi rmly using two
screws that are included.
AC IN
AUTO/EXIT
SOURCE/OK
MENU
LED
IR
USB
HDMI4 HDMI3 HDMI2 HDMI1 DP
IN IN IN IN IN
DP
OUT
RS232 LAN A/SIR
OUT
RS232
IN
Router etc.
RS232 IN
Connector
DP IN
Connector
Computer
AV Equipment
HDMI Cable (Accessory)
Power Cable (Accessory)
USB Cable (Accessory)
RS-232C Cable (Not Included)
IR Extender Cable (Accessory)
LAN Cable (Not Included)
DisplayPort Cable (Not Included)
DisplayPort Cable (Accessory)
RS-232C Cable
(Not Included)
GAME
Equipment
etc.
HDMI Cable
(Not Included)
HDMI Cable
(Not Included)
AC IN USB
HDMI4 HDMI3 HDMI2 HDMI1 DP
IN IN IN IN IN
DP
OUT
RS232 LAN A/SIR
OUT
RS232
IN
Cable Cover
included screws
Cable Cover

ENGLISH
BEFORE YOU OPERATE THE MONITOR 17
[ About the daisy chain ]
PC
[RS-232C IN]
[RS-232C]
[RS-232C OUT] [RS-232C IN]
MONITOR1 MONITOR2
 Monitor control connection
RS-232C
 Digital video connection
DisplayPort
PC
[DP IN]
[DP]
]TUOPD[
MONITOR1 MONITOR2
[DP IN] ]NIPD[]TUOPD[
MONITOR3
DisplayPort v1.2 multiple stream support allows daisy-chain up to 3 monitors showing diff erent
content on each screen.
Connection conditions

Up 2 monitors can be connected, when operating at 3840 × 2160 / 60Hz resolution.
(MONITOR1: 3840 × 2160 / 60Hz, MONITOR2: 1920 × 1080 / 60Hz)

Up 2 monitors can be connected, when operating at 3840 × 2160 / 30Hz resolution.
(MONITOR1: 3840 × 2160 / 30Hz, MONITOR2: 3840 × 2160 / 30Hz)

Up 3 monitors can be connected, when operating at 1920 × 1080 / 60Hz resolution.
(MONITOR1,2,3: 1920 × 1080 / 60Hz)
NOTE
