DL4 DS Link Fujifilm TTL Converter Ikelite
FT1 Hotshoe Kit
Product # 46082
Included in the Box
• DL4 DS Link Fujilm TTL Converter # 46083
• FT1 Fujilm TTL Hotshoe # 46081
Important Notices
»The DL4 DS Link is not compatible with other
manufacturers’ strobes.
»Use of two strobes requires a dual sync cord. Two
strobes cannot be controlled by individual converters
even if the housing is equipped with two bulkheads.
Installation and Use
Installing the FT1 TTL Hotshoe
1.
Depress the tab on the manual hotshoe connector and
gently pull connector ends apart to remove the housing’s
manual hotshoe.
2.
Align TTL hotshoe and bulkhead connector ends and
push together until tab clicks into place.
3.
Push hotshoe forward into camera’s hotshoe mount.
Make sure that the hotshoe is all the way forward to
ensure proper connection.
»The FT1 TTL Hotshoe is only intended for use with
compatible Ikelite brand housings.
Testing the Housing
1.
Assemble the housing without a camera installed.
Ensure that a waterproof bulkhead cap is in place on the
bulkhead.
2.
Submerge the housing in fresh water for several minutes.
3.
Remove the housing from water and dry the outside of
the housing with a clean, lint-free cloth.
4.
Look through the back of the housing for signs that water
has entered the housing. Signs include fogging or water
droplets.
5.
We recommend making at least one dive without a
camera installed to ensure waterproof operation.
Attaching the Converter
1.
Remove connector protectors and bulkhead caps from
each connection.
DL1 DS LINK
MADE
IN USA
2.
Apply a very thin, even layer of lubricant on all threads,
sealing surfaces, and the exposed portion of the plug
o-ring. Do not allow lubricant to get into the pins and
receptacles of the plug or bulkheads.
3.
Align plug and insert into the housing bulkhead. Each
male pin mates with a female receptacle. Failing to line up
the contacts properly before tightening may result in
damage to the converter plug and/or housing bulkhead.
4.
Hand-tighten the retaining ring.
Retaining ring Mode button
LED indicator
BulkheadPlug o-ring
5.
Attach a compatible sync cord to the converter using the
same method. Hold the converter while tightening the
sync cord retaining ring.
6.
Attach a compatible strobe(s) to the sync cord.
Setting Your Camera
Refer to your camera and housing instruction manuals for
recommendations on ash settings for external strobes.
If you are having trouble getting your strobe(s) to re or
expose properly we recommend restoring your camera
to factory default settings and making sure the hotshoe is
pushed all of the way forward.
Shooting with TTL Strobe Exposure
1.
Turn strobe on. When turned on the DL4 DS Link will be
in TTL mode. The LED indicator glows blue in TTL mode.
2.
Set the strobe to TTL.
3.
Exposure compensation may be added or subtracted
through the camera’s menus. Refer to your camera
instruction manual for more information.
»It is only possible to toggle between TTL (blue LED) and
Manual (red LED) when a camera is connected.
»An incorrectly mounted hotshoe may prevent toggling
between TTL and Manual.
Shooting with Manual Strobe Exposure
1.
Push the mode button on the side of the converter. The
LED indicator light will change from blue to red.
2.
Set the strobe to full or a fractional power setting.
3.
Adjust strobe power settings as necessary for each
photo.
4.
To revert to TTL operation push the mode button and set
your strobe to TTL.
Maintenance and Storage
Post-Dive
1.
Submerge the fully assembled system in clean, fresh
water after each use. Press the mode button several
times while submerged.
2.
Remove the system from the rinse tank and ush with
running fresh water.
3.
Dry the system with a clean, lint-free cloth.
4.
Separate the components and lubricate the threads and
o-ring(s) every 2-3 days during continuous use.
Travel and Storage
1.
Separate the converter from the sync cord and housing.
2.
Wipe off the threads of each bulkhead and retaining ring
using a clean, lint-free cloth.
3.
Lightly lubricate all o-rings, threads, and sealing surfaces.
4.
Attach the connector protector and waterproof bulkhead
cap to converter ends.
Limited Warranty
This Ikelite product is warranted against any manufacturing
defects for a period of one (1) year from the original date
of purchase. To obtain warranty service, the product must
be returned to Ikelite postage paid. Ikelite will, at its sole
discretion, repair or replace such products, and will return
to customer postage paid. All other claims of any nature are
not covered. Except as mentioned above, no other warranty
expressed or implied applies to this Ikelite product.
Ikelite Underwater Systems
50 W 33rd St
Indianapolis, IN 46208 USA
(317) 923-4523
[email protected]
