What’s Included
1 x SB200 Light Fixture
1 x Barn Doors
1 x Power Supply with Cable
1 x Yoke
QUICKSTART GUIDE
SB200
Stryder 200 Watt LED Bi-Color Light

Getting Started
Thank you for buying the Stryder Portable LED Fresnel Spotlight from Ikan. Please carefully read the instructions and guide
before operating the products. The guide includes product usage and maintenance. When you operate the product, please
make sure that you have read the instructions carefully.
All the content of the manual is based on up-to-date information; technical data subject to change without notice.
Safety Instructions:
1. Connect the power supply to the 15VDC Connector on the SB200 Light before plugging into the power source. You risk
electrocution by not following the instruction.
2. Don’t drag cables with excessive force. Any repairs on the products should be performed by Ikan technicians. Users
should not remove the power supply, or else the damage will not be covered under warranty.
3. Confirm that the power is off before connecting and changing the fixture head or disconnecting your cable from the
power source. We recommend using Ikan customized connecting cables and connectors to avoid electrical shock.
4. The voltage shouldn’t exceed the value in the technical specifications. If the voltage is greater than, or less than the
regulated values, it could damage the product.
Overview
Benchmark color temperatures for today’s TV production are 5600K (daylight) and 3200K (tungsten). Ikan developed the SB-
200 Spotlight to handle both these temperatures. With patented technologies, the SB200 offers a professional and customizable
LED light source. In addition, the light features separately-cooling ducts for optimizing heat dissipation. Specifically, the SB-200
Spotlight offers the following features:
1. The 0-100% brightness incremental adjustment of the 2700K-5600K temperature enable fine-tuning your color range.
2. A 7-inch diameter Fresnel lens provides even, well-distributed light at a 60 degree beam angle.
3. Fresnel Spot adaptor allows the Beam to be reduced to a 30 degree spot.
4. Ultra-low noise and active cooling technology contribute to excellent thermal stability.
5. The power supply will automatically cut off when the fixture overheats.
6. The bright LCD readout is easy to view, enabling smooth adjustment of functions.
7. Digitally adjustable knob allows you to adjust menu settings quickly and accurately.
8. AC/DC power supply, AC110VAC-270VAC, DC 15V.
Instructions:
LED spotlight’s housing is made of fiber reinforced plastic which is heavy-duty, lightweight, flexible and easy to transport/ The
SB200 structure is illustrated as follows:
What’s in the Box?
Please carry and place the packing box carefully. Check the lighting equipment and accessories upon opening the box. Please
contact us if anything is damaged or missing. Please save the packing materials for replacing and repairing the products in the future.
What’s Included:
SB200 Light Fixture
Power Supply with Cable
Barn Doors
Yoke Mount

Appearance & Structure - Front
5/8" Receiver: Connecting the lamp with stands
Yoke: Adjustable lighting direction
Adjustable Beam Limiter: It allows the light to move from a 60°beam angle to a 30°beam angle
Carry Handle: Top grip handle for easy grab and go lighting
Appearance & Structure - Back
Power Switch: Turn ON/OFF Power under the fixture
LCD Settings: Displays brightness & color temperature
Large Yellow Knob: Allows for adjustment of brightness & color temperature
Four Adjustment Buttons: ON/OFF-A, Menu-M, Advanced-B, Enter-E
Grip Handles: For making adjustments while the light is on the stand
Power Button
Adjustment Buttons
Large Yellow Knob
LCD Screen
Grip Handle
Yoke
Adjustable Beam Limiter
Barn Doors
Carry Handle
5/8"Receiver
5/8"Receiver

Specifications
Optional Accessories
Some other products that work well with the Stryder Light available from Ikan include:
HD-STND-V2
KCP-703
ROLLR-STND10
SW-04
IDX-096
Heavy Duty Light Stand
Stage Clamp with 16mm Stud
2-Stage Roller Stand 10 ft 6 in.
Safety Wire
96 Channel DMX Console
Installation & Power Supply
1. Ensure power is OFF before installation.
2. Place the light on the Ikan stands, release the tension knob on the 5/8” receiver, adjust the light in the desired direction, and
tighten the tension knob on the 5/8” receiver.
3. When connecting the power cords, plug the DC power cords into the socket on the rear panel (as shown on the drawing).
If batteries are used: Illuminate light by pressing power switch. On the default screen the number 13.8V at the upper right corner
indicated the current internal DC voltage. When powered by the battery it means the current battery voltage; however, this
number will display in flashing status if the voltage is lower than 11V which indicates low battery voltage.
Power the LEDs
The SB200 light comes with an included AC power supply and 4 ft cable. This allows the user to plug into any standard 120-240
VAC electrical outlet. The SB200 light can be powered from either an AB Mount Pro Battery, or a V-Mount Battery. The fixture comes
standard with either AB-Mount or V-Mount plates.
SB200 Specifications
Beam Angle 60° - with adapter 30°
Build Material Fiber Reinforced Plastic
Control Toggle Button with Knob Control
Cooling System Active Cooling Fan
Dimming Flicker Free Dimming
Onboard Dimming Knob: 100-0%
Fixture Size 16 x 11 x 9 in.
Fixture Weight 11 lbs
Head Type 3200K-5600K (Adjustable 2700K-6500K)
Lens 6 Inch Fresnel
Light Source 200 Watt Bi-Color LED
Power Supply Input: 100-240VAC
Output: 15VDC
Yoke Cast Aluminum with 1 1/8” Pin Receiver
DMX 512 Controls
The DMX IN/OUT on the SB-200 allows for remote fixture control over the
color and brightness.
The 8Bit DMX allows for use with controllers that use just dimmer controls.
Depending on channel assigned the brightness is controlled on the first
fader. The next fader controls the color temperature from 2700K at 0% to
6500K at 100%.

Learn More
More dynamic information at official website: www.ikancorp.com
Support
Contact email: [email protected]
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period is expired.
Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
©2017 ikan Corporation. All rights reserved
