iKAMPER WIND DEFLECTOR User manual

1
WIND DEFLECTOR
ASSEMBLY

2
Instructions
Included parts:
Ex2 Fx3 Gx3
Hx6 Ix2 Jx2 Kx2

3
STEP 1
Remove the protective vinyl covering from panel [A].
STEP 2
Take rubber strap [B] and wrap it around panel [A]. The harder rubber side
should be facing the front of panel [A] with the iKamper logo, with the softer
rubber side facing the back.
STEP 3
Insert 3 short bolts [F] into the front of panel [A].

4
STEP 4
Take metal piece [C] and place the short side over bolt [F]. Then screw on
head nut [H], and repeat for the other two bolts.
STEP 5
Slide 3 long bolts [G] into the side of rail [D].

5
STEP 6
Place rail [D] over the 3 metal pieces [C], insert the 3 bolts [G], and screw on
the 3 head nuts [H]. The thicker end of rail [D] should be facing panel [A].
STEP 7
Screw square nuts [J] on to bolts [K], and insert them in the holes on top of rail
[D]. The wider sides should be facing the front and back of the rail. Loosely
screw on head nuts [I].

6
STEP 8
- Remove the two plastic pieces covering the front of rails under the Skycamp.
- Insert the square nuts [J] into the rails, choose the appropriate position, and
tightly screw on the head nuts.
- Put the cover pieces back in place in front of the rails.
STEP 9
Place the 2 plastic pieces [E] on the sides of rail [D].

7
STEP 10
Adjust the height and position of the Wind Deflector by unscrewing the head
nuts [I] and tightening them once the Wind Deflector is in the right position.
For more instructions and explanation videos, please visit
www.ikamper.com/instructions
