IKEA LAGAN User manual

LAGAN
GB

Please refer to www.IKEA.com
and select your local store for local
store phone numbers and opening
times.
ENGLISH 4

4
Before rst use
Your safety and that of others is
paramount.
Remove cardboard protection
pieces, protective lm and
adhesive labels from accessories.
Check the appliance for any
transport damage.
To avoid any damage do
not place any weights on the
appliance. Do not expose the
appliance to atmospheric agents.
This manual and the appliance
itself provide important safety
warnings, to be read and
observed at all times.
This is the attention symbol,
pertaining to safety, which
alerts users to potential risks to
themselves and others.
All safety warnings are preceded
by the attention symbol and the
following terms:
DANGER: indicates a
hazardous situation which, if
not avoided, will cause serious
injury.
WARNING: Indicates a
hazardous situation which, if
not avoided, could cause serious
injury.
All safety warnings give specic
details of the potential danger/
warning present and indicate how
to reduce risk of injury, damage
and electric shock resulting from
improper use of the appliance.
Carefully observe the following
instructions.
Precautions and general
recommendations
• The electrical installation and
the electrical connection must
be carried out by a qualied
technician according to the
manufacturer’s instructions
and in compliance with the
local safety regulations. Do not
repair or replace any part of
the appliance unless specically
stated in the user manual.
• The appliance must be
disconnected from the power
supply before carrying out any
installation work.
WARNING: Failure to install
the screws or xing device in
accordance with these instructions
may result in electrical hazards.
Safety Information
Contents
GB
ENGLISH
Safety Information 4
Use 7
Product description 8
Control panel 8
Cleaning and maintenance 8
What to do if ... 10
Technical data 11
Environmental concerns 12
IKEA GUARANTEE 13

5ENGLISH
• Earthing of the appliance is
compulsory. (Not possible for
class II hoods identied by the
symbol on the dataplate).
• Do not pull the power supply
cable in order to unplug the
appliance.
• The electrical components must
not be accessible to the user
after installation.
• Do not touch the appliance
with any wet part of the body
and do not operate it when
barefoot.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
• All other maintenance services
must be carried out by a
specialised technician.
• When drilling through the wall
pay attention not to damage
electric connections and/or
pipes.
• Air vents must always discharge
to the outside.
• The manufacturer rejects all
responsibilities for any damage
caused by improper use or
wrong settings.
• Appropriate maintenance
and cleaning ensure the good
working order and the best
performance of the appliance.
Regularly clean all stubborn
surface dirt to avoid grease
build up. Remove and clean
or change the lter regularly.
This must be completed in
accordance with the “Cleaning
and maintenance” instructions
provided.
• Never ame cook food (ambé)
under the appliance. Using free
ames might cause re.
• Failure to observe the
instructions for cleaning the
hood and replacing the lters
may result in a re.
• Exhaust air must not be vented
through a ue used for removal
of fumes produced by gas
combustion appliances or other
combustible materials, but must
have a separate outlet. All
national regulations governing
extraction of fumes must be
observed.
• There shall be adequate
ventilation if the hood is being
used at the same time as other
appliances using gas or other
combustible materials. The
negative pressure of the room

6ENGLISH
must not exceed 4 Pa (4x 10-5
bars). For this reason ensure
that the room is well ventilated.
In case of doubts, please consult
an autorized service assitance
center or similar qualied
person.
• Do not leave frying pans
unattended when frying, as the
frying oil may catch re.
• Before touching the light bulbs,
ensure that they are cold.
• Do not use or leave the hood
without the light bulb correctly
tted, as this may cause electric
shock.
• The hood is not a work surface,
therefore do not place any
objects on top of it or overload
it.
• During all installation and
maintenance operations wear
appropriate working gloves.
• This appliance is not suitable for
outdoor use.
WARNING: when the hob is in
use, accessible parts of the
hood may become hot.
Installation and connection
In the event of problems, contact
the Authorized Service Centre. To
prevent any damage, only remove
the appliance from its packaging
at the time of installation.
Preparing for installation
WARNING: this is a heavy
product; the hood should only be
lifted and installed by two or more
people.
The minimum distance between
the hob and the bottom part of the
hood must not be less than 65 cm
for burning gas or other fuels and
50cm for electric cookers.
Only for Korea, minimum distance
must not be less than 65 cm also
for electric cookers.
Before installation also check the
minimum distances stated in the
manual of the cooker.
If the installation instructions for the
cooker specify a greater distance
between cooker and hood, this
distance must be observed.
Electrical connection
Make sure the power voltage
specied on the appliance rating
plate is the same as the mains
voltage.
This information can be found
on the inside of the hood, under
the grease lter. Power cable
replacement (type H05 VV-F)
must be carried out by a qualied
electrician. Contact an authorized
service centre.
If the hood is tted with an electric
plug, connect the plug to a socket
complying with current regulations,
located in an accessible place.

7ENGLISH
The hood has been designed to be installed
and used either as a “Extraction installation”,
or as a “Recirculation installation”.
Extraction installation (see symbol in
installation booklet)
Cooking steam is sucked and channelled
outside the house through a discharge duct
(not supplied), tted to the hood steam outlet.
Ensure that the discharge duct is correctly tted
to the air outlet, unit using an appropriate
connection system.
Important: If already installed, remove the
charcoal lter/s.
Recirculation installation
(see symbol in installation booklet)
The air is ltered through one or more the
charcoal lters, and then resent into room.
Important: Ensure appropriate air circulation
around the hood.
Important: If the hood is supplied without
charcoal lters, these must be tted before the
hood can be used. Filters are available in IKEA
shops.
The hood should be installed away from
particularly dirty areas, windows, doors and
heat sources.
The accessories for wall xing are not included
because walls made of different materials
require different types of xing accessories.
Use xing systems suitable for the walls of your
home and the weight of the appliance. For
more details, contact a specialized dealer.
Keep this booklet for future consultation.
WARNING: if no plug is tted
(direct wiring to the mains), or
if the socket is not located in an
accessible place, a qualied
electrician should install a
standardised double pole power
switch that will enable complete
isolation from the mains in case of
category III overvoltage conditions,
in accordance with wiring rules.
Use

8ENGLISH
Product description
1 Control Panel.
2 Grease lter.
3 Lighting unit.
Control panel
WARNING:
-Never use steam cleaning equipment.
-Disconnect the appliance from the power
supply.
IMPORTANT: do not use corrosive or
abrasive detergents. If any of these products
accidentally comes into contact with the
appliance, clean immediately with a damp
cloth.
• Clean the surfaces with a damp cloth. If it is
very dirty, add a few drops of washing up
detergent to the water. Finish off with a dry
cloth.
IMPORTANT: do not use abrasive sponges or
metallic scrapers or scourers. Over time, these
can ruin the surface.
• Use detergents specically designed for
Cleaning and maintenance
A Light button.
The light button has two positions.
To switch on the lights: move the button to
the right.
B Extraction power selection button.
The extraction speed switch has different
settings, depending on the amount of
steam and fumes.
To increase the extraction power: move the
button to the right.
cleaning the appliance and follow the
manufacturer instructions.
IMPORTANT: clean the lters at least monthly
to remove any oil or grease residuals.
To clean the grease lter
The metal grease lter has an unlimited life
and must be washed once a month by hand
or dishwasher at low temperature and with a
short cycle. With cleaning in a dishwasher the
grease lter may become dull; this does not
effect its ltering capacity.
Grease lter maintenance:
1. Unplug the appliance or disconnect the
power supply.
2. Remove the grease lters: pull the spring
release handle, then remove the lter
downwards.
32
1
AB

9ENGLISH
3. After cleaning the grease lter, remount in
reverse order ensuring the entire extraction
surface is covered.
Charcoal lter maintenance (if the hood is
installed in recirculation installation)
1. Pull out the plug or disconnect the power
supply.
2. Remove the grease lter
3. If the carbon lters are already tted (two
lters that cover the protective grilles for the
motor impeller) and have to be replaced,
turn the central handle anti-clockwise to
unlock them.
4. Open the two lter shells
5. Pull out the two circular mats
6. Proceed in reverse order to t the new
lters.
7. Ret the grease lters.
Unlike traditional charcoal lters, this
charcoal lter can be washed and
reactivated.
Care and cleaning long life Charcoal lter
• The anti-odour lter shall be washed and
regenerated every 3-4 months (or more
frequently if the hood is subject to intensive
use), up to a Max. of 8 regeneration cycles
(in case of particularly intensive use it is
recommended that you do not exceed 5
cycles).
Regeneration procedure:
• Wash in the dishwasher at a MAX
temperature of 70° or hand wash in hot
water without using abrasive sponges (do
not use detergents!)
• Dry in the oven at a MAX temperature of
70° for 2 hours or dry at room temperature,
standing the lter in a vertical position to
facilitate drainage.
Lamp maintenance
1. Disconnect the hood from the power
supply.
2. Open the extractor grille or remove the
self-supporting grease lter.
3. Replace the damaged lamp. Use E14 3W
max LED lamps only.
4. Ret the extractor grille or grease lter.
IMPORTANT: make sure you don’t touch the
lamp with your bare hands.
Lamp Power
(W)
Socket Voltage
(V)
LCL ILCOS D Code
3E 14 230 55 DRGSB/C/UB-3/27/
1B-230-E14-55

10ENGLISH
Before contacting the Authorized Service
Centre:
Switch the appliance on again to see if the
problem has disappeared. If not, switch it off
again and repeat the operation after an hour.
If your appliance still does not work properly
after carrying out the checks listed in the
troubleshooting guide and switching the
appliance on again, contact the Authorized
Service Centre, clearly explaining the problem
and specifying:
Problem Possible cause Solution
The appliance does not
work
There is no mains
electrical power
Check for the presence of mains
electrical power.
Turn off the appliance and restart it to
see if the faults persists.
The appliance is not
connected to the
electrical supply
Check if the appliance is connected to
the electrical supply.
Turn off the appliance and restart it to
see if the faults persists.
The hood’s suction level
is not enough
The suction speed is too
low
Check the suction speed and adjust as
necessary.
The grease lters are
dirty 2
Check that the lters are clean
If not, clean the lters in the dishwasher.
The anti-odors lters are
dirty
Check that the anti-odour lters are
properly washed as recommended
The air vents ar e
obstructed
Check the air vents for any obstructions
and remove as necessary.
The light does not work The LED is broken 3For replacement, contact the Authorized
Service Centre.
• the type of fault;
• the model;
• the type and serial number of the appliance
(given on the rating plate);
• the Service number (the number after the
word SERVICE on the rating plate inside the
appliance).
What to do if ...

600
510
132
132
118
LED Bulb
1x3W
E 14
650
500
650
7,2
63,3
1,7
8,1
89
16 0
180
272
98,5
3
87
na
na
71
11ENGLISH
Technical data
The technical information is situated in the rating
plate on the internal side of the appliance.
Type of product Wall mounted hood
Dimensions
Width mm
Depth mm
Total height in extraction installation version min-max mm
Total height in recirculation installation version min-max mm
Total power W
Lamps info
Type
Number & Power W
Socket
Installation minimum height - gas hob mm
Installation minimum height - elec hob mm
Installation minimum height - elec hob (VALID ONLY FOR KOREA) mm
Product Weight Kg
Additional Product Information compliant to commission regulation (EU) No 66/2014
Model identier
LAGAN 105.093.28
LAGAN 305.093.27
LAGAN 705.093.30
LAGAN 905.093.29
Annual Energy Consumption kWh/a
Time increase factor
Fluid Dynamic Efciency %
Energy Efciency Index
Measured air ow rate at best efciency point m³/h
Measured air pressure at best efciency point Pa
Maximum air ow m³/h
Measured electric power input at best efciency point W
Nominal power of the lighting system W
Average illumination of the lighting system on the cooking surface lux
Power consumption in standby mode W
Power consumption off mode W
A-waighted Sound Power Emission at maximum speed dB(A)

12ENGLISH
Environmental concerns
Maintenance
The symbol on the product or on its
packaging indicates that this product may not be
treated as household waste.
Instead it shall be handed over to the applicable
collection point for the recycling of electrical and
electronic equipment.
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
For more detailed information about recycling of
this product, please contact your local city ofce,
your household waste disposal service or the
shop where you purchased the product.
Packaging materials
The materials with the symbol are
recyclable. Dispose the packaging in suitable
collection containers to recycle it.

13ENGLISH
IKEA GUARANTEE
How long is the IKEA guarantee valid?
This guarantee is valid for two (2) years
from the original date of purchase of your
appliance at IKEA. The original sales receipt
isrequired as proof of purchase. If service
workis carried out under guarantee, this
will not extend the guarantee period for the
appliance.
Who will execute the service?
IKEA service provider will provide the service
through its own service operations or
authorized service partner network.
What does this guarantee cover?
The guarantee covers faults of the appliance,
which have been caused by faulty costruction
or material faults from the dateof purchase
from IKEA. This guarantee applies to domstic
use only. The exceptionsare speci ied under
the headline “What is notcovered under this
guarantee?” Within the guarantee period,
the costs to remedy the fault e.g. repairs,
parts, labour and travel willbe covered,
provided that the appliance is accessible for
repair without special expenditure. On these
conditions the respective local regulations
are applicable. Replaced parts become the
property of IKEA.
What will IKEA do to correct the problem?
IKEA appointed Service Provider will examine
the product and decide, at its sole discretion,
if it is covered under this guarantee. If
considered covered, IKEA Service Provider
or its authorized service partner through its
own service operations, will then, at its sole
discretion, either repair the defective product
or replace it with the same or a comparable
product.
What is not covered under this guarantee?
• Normal wear and tear.
• Deliberate or negligent damage, damage
caused by failure to observe operating
instructions, incorrect installation or by
connection to the wrong voltage, damage
caused by chemical or electro-chemical
reaction, rust, corrosion or water damage
including but not limited to damage
caused by excessive lime in the water
supply, damage caused by abnormal
environmental conditions.
• Consumable parts including batteries and
lamps.
• Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible color differences.
• Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of lters, drainage systems or
soap drawers.
• Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
• Cases where no fault could be found
during a technician’s visit.
• Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where non-
original parts have been used.
• Repairs caused by installation which is
faulty or not according to specication.
• The use of the appliance in a non-
domestic environment i.e. professional
use.
• Transportation damages. If a customer
transports the product to his home or
another address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product
to the customer’s delivery address, then
damage to the product that occurs during
this delivery will be covered by IKEA.

14ENGLISH
• Cost for carrying out the initial installation
of the IKEA appliance.
• However, if an IKEA appointed Service
Provider or its authorized service partner
repairs or replaces the appliance under
the terms of this guarantee, the appointed
Service Provider or its authorized
service partner will reinstall the repaired
appliance or install the replacement, if
necessary.
• All plumping and electrical installation,
are not the responsibility of IKEA, and
customer must complete these work
before the execution work.
How country law applies
The IKEA guarantee gives you specic legal
rights, which cover or exceed all the local
legal demands. However these conditions
donot limit in any way consumer rights
described in the local legislation.
Valid for INDIA only: The courts at New
Delhi have exclusive jurisdiction for setting
the claims or disputes or matters arising outof
present Warranty.
Area of validity
This warranty is valid only in the country
where the product has been purchased; the
services will be provided in the framework
ofthe guarantee conditions. An obligation
to carry out services in the framework of
the guarantee exists only if the appliance
complies and is installed in accordance with:
• the technical specications of the country
in which the guarantee claim is made;
• the Assembly Instructions and User
Manual Safety Information;
The dedicated AFTER SALES for IKEA
appliances
Please don’t hesitate to contact IKEA
appointed Authorized Service Centre to:
• make a service request under this
guarantee;
• ask for clarications on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture;
• ask for clarication on functions of IKEA
appliances.
To ensure that we provide you with the
bestassistance, please read carefully the
Assembly Instructions and/or the User
Manual before contacting us.
How to reach us if you need our service
The IKEA after sales customer service
center will assist you on thephone
with basic trouble-shooting for your
appliances at the time of service call
request. Please refer to
www.IKEA.com
and select your local store for local store
phone numbers and opening times.
i
In order to provide you a quicker
service, we recommend to use the
specic phone numbers listed on this
manual. Always refer to the numbers
listed in the booklet of the specic
appliance you need an assistance for.
Please also always refer to the IKEA
article number (8 digit code) and 12
digit service number placed on the
rating plate of your appliance.
i
SAVE THE SALES RECEIPT!
It is your proof of purchase and required
for the guarantee to apply. Note that
the receipt reports also the IKEA article
name and number (8 digit code) for each
of the appliances youhave purchased.
Do you need extra help?
For any additional questions not related
to After Sales of your appliances please
contactyour nearest IKEA store call centre.
We recommend you read the appliance
documentation carefully before contacting us.

© Inter IKEA Systems B.V. 2021 23232 AA-2278866-2
LIB0178385A Ed.12/21
