Ikea Stangby User manual

STÅNGBY

WELCOME & CONGRATULATIONS

Please record your model and serial numbers below for

reference.

Veuillez enregistrer vos numéros de modèle et de série ci-

dessous pour référence.

Purchase Date / Date d’achat

Model Number / Numéro de modèle

Serial Number / Numéro de série

Rating Plate Location /

Emplacement

Please refer to the last page of this manual for the

full list of IKEA appointed After Sales Service Pro-

vider and relative national phone numbers.

Veuillez vous reporter à la dernière page de ce man-

uel pour obtenir la liste complète des fournisseurs

de services après-vente désignés par IKEA et les

numéros de téléphone nationaux correspondants.

NOTE

Please attach sales receipt here for future

reference.

Veuillez joindre le reçu de vente ici pour référence

future.

3hsilgnE

Français

Consulte la última página de este manual para

obtener una lista completa de Proveedores de

Servicios de posventa definidos por IKEA y sus

números de teléfono relacionados.

Español

Adjunte su boleta de compra aquí para consultas

futuras.

A continuación, registre tanto el modelo como los

números de serie para futuras consultas.

/ Fecha de compra:

/ Número de

modelo:

/ Número de

serie:

de la plaque signalétique / Ubicación

de la placa de clasificación

IMPORTANT SAFETY INSTRUCTIONS

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE

(a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful

exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to

accumulate on sealing surfaces.

that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals

and sealing surfaces.

(d) The oven should not be adjusted or repaired by anyone except properly qualiﬁed service personnel.

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ................................... 3

WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS... 4

GROUNDING INSTRUCTIONS ............................................. 5

RADIO INTERFERENCE ...................................................... 6

FEATURES & SPECIFICATIONS............................................ 7

BEFORE OPERATING ......................................................... 8

MANUAL OPERATION......................................................... 9

SENSOR OPERATIONS......................................................12

CONVENIENT FEATURES...................................................13

CARE & CLEANING...........................................................14

SPECIFICATIONS.............................................................15

IKEA LIMITED GUARANTEE ...............................................16

TO EXCESSIVE MICROWAVE ENERGY

WARNING

When using electrical appliances, basic safety precautions

should be followed to reduce the risk of burns, electric

shocks, ﬁre or injury to persons or exposure to excessive

microwave energy.

• READ ALL instructions before using oven.

•READ AND FOLLOW the speciﬁc “PRECAUTIONS

TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY” on page 3.

• This appliance must be grounded. Connect only

to properly grounded outlet. See GROUNDING

INSTRUCTIONS found on Page 5.

• Install or locate this oven ONLY in accordance with the

installation instructions in this

User Manual.

• Some products such as whole eggs and sealed

containers -for example, closed jars -are able to

explode and SHOULD NOT be HEATED in this oven.

• Use this oven ONLY for its intended use as described in

this Do not use corrosive chemicals

or vapors in this oven. This type of oven is speciﬁcally

designed to heat, cook, or dry food. It is not designed

for industrial or laboratory use.

•

•DO NOT operate this oven if it has a damaged cord

or power plug, if it is not working properly, or if it has

been damaged or dropped.

• This oven, including power cord, must be serviced

ONLY by qualiﬁed service personnel. Special tools are

required to service oven. Contact nearest authorized

service facility for examination, repair, or adjustment.

•DO NOT cover or block any vents or openings on the

oven.

•DO NOT store this oven outdoors. DO NOT use this

appliance near water -(for example, near a kitchen

sink, in a wet basement, near a swimming pool or

similar locations).

•DO NOT immerse cord or plug in water.

• Keep cord AWAY from HEATED surfaces.

•DO NOT let cord hang over edge of table or counter.

• Review the door cleaning instructions in the Care &

Cleaning section on page 14.

•To avoid the risk of ﬁre in the oven cavity, injury to

persons, or exposure to excessive microwave energy.

-DO NOT overcook food. Carefully attend oven when

paper, plastic or other combustible materials are

placed inside the oven to facilitate cooking.

- Remove wire twist-ties from paper or plastic bags

before placing bag in oven.

- If materials inside the oven ignite, keep oven door

CLOSED, turn oven off and disconnect the power

cord, or shut off power at the fuse or circuit breaker

panel.

-DO NOT use this oven cavity for storage. DO NOT

leave paper products, cooking utensils or food in the

cavity when not in use.

• Liquids such as water, coffee, or tea can be overheated

beyond the boiling point without appearing to be boiling

due to surface tension of the liquid. Visible bubbling

or boiling when the container is removed from the

microwave oven is not always present. THIS COULD

RESULT IN VERY HOT LIQUIDS SUDDENBLY BOILING

OVER WHEN A UTENSIL IS INSERTED INTO THE

CONTAINER OR LIQUID.

•DO NOT heat baby bottles in oven.

• Jars must be open when heated and the contents

stirred or shaken before consumption, in order to avoid

burns.

•DO NOT use this oven for commercial purposes. It is

made for household use only.

SAVE THESE

INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

WHAT YOU NEED TO KNOW ABOUT SAFETY

INSTRUCTIONS

Warning and Important Safety Instructions appearing in

the are not meant to cover all possible

conditions and situations that may occur. Common sense,

caution, and care must be exercised when installing,

maintaining or operating a microwave.

Always contact your dealer, distributor, service agent or

manufacturer about problems or conditions you do not

understand.

Recognize Safety Symbols, Words, Labels

DANGER

DANGER - Immediate hazards which WILL result in

severe personal injury or death.

WARNING

WARNING - Hazards or unsafe practices which COULD

result in severe personal injury or death.

User Manual.

User Manual

HOT CONTENTS CAN CAUSE SEVERE BURNS. DO

NOT ALLOW CHILDREN TO USE THE MICROWAVE.

Use caution when removing hot items.

CAUTION

CAUTION - Hazards or unsafe practices which COULD

result in minor personal injury.

CAUTION

To avoid personal injury or property damage, observe

the following:

1. Do not deep fat fry in oven. Fat could overheat and

be hazardous to handle.

2. Do not cook or reheat eggs in shell or with an

unbroken yolk using microwave energy. Pressure

may build up and erupt. Pierce yolk with fork or

knife before cooking.

3. Pierce skin of potatoes, tomatoes, and similar foods

before cooking wit^i microwave energy. When skin

is pierced, steam escapes evenly.

4. Do not operate oven without load or food in oven

cavity.

5. Use only popcorn in packages designed and labeled

for microwave use. Popping time varies depending

on oven wattage. Do not continue to heat after

popping has stopped. Popcorn will scorch or burn.

Do not leave oven unattended.

6. Do not use regular cooking thermometers in oven.

Most cooking thermometers contain mercury and

may cause an electrical arc, malfunction, or damage

to oven.

7. Do not use metal utensils in oven.

8. Never use paper, plastic, or other combustible

materials that are not intended for cooking.

9. When cooking with paper, plastic, or other

combustible materials, follow manufacturer's

recommendations on product use.

CAUTION

10. Do not use paper towels which contain nylon or

other synthetic ﬁbers. Heated synthetics could melt

and cause paper to ignite.

11. Do not heat sealed containers or plastic bags in

oven. Food or liquid could expand quickly and cause

container or bag to break. Pierce or open container

or bag before cooking.

12. To avoid pacemaker malfunction, consult physician

or pacemaker manufacturer about effects of

microwave energy on pacemaker.

GROUNDING INSTRUCTIONS

Oven MUST be grounded.

In the event of an electrical short circuit, grounding

reduces risk of electric shock by providing an escape

wire for the electric current. This oven is equipped

with a cord having a grounding wire with a grounding

plug. The must plugged into an outlet that is properly

installed and grounded. See installation instructions.

Consult a qualiﬁed electrician or servicer if grounding

instructions are not completely understood, or if doubt

exists as to whether the oven is properly grounded. If it

is necessary to use an extension cord, use only a 3-wire

extension cord that has a 3-pronged grounding plug and

a 3-slot. This oven should be plugged into a separate

60 hertz circuit with the electrical rating as shown in

speciﬁcations table. When the oven is on a circuit with

other equipment, an increase in cooking times may be

required and fuses can be blown. Microwave operates on

standard household current, 120V.

• A short power-supply cord is provided to reduce the

risks resulting from becoming entangled in or tripping

over a longer cord.

• Longer cord sets or extension cords may be used if

care is exercised in their use.

• If a long cord or extension cord is used:

- The marked electrical rating of the cord set or

extension cord set should be at least as great as

- The extension cord must be a grounding-type 3-

WARNING

Improper use of the grounding can result in electric

shock. To avoid risk of electrical shock or death, this

oven must be grounded and plug must not be altered.

WARNING

the electrical rating of the appliance.

wire cord.

- The longer cord should be arranged so that it will not

drape over the countertop or tabletop where it can

be tripped over, snagged, or pulled on by children or

tripped over unintentionally.

Federal Communications Commission Radio

Frequency Interference Statement (U.S.A.

Only)

This equipment generates and uses ISM frequency

energy and if not installed and used properly, that is in

strict accordance with the manufacturer’s instructions,

may cause interference to radio and television reception.

It has been type tested and found to comply with limits

for ISM Equipment, pursuant to part 18 of FCC Rules,

which are designed to provide reasonable protection

against such interference in a residential installation.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause interference to radio or television reception, which

can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference

by one or more of the following:

- Reorient the receiving antenna of the radio or

television.

- Relocate the microwave oven with respect to the

receiver.

- Move the microwave oven away from the receiver.

- Plug the microwave oven into a different outlet so

that the microwave oven and the receiver are on

different branch circuits.

The manufacturer is not responsible for any radio

or television interference caused by unauthorized

modiﬁcation to this microwave oven. It is the

responsibility of the user to correct such interference.

GROUNDING INSTRUCTIONS

RADIO INTERFERENCE

1. Operation of the microwave oven may cause

interference to your radio, TV or similar equipment.

2. When there is interference, it may be reduced or

eliminated by taking the following measures:

1) Clean door and sealing surface of the oven

2) Reorient the receiving antenna of radio or

television.

3) Relocate the microwave oven with respect to the

receiver.

4) Move the microwave oven away from the receiver.

5) Plug the microwave oven into a different outlet so

that microwave oven and receiver are on different

branch circuits.

This MWO may be adapted to a built-in installation

by using Trim Kit (705.427.30/905.427.29), refer to

Trim Kit Installation

Instruction for details.

WARNING

Liquids such as water, coffee, or tea can be overheated

beyond the boiling point without appearing to be

boiling due to surface tension of the liquid. Visible

bubbling or boiling when the container is removed

from the microwave oven is not always present. THIS

COULD RESULT IN VERY HOT LIQUIDS SUDDENLY

BOILING OVER WHEN THE CONTAINER IS

DISTURBED OR A UTENSIL IS INSERTED INTO THE

LIQUID.

To reduce the risk of injury to persons:

1. Do not overheat the liquid.

2. Stir the liquid both before and halfway through

heating it.

3. Do not use straight-sided containers with narrow

necks.

4. After heating, allow the container to stand in the

microwave oven for a short time before removing

the container.

5. Use extreme care when inserting a spoon or other

utensils into the container.

CHOOSING A LOCATION FOR YOUR MICROWAVE OVEN IF BUILT-IN

Microwave Models:

705.427.06 Black SS

705.427.30 SS

905.427.29 Black SS

Microwave

30" Trim Kit

Microwave

905.427.05

Color Description

Model Number

Built-In Trim Kit allows for the installation of microwaves listed below to be built into a cabinet or wall by itself or over

an electric wall oven*.

WARNING

*NOTE: Trim Kit and microwave can only be built-in over an electric self-clean or non self-clean single cavity wall oven.

FEATURES & SPECIFICATIONS

Microwave features

ring

assembly

Turntable

glass

tray

Turntable

Shaft

Turntable Contro

panel

Door

assembly

Interloc

system

Window

Control panel

(1)

(2)

(3)

(4)

(5)

(6)

(10)

(7)

(8)

(9)

(11)

(12)

(13)

(14)

(15)

(16)

(17)

(1) Potato

(2) Popcorn

(3) Melt/Soften

(4) Auto Cook

(5) Sensor Cook

(6) Sensor Reheat

(7) Veggies

(8) Defrost

(9) Power level (10 power levels available)

(10) Number Keys

(11) Stop/Cancel(Hold 3s to lock):

clears all previous settings pressed

before cooking starts.

During cooking: press once to stop oven;

twice to stop and clear all entries.

Display

1A - Background

2A- TIMER & DEFR

2A - NUMBERS

2A - LOCK

2A - MICRO

2A - SENSOR COOK

3A - NUMBERS

2A -

PRESS AGAIN

PRESS START

(12) +10 Sec

(13) Timer

(14) User Pref

(15) Start

(16) +30Sec

(17) Clock(Hold 3s on/off)

- kg, oz or lb

FOR OPTIONS/

BEFORE OPERATING

Learn more about your microwave oven

CAUTION

To avoid risk of personal injury or property damage, do

not operate the microwave oven empty.

To avoid risk of personal injury or property damage, do

not use stoneware, aluminum foil, metal utensils, or

metal trimmed utensils in the microwave oven.

Microwave utensil guide

Use Do not use

•Oven proof glass (speciﬁcally

treated for high intensity heat):

Utility dishes, loaf dishes, pie plates,

cake plates, liquid measuring cups,

casseroles and bowls without metallic

trim.

•China:

Bowls, cups, serving plates and

platters without metallic trim.

•Plastic:

Plastic must be rated as microwave-

safe.

Plastic wrap (as a cover) - lay the

plastic wrap loosely over the dish

and press it to the sides. Vent

plastic wrap by turning back one

edge slightly to allow excess steam

to escape. The dish should be deep

enough so that the plastic wrap

will not touch the food. Use plastic

dishes, cups, semi-rigid freezer

containers and plastic bags for short

cooking times. Use these with care

because the plastic may soften from

the heat of the food. Look for the

manufacturer’s label for any special

instructions for use in the microwave

oven.

•Paper:

Paper towels, waxed paper, paper

napkins and paper plates with no

metallic trim or design. Look for the

manufacturer’s label for any special

instructions for use in the microwave

oven.

•Metal utensils:

Metal shields the food from microwave energy and produces uneven cooking.

Also, avoid metal skewers, thermometers or foil trays. Metal utensils can

cause arcing, which can damage your microwave oven.

•Metal decoration:

Bowls, cups, serving plates and platters with metallic trim.

•Aluminum foil:

Avoid aluminum foil.

•Wood:

Wooden bowls and boards will dry out and may split or crack when you use

them in the microwave oven. Baskets made of wood will react in the same

way.

•Tightly covered utensils:

Be sure to leave openings for steam to escape from covered cookware.

Pierce plastic pouches of vegetables or other food items before cooking.

Tightly closed pouches may explode. Look for the manufacturer’s label for

any special instructions for use in the microwave oven.

•Brown paper:

Avoid using brown paper bags. They absorb heat and can burn.

•Flawed or chipped cooking utensils:

Any utensil that is cracked, awed or chipped may break in the oven.

•Metal twist ties:

Remove metal twist ties from plastic or paper bags. They become hot and

could cause a ﬁre.

MANUAL OPERATION

Setting the clock

• Example: setting clock display for 9:00:

1. Touch pad once.

2. Enter time using number pads.

3. Touch START pad .

Setting the clock ON/OFF

Clock display ON default.

1. Touch pad and hold.

2. Time will display, after 3s, OFF will

display. OFF

NOTE

When the clock display off:

Press the button to enter the clock query state and

return to the standby mode after 1 second. The clock is

not displayed.

Hold down the key for 1-3 seconds to display the

current clock. After 1 second, display the current clock

and enter the clock setting mode.

Setting the timer

• Example: setting timer for 5 minutes:

1. Touch Timer pad once.

2. Enter desired time using number pads.

3. Touch Timer pad.

Timer count down does not stop even if the door is

opened. To stop/cancel the timer, press the Timer

key once. When the timer has reached the end of

set time, you will hear beep alerts indicating the

timer has run out.

Control Lock

You may lock the control panel to prevent the

microwave from being accidentally started or used

by children.

The control lock feature is very useful when

cleaning the control panel. The lock will prevent

accidental programming when wiping the control

panel clean.

• Example: to set the control lock ON:

Touch and hold the Stop/Cancel pad for

more than 3 seconds. The Lock icon will

appear in the display window along with 1

beep.

• Example: to change the control lock from

ON to OFF:

Touch and hold the Stop/Cancel pad for

more than 3 seconds. The Lock icon will

disappear in the display window.

Using the +10 sec /+ 30 sec key

This feature will let you quickly start or add 10 or

30 seconds.

Touch the +10 sec /+30 sec pad to:

1) Start programmed cooking.

2) Start cooking for 10 seconds/30

seconds at 100% power level.

3) Extend cooking time in multiples

of 10 seconds/30 seconds each

time this pad is touched during

microwave cooking.

+10 Sec /

+30 Sec

• Example: to add 1 minute of cook time

during 100% microwave cooking :

Press +30 sec pad twice.

NOTE

"Food" will be displayed if a quick start cooking cycle or

+ 10 Sec / +30 Sec key is pressed more than 5 minutes

after the door of microwave oven is closed. You must

open then close the door again to clear ''Food'' from the

display.

Using Quick Start

Microwave heating or cooking may be quickly set

at 100% power level for 1-6 minutes. Use the

number keys 1-6 to choose the desired minutes of

cook time (this option will only work using the 1-6

numeric pads).

•Example: to quickly heat for 2 minutes at

100% power:

Press number pad for desired minute(s).

The microwave will start at once.

Heating with high power level

• Example: To heat for 5 minutes and 30

seconds at 100%power:

1. Use the number pads to enter desired

heating time.

2. Pres START pad. When ﬁnished, you

will hear a series of beeps.

NOTE

For time sets that start with numbers 1 - 6, the

remaining numbers must be entered within 2 second

from the ﬁrst key press, otherwise the Quick Start time

will be used.

Heating with lower power levels

Using the highest power level to heat foods does

not always give the best results when some types

of food need slower cooking, such as roasts, baked

goods or custards. Your oven has nine other power

levels you may choose.

•Example: To heat for 4 minutes and 30

seconds at 70%power:

1. Enter cook time.

2. Press Power Level pad once for

power level PL-HI.

3. Press Power Level times to

change to 70% power level. PL-70

appears in the display.

4. Press START pad.

When ﬁnished, you will hear a series of beeps.

NOTE

For time sets that start with numbers 1 - 6, the

remaining numbers must be entered within 2 second

from the ﬁrst key press, otherwise the Quick Start time

will be used.

Heating with multiple cooking stages

For best results, some microwave recipes call for

different power levels or different lengths of time

for cooking. Your microwave may be set to change

from one stage to another automatically (2 stages

maximum).

• Example: to cook food at 80% power for 3

minutes and then 50% power for 6 minutes

30 seconds:

1. Use the number pads to enter heating

time for the 1st stage.

2. Press Power Level pad.

3. Press Power Level two times to

change to 80% power level. PL-80

appears in the display.

4. Use the number pads to enter heating

time for the 2nd stage.

5. Press Power Level (within 1 second)

for the 2nd stage.

6. Press Power Level five times to

change to 50% power level for the 2nd

stage. PL-50 appears in the display.

7. Press START pad.

When ﬁnished, you will hear a series of beeps.

NOTE

The “Convenience operation” can’t be set as one of

multiple cooking.

Auto Cook

Do not leave microwave unattended during any of

auto cook selections.

Key Press Food Amount Key

Auto Cook x1 Bacon 1 - 3 slices 1 - 3

Auto Cook x2 Frozen

Entree 10 oz - 20 oz -

Auto Cook x3 Rice 1 cup - 2 cups -

• Example: to cook Rice.

1. Press Auto Cook pad 3 times.

2. Press START pad. The microwave will

beep when ﬁnished.

USING AUTO DEFROST

Three defrost sequences are preset in the oven.

The auto defrost feature provides you with the best

defrosting method for frozen foods.

The cooking guide will show you which defrost

sequence is recommended for the food you are

defrosting.

For added convenience, the Auto Defrost includes

a built-in beep mechanism that reminds you to

MANUAL OPERATION

three

check, turn over, separate, or rearrange the food in

order to get the best defrost results. Three different

defrosting levels are provided:

1. MEAT

2. POULTRY

3. FISH

Available weight is 0.1 to 6.0 lbs.

•Suppose you want to defrost 2.0 lbs of

meat.

1. Press Defrost pad.

2. Press START pad.

3. Enter cook weight

4. Press START pad. (Refer the table on

next page)

Key Press Category WEIGHTS YOU CAN SET

(tenths of a pound)

Defrost Meat 0.1 to 6.0

Defrost Poultry 0.1 to 6.0

Defrost Fish 0.1 to 6.0

Popcorn

CAUTION

DO NOT leave microwave oven unattended while

popping popcorn.

The popcorn feature lets you pop 3 different

commercially packaged microwave popcorn sized bags.

Use the table below to determine the setting to use:

Key Food

Popcorn x1 3.3 oz. (default)

Popcorn x2 3.0 oz.

Popcorn x3 1.75 oz.

• Example: To pop a 1.75 oz. bag of popcorn

automatically:

1. Press POPCORN pad 3 times (refer to

table above).

2. Press START pad

When ﬁnished, you will hear a series of beeps.

SETTING VEGGIES

The Veggies quick touch pad lets you cook fresh

and frozen vegetables.

Key Food

Veggies x1 Fresh

Veggies x2 Frozen

• Suppose you want to cook frozen veggies.

1. Press Veggies pad 2 times (refer to

table above).

2. Press START pad.

SETTING MELT/SOFTEN

The oven uses low power to melt and soften items.

See the following table.

Key Food Amount Key

Melt / Soften x1 Melt Butter 1 stick 1

2 sticks 2

Melt / Soften x2 Melt

Chocolate

2 oz. 2

4 oz. 4

8 oz. 8

Melt / Soften x3 Soften Ice

Cream

1 Pint 1

1.5 Quart 2

Melt / Soften x4 Soften Cream

Cheese

3 oz. 3

8 oz. 8

• Suppose you want to melt 8 oz. of

Chocolate.

1. Press Melt/Soften pad 2 times (refer

to table above).

2. Press START pad

3. Enter cook weight

4. Press START pad

MANUAL OPERATION

SENSOR OPERATIONS

Sensor Cook Operating Tips

The Sensor Cook categories are designed to detect

the increasing humidity released by the food during

the cooking process. The microwave oven sensor

will automatically adjust the cooking time to the

type and amount of food. The food categories that

are controlled with the humidity sensor are:

Key Food

Sensor Cook x1 Frozen Breakfast (8-

12oz)

Sensor Cook x2 Ground Meat

Sensor Cook x3 Fish Seafood

Sensor Cook x4 Chicken Breast

For best results, do not use one of the Sensor Cook

categories twice in succession on the same food

portion. This may result in severely overcooked or

burnt food. If the food appears to be undercooked,

use one of the Easy Set pads or cook time pads to

add more time.

Additional sensor cook suggestions are:

- Never start with less than 4 oz. of food.

- Use proper containers and covers for best

sensor cooking results.

- Always use microwave-safe containers.

Never usetight sealing plastic containers.

They will prevent steam from escaping and this

will mislead the sensor, usually causing the

food to overcook.

Be sure the outside of the cooking containers and

the cavity of the microwave oven are dry before

placing food in the oven. Excessive moisture

turning into steam that does not result from the

food cooking can mislead the sensor.

•Suppose you want to cook Frozen Breakfast.

1. Press the Sensor Cook pad.

2. Press START pad.

• Suppose you want to cook Fish Seafood.

1. Press the Sensor Cook pad three

times.

2. Press START pad.

Sensor Reheat

The reheat feature is designed to detect the

increasing humidity released by the food during the

cooking process. The microwave oven sensor will

automatically adjust the cooking time to the type

and amount of food.

Key Press Selection Amount

Sensor Reheat x1 Beverage 1 - 3 cups

Sensor Reheat x2 Dinner Plate 1 - 2 plates

Sensor Reheat x3 Soup - Sauce 1 - 2 cups

Sensor Reheat x4 Casserole 1 - 4 servings

Notes concerning sensor reheat:

• For casseroles, add 2 - 3 tablespoons of liquid,

cover with lid or vented plastic wrap. Stir when

instructed from display.

• For canned foods, empty contents of can into a

casserole dish or serving bowl. Cover dish with lid

or vented plastic wrap. Let stand a few minutes

before serving.

• For plates of food, arrange food on plate and add

any butter or gravies, etc. Cover with loose-ﬁtting

lid or vented plastic wrap. After reheating, let

stand a few minutes be.;

• Example: suppose you want to reheat 1 cup

beverage.

1. Press Sensor Reheat pad.

2. Press START pad

3. Enter 1.

4. Press START pad

Baked Potato

The potato feature cooks 1 - 4 baked potato

automatically (starting from room temperature).

1. Press the Potato pad. Potato

2. Press START pad.

USER REFERENCE

This section gives instructions for operating each

function. Please read this section carefully.

PREFERENCES

The microwave oven has settings that allow you

to customize the operation for your convenience.

Below is the table showing the various settings.

Touch the User Pref key multiple times to scroll to

the desired setting function.

Key Function

User Pref x 1 Volume

User Pref x 2 Weight

User Pref x 3 Language

User Pref x 4 Demo Mode

SETTING AUDIO LOW/MED/HIGH/OFF

•Suppose you want to turn on the Volume

Off.

1. Press the User Pref pad once.

2. Press START pad when display

indicates volume level is off.

SETTING WEIGHT LBS/KG

•Suppose you want to toggle weight between

pounds & kilograms.

1. Press the User Pref pad twice.

2. Press START pad.

SETTING LANGUAGE MODE

• Suppose you want to enter Language Mode.

1. Press the User Pref pad three times.

2. Press START pad.

SETTING DEMO MODE

• Suppose you want to enter Demo Mode.

1. Press the User Pref pad four times.

2. Press START pad.

CONVENIENT FEATURES

Cleaning suggestions

For best performance and for safety reasons, keep the

oven clean inside and outside. Take special care to keep

the inner door panel and oven from frame free of food

and grease build-up.

Never use rough scouring powder or pads on the

microwave. Wipe the microwave oven inside and out

with a soft cloth and warm (not hot) mild detergent

solution. Then rinse and wipe completely dry.

Wipe spattersimmediately with a wet paper towel,

especially after cooking greasy foods like chicken or

bacon.

Follow these instructions to clean and care for

your microwaveoven:

Keep the inside (cavity) of the oven clean. Food

particlesand spilled liquids can stick to the oven

Wipe up spillsimmediately. Use a damp, clean

cloth and mild detergent. DO NOT use harsh

detergentsor abrasive cleaners.

To help loosen baked-on food particles or liquids,

heat 2 cupsof water (add the juice of 1 lemon if

you desire to keep the oven fresh smelling) in a 4

cup measuring glass at High power for 5 minutes

or until boiling. Let stand in oven cavity for 1 or 2

minutes.

Remove the glass turntable tray from the oven

when cleaning the oven cavity or tray. To prevent

the glass turntable from breaking, handle with

care and do not put it in water immediately

after cooking. Wash the turntable tray with mild

detergent.

Clean the outside surface of the microwave with

mild detergent and a clean damp cloth. Dry with

a clean soft cloth. To prevent damage to the

operating partsof the oven,donot let water seep

into any ventsor openings.

Wash the oven door window with very mild soap

and water. Be sure to use a soft clean cloth to

avoid scratching.

If steam accumulatesinside or outside the oven

door, wipe with a soft cloth. Steam can accumulate

when operating the oven in high humidity and in

no way indicatesmicrowave leakage.

Never operate the oven without food in the oven

cavity; this can damage the magnetron tube or

glass tray.

Solutions to Common Problems

Troubleshooting guide

If you have a problem you cannot solve, please do not

hesitate to call our service line:

Before you call a repair person for your microwave,

check the list below for possible easy solutions to some

common problems.

Neither the microwave’s display oroven operates -

Properly insert the plug into a grounded power outlet.

Remove the plug from the outlet, wait 10 seconds, then

plug the microwave in again.

Check the household circuit breaker.

Plug the microwave intoa different power outlet.

The oven display works, but the oven will not

operate -

Make sure the oven door is closed securely and

completely.

Check to see if packing material or other materials are

stuck to the door seal.

Check for damage to the oven door.Contact service if

dagered.

Press the STOP pad twice and attempt to re-enter

cooking instruc tions.

Plug the microwave intoa different power outlet.

The power goes off before the cook time has

elapsed -

If there has been a power interruption, remove

the plug from the outlet; wait 10 seconds, then

plug the microwave in again. If there was a power

outage, the time indicator in the display will show

00:00.

Reset the clock and any cooking instructions

Check the household circuit breaker.

Press the STOP pad twice and attempt to re-enter

cooking instructions.

Plug the microwave intoa different power outlet.

Foodis cooking too slowly -

Make sure the oven is on a separate 20 amp circuit line.

Operating another appliance on the same circuit can

cause a voltage drop.

You see sparks orarcing -

Remove any metallicutensils, cookware or metal ties

from the oven cavity.

The turntable makes noises or sticks -

Clean the turntable, roller ring and oven cavity bottom.

Make sure the turntable and roller ring are positioned

correctly.

Care & Cleaning Before YouCall

Questionsor for Service Call: (833) 337-4006

Using your microwave causes TV or radio

interference -

Thisis similar tothe interference caused by other small

appliances, such as hair dryers. Move your microwave

further away from other appliances.

Please note: Ifthe oven is set to cook for more

than 30 minutes at 100% power level, it will

automatically adjust itself to a 80% power level

after 30 minutes to avoidovercooking

SPECIFICATIONS

AC Line Voltage: Single phase 120V, 60Hz, AC

only

Rated Input AC Power

Required: 1500W

Rated Output Power*: 1100W

Frequency: 2450 MHz

Outside Dimensions

(including handle): 24.4" X 19.8" X 13.5"

Cavity Dimensions:

Microwave oven

Capacity***: 2.2Cu.Ft.

Cooking Uniformity: Turntable

Weight: Approx. (net) 42.90 Lbs,

(gross)48.30 Lbs

Oven Light: 1*1.5 W LED

*The International Electrotechnical Commission’s

standardized method for measuring output wattage.

This test method is widely recognized.

**This is the classiﬁcation of ISM (Industrial,

Scientiﬁc and Medical) equipment described in the

International Standard CISPR11.

*** Internal capacity is calculated by measuring

maximum width, depth and height. Actual capacity

for holding food is less.

In compliance with standards set by:

FCC - Federal Communications Commission

Authorized.

DHHS

- Complies with Department of Health and

Human Services (DHHS) rule, CFR, Title

21, Chapter I, Subchapter J.

- This symbol on the nameplate means

the product is listed by Underwriters

Laboratories, Inc.

- This symbol on the nameplate means

the product is listed by Underwriters

Laboratories, Inc. for use in USA or

Canada.

17.8"X 19.1" X 11.2"

IKEA LIMITED GUARANTEE

How long is the IKEA guarantee valid?

This guarantee is valid for five (5) years from the original date of purchase of Your appliance atIKEA, unless the

appliance is named LAGAN or TILLREDA in which case two (2) years of guarantee apply. The original sales receipt is

required as proof of purchase. If service work is carried out under guarantee, this will not extend the guarantee

period for the appliance.

Who will execute the service?

IKEA “Service Provider” will provide the service through its own service operations or authorized service partner

network.

What does this guarantee cover?

The guarantee covers faults of the appliance which have been caused by faulty construction or material faults from

the date of purchase from IKEA. This guarantee applies to domestic use only. Some exceptions not guaranteed are

specified under the headline “What is not covered under this guarantee?” Within the guarantee period, the costs to

remedy the fault (e.g., repairs, parts, labour and travel) will be covered, provided that the appliance is accessible for

repair without special expenditure. On these conditions the local regulations are applicable. Replaced parts become

the property of IKEA.

What will IKEA do to correct the problem?

IKEA appointed Service Provider will examine the product and decide, at its sole discretion, if it is covered under this

guarantee. If considered covered, IKEA Service Provider or its authorized service partner through its own service

operations, will then, at its sole discretion, either repair thedefective product or replace it with the same or a

comparable product.

What is not covered under this guarantee?

• Normal wear and tear.

• Deliberate or negligent damage, damage caused by failure to observe operating instructions, incorrect

installation or by connection to thewrong voltage, damage caused by chemical or electrochemical reaction, rust,

corrosion or water damage including but not limited to damage caused by excessive lime in the water supply,

damage caused by abnormal environmental conditions.

• Consumable parts including batteriesand lamps.

• Non-functional and decorative parts which do not affect normal use of the appliance, including any scratches and

possible colour differences.

• Accidental damage caused by foreign objects or substances and cleaning or unblocking of filters, drainage

systems or soap drawers.

• Damage to the following parts: ceramic glass, accessories, crockery and cutlery baskets, feed and drainage pipes,

seals, lamps and lamp covers, screens, knobs, casings and parts of casings. Unless such damages can be proved to

have been caused by production faults.

• Cases where no fault could be found during a technician’s visit.

• Repairs not carried out by our appointed service providers and/or an authorized service contractual partner or

where non-original parts have been used.

• Repairs caused by installation which is faulty or not according to specification.

• The use of the appliance in a non-domestic environment i.e. professional use.

• Transportation damages. If a customer transports the product to his home or another address, IKEA is not liable

for any damage that may occur during transport. However, if IKEA delivers the product to the customer’s delivery

address, then damage to the product that occurs during this delivery will be covered by IKEA.

• Cost for carrying out the initial installation of the IKEA appliance. However, if an IKEA appointed Service Provider

or its authorized service partner repairs or replaces the appliance under the terms of this guarantee, the appointed

Service Provider or its authorized service partner will reinstall the repaired appliance or install the replacement, if

necessary.

The dedicated AFTER SALES for IKEA appliances

Please don’t hesitate to contact IKEA appointed After Sales Service Provider to:

• make a service request under this guarantee;

• ask for clarifications on installation of the IKEA appliance in the dedicated IKEA kitchen furniture;

• ask for clarification on functions of IKEA appliances.

To ensure that we provide you with the best assistance, please read carefully the Assembly Instructions and/or the

User Manual before contacting us.

How to reach us if you need our service

In order to provide you a quicker service, we recommend to use the specific phone

numbers listed on this manual. Always refer to the numbers listed in the booklet of the specific appliance you need

an assistance for.

Please also always refer to the IKEA article number (8 digit code) placed on the rating plate of your appliance.

SAVE THE SALES RECEIPT!

It is your proof of purchase and required for the guarantee to apply. The sales receipt also reports the IKEA name

and article number (8 digit code) for each of the appliances you have purchased.

Do you need extra help?

For any additional questions not related to After Sales of your appliances please contact your nearest IKEA store call

centre. We recommend you read the appliancedocumentation carefully before contacting us.

Phone number:

(833) 337-4006

Opening hours:

Monday - Friday

8:30 am - 8:00 pm EST

How country law applies

The IKEA guarantee gives you specic legal rights, and you may also have other rights which vary from

state to state or jurisdiction to jurisdiction. However these conditions do not limit in any way consumer

rights described in the local legislation.

Area of validity

For appliances which are purchased in United States or Canada, or moved to one of the mentioned coun-

tries, the services will be provided in the framework of the guarantee conditions normal in the specied

country.

An obligation to carry out services in the framework of the guarantee exists only if the appliance complies

and is installed in accordance with:

- the technical specications of the country in which the guarantee claim is made;

- the Assembly Instructions and User Manual Safety Information.

IKEA LIMITED GUARANTEE

How long is the IKEA guarantee valid?

This guarantee is valid for five (5) years from the original date of purchase of Your appliance atIKEA, unless the

appliance is named LAGAN or TILLREDA in which case two (2) years of guarantee apply. The original sales receipt is

required as proof of purchase. If service work is carried out under guarantee, this will not extend the guarantee

period for the appliance.

Who will execute the service?

IKEA “Service Provider” will provide the service through its own service operations or authorized service partner

network.

What does this guarantee cover?

The guarantee covers faults of the appliance which have been caused by faulty construction or material faults from

the date of purchase from IKEA. This guarantee applies to domestic use only. Some exceptions not guaranteed are

specified under the headline “What is not covered under this guarantee?” Within the guarantee period, the costs to

remedy the fault (e.g., repairs, parts, labour and travel) will be covered, provided that the appliance is accessible for

repair without special expenditure. On these conditions the local regulations are applicable. Replaced parts become

the property of IKEA.

What will IKEA do to correct the problem?

IKEA appointed Service Provider will examine the product and decide, at its sole discretion, if it is covered under this

guarantee. If considered covered, IKEA Service Provider or its authorized service partner through its own service

operations, will then, at its sole discretion, either repair thedefective product or replace it with the same or a

comparable product.

What is not covered under this guarantee?

• Normal wear and tear.

• Deliberate or negligent damage, damage caused by failure to observe operating instructions, incorrect

installation or by connection to the wrong voltage, damage caused by chemical or electrochemical reaction, rust,

corrosion or water damage including but not limited to damage caused by excessive lime in the water supply,

damage caused by abnormal environmental conditions.

• Consumable parts including batteries and lamps.
