Ikegami HC-D57 User manual

HC-D57 IT CCD Chip, 4:3 fixed aspect ratio.
HC-D57W AIT CCD Chip, 4:3 / 16:9 switchable aspect ratio.
The two models are available:
Ikegami portable cameras have entered upon a new stage in broadcast technology. Ikegami has introduced a new
digital processing camera, the HC-D57 / HC-D57W, which employs a new 12-bit digital processing IC. Compatible
with the TA/BS-45 triax system, the HC-D57 / HC-D57W maintains flexibility for studio and field productions.
This professional camera offers both broadcast grade picture quality and studio system expansion.
General

Digital processing
New Digital Processing ICs (ASIC) with 12 bit A/D
conversion is employed (internally up to 30bit
conversion). All the process after pre-knee is digitized,
providing stable and hi-quality pictures. Processes such
as Gamma and DTL signals are performed digitally with
up to 30-bit internal quantization, achieving superb
picture quality with good S/N in actual operation.
AIT Lower Smear-CCD (HC-D57W)
The HC-D57 employs high-performance 2/3" IT CCD with 410,000 pixels(NTSC) / 470,000 pixels(PAL). The
HC-D57W employs 2/3" AIT CCDs with 520,000 pixels(NTSC) / 600,000 pixels(PAL). The AIT CCD sensor
has less smear characteristics. It guarantees closer performance to FIT chip.
F11 Sensitivity
The sensitivity of F11 at 2000lux is realized. A greater depth-of-field facilitates simple focusing. Also vivid
images can be acquired even when the camera is used under low light condition.
Normal Black Stretch On (7%)
DTL function
Various DTL functions are incorporated such as Diagonal DTL, Soft DTL and Skin DTL.
Back-Light Compensation
The back light compensation function is incorporated in Auto-Iris mode. It guarantees proper operation of
the iris even in case of high contrast situation.
Black Stretch
The Black Stretch function improves the luminance reproduction shadow areas of the scene by raising the
video level only for low-brightness portion. The stretch level is variable in 3%, 5% and 7%
Features
Digital-Specific Versatile Videography

VF
Charactor
Button
Menu Switch
Menu Switch
More Flexibility For High Image Quality
+36dB Gain up
36dB of gain allows for minimum illumination of 0.5 lux at F1.4. Because enhanced sensitivity is achived
electronically, loss of the resolution is minimized.
Supports Various Video Output Signals
The HC-D57/D57W can output composite video, Y/C, component, and RGB signals.
Memory Card (HC-D57W)
The HC-D57W incorporates memory card slot so that
camera operating status can be stored into Smart
Media memory card. Thus, camera setup, color
matching and identical DTL setting for several cameras
have been greatly simplified.
Shutter function
In addition to six preset shutters (1/100, 1/120, 1/250,
1/500, 1/1000, 1/2000), The camera incorporates
variable shutter function that can be set from 1/60.3 to
1/201 sec (NTSC) or 1/50.3 to1/200 sec (PAL) variably.
Menu Switch
Shutter speed and Super-V can be set with a menu switch
located on the switch panel. Various camera settings can be
made on screen in a menu-driven manner, thereby
substantially improving ease of operation.
VF character button
By pressing VF character button on the right side of HC-D57
/ HC-D57W, various camera conditions are displayed by
character display in viewfinder instantly. The VF character
button and Menu rotary encoder facilities navigation of the
camera menu for setting various camera.
Initialize SW
Selection of INITIALIZE in MENU mode sets the camera to the at the factory setting (condition when delivered)
Shoulder Pad
A Non-slip material is used for the shoulder pad. Pad position can readily be adjusted to the front and rear
as left and right side.
High-Resolution Viewfinder
The HC-D57/ HC-D57W comes standard with a 1.5-inch high-resolution viewfinder that delivers a horizontal
resolution of 600TV lines. This ensures clarity and consistently high image quality.
Various accessories
Various accessories for HC-series cameras can be used.

Triax Operation
Triax operation can be achieved by connecting the
existing TA/BS/OCP-40. Remote control and high-res
video transmission can be implemented.
And also, a newly developed triax system (TA/BS/OCP-
45) is now available. Moreover, because a 5-inch or 6-
inch VF can be mounted, the HC-D57/D57W can be
configured as a studio camera.
Combination with various dockable VTR
The HC-D57 / HC-D57W can be directly docked with various VTRs such as DVCAM, Betacam SP and DVC
Pro etc.
TA-45
¡Equipped with a pivoting type TRIAX
connector.
¡INCOM facilities.
¡Q-TV output available as an option.
BS-45
¡Compact Size(4U half-rack size) and
lightweight(13.2 lbs)
¡SDI(D1) output and Q-TV(max. 300m with
8.8mm diameter TRIAX cable) available as
options.
¡DC operation available as an option.
Control Panel
¡Three types of control panels available;
(1)OCP-45
¡Joystick operational remote control for HL-
45/45W and BS-45.
¡Various set-up controls available by the
remote function of the camera menu.
(2)RM-45
¡Compact control panel equipped with basic
operating controls.
¡Can be attached to the front of the BS-45.
(3)RCP-50
¡Full control of camera functionality.
¡Can be attached to the front of the BS-45.
Main Features of New Triax System
With Triax Adaptor
(TA-45)
With Betacam SP VCR (BVV-5) With DVCAM VCR (DSR-1)With DVCPRO50 VCR(IR-D90/AJ-D90)
Quest for Further Improvement in Operability

Camera Adaptor
CA-450
Triax Adaptor
TA-45
Base Station
BS-45
Operation Control Panel
OCP-45
Remote Control Box
RCP-50
Remote Control Panel
RM-45
Remote Control Box
RM-11
Camera Control Unit
MA-400
5-inch Viewfinder
VF5045W
1.5-inch Viewfinder
VF15-46
for DVCAM VCR (DSR-1)
for Betacam SP VCR (PVV-3)
VA-39P for DVCPRO VCR
(IR-D90/AJ-D90)
VA-39A
VCR Adaptor Kit
BS-45 (with RCP-50)
BS-45 (with RM-45+RMP-45)
Triax System
Specifications
Accessories
TA-45
MIC Input
Q-TV Out
Incom
Max. Transmission Distance
Power Consumption
Weight
Dimensions
BS-45
Genlock In
Q-TV In
Composite Video Out
Component Video Out
RGB Video Out
SDI Out
Intercom
MIC Output
Power
Power Consumption
Dimensions
Weight
OCP-45
Power Consumption
Dimensions
Weight
1ch (ch-2: option)
1ch BNC 1.0Vp-p 75Ω(Option)
1ch XLR or 110 type
600m (8.8mm diameter TRIAX cable) *Q-TV : 300mm
7W approx.
2.2kg approx. (4.85 lbs)
W110 x H233 x D180mm (4.33 x 9.17 x 7.09 inches)
BNC (loop through) VBS/BB
1ch BNC(loop through) VBS
2ch BNC 1.0Vp-p 75Ω
1ch each 75Ω
1ch each BNC 0.7Vp-p 75Ω
2ch BNC 0.8Vp-p 75Ω(Option)
1ch XLR or 110 type
1ch XLR 3pin
AC or DC12V
95W
W212 x H155 x D291mm (8.35 x 6.10 x 11.46 inches)
6kg approx. (13.23 lbs)
5W approx.
W92.2 x H343 x D107.2mm (3.63 x 13.50 x 4.22 inches)
2kg approx. (4.41 lbs)

HC-D57 HC-D57W
Optical system
Image Sensor
Effective No.
of Pixelspixels
Total No.
of Pixels
Scanning system
Sync system
Lens mount
Optical Filtre
Sensitivity
Horizontal
Resolution
Vertical
Resolution
S/N
Shutter system
Registration
Aspect Ratio
Auto Function
Gain
Input Signals
Output signals
Power
Consumption
Ambient
Temperature
Weight
Measurement
F1.4 RGB Prism
2/3" IT 3-CCD 2/3" AIT CCD
NTSC : 768Hx494V, approx 380,000 NTSC : 948Hx485V, approx 460,000 pixels
PAL : 752Hx582V, approx 440,000 pixels PAL : 936Hx575V, approx 540,000 pixels
NTSC : 811Hx508V, approx 410,000 pixels NTSC : 1020Hx505V, approx 520,000 pixels
PAL : 795Hx596V, approx 470,000 pixels PAL : 1008Hx591V, approx 600,000 pixels
NTSC : 2:1 interlace 525TVL 60 fields/30 frame/sec
PAL : 2:1 interlace 625TVL 50 fields/25 frame/sec
Internal / External (Genlock)
2/3" B4 Bayonet mount
3200K, 5600K+1/16 ND , 5600K, 5600K+1/64 ND
Standard F11 at 2000 lux (3200K)
Minimum 0.5 lux at F1.4 (+36dB)
800TVL or better at center 750TVL or better at center (4:3/16:9)
Standard : 400TVL (NTSC) / 450TVL (PAL)
Super-V mode : 480TVL (NTSC) / 570TVL (PAL)
NTSC : 63dB PAL : 61dB NTSC : 64dB PAL : 62dB
Preset mode : 1/100 ,1/120,1/250,1/500,1/1000,1/2000
Variable mode : NTSC : 1/60.3 to 1/201 sec / PAL : 1/50.3 to 1/200 sec
Less than 0.05% In all Zones
4:3 4:3 /16:9 switchable (from MENU)
Auto White Balance , Auto Black Balance ,Auto Iris,
Auto Shading, Auto Knee
-3,0,6,9,12,18,30,36dB
External Signal : VBS 1.0p-p 75 Ω
BBS 0.45 Vp-p 75 Ω
Return Signal : VBS 1.0 Vp-p 75 Ω
Microphone : -60dB Balanced, Hi impedance
Video signal : 1.0 p-p ,75 Ω
Y/C signal : Y 1.0Vp-p 75 ΩC 0.286Vp-p75 Ω
Component : Y 1.0V p-p 75 Ω
: PB/PR0.525Vp-p 75 Ω(Betacam SP , MII)
RGB : 0.7Vp-p 75 Ω
Audio : -20dBm/-60dBm 600 Ω
DC+11V to +16V approx.15W (w/o VF)
approx. 2.5W (VF15-46)
-10 ºC to +40 ºC
Approx. 2.6 kg (excluding VF , lens ,Mic)
W126xH281xD170 (mm) / W4.96xH11.06xD6.69 (inch)
Specifications
