IKEA TORSBODA User manual

TORSBODA
en

3
Table of contents
Safety........................................................................ ....4
General information ................................................... .....4
Intended use.............................................................. .....4
Restriction on user group............................................ .....4
Safe installation.......................................................... .....4
Safe use ..................................................................... .....5
Damaged appliance.................................................... .....6
Risk to children........................................................... .....6
Preventing material damage.................................... ....8
Safe installation.......................................................... .....8
Safe use ..................................................................... .....8
Environmental protection and saving energy........... ....8
Disposing of packaging............................................... .....8
Saving energy ............................................................ .....8
Aqua sensor............................................................... .....8
Automatic door opening ............................................. .....9
Installation and connection...................................... ....9
Scope of supply .......................................................... .....9
Installing and connecting the appliance ....................... .....9
Drainage connection................................................... .....9
Drinking water connection.......................................... .....9
Electrical connection................................................... .....9
Product description .................................................. .. 10
Appliance................................................................... ... 10
Control panel ............................................................. ....11
Overview of programmes ......................................... .. 13
Information for test institutes...................................... ... 13
Additional functions ................................................. .. 14
Features.................................................................... .. 14
Top basket ................................................................. ... 14
Bottom basket............................................................ ... 15
Cutlery drawer ........................................................... ... 15
Etagere...................................................................... ... 16
Folding prongs........................................................... ... 16
Basket heights............................................................ ... 17
Before first use ......................................................... .. 17
Performing the initial configuration............................. ... 17
Water softening system............................................ .. 17
Overview of water hardness settings ........................... ... 17
Setting the water softening system.............................. ... 17
Special salt................................................................. ... 18
Switching off the water softening system..................... ... 18
Regeneration of the water softening system ................ ... 18
Rinse aid system ....................................................... .. 18
Rinse aid .................................................................... ... 18
Setting the amount of rinse aid ................................... ... 19
Switching the rinse aid system off ............................... ... 19
Detergent ................................................................. .. 19
Suitable detergents .................................................... ... 19
Unsuitable detergents ................................................ ...20
Information on detergents .......................................... ...20
Adding detergent ....................................................... ...20
Tableware ................................................................. .. 21
Damage to glass and tableware................................... ... 21
Arrange tableware...................................................... ... 21
Removing tableware ................................................... ...22
Basic operation ......................................................... ..22
Switching on the appliance.......................................... ...22
Setting a programme.................................................. ...22
Setting additional functions......................................... ...22
Setting timer programming......................................... ...22
Starting the programme ............................................. ...22
Interrupting programme............................................. ...22
Terminate programme................................................ ...22
Switching off appliance ............................................... ...22
Basic settings............................................................ ..23
Overview of basic settings........................................... ...23
Changing basic settings .............................................. ...24
Cleaning and servicing.............................................. ..24
Cleaning the tub ......................................................... ...24
Cleaning products....................................................... ...24
Tips on appliance care................................................. ...24
Machine Care ......................................................... ...24
Filter system............................................................... ...25
Cleaning spray arms ................................................... ...26
Troubleshooting........................................................ ..27
Appliance safety ......................................................... ...27
Error code / Fault display / Signal................................. ...27
Washing results.......................................................... ...29
Information on display panel....................................... ...33
Malfunctions .............................................................. ...33
Mechanical damage.................................................... ...34
Noise ......................................................................... ...34
Clean wastewater pump.............................................. ...35
Transportation, storage and disposal ....................... ..35
Removing the appliance.............................................. ...35
Protect appliance from frost........................................ ...35
Transporting the appliance ......................................... ...35
Disposing of old appliance .......................................... ...36
Technical specifications ............................................ ..36
Information regarding free and open source software.. ...36
Declaration of Conformity ........................................ ..36
IKEA guarantee ......................................................... ..37
After-sales service..................................................... ..38

4
Safety
Observe the following safety instructions.
General information
●Read this instruction manual carefully.
●Keep the instruction manual and the product information safe for future reference or for
the next owner.
●Do not connect the appliance if it has been damaged in transit.
Intended use
Only use this appliance:
●For cleaning household tableware.
●in private households and in enclosed spaces in a domestic environment.
●Up to an altitude of 4000 m above sea level.
Restriction on user group
This appliance may be used by children aged 8 or over and by people who have reduced
physical, sensory or mental abilities or inadequate experience and/or knowledge, provided
that they are supervised or have been instructed on how to use the appliance safely and have
understood the resulting dangers.
Do not let children play with the appliance.
Cleaning and user maintenance must not be performed by children unless they are being su-
pervised.
Keep children under the age of 8 years away from the appliance and power cable.
Safe installation
WARNING‒Risk of injury!
●Improper installation may cause injury.
●When installing and connecting the appliance, follow the instructions in the manual and
installation instructions.
WARNING‒Risk of electric shock!
●Incorrect installation is dangerous.
●Connect and operate the appliance only in accordance with the specifications on the
rating plate.
●Always use the supplied power cable for the new appliance.
●Connect the appliance to a power supply with alternating current only via a properly in-
stalled socket with earthing.
●The protective conductor system of the domestic electrical installation must be properly
installed.
●Never equip the appliance with an external switching device, e.g. a timer or remote
control.
●When the appliance is installed, the mains plug of the power cord must be freely ac-
cessible. If free access is not possible, an isolating switch must be integrated into the
permanent electrical installation according to the installation regulations.
●When installing the appliance, check that the power cable is not trapped or damaged.

5
●Cutting through the supply hose or immersing the Aqua-Stop valve in water is danger-
ous.
●Never immerse the plastic housing in water. The plastic housing on the supply hose
contains an electric valve.
●Never cut through the supply hose. The supply hose contains electric power cables.
WARNING‒Risk of fire!
●It is dangerous to use an extended power cord and non-approved adapters.
●Do not use extension cables or multiple socket strips.
●Only use adapters and power cords approved by the manufacturer.
●If the power cord is too short and a longer one is not available, please contact an elec-
trician to have the domestic installation adapted.
●Contact between the appliance and installation lines may lead to a defect in these lines,
e.g. gas pipes and power lines. Gas from a corroded gas pipe can ignite. A damaged
power line can cause a short circuit.
●Check that there is a distance of at least 5cm between the appliance and installation
lines.
WARNING‒Risk of injury!
●Hinges move when opening and closing the appliance door and can cause injury.
●If built-under or integrable appliances are not in a cavity so that one side is accessible,
the hinge area must be covered at the side. Covers are available from IKEA or Customer
Service.
WARNING‒Risk of tipping!
●Improper installation may cause the appliance to tip up.
●Only install built-under or integrable appliances under a continuous worktop that is se-
curely connected to adjacent cabinets.
Safe use
WARNING‒Risk of serious harm to health!
●Failure to comply with safety instructions and directions for use on packagings of deter-
gent and rinse aid products may cause serious harm to health.
●Follow the safety instructions and directions for use on the packagings of detergent
and rinse aid products.
WARNING‒Risk of explosion!
●Adding solvents to the interior of the appliance may cause explosions.
●Never add solvents to the interior of the appliance.
●Highly caustic alkaline or highly acidic cleaning agents in conjunction with aluminium
parts in the interior of the appliance may cause explosions.
●Never use highly caustic alkaline or highly acidic cleaning agents, in particular commer-
cial or industrial products, in conjunction with aluminium parts (e.g. grease filters of ex-
tractor hoods or aluminium pans), e.g. for the Machine Care programme.
WARNING‒Risk of injury!
●Leaving the appliance door open may result in injury.
●Only open the appliance door to load or unload tableware in order to prevent acci-
dents, e.g. through tripping.
●Do not sit or stand on the appliance door when open.

6
●Knives and utensils with sharp points can cause injuries.
●Arrange knives and utensils with sharp points in the cutlery basket with the points
downwards, on the knife shelf or in the cutlery drawer.
WARNING‒Risk of scalding!
●If you open the appliance door while the programme is running, hot water may splash
out of the appliance.
●Open the appliance door carefully if the programme is still running.
WARNING‒Risk of electric shock!
●An ingress of moisture can cause an electric shock.
●Only use the appliance in enclosed spaces.
●Never expose the appliance to intense heat or humidity.
●Do not use steam- or high-pressure cleaners to clean the appliance.
●If the insulation of the power cord is damaged, this is dangerous.
●Never let the power cord come into contact with hot appliance parts or heat sources.
●Never let the power cord come into contact with sharp points or edges.
●Never kink, crush or modify the power cord.
Damaged appliance
WARNING‒Risk of electric shock!
●If the appliance or the power cord is damaged, this is dangerous.
●Never operate a damaged appliance.
●Never operate an appliance with a cracked or fractured surface.
●Never pull on the power cord to unplug the appliance. Always unplug the appliance at
the mains.
●If the appliance or the power cord is damaged, immediately unplug the power cord or
switch off the fuse in the fuse box and turn off the water tap.
●Call customer services.
●Incorrect repairs are dangerous.
●Repairs to the appliance should only be carried out by trained specialist staff.
●Only use genuine spare parts when repairing the appliance.
●If the power cord or the appliance power cable of this appliance is damaged, it must be
replaced with a special power cord or special appliance power cable, which is available
from the manufacturer or its Customer Service.
Risk to children
WARNING‒Risk of suffocation!
●Children may put packaging material over their heads or wrap themselves up in it and
suffocate.
●Keep packaging material away from children.
●Do not let children play with packaging material.
●Children may breathe in or swallow small parts, causing them to suffocate.
●Keep small parts away from children.
●Do not let children play with small parts.
●Children may become trapped in the appliance and suffocate.
●Use the childproof lock if fitted.
●Never let children play with or operate the appliance.

7
WARNING‒Risk of harm to health!
●Children can lock themselves in the appliance, thereby putting their lives at risk.
●With redundant appliances, unplug the power cord. Then cut through the cord and
damage the lock on the appliance door beyond repair so that the appliance door will no
longer close.
WARNING‒Risk of crushing!
●With higher-level appliances, children can become crushed between the appliance door
and cabinet doors underneath.
●Keep an eye on children when opening and closing the appliance door.
WARNING‒Risk of chemical burns!
●Rinse aid and detergent may cause chemical burns to the mouth, throat and eyes.
●Keep children away from detergent and rinse aid products.
●Keep children away from the appliance when open. The water in the interior of the
dishwasher is not drinking water. It may contain residues of detergents and rinse aid.
WARNING‒Risk of injury!
●Children may get their fingers caught in the slots of the tablet collecting tray and injure
themselves.
●Keep children away from the appliance when open.

8
Preventing material damage
Preventing material damage
Preventing material damage
Safe installation
ATTENTION!
●Improper installation of the appliance may cause damage.
●If the dishwasher is installed above or below other do-
mestic appliances, follow the information on installa-
tion in combination with a dishwasher in the installa-
tion instructions for the individual appliances.
●If there is no information or if the installation instruc-
tions do not include the relevant information, contact
the manufacturer of these appliances to check that the
dishwasher can be installed above or below these ap-
pliances.
●If no information is available from the manufacturer,
the dishwasher should not be installed above or below
such appliances.
●To ensure the safe operation of all domestic appli-
ances, continue following the installation instructions
for the dishwasher.
●Do not install the dishwasher under a hob.
●Do not install the dishwasher near heat sources, e.g.
radiators, heat storage tanks, ovens or other appli-
ances that generate heat.
●Contact between the appliance and water pipes may lead
to corrosion of these pipes, possibly causing them to leak.
●Check that there is a distance of at least 5cm between
the appliance and the water pipe. The pipes supplied
for the drinking water and waste water connections are
not affected here.
●Modified or damaged water hoses may result in material
damage and damage to the appliance.
●Never kink, crush, modify or cut through water hoses.
●Only use the water hoses supplied with the appliance
or genuine spare hoses.
●Never re-use water hoses that have been used before.
●If the water pressure is too high or too low, the appliance
may not be able to operate properly.
●Make sure that the water pressure in the water supply
system is min. 50kPa (0.5bar) and max. 1000kPa
(10bar).
●If the water pressure exceeds the maximum value spe-
cified, a pressure-reducing valve must be installed
between the drinking water connection and the hose
set of the appliance.
Safe use
ATTENTION!
●Escaping water vapour can damage fitted units.
●When the programme ends, leave the appliance to cool
down for a while before opening the door.
●Special salt for dishwashers can damage the tub due to
corrosion.
●To make sure that any special salt that escapes is
washed out of the tub, add the special salt to the dis-
penser for special salt immediately before the pro-
gramme starts.
●Detergent may damage the water softening system.
●Only fill the dispenser of the water softening system
with special dishwasher salt.
●Unsuitable cleaning agents may damage the appliance.
●Do not use a steam cleaner.
●So as not to scratch the finish on the appliance, do not
use sponges with a rough surface or abrasive cleaning
agents.
●To prevent corrosion, do not use sponge cloths on
dishwashers with a stainless steel front or rinse such
cloths thoroughly several times before using them for
the first time.
Environmental protection and saving energy
Environmental protection and saving energy
Environmental protection and saving energy
Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
●Sort the individual components by type and dispose of
them separately.
Information about current disposal methods is available
from IKEA or your local authority.
Saving energy
If you follow these instructions, your appliance will use less
electricity and less water.
Use the Eco50° programme.
The Eco50° programme is energy-efficient and environ-
mentally friendly.
If you do not have much tableware to wash, use the addi-
tional Half Load function.1
The programme will adjust to a lower load and consump-
tion will be reduced.
→"Additional functions", Page14
Aqua sensor
The aqua sensor is an optical measuring device (light bar-
rier) which measures the turbidity of the washing water. You
can save water with the aqua sensor.
Use of the aqua sensor depends on the programme. If the
soiling level is high, the rinsing water is drained off and re-
placed with fresh water. If the soiling level is lower, the rins-
ing water is used in the next wash cycle, so reducing water
consumption by 3-6 litres. In the automatic programmes the
temperature and running time are additionally adjusted to
the level of soiling.
1Depending on the appliance specifications

9
Automatic door opening
The appliance door opens automatically during the drying
phase. This ensures a particularly economical drying result.
For best drying results wait until the end of programme be-
fore unloading the tableware. The programme has ended
when the display shows "0h:00m".
If automatic door opening is deactivated, energy consump-
tion increases and the drying phase is usually shortened.
→"Overview of basic settings", Page23
Installation and connection
Installation and connection
Installation and connection
To ensure proper operation, connect the appliance to the
power and water supply correctly. Observe the specified cri-
teria and the installation instructions.
Scope of supply
After unpacking all parts, check for any damage in transit
and completeness of the delivery.
If you have any complaints, contact IKEA or our Customer
Service.
Note:The appliance has been tested at the factory to check
it is in working order. It is possible that water has left marks
on the appliance. These marks will disappear after the first
wash cycle.
The delivery consists of the following:
●Dishwasher
●Operating instructions
●Installation Instructions
●Installation material
●Steam guard plate
●Salt filling aid funnel
●Mains cable
Installing and connecting the appliance
You can position your built-under or integrable appliance in
a fitted kitchen between wooden and plastic walls. If you
subsequently install your dishwasher as a free-standing ap-
pliance, you must stop it from tipping over, e.g. by screwing
it to the wall or installing it under a continuous worktop that
is securely connected to adjacent cabinets.
1. "Follow the safety instructions." →Page4
2. "Follow the instructions for electrical connection."
→Page9
3. Check the Scope of supply and the condition of the appli-
ance.
4. Consult the installation instructions for the installation di-
mensions required.
5. Make the appliance level using the height-adjustable feet.
Make sure that the appliance is standing on the floor se-
curely.
6. "Install the drainage connection." →Page9
7. "Install the drinking water connection." →Page9
8. Connect the appliance to the power supply.
Drainage connection
Connect your appliance to drainage connection so dirty wa-
ter is discharged via the wash cycle.
Installing the drainage connection
1. Consult the installation instructions supplied for the steps
required here.
2. Connect the wastewater hose to the outlet connection of
the siphon using the enclosed parts.
3. When doing so, check that the wastewater hose is not
kinked, crushed or twisted.
4. Also check that there is no cover in the drainage system
preventing the wastewater from being discharged.
Drinking water connection
Connect your appliance to a drinking water connection.
Installing the drinking water connection
Note
●If you are replacing the appliance, you must use a new
water supply hose.
1. Consult the installation instructions supplied for the steps
required here.
2. Connect the appliance to the drinking water connection
using the enclosed parts.
Observe the Technical data.
3. When doing so, check that the drinking water connection
is not kinked, crushed or twisted.
Electrical connection
Connecting the appliance to the electricity supply
Notes
●Please follow the "Safety instructions" →Page4.
●Connect the appliance to alternating current only, in the
range of 220 - 240V and 50Hz or 60Hz.
●Please note that the water safety system is only functional
if there is a power supply.
1. Insert the non-heating appliance plug of the power cable
into the appliance.
2. Insert the mains plug of the appliance into a nearby
socket.
The connection data for the appliance can be found on
the rating plate.
3. Check that the mains plug is inserted properly.

10
Product description
Product description
Product description
Appliance
You can find an overview of the parts of your appliance here.
2
3
4
5
6
7
8
9
10
11
12
13
1
1
Rating plate Rating plate with E number and FD number.
The data you need for Customer Service.
2
Detergent dispenser Add detergent to the detergent dispenser.
→"Detergent", Page19
3
Bottom basket "Bottom basket" →Page15
4
Dispenser for special salt Add special salt to the dispenser for special salt.
→"Water softening system", Page17
1Depending on the appliance specifications

11
5
Lower spray arm The lower spray arm washes the tableware in the bottom basket.
If the tableware has not been washed properly, clean the spray
arms.
→"Cleaning spray arms", Page26
6
Tablet collecting tray During the wash cycle tablets automatically fall out of the deter-
gent dispenser into the tablet collecting tray where they can fully
dissolve.
7
Top basket "Top basket" →Page14
8
Cutlery drawer "Cutlery drawer" →Page15
9
EmotionLight Interior lighting of the appliance.
→"Overview of basic settings", Page23
10
Cutlery shelf1"Cutlery shelf" →Page16
11
Upper spray arm The upper spray arm washes the tableware in the top basket.
If the tableware has not been washed properly, clean the spray
arms.
→"Cleaning spray arms", Page26
12
Filter system "Filter system" →Page25
13
Dispenser for rinse aid Add rinse aid to the dispenser for rinse aid.
→"Rinse aid system", Page18
1Depending on the appliance specifications
Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operating
status.
With some buttons you can perform different functions.
1 2 3 4 5
11 10 9 8
76
1
ON/OFF button and reset button "Switching on the appliance" →Page22
"Switching off the appliance" →Page22
"Terminating the programme" →Page22
2
Programme buttons "Programmes" →Page13
3
Special salt refill indicator Water softening system
→"Adding special salt", Page18
4
Rinse aid refill indicator Rinse aid system
→"Adding rinse aid", Page18
5
Water supply display Display for water supply
1Depending on the appliance specifications

12
6
Programme buttons and additional functions Programmes
→"Overview of programmes", Page13
Additional functions
→"Additional functions", Page14
7
Start button "Starting the programme" →Page22
8
button If you press for approx. 3 seconds, you can open
the basic settings.
→"Changing basic settings", Page24
9
Timer programming "Setting timer programming" →Page22
10
Door handle1Open the appliance door.
11
Display The display shows information about the remaining running
time or the basic settings. You can change the basic settings
via the display and the setting buttons.
→"Changing basic settings", Page24
1Depending on the appliance specifications
Symbols on the display 1
The display shows the following symbols depending on the
model. See here for an explanation.
SYMBOL DESCRIPTION
If the symbol for machine care lights up
on the display, run machine care.
→"Machine Care ", Page24
If the rinse aid refill indicator lights up
on the display, top up with rinse aid.
→"Adding rinse aid", Page18
If the special salt refill indicator lights up
on the display, add special salt to the dis-
penser for special salt just before the
programme starts.
→"Adding special salt", Page18
When using for the first time, the symbol
lights up on the display and then goes
out again. The appliance has no WiFi
capability1.
If the water inflow or drainage malfunc-
tions, the symbol lights up or flashes on
the display.
1Wi-Fi is a registered trademark of the Wi-Fi Alliance.
1Depending on the appliance specifications

13
Overview of programmes
Overview of programmes
Overview of programmes
You can find an overview of the programmes that can be se-
lected here. Different programmes, which can be found on
the control panel of your appliance, are available depending
on the appliance configuration.
The running time may vary depending on the programme
selected. The running time depends on the water temperat-
ure, the quantity of tableware, the level of soiling and the
Additional function selected. The running time will change if
the rinse aid system is switched off or rinse aid needs to be
added.
The consumption values can be found in the quick reference
guide. The consumption values relate to normal conditions
and a water hardness of 16 - 20°E. Different influencing
factors such as water temperature or pipe pressure may res-
ult in deviations.
PROGRAMME USE PROGRAMME SEQUENCE
Intensive 70°
Tableware:
●Pots and pans, non-fragile tableware and cutlery
Level of soiling:
●Stubborn, burned or dried-on food remnants con-
taining starch and protein
Intensive:
●Pre-Rinse
●Cleaning 70°C
●Intermediate rinse
●Final rinse 69°C
●Dry
Auto 45-65°
Tableware:
●Mixed tableware and cutlery
Level of soiling:
●Common household food remnants lightly dried on
Sensor-controlled:
●Optimised by sensors depending
on the soiling of the washing wa-
ter.
Eco 50°
Tableware:
●Mixed tableware and cutlery
Level of soiling:
●Common household food remnants lightly dried on
Most economical programme:
●Pre-Rinse
●Cleaning 50°C
●Intermediate rinse
●Final rinse 48°C
●Drying
Quiet 50°
Tableware:
●Mixed tableware and cutlery
Level of soiling:
●Common household food remnants lightly dried on
Reduced noise:
●Pre-Rinse
●Cleaning 50°C
●Intermediate rinse
●Final rinse 63°C
●Dry
Quick 1h 65°
Tableware:
●Mixed tableware and cutlery
Level of soiling:
●Common household food remnants lightly dried on
Time-optimised:
●Cleaning 65°C
●Intermediate rinse
●Final rinse 69°C
●Dry
Quick 45°
Tableware:
●Delicate tableware, cutlery, temperature-sensitive
plastics and glasses
Level of soiling:
●Lightly adhering fresh food remnants
Time-optimised:
●Cleaning 45°C
●Intermediate rinse
●Final rinse 55°C
PreRinse
Tableware:
●All types of dishes
Level of soiling:
●Cold rinsing, intermediate cleaning
Cold rinsing:
●Pre-Rinse
Machine Care
Use only if appliance is unloaded. Machine Care 70°C
Note:The relatively long running time in the Eco50° pro-
gramme is due to longer soaking and drying times. This res-
ults in optimal consumption values.
Information for test institutes
Test institutes are provided with information for comparabil-
ity tests, e.g. according to EN60436.
These are the conditions for conducting the tests, however
they are not the results or consumption values.
Request by e-mail to:
[email protected]
The product number (E-Nr.) and the production number (FD)
are required here. They can be found on the rating plate on
the appliance door.

14
Additional functions
Additional functions
Additional functions
You can find an overview of the additional functions that can
be selected here. Different additional functions, which can
be found on the control panel of your appliance, are avail-
able depending on the appliance configuration.
ADDITIONAL FUNCTION USE
Half Load
●Switch on with small loads.
●It is recommended adding less
detergent to the detergent dis-
penser than for a full machine
load.
●The run time is shortened.
●Energy and water consumption
are reduced.
ADDITIONAL FUNCTION USE
IntensiveZone
●Switch on with mixed loads con-
taining tableware with different
soiling levels, e.g. place very
soiled pots and pans in the bot-
tom basket and normally soiled
tableware in the upper basket.
●The spray pressure in the bot-
tom basket is increased and the
maximum programme temper-
ature held longer. This will in-
crease the run time and energy
consumption.
ExtraDry
●For a better drying result the fi-
nal rinse temperature is in-
creased and the drying phase
extended.
●Especially suitable for drying
plastic parts.
●There is a slight increase in en-
ergy consumption and the run
time is extended.
Features
Features
Features
You can find an overview of the possible features of your ap-
pliance and how to use them here.
These features depend on the model of your appliance.
Top basket
Arrange cups, glasses and small items of tableware in the
top basket.
You can adjust the height of the top basket to make room
for larger items of tableware.
Adjusting top basket with side levers
To wash large items of tableware in the baskets, adjust the
shelf position of the top basket.
1. Pull out the top basket.
2. To prevent the basket from suddenly dropping down,
hold the side of the basket by the top edge.
3. Press in the levers on the right and left on the outside of
the basket.
4. Raise or lower the basket evenly to the right level.
Check that the basket is level on both sides.

15
5. Release the levers.
aThe basket clicks into position.
6. Slide the basket back in.
Bottom basket
Arrange pans and plates in the bottom basket.
Large plates up to a diameter of 34cm can be arranged in
the bottom basket as shown.
Cutlery drawer
Arrange cutlery in the cutlery drawer.
Arrange cutlery with the points and sharp edges down-
wards.
You can reorganise the cutlery drawer to make more space
for longer/wider items of cutlery.
Reorganising cutlery drawer
You can fold down the side shelves and front prongs to
make more space for longer/wider items of cutlery.
1. To fold down a side shelf, push the lever forwards and
fold down the side shelf ⁠.
1
2
2. To fold down the front prongs, push the lever forwards
and fold down the prongs ⁠.
1
Tip
If you want to return the cutlery drawer to the original posi-
tion, fold the side shelf back up until it clicks into position.

16
Etagere
Use the cutlery shelf and space underneath for small cups
and glasses or for large items of cutlery, e.g. cooking spoons
or serving cutlery.
If you do not need the cutlery shelf, you can fold it up.
Folding prongs
Use the folding prongs to position tableware securely, e.g.
plates.
You can fold the prongs down to position pans, bowls and
glasses better.1
Folding down prongs1
If you do not need the prongs, fold them down.
1. Push the lever forwards and fold down the prongs ⁠.
12
2. To use the prongs again, fold them back up.
aThe prongs audibly click into position.
1Depending on the appliance specifications

17
Basket heights
Set the baskets at the right height.
Appliance height 86.5cm with cutlery drawer
LEVEL TOP BASKET BOTTOM BASKET
1 max. ø 18 cm 33 cm/"34 cm" →Page15
2 max. ø 20.5 cm 30.5 cm
3 max. ø 23 cm 28 cm
Before first use
Before first use
Before first use
Performing the initial configuration
On initial start-up or after a reset to the factory settings, you
will need to make settings.
Requirement:"The appliance has been installed and con-
nected." →Page9
1. "Add special salt." →Page18
2. "Add rinse aid." →Page18
3. "Switch on the appliance." →Page22
4. "Setting the water softening system." →Page17
5. "Set the amount of rinse aid to be dispensed." →Page19
6. "Add detergent" →Page19.
7. Start the Programme with the highest cleaning temperat-
ure without tableware.
To remove any marks from water or other residues, we
recommend you operate the appliance without tableware
before using it for the first time.
Tip:You can change these settings and other Basic settings
at any time.
Water softening system
Water softening system
Water softening system
Hard water leaves limescale on the tableware as well as the
washing tank, and parts of the appliance may become
blocked.
To ensure good dishwashing results, you can treat the water
with special salt and the water softening system. To avoid
damage to the appliance, water with a hardness above 9°E
must be softened.
Overview of water hardness settings
You can find an overview of the water hardness values that can be selected here.
You can find out how hard your water is from your local water company or by using a water hardness tester.
WATER HARDNESS °E HARDNESS RANGE MMOL/L SETTING VALUE
0 - 8 Soft 0 - 1.1 H00
9 - 10 Soft 1.2 - 1.4 H01
11 - 12 Medium 1.5 - 1.8 H02
13 - 15 Medium 1.9 - 2.1 H03
16 - 20 Medium 2.2 - 2.9 H04
21 - 26 Hard 3.0 - 3.7 H05
27 - 38 Hard 3.8 - 5.4 H06
39 - 62 Hard 5.5 - 8.9 H07
Note:Set the water hardness determined on your appliance.
→"Setting the water softening system", Page17
With a water hardness of 0 - 8°E you can dispense with spe-
cial salt for dishwashers and switch off the water softening
system.
→"Switching off the water softening system", Page18
Setting the water softening system
Set the water hardness on your appliance.
1. Determine the water hardness and the appropriate set-
ting value.
→"Overview of water hardness settings", Page17
2. Press ⁠.
3. To open the basic settings, press for 3
seconds.
aThe display shows Hxx.
aThe display shows ⁠.
4. Press repeatedly until the right water hardness has
been set.
The value H04 is set at the factory.
5. To save the settings, press for 3 seconds.

18
Special salt
You can use special salt to soften water.
Adding special salt
If the special salt refill indicator lights up, add special salt to
the dispenser for special salt just before the programme
starts. The consumption of special salt depends on the water
hardness. The higher the water hardness, the greater the
consumption of special salt.
ATTENTION!
●Detergent may damage the water softening system.
●Only fill the dispenser of the water softening system
with special dishwasher salt.
●Special salt for dishwashers can damage the tub due to
corrosion.
●To make sure that any special salt that escapes is
washed out of the tub, add the special salt to the dis-
penser for special salt immediately before the pro-
gramme starts.
1. Unscrew the lid of the dispenser for special salt and re-
move.
2. On initial start-up: Fill the dispenser right up with water.
3. Note:Only use special salt for dishwashers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dispenser.
Fill the dispenser right up with special salt. The water in
the dispenser is displaced and forced out.
4. Place the lid back on the dispenser and turn to close.
Switching off the water softening system
If you find the special salt refill indicator irritating, e.g. when
using combined detergents with salt replacement sub-
stances, you can switch the indicator off.
Note
To avoid damage to the appliance, only switch off the water
softening system in the following cases:
●The water hardness is max. 26°E and you are using a
combined detergent with salt replacement substances.
According to the manufacturers, combined detergents
with salt replacement substances can generally only be
used up to a water hardness of 26°E without adding spe-
cial salt.
●The water hardness is 0 - 8°E. You do not need to use
special salt.
1. Press ⁠.
2. To open the basic settings, press for 3
seconds.
aThe display shows Hxx.
aThe display shows ⁠.
3. Press repeatedly until the display shows H00.
4. To save the settings, press for 3 seconds.
aThe water softening system is switched off and the salt re-
fill indicator is deactivated.
Regeneration of the water softening sys-
tem
In order to obtain fault-free function of the water softening
system, the appliance performs regeneration of the water
softening system at regular intervals.
Regeneration of the water softening system takes place be-
fore the end of the main rinse cycle in all programmes. It will
increase the run time and consumption values, e.g. water
and electricity.
Overview of consumption values with regeneration
the water softening system
Here you can find an overview of the maximum additional
running time and consumption values during regeneration
of the water softening system.
Regeneration of the water softening system
after x washing programmes 6
Additional running time in minutes 7
Additional water consumption in litres 5
Additional power consumption in kWh 0.05
The consumption values specified are laboratory measure-
ments determined in accordance with the currently applic-
able standard using the Eco 50° programme and with the
factory value of the water hardness set to 16 - 20°E.
Rinse aid system
Rinse aid system
Rinse aid system
Rinse aid
For optimum drying results, use rinse aid.
Only use rinse aid for domestic dishwashers.
Adding rinse aid
If the rinse aid refill indicator lights up, top up with rinse aid.
Only use rinse aid for domestic dishwashers.
1. Press the catch on the lid of the dispenser for rinse aid
and lift ⁠.

19
1
2
2. Add rinse aid up to the max mark.
max
3. If rinse aid spills out, remove it from the tub.
Spilled rinse aid can cause excessive frothing during the
wash cycle.
4. Close the lid of the dispenser for rinse aid.
aThe lid clicks into position.
Setting the amount of rinse aid
If there are streaks or water marks on tableware, change the
amount of rinse aid.
1. Press ⁠.
2. To open the basic settings, press for 3
seconds.
aThe display shows Hxx.
aThe display shows ⁠.
3. Press repeatedly until the display shows the
value r05 set at the factory.
4. Press repeatedly until the right amount of rinse aid
has been set.
– A low setting adds less rinse aid during the wash cycle
and reduces streaking on tableware.
– A higher setting adds more rinse aid during the wash
cycle, reduces water marks and improves the drying
result.
5. To save the settings, press for 3 seconds.
Switching the rinse aid system off
If you find the rinse aid refill indicator irritating, e.g. when
using combined detergents with a rinse aid component, you
can switch the rinse aid system off.
Tip:The function of rinse aid is limited with combined deter-
gents. You will generally get better results using rinse aid.
1. Press ⁠.
2. To open the basic settings, press for 3
seconds.
aThe display shows Hxx.
aThe display shows ⁠.
3. Press repeatedly until the display shows the
value r05 set at the factory.
4. Press repeatedly until the display shows r00.
5. To save the settings, press for 3 seconds.
aThe rinse aid system is switched off and the rinse aid refill
indicator is deactivated.
Detergent
Detergent
Detergent
Suitable detergents
Only use detergents that are suitable for dishwashers. Both
separate and combined detergents are suitable.
For optimum washing and drying results, use separate de-
tergent, adding "Special salt" →Page18 and "Rinse aid"
→Page18 separately.
Modern, powerful detergents mainly use a low-alkaline for-
mulation with enzymes. Enzymes break down starch and re-
move protein. Oxygen-based bleaching agents are generally
used to remove coloured marks, e.g. tea or ketchup.
Note:Follow the manufacturer's instructions for each deter-
gent.
Tabs
Tabs are suitable for all cleaning functions and do not need
to be measured out.
With shorter programmes tabs sometimes do not dissolve
entirely and leave residues of detergent. This may impair the
cleaning effect.
Powder detergent
Powder detergent is recommended for shorter pro-
grammes.
The dosage can be adjusted to the level of soiling.
Liquid detergent
Liquid detergent works faster and is recommended for
shorter programmes without PreRinse.
Sometimes liquid detergent may leak out despite the
detergent dispenser being closed. This is not a fault and is
non-critical if you remember the following:
●Only choose a programme without PreRinse.
●Do not select timer programming for starting the pro-
gramme.
The dosage can be adjusted to the level of soiling.
Separate detergents
Separate detergents are products that do not contain com-
ponents other than detergent, e.g. powder detergent or li-
quid detergent.

20
With powder and liquid detergent the dosage can be indi-
vidually adjusted to the level of soiling of the tableware.
For better washing and drying results and to avoid damage
to the appliance, please additionally use "Special salt"
→Page18 and "Rinse aid" →Page18.
Combined detergent
Besides conventional separate detergents, a number of
products are available with additional functions. These
products contain not only detergent but also rinse aid and
salt replacement substances (3in1) and, depending on the
combination (4in1, 5in1,...), additional components such as
glass protection or stainless steel cleaner.
According to the manufacturers, combined detergents gen-
erally only function up to a water hardness of 26°E. With a
water hardness above 26°E you will need to add special salt
and rinse aid. For the best washing and drying results we re-
commend using special salt and rinse aid from a water hard-
ness of 17°E. If you are using combined detergent, the
washing programme is adjusted automatically to ensure the
best possible washing and drying result.
Unsuitable detergents
Do not use detergent which could cause damage to the ap-
pliance or present a risk to health.
Hand washing-up liquid
Hand washing-up liquid can cause increased frothing and
damage the appliance.
Detergent containing chlorine
Chlorine residue on tableware may present a risk to health.
Information on detergents
Follow the instructions on detergents in everyday use.
●Detergents marked as "organic" or "ecological" (environ-
mentally friendly) generally contain lower levels of active
agents or completely dispense with certain substances.
The cleaning effect may be restricted here.
●Set the rinse aid and the water softening system to the
separate detergent or combined detergent in use.
●According to the manufacturers, combined detergents
with salt replacement substances can only be used up to
a certain water hardness, usually 26°E, without adding
special salt. For the best washing and drying results we
recommend using special salt from a water hardness of
17°E.
●To prevent sticking, only touch detergents in a water-sol-
uble pouch with dry hands and only ever place them in a
dry detergent dispenser.
●Even if the rinse aid and special salt refill indicators light
up, washing programmes will run properly with combined
detergents.
●The function of rinse aid is limited with combined deter-
gents. You will generally get better results using a separ-
ate rinse aid.
●Use tablets with a special drying performance.
Adding detergent
1. To open the detergent dispenser, press the locking latch.
2. Add the detergent to the dry detergent dispenser.
15 ml
25 ml
50 ml
If you are using tablets, one is enough. Insert the tablets
in a horizontal position.
If you are using powder or liquid detergent, follow the
manufacturer's instructions and quantities for dosage in
the detergent dispenser.
20ml–25ml detergent is sufficient for normal soiling. If
tableware is only lightly soiled, slightly less than the
amount of detergent specified is usually sufficient.
3. Close the lid of the detergent dispenser.
aThe lid clicks into position.
aThe detergent dispenser will open automatically at the
optimum time during the programme. Powder or liquid
detergent will spread around the washing tank and dis-
solve there. Tablets will fall into the tablet collecting tray
and dissolve in the right dosage. In order to ensure that
tablets can dissolve evenly, do not place any other objects
in the tablet collecting tray.
Tip:If you use powder detergent and select a program with
pre-rinse, you can also add a little detergent to the interior
door of the appliance.
