ikross IKBT15 User manual

User’s manual
IKBT15 Bluetooth Speakerphone
Handsfree Car Kit
Brief introduction……………………………………………….…1
1. Bluetooth wireless communication technology………………….…1
2. About IKBT15…………………………………………………...…1
Before use…………………………………………………….…….2
1. Overview………………………………………………………..…..2
2. Installation………………………………………………………..…2
How to use……………………………………………………..…...2
1. Turning on/off the car kit………………………………………..….2
2. Pairing the car kit with a Bluetooth cell phone………………….….3
3. Making a call with the car kit…………………………………….....4
4. Charging other devices……………………………………………...5
5. Re-connecting with a Bluetooth device……………………………..5
6. LED indicator…………………………………………………..…...6
7. Indication tone……………………………………………………....6
Care and maintenance……………………………………….….....6
FAQs…………………………………………………………….…..7
Specifications………………………………………………….........7

Welcome to use this Bluetooth car kit, IKBT15. Please read this user’s
manual carefully before use.
Brief introduction
1. Bluetooth wireless communication technology
Bluetooth is a standard of close range radio-communication technology that
was drawn up by Ericsson, IBM, Intel, Nokia and Toshiba. With Bluetooth
technology, we can achieve the highest transmission rate among cell phones,
computers, printers, PDAs and other devices. The max transmission range of
class II is 10 meters while the max transmission range of class I can reach
up to 100 meters.
2. About IKBT15
IKBT15 is a Bluetooth car kit which adopts echo cancelling technology, so,
it can provide high-level sound quality. It can pair with a Bluetooth cell
phone or PDA supporting HSP and HFP. Its features are as follows:
Answer a call, end a call and reject a call
Redial last number
Voice dial (This function needs to be supported by your cell phone)
Adjust the volume
Call transfer between the car kit and your cell phone
Microphone mute
Remark: Even though the paired device and the car kit support the same
Bluetooth profiles, functions may vary due to specification differences of
the paired devices.
1

Before use
1. Overview
2. Installation
1) Insert the car kit into your car’s cigarette lighter socket;
2) Make the microphone face up towards the driver, and is unobstructed;
3) Make the speaker of the car kit face up towards the driver and there are
not barriers between the driver and the car kit.
How to use
1. Turning on/off the car kit
Function Operation LED
indicator
Indication
tone
Turning on
Press and hold
button for about 3-5
seconds until hearing
indication tone
Blue LED
flashes 3 times
continuously
One tone
2
1 VOL- button
2 VOL+ button
3 Answer a call/redial last number/voice dial/microphone mute/call
transfer
4 Power on/off/pair/reject a call/end a call/cancel calling
5 LED indicator
6 Built-in microphone
7 USB charging output jack

Function Operation LED
indicator
Indication
tone
Turning off
Press and hold
button for about 3-5
seconds until hearing
indication tone
Red LED
flashes 3 times
continuously
One tone
Enter
pairing
mode
Ensure the car kit is
turned off, then press
and hold button
for about 5-7 seconds
until LED flashes red
and blue alternately
LED flashes
red and blue
alternately
Two tones
2. Pairing the car kit with a Bluetooth cell phone
Please make sure your cell phone is Bluetooth-enabled. The pairing steps are
subject to different models of cell phones. Please refer to your cell phone’s
user’s manual for further information. The general pairing steps are as
follows:
1) Keep the car kit and Bluetooth cell phone where they are easily viewable
by no more than 1 meter apart;
2) Ensure the car kit is turned off, otherwise turn off the car kit first (please
refer to “Turning on/off the car kit);
3) Press and hold button for about 5-7 seconds until LED flashes red
and blue alternately, the car kit successfully entered pairing mode;
4) Activate the cell phone’s Bluetooth function and search for Bluetooth
device. After the search is completed, select “IKBT15” from the
Bluetooth device list;
5) According to the indication, enter password or PIN No. : “0000”, and
press “Yes” or “confirm”;
6) After successful pairing, select “IKBT15” from the Bluetooth device list,
and press “connect”. After successful connecting, blue LED is on for 1
second every 30 seconds.
Remarks:
Pairing mode will last 2 minutes. If no devices can be connected after 2
minutes, IKBT15 will exit pairing mode. If you want to repair, please
turn off IKBT15 first and then try re-pairing according to steps 1～6
mentioned above.
3

After successful pairing, IKBT15 and the Bluetooth cell phone will
remember each other, IKBT15 will not need to re-pair with the Bluetooth
cell phone next time unless the pairing information is deleted because of
a new pairing.
IKBT15 can remember 8 paired devices. When the number of paired
devices exceeds 8, the first one will be replaced.
Every time IKBT15 is turned on, it will connect to last connected device
automatically. If you want to pair it with other devices, please turn off the
Bluetooth function of current Bluetooth device paired with IKBT15 first
and then pair IKBT15 with the new device according to steps 1～6
mentioned above.
3. Making a call with the car kit
Function Status of IKBT15 Operation
Cancel calling Calling Short press once
Answer a call Incoming ring Short press once
Reject a call Incoming ring Short press once
End a call During a call Short press once
Volume up During a call Short or long press
VOL+ button
Voume down During a call Short or long press
VOL- button
Microphone mute During a call Short press twice
continuously
Cancel mute During a call
(microphone mute)
Short press twice
continuously
Call transferred to
cell phone
During a call (the car
kit)
Press and hold for
about 2 seconds until
hearing indication tone
Call transferred to
the car kit
During a call（cell
phone）
Press and hold for
about 2 seconds until
hearing indication tone
Redial last
number
Standby mode
(connected to a cell
phone)
Short press twice
continuously
4

Remarks:
Not all cell phones support all functions listed above. Please refer to your
cell phone’s user’s manual for further information.
When pressing the answer button on some cell phones, the call will be
sent to the cell phone. You have to switch the call to the car kit manually
then. Please refer to your cell phone’s user’s manual for further
information.
4. Charging other devices
The car kit has a USB charging output jack (DC5V/500mA), you can charge
your iPhone or iPod through this USB charging output jack.
Connect USB plug of USB cable into the USB jack of the car kit, and then
connect the other end of USB cable into your iPhone or iPod, now it can
charge your iPhone or iPod.
5. Re-connecting with a Bluetooth device
1) Automatic connecting
Every time the car kit is turned on, it will connect to last connected device
automatically.
2) Connecting manually
When the car kit gets disconnect from the Bluetooth device, short press
button once, it will connect to last connected device again.
Remarks:
The car kit only tries to connect to last connected device.
Please enable Bluetooth on your Bluetooth device before trying to
connect.
On some Bluetooth devices, take some Nokia cell phones for example,
you have to allow automatic connecting in the cell phone’s settings.
Please refer to your cell phone’s manual for further information.
5

6. LED indicator
Status of IKBT15 LED indicator
Pairing mode LED flashes red and blue alternately
Standy mode and not
connected to a device
Blue LED flashes once every 2 seconds
Standy mode and connected
to a device
Blue LED is on for 1 second every 30
seconds
Incoming call/calling Blue LED flashes quickly
During a call Blue LED is on
7. Indication tone
Status of IKBT15 LED indicator
Pairing mode Two “DU” tones
During a call (microphone mute) Two “DU” tones every 3 seconds
Care and maintenance
Read the following recommendations before using the car kit. Following
these you will be able to enjoy the product for many years.
Do not expose the car kit to liquid, moisture or humidity to avoid the
product’s internal circuit being affected.
Don’t use abrasive cleaning solvents to clean the car kit.
Do not expose the car kit to extremely high or low temperatures as this
will shorten the life of electronic devices, destroy the battery or distort
certain plastic parts.
Don’t dispose of the car kit in a fire as it will result in an explosion
Don’t expose the car kit to contact with sharp objects as this will cause
scratches and damage.
Don’t let the car kit fall down onto the floor. The internal circuit might
get damaged.
Don’t attempt to disassemble the car kit as it may get damaged if you are
not professional.
In case the car kit doesn’t function properly, send it to the store you bought
it. The staff will help you to solve the problem.
6

FAQs
1. What to do when my cell phone can not find IKBT15?
If IKBT15 is not in paring mode, your cell phone can’t find it. Please make
sure IKBT15 is in pairing mode and in the effective working range.
2. What to do when the voice is not clear?
a) Ensure your cell phone is in strong-signal areas;
b) Make sure IKBT15 is in the effective working range.
3. How far is the effective range between IKBT15 and Bluetooth cell
phone?
According to the Bluetooth standard, the max. controllable range of Class
II car kit is 10 meters. But it varies with different environment and paired
cell phone.
4. There is no sound when making a call with IKBT15, what to do?
a) Ensure IKBT15 connects well with Bluetooth cell phone;
b) Make sure the volume has already been properly adjusted.
Specifications
Bluetooth specification Bluetooth V2.1
Bluetooth profiles HSP and HFP
Operating distance 10 meters Class II
Power supply DC12V & DC24V
Working temperature -10~45℃
Storage temperature -20~60℃
Dimensions 130×70×70mm
Weight 75.9g
Notes:
1. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
7
