ILC Dover S-5000 Series Operator's manual

S-2018
REV. D
SENTINEL XL™ PAPR CBRN SYSTEM
USER INSTRUCTION MANUAL
FOR MODEL NO. S-5000
∆
WARNING
IMPROPER USE OF THIS RESPIRATOR MAY RESULT IN PERSONAL INJURY OR DEATH.
IMPROPER USE INCLUDES, BUT IS NOT LIMITED TO, USE IN ATMOSPHERES
CONTAINING UNKNOWN CONTAMINATES AND/OR UNKNOWN CONCENTRATIONS OF
CONTAMINANTS, USE WITHOUT ADEQUATE TRAINING, DISREGARD TO THE
WARNINGS AND INSTRUCTIONS CONTAINED HEREIN AND FAILURE TO INSPECT AND
MAINTAIN THIS RESPIRATOR.
THE RESPIRATOR IS NOT INTENDED FOR USE IN ATMOSPH
ERES WHERE THE
IDENTITY AND/OR CONCENTRATION OF THE CONTAMINANT IS UNKNOWN. THIS MAY
RESULT IN IMMEDIATE DANGER TO PERSONNEL.
THIS RESPIRATOR DOES NOT SUPPLY OXYGEN AND MUST NOT BE USED IN OXYGEN-
DEFICIENT ENVIRONMENTS CONTAINING LESS THAN 19.5% OXYGEN.

- 1 - S-2018
REV. D
TABLE OF CONTENTS
ITEM PAGE
SAFETY PRECAUTIONS......................................................................................................................... 2
INTRODUCTION ...................................................................................................................................... 3
DESCRIPTION........................................................................................................................................... 4
GENERAL SAFETY INFORMATION..................................................................................................... 8
REPLACEMENT PARTS .......................................................................................................................... 11
PREPARATION FOR USE (USING ADJUSTABLE WAIST BELT
OR DECON AND QUICK RELEASE BELT AND CLIP)..................................................................... 12
PAPR BACKPACK COMPONENT INTEGRATION.............................................................................. 16
PREPARATION FOR USE (USING BACKPACK ASSEMBLY)........................................................... 18
HEAD HARNESS SIZING INSTRUCTIONS .......................................................................................... 22
HEAD HARNESS REPLACEMENT INSTRUCTIONS .......................................................................... 23
DECONTAMINATION PROCEDURES .................................................................................................. 26
REMOVING THE PAPR SYSTEM .......................................................................................................... 26
DISPOSAL OF CARTRIDGES ................................................................................................................. 26
GENERAL CLEANING ............................................................................................................................ 27
INSPECTION ............................................................................................................................................. 27
CHANGING BATTERY PACK ................................................................................................................ 29
INSTALLING THE ALKALINE BATTERY ADAPTOR ...................................................................... 30
REMOVING THE ALKALINE BATTERY ADAPTOR.......................................................................... 33
STORAGE .................................................................................................................................................. 35
TROUBLESHOOTING.............................................................................................................................. 35
CUSTOMER SERVICE INFORMATION ................................................................................................ 36
∆WARNING
TRAINING IS REQUIRED BEFORE USE OF THIS RESPIRATOR. FOL
LOW THESE
INSTRUCTIONS CAREFULLY. THIS POWERED AIR PURIFYING DEVICE IS ONLY FOR
USE IN SPECIFIC ATMOSPHERES AND UNDER CERTAIN CONDITIONS. USE OF THIS
RESPIRATOR WITHOUT PROPER TRAINING COULD RESULT IN SERIOUS INJURY OR
DEATH.
This product is designed for use in an emergency situation. You may not have time to read and under-
stand all of the instructions and warnings in that situation. Please take the time to learn about your
Sentinel XL™ PAPR CBRN now and refresh your knowledge every 30 days.

- 2 - S-2018
REV. D
SAFETY PRECAUTIONS
The Danger, Warnings, Cautions, and Notes contained in this instruction manual have the following
significance.
∆
DANGER
Danger
indicates an imminently hazardous situation, which if not avoided, will result in serious
personal injury, serious illness or death.
∆WARNING
Warning indicates a potentially hazardous situation, which if not avoided, could result in serious
personal injury, serious illness or death.
CAUTIONS
Caution indicates a potentially hazardous situation, which if not avoided, may result in damage to
equipment and/or minor to moderate personal injury.
Note
Operating procedures and techniques or information considered important to emphasize.
∆
WARNING
DO NOT USE the Sentinel XL™ PAPR CBRN until you have read and completely understand this
instruction manual. You are required to inspect the packaging of this system
immediately after
purchasing it. Refer to the inspection procedures in this manual which explain how to do so.
Failure to comply with this WARNING could
lead to serious personal injury, serious illness or
death.
Note
The Sentinel XL™ PAPR CBRN system
has been tested against live chemical warfare agents, agent
stimulants, and industrial chemicals under controlled laboratory conditions. Protection time (time before
breakthrough and loss of adequate protection) may decrease, depending
upon agent type, agent
concentration, breakthrough criteria, temperature and humidity. The protection time provided by the
Sentinel XL™ PAPR CBRN in an actual emergency will depend on the aforementioned variables. The
wearer should immediately evacuate the contaminated area if the low voltage alarm sounds, if the blower
fails, or if other anomalies occur. The Sentinel XL™ PAPR CBRN is designed to operate per NIOSH
Statement of Standard for a Chemical, Biological, Radiological, and Nuclear (CBRN) Powered Air-
Purifying Respirator.

- 3 - S-2018
REV. D
INTRODUCTION
This manual provides instructions for the proper use and care of the Sentinel XL™ PAPR CBRN. Before
attempting to use the Sentinel XL™ PAPR CBRN in an emergency you must read, understand, and be able to
follow all instructions as specified in this Sentinel XL™ PAPR CBRN Instruction Manual.
A NIOSH approval label is included as part of this manual.
∆
WARNING
DO NOT USE the Sentinel XL™ PAPR CBRN until you are fully acquainted with its proper use. In
order to safely use the Sentinel XL™ PAPR CBRN, you MUST comply with ALL of the following
requirements:
1. Read, understand, and follow all warnings and instructions as specified in this Sentinel XL™
PAPR CBRN User Instruction Manual.
2. Review the instructions and warnings contained within this manual at least once every 30 days
to ensure you understand how to use this device.
3. The wearer should evacuate the contaminated area as quickly as possible and should under no
circumstances reenter the contaminated area i
f the low voltage alarm sounds, if the blower
fails, or if other anomalies occur.
4. Failure to comply with this warning may lead to serious personal injury, serious il
lness, or
death.
∆
WARNING
You must be fully familiar with the operation of Sentinel XL™ PAPR CBRN described within this
manual prior to an emergency. Emergency situations can be stressful. To ensure that you obtain
the maximum protection available from the Sentinel XL™ PAPR CBRN
, you must read and
understand these instructions before the emergency happens.
SPECIAL AND CRITICAL CAUTIONS AND LIMITATIONS
1. Do not use if blower is non-operational.
2. Remove the respirator immediately if the blower stops.
3. This respirator will protect against the inhalation of certain respiratory hazards.
4. Not for use in atmospheres containing less than 19.5 percent oxygen.
5. Failure to properly use and maintain this product could result in serious personal injury,
serious illness, or death.
6. All approved respirators shall be selected, fitted, u
sed, and maintained in accordance with
MSHA, OSHA, and other applicable regulations.
7. Refer to User’s Instructions and/or maintenance manual for information on use and
maintenance of this respirator.
8. Consult manufacturer’s User Instructions for information on the use, storage and maintenance
of this respirator at various temperatures.

- 4 - S-2018
REV. D
9. This respirator provides respiratory protection against inhalation of certain g
as and vapor
chemical agents, biological particulates, and radiological and nuclear dust
particles. This
respirator provides limited dermal (skin) protection to the head area and eyes. This respirator
does not protect against radioactive x-rays, gamma rays, or neutrons.
10. Eye irritation may be experienced based upon the Chemical, Biologica
l, Radiological and
Nuclear (“CBRN”) agent and exposure (concentration and duration).
11. Some CBRN agents may not present immediate effects from exposure, but can result in delayed
impairment, serious illness, serious injury, or death.
12. CBRN agents, depending on how they are used, may provide disabling effects as a result of skin
exposure.
13. Direct contact with CBRN agents requires proper handling of the respirator after use. Correct
decontamination and/or disposal procedures must be followed.
14. DO NOT USE for applications other than CBRN incidents.
15. DO NOT USE for gamma rays, x-rays and neutrons.
16. DO NOT USE for hazardous projectiles.
17. DO NOT USE for protection against or contact with liquid droplets of chemical warfare agents.
18. A written respiratory protection program must be implemented meeting all the requirements of
OSHA 29 CFR 1910.134. In Canada, the Z94.4 requirements must be met. Annual training on
how to store, care for, and use this product and your emergency escape plan is required.
DESCRIPTION
The ILC Dover SENTINEL XL™ PAPR CBRN is a blower-assisted air-purifying respirator known as a
Powered Air Purifying Respirator or PAPR. The SENTINEL XL™ PAPR CBRN is comprised of the
following components:
1. Butyl Hood, one size fit all P/N S-2001
The hood is equipped with a large area visor, allowing for an undisturbed field of vision, an adjustable
head harness that fits all head sizes, a double skirt, and an integrated breathing hose that connects the hood
to the blower unit. The Butyl Hood Assembly is packed and stored in a flat configuration to save storage
space. Adjusting the head harness to the wearer’s head circumference creates the three dimensional
structure.
2. Blower P/N S-2002
The blower is comprised of an electrical motor that drives an air blower. An on/off switch is located on
top of the blower. A red LED near the on/off switch at the top indicates when the blower is on. There is
one male thread at the blower top to connect the breathing hose. There are three female threaded inlets
with rubber gaskets at the blower sides and bottom to connect three Cartridges. The blower is equipped
with a self-test mechanism. Upon starting the blower, the red LED will blink once or twice, a buzzer will
sound one or two short beeps, followed by continuous LED light and no sound. This indicates that the
blower is functioning correctly. The blower is equipped with an audio-visual low voltage alarm,
indicating that battery voltage is decreasing. The alarm is given by the blinking LED and successive
buzzer beeps. The sound from the alarm is easily heard within the hood. Once the low voltage alarm has
sounded, the user must exit the contaminated area.

- 5 - S-2018
REV. D
3. Battery Pack
The battery pack is integrated to the blower assembly by a snap fastener at the blower assembly’s aft side,
which faces the user’s body. There are three types of battery packs:
A. Rechargeable NiMH Battery Pack P/N S-2003
The NiMH Battery can be used up to 500 charge/discharge cycles and does not have a considerable
memory effect. The battery is equipped with a charging jack at its aft side. Charging the battery can
be done without dissembling it from waist belt, backpack, or the blower assembly.
B. Non Rechargeable LiMnO2 Battery Pack P/N S-2004
High capacity Lithium Battery, capable of extended shelf life.
C. Alkaline Battery Adaptor P/N S-4013 (Optional)
Batteries are not included. Adaptor is capable of running approximately 8 hours. Five D-cell
Duracell batteries need to be purchased to operate the Sentinel XL blower. Batteries have a long
term shelf life and are easily accessible.
4. Cartridge P/N S-2016
ILC Dover SENTINEL XL™ PAPR CBRN utilizes three NIOSH approved CBRN Cartridges that have
been tested and approved to filter certain CBRN agents.
5. Adjustable Waist Belt P/N S-2007
Supports the blower assembly on the user’s waist and is adjustable.
6. Decon and Quick Release Belt and Clip P/N S-4011 (Optional)
This blower mounting option allows for quick and easy attachment or removal of the blower from the belt
and also facilitates the cleaning/disinfecting of biological materials from the belt with standard cleaning or
disinfecting materials. Note: Do not use autoclave or other high temperature sterilization methods.
7. Backpack Assembly P/N S-2008
An optional backpack provides comfortable support of the blower assembly on the user’s back and waist.
The Backpack can also be used to store the hood and other Sentinel XL components.
8. Fast Battery Charger P/N S-2009
A smart charger that recharges the NiMH Battery Pack within approximately 5 hours.
9. Flow Meter Assembly P/N S-2010
Used to check the ability of the blower to provide sufficient air flow to the Butyl Hood. The air flow must
be checked before each use.
∆WARNING
FOLLOW THESE INSTRUCTIONS CAREFULLY. THIS POWERED AIR PURIFYING DEVICE
IS ONLY FOR USE IN SPECIFIC ATMOSPHERES AND UNDER CERTAIN CONDITIONS.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY COULD RESULT IN SERIOUS
INJURY OR DEATH.

- 6 - S-2018
REV. D
ILC DOVER SENTINEL XL™ PAPR CBRN SYSTEM
(WITH ADJUSTABLE WAIST BELT)
OR DECON AND QUICK RELEASE BELT AND CLIP
Alkaline
Battery
Adaptor
Decon and Quick Release
Belt and Clip
Not to Scale

- 7 - S-2018
REV. D
ILC DOVER SENTINEL XL™ PAPR CBRN SYSTEM
(WITH BACKPACK AND ADJUSTABLE WAIST BELT)
Decon and
Quick Release
Belt and Clip
OR
Alkaline
Battery
Adaptor

- 8 - S-2018
REV. D
GENERAL SAFETY INFORMATION
Intended Use:
The ILC Dover SENTINEL XL™ PAPR CBRN blower can be mounted to the Adjustable waist belt, Decon
and Quick Release Belt and Clip, or optional backpack, and is connected to the hood assembly via an integrated
flexible breathing tube. The ILC Dover SENTINEL XL™ PAPR CBRN must be used with the S-2016
CBRN Cartridge.The ILC Dover SENTINEL XL™ PAPR CBRN systems are intended to provide
respiratory protection against inhalation of certain gas and vapor chemical agents, biological particulates, and
radiological and nuclear dust particles. This respirator provides limited dermal (skin) protection to the head area
and eyes. This respirator does not protect against radioactive x-rays, gamma rays, or neutrons.
Note: Inspect emergency use respirators on a monthly basis.
∆WARNING
THESE RESPIRATORS HELP PROTECT AGAINST CERTAIN AIRBORNE CONTAMINANTS.
MISUSE MAY RESULT IN INJURY OR DEATH. FOR PROPER USE, SEE SUPERVISOR, USER
INSTRUCTIONS, OR CALL ILC DOVER TECHNICAL SERVICE AT 1-800-631-9567. USE ONLY
ILC DOVER PARTS AND ACCESSORIES FOR THE ILC SENTINEL XL™ PAPR CBRN SYSTEM
AS DESCRIBED IN THESE USER INSTRUCTIONS.
ALWAYS DON THE RESPIRATOR SYSTEM PROPERLY AND IN AN UNCONTAMINATED
AREA.
DO NOT REACH YOUR HAND INTO THE FACE PIECE IN AREAS WHERE T
HE AIR IS
CONTAMINATED. LEAVE THE CONTAMINATED AREA AND CLEAN CONTAMINANTS
FROM YOUR HANDS BEFORE REACHING INSIDE THE HOOD.
IF YOU DISCOVER ANY OF THE WEAR AND DAMAGE DESCRIBED IN THE
TROUBLESHOOTING SECTION OF THIS USER INSTRUCTION, DISCARD COMPONENT AND
REPLACE IT WITH A NEW ONE. FAILURE TO DO SO MAY ADVERSELY AFFECT
RESPIRATOR PERFORMANCE AND RESULT IN SICKNESS OR DEATH.
BEFORE USE, THE WEARER MUST READ AND FULLY UNDERSTAND THESE USER
INSTRUCTIONS. KEEP THIS INSERT FOR FUTURE REFERENCE. IF YOU HAVE ANY
DOUBTS ABOUT THE APPLICABILITY OF THESE RESPIRATOR SYSTEMS TO YOUR JOB
SITUATION, CONSULT AN INDUSTRIAL HYGIENIST OR CALL THE ILC DOVER TECHNICAL
SERVICE LINE.
Use the ILC Dover SENTINEL XL™ PAPR CBRN for:
The ILC Dover SENTINEL XL™ PAPR CBRN systems are intended to provide respiratory protection against
inhalation of certain gas and vapor chemical agents, biological particulates, and radiological and nuclear dust
particles. This respirator provides limited dermal (skin) protection to the head area and eyes. This respirator
does not protect against radioactive x-rays, gamma rays, or neutrons.
Never use the ILC Dover SENTINEL XL™ PAPR CBRN for:
Atmospheres where oxygen concentration is below 19.5%, where concentrations of contaminants are:
unknown; immediately dangerous to life or health (IDLH); exceed applicable local standards or OSHA
standards for maximum use concentrations for the respirator, whichever is lower. Refer to additional
limitations and cautions under NIOSH Cautions and Limitations.

- 9 - S-2018
REV. D
RESPIRATOR SELECTION AND TRAINING
∆WARNING
THIS RESPIRATOR IS INTENDED TO BE USED ONLY IN CONJUNCTION WITH AN
ORGANIZED RESPIRATORY PROTECTION PROGRAM WHICH COMPLIES WITH THE
REQUIREMENTS OF “PRACTICES FOR RESPIRATORY PROTECTION” Z88.2-1992
AVAILABLE FROM
AMERICAN NATIONAL STANDARDS INSTITUTE, 11 WEST 42ND
STREET, NEW YORK, NY 10036, OR WITH THE REQUIREMENTS OF OSHA STANDARD 29
CFR 1910.134 AVAILABLE FROM THE US DEPARTMENT OF LABOR, OCCUPATIONAL
SAFETY AND HEALTH ADMINISTRATION, OR WITH OTHER PERTINENT NATIONAL
RECOGNIZED STANDARDS.
BEFORE USE, THE EMPLOYER MUST ASSURE THAT EACH RESPIRATOR USER HAS BEEN
TRAINED BY A QUALIFIED PERSON IN THE PROPER USE AND MAINTENANCE OF THE
RESPIRATOR ACCORDING TO THE INSTRU
CTIONS CONTAINED IN THIS USER
INSTRUCTION AND OTHER APPLICABLE USER INSTRUCTIONS.
∆WARNING
BEFORE USING THE ILC DOVER SENTINEL XL™ PAPR CBRN SYSTEMS, EACH PERSON
MUST READ AND UNDERSTAND THE INFORMATION IN THIS USER INSTRUCTION. USE
OF THE RESPIRATOR SYSTEMS BY UNTRAINED OR UNQUALIFIED PERSONS, OR USE
THAT IS NOT IN ACCORDANCE WITH THESE INSTRUCTIONS, MAY ADVERSELY AFFECT
RESPIRATOR PERFORMANCE AND MAY RESULT IN INJURY OR DEATH.
SERVICE LIFE OF CHEMICAL CARTRIDGE
The useful service life of chemical Cartridge will depend upon the flow rate, the specific type, volatility and
concentration of the contaminants and environmental conditions such as humidity and temperature. Replace
Cartridge in accordance with an established Cartridge change schedule. Cartridge should be changed earlier
than scheduled if smell, taste or irritation from the contaminant is detected. Cartridges must be replaced if they
become damaged, soiled, or if increased breathing resistance occurs.
EYE, FACE AND HEAD PROTECTION
∆
WARNING
THESE HOODS DO NOT PROVIDE EYE, FACE, OR HEAD PROTECTION WHEN EXPOSED TO
EYE, FACE, OR HEAD HAZARDS. THE RESPIRATOR WEARER MUST WEAR EYE, FACE,
AND/OR HEAD PROTECTION APPROPRIATE TO THE HAZARD. FAILURE TO DO SO MAY
RESULT IN INJURY OR DEATH.

- 10 - S-2018
REV. D
NIOSH APPROVAL
For a listing of the components in the ILC Dover respirator systems (ILC Dover SENTINEL XL™ PAPR
CBRN)that are NIOSH approved, refer to the NIOSH-approved label insert.
NIOSH CAUTIONS AND LIMITATIONS
A. Not for use in atmospheres containing less than 19.5 percent oxygen.
B. Not for use in atmospheres immediately dangerous to life or health.
C. Do not exceed maximum use concentrations established by regulatory standards.
F. Do not use this respirator if airflow is less than four cfm (115 lpm) for tight-fitting facepieces or six cfm
(170 lpm) for hoods and/or helmets
H. Follow established cartridge and canister change schedules or observe ESLI to ensure that cartridges and
canisters are replaced before breakthrough occurs.
I. Contains electrical parts that may cause an ignition in flammable or explosive atmospheres.
J. Failure to properly use and maintain this product could result in death or serious injury.
L. Follow the manufacturer's instructions for changing cartridges and/or filters.
M. All approved respirators shall be selected, fitted, used, and maintained in accordance with MSHA, OSHA,
and other applicable regulations.
N. Never substitute, modify, add, or omit parts. Use only exact replacement parts in the configuration as
specified by the manufacturer.
O. Refer to users instructions. And/or maintenance manuals for information on use and maintenance of these
respirators.
R. Some CBRN agents may not present immediate effects from exposure, but can result in delayed
impairment, illness, or death.
S. Special or critical User's Instructions and/or specific use limitations apply. Refer to User's Instructions
before donning.
Y. The respirator provides respiratory protection against inhalation of radiological and nuclear dust particles.
Procedures for monitoring radiation exposure and full radiation protection must be followed
GG. Direct contact with CBRN agents requires proper handling of the respirator after use. Correct disposal
procedures must be followed.
QQ. Use in conjunction with personal protective ensembles that provide appropriate levels of protection against
dermal hazard. Failure to do so may result in personal injury even when the respirator is properly fitted,
used, and maintained.
UU. The respirator should not be used beyond eight (8) hours after initial exposure to chemical warfare agents
to avoid possibility of agent permeation. If liquid exposure is encountered, the respirator should not be
used for more than two (2) hours.
VV. PAPRS with TC-23C approvals may NOT be used for escape from IDLH atmospheres.

- 11 - S-2018
REV. D
REPLACEMENT PARTS
Part No. Component
Cartridge
S-2016 CBRN Toxic Chemical Cartridge (with Instructions)
Battery Packs and Charger
S-2003 Rechargeable NiMH Battery Pack Assembly
S-2004 Non Rechargeable LiMnO2 Battery Pack Assembly
S-4013 (Optional) Alkaline Battery Adaptor (Batteries NOT included)
S-2009
Fast Battery Charger (with Instructions)
Blower
S-2002
Standard Blower Assembly
Hood
S-2001 Butyl Hood Assembly
Waist Belt
S-2007 Adjustable Waist Belt
S-4011 (Optional) Decon and Quick Release Belt and Clip
Backpack
S-2008 Backpack
Accessories
S-2010 Flow Meter
S-2018 Instruction Manual
S-2023 Antimicrobial Head Harness

- 12 - S-2018
REV. D
PREPARATION FOR USE (USING ADJUSTABLE WAIST BELT OR DECON BELT)
1. Open the package/box and take out the components:
• Blower S-2002
•Battery S-2003 Rechargeable NiMH Battery Pack Assembly or S-2004 Non Rechargeable LiMnO2
Battery pack Assembly
•Alkaline Battery Adaptor S-4013 (Optional) Batteries NOT included
• Battery Charger (with Instructions) S-2009
• Cartridge x 3 (with Instructions) S-2016
• Flow Meter S-2010
• Adjustable Waist Belt S-2007 or Decon and Quick Release Belt and Clip S-4011 (Optional)
• PAPR Hood S-2001
2. Remove the Blower from its box.
3. If using a rechargeable battery, remove the Battery Charger from
its box. To charge the PAPR:
• Make sure that the battery pack is assembled to the blower unit at
all times. The battery pack should be separated from the blower
only for battery pack replacement.
• Plug the battery charger to the socket at the back of the PAPR.
• Connect the battery charger to an electrical outlet. If charger is
connected to an electrical outlet before connecting to a battery, a
solid green LED light indicates that the charger is operating
properly. When plugged into the battery the charger
LED will turn solid red after a short time, indicating
that charging is underway.
• Charge the battery for approximately 5 hours.
• The charger’s LED will change from solid red to
flashing green when charging is complete. The
charger will then be in a “trickle charge” mode. If the
light goes to continuous green the battery will cool
down automatically and then will go to red and
continue charging.
• Charging is also possible when the blower is attached
to the waist belt or decon belt, as demonstrated.
4. If you are using the Non-Rechargeable Battery or Alkaline Battery
Adaptor continue onto Step 5. If there is no battery installed into the
blower refer to pages 29 and 30 respectively for battery installation
instructions.
5. Fit the Waist belt length to your waist size when dressed in your
protective garments.

- 13 - S-2018
REV. D
6. Position the Blower on the Waist Belt pad.
•The charging socket should be accessible through the pad.
Attach the blower to the waist belt by passing the 4 straps
through the blower’s loops and snapping them to the back of the
waist belt pad.
•For the S-4011 Decon and Quick Release Belt and Clip, follow
same steps as on page 11, then align the quick don snap features
as shown below and press belt clip firmly into place. The hole
in the clip should align with battery recharging port.
∆
WARNING
USE OF THESE RESPIRATOR SYSTEMS BY UNTRAINED OR UNQUALIFIED PERSONS OR
USE NOT IN
ACCORDANCE WITH THESE INSTRUCTIONS MAY ADVERSELY AFFECT
RESPIRATOR PERFORMANCE AND RESULT IN INJURY OR DEATH.
USE OF THESE RESPIRATOR SYSTEMS MUST BE IN ACCORDANCE WITH APPLICABLE
SAFETY AND HEALTH STAND
ARDS, RESPIRATOR SELECTION TABLES CONTAINED IN
SUCH PUBLICATIONS AS ANSI Z88.2-
1992, OR PURSUANT TO THE RECOMMENDATIONS
OF AN INDUSTRIAL HYGIENIST. USE OF A RESPIRATOR REQUIRES THAT A WRITTEN
RESPIRATOR PROGRAM BE IN PLACE, WHICH IS IN ACCORDANCE WITH THE OSHA
RESPIRATORY PROTECTION STANDARD FOUND IN 29 CF
R 1910.134 PRIOR TO USING ANY
RESPIRATOR SYSTEM.
BEFORE USE, THE USER MUST BE TRAINED BY THE EMPLOYER IN THE PROPER USE
AND MAINTENANCE OF THE ILC DOVER SENTINEL XL™ PAPR CBRN
SYSTEM. SUCH
TRAINING MUST BE IN ACCORDANCE WITH THIS USER INSTRUCTION. EACH PERSON
USING THESE RESPIRATOR SYSTEMS MUST FIRST READ AND UNDERSTAND THIS
ENTIRE USER INSTRUCTION. FAILURE TO DO SO MAY ADVERSELY AFFECT
RESPIRATOR SYSTEM PERFORMANCE AND RESULT IN INJURY OR DEATH.
IF THESE RESPIRATOR SYSTEMS FAIL ANY OF THE REQUIREMENTS O
F THE USER
INSPECTION AND PERFORMANCE CHECK, DO NOT USE THE RESPIRATOR SYSTEM
UNTIL ALL NECESSARY REPAIRS HAVE BEEN PERFORMED AND THE RESPIRATOR
SYSTEMS PASS THE PERFORMANCE CHECKS. FAILURE TO DO SO MAY ADVERSELY
AFFECT RESPIRATOR SYSTEM PERFORMANCE AND RESULT IN INJURY OR DEATH.

- 14 - S-2018
REV. D
7. Cartridge Installation.
Verify that the Cartridges are the appropriate type for the application by
examining the label attached to the cartridge.
• Before removing the Cartridges, verify that the foil package is
vacuum sealed and inspect the foil bag for any damage. Do not use
the Cartridges if the foil bag has been damaged. If the foil bag has no
damage and the vacuum was maintained, remove the Cartridges from
their packaging. Confirm that the Cartridges do not exceed the “use-
by” date and that the connecting thread is not damaged.
• Confirm that the threads in the three Cartridge threaded inlets are in good
condition and clear of foreign matter.
• Verify that each Cartridge threaded inlet has a black rubber gasket present
that is properly seated without twists, raised areas, or surface defects that
may prevent proper sealing of the Cartridge.
• Remove all plugs from the Cartridge openings before using the system.
Retain the plugs for future use.
• Screw the Cartridge into the threads until they are hand tight.
∆
WARNING
DO NOT OVER TIGHTEN CARTRIDGE. OVER TIGHTENING MAY RESULT IN DISTORTION
OR DISPLACEMENT OF THE SEAL AND
ALLOW CONTAMINATED AIR TO ENTER THE
RESPIRATOR HEADPIECE RESULTING IN INJURY OR DEATH.
8. Check the airflow with the Flow Meter.
• Ensure that the Cartridges are installed on the blower. The
blower can be installed on the waist belt.
• Switch the blower ON. A short beep should sound.
• Place the flow meter in the blower’s hood connector, applying
light pressure to allow for a seal between the flow meter and the
blower. Keep the flow meter vertical. Assure that nothing is
restricting air flow into the cartridges.
• The position of the upper (flat surface) black cone in the flow
meter should be above the indication line. If any part of the
upper (flat surface) of the black cone is below the line on the
flow meter, check for:
oBlower malfunction.
oImproperly installed, clogged, or damaged Cartridge(s).
oLow battery charge or battery malfunction.
oImproperly seated filter gasket(s).
• If the upper portion of the black cone is above the indication line on the
flow meter, the system is ready for use.

- 15 - S-2018
REV. D
∆WARNING
BEFORE ENTERING A HAZARDOUS ATMOSPHERE WEARING THIS RESPIRATOR SYSTEM,
THE RESPIRATOR SYSTEM MUST BE INSPECTED. COMPLETE AN AIRFLOW CHECK, AND
DON THE SYSTEM ACCORDING TO THE INSTRUCTIONS IN THIS MANUAL. FAILURE TO
DO SO MAY NOT
ADVERSELY AFFECT RESPIRATOR PERFORMANCE AND MAY RESULT
IN INJURY OR DEATH.
DO NOT WEAR THIS RESPIRATOR SYSTEM
TO ENTER AREAS WHERE ATMOSPHERIC
CONCENTRATIONS OF CONTAMINANTS ARE UNKNOWN. THE AREA MAY NOT EXCEED
THE MAXIMUM USE CONCENTRATION (MUC) FOR THE RESPIRATOR HEAD PIECE, OR
ATMOSPHERE MAY NOT CONTAIN LESS
THAN 19.5% OXYGEN. THIS MAY RESULT IN
IMMEDIATE DANGER TO PERSONNEL.
9. Connect the Hood’s Breathing Tube to the Blower.
• Check that the breathing tube thread has the black rubber gasket seal
present.
• Check that the thread in the blower unit is in good condition and clear
of foreign matter.
• Screw the end of the breathing tube into the blower unit until it is hand
tight. Ensure that there is not excessive twist on the hose. If so,
loosen the breathing tube fitting where it attaches to the blower, rotate
the hose to eliminate the twist, and retighten the fitting.
Do not over-tighten!

- 16 - S-2018
REV. D
PAPR BACKPACK COMPONENT INTEGRATION
The Sentinel XLTM PAPR CBRN system is shipped with components pre-installed in the backpack. Use the
following instructions for general storage or addition of replacement components in the backpack.
1. Open the package/boxes and take out the components:
• Blower S-2002 (installed in backpack)
•Battery S-2003 Rechargeable NiMH Battery Pack Assembly or S-2004 Non Rechargeable LiMnO2
Battery pack Assembly (installed in blower)
•Alkaline Battery Adaptor S-4013 (Optional) Batteries NOT included
• Battery charger (with Instructions) S-2009
• Cartridge x 3 (with Instructions) S-2016
• Flow Meter S-2010
• Backpack S-2007
• PAPR Hood S-2001
2. Insert the hood, wrapped in its plastic bag, into the backpack hood
compartment, and close the hood compartment using the zippers.
3. Open the blower compartment cover, roll it upwards, and
fasten the straps with the buckles, exposing the backpack
pad, and the three net Cartridge receptacles.
4. Position the blower on the backpack pad – the charging socket is
accessible through the pad. Attach the blower to the backpack, by
passing the 4 straps through the blower’s loops and snapping them
to the back of the backpack pad.

- 17 - S-2018
REV. D
5. Insert the foil wrapped Cartridges into the
three net receptacles on the backpack.
6. Undo the strap buckles and unfold the blower compartment cover.
7. Close the blower compartment using the zipper (see
picture below).The backpack is now in stand-by storage
configuration.
Blower
compartment
zipper

- 18 - S-2018
REV. D
PREPARATION FOR USE (USING BACKPACK ASSEMBLY)
1. Open the blower compartment using the zipper (see picture to the right).
2. If using a rechargeable battery pack, remove the battery
charger from the backpack. To charge the PAPR:
• Make sure that the battery pack is assembled to the blower unit
at all times. The battery pack should be separated from the
blower only for battery pack replacement.
• Plug the battery charger to the socket at the back of the PAPR.
• Connect the battery charger to an electrical outlet. A solid green
LED light indicates that the charger is operating properly. When
plugged into the battery the charger LED will turn solid red after
a short time, indicating that charging is underway.
• Charge the battery for approximately 5
hours.
• While the battery is charging, the red LED
on the battery charger will be continuous.
• The charger LED may flash green when
charging is complete. The charger will then
be in a “trickle charge” mode.
Occasionally, the charger may indicate a
solid green light following a full charge
cycle, which is also considered normal.
• Charging is also possible when the blower
is attached to the backpack, as
demonstrated.
Blower
compartment
zipper

- 19 - S-2018
REV. D
∆WARNING
USE OF THESE RESPIRATOR
SYSTEMS BY UNTRAINED OR UNQUALIFIED PERSONS, OR
USE NOT IN ACCORDANCE WITH THESE INSTRUCTIONS MAY ADVERSELY AFFECT
RESPIRATOR PERFORMANCE AND RESULT IN INJURY OR DEATH.
USE OF THESE RESPIRATOR SYSTEMS MU
ST BE IN ACCORDANCE WITH APPLICABLE
SAFETY AND HEALT
H STANDARDS, RESPIRATOR SELECTION TABLES CONTAINED IN
SUCH PUBLICATIONS AS ANSI Z88.2-
1992, OR PURSUANT TO THE RECOMMENDATIONS
OF AN INDUSTRIAL HYGIENIST. USE OF A RESPIRATOR REQUIRES THAT A WRITTEN
RESPIRATOR PROGRAM BE IN PLACE, WHICH IS IN ACCORDANCE WI
TH THE OSHA
RESPIRATORY PROTECTION STANDARD FOUND IN 29 CFR 1910.134 PRIOR TO USING
ANY RESPIRATOR SYSTEM.
BEFORE USE, THE USER MUST BE TRAINED BY THE EMPLOYER IN THE PROPER USE
AND MAINTENANCE OF THE ILC DOVER SENTINEL XL™ PAPR CBRN
SYSTEM. SUCH
TRAINING
MUST BE IN ACCORDANCE WITH THIS USER INSTRUCTION. EACH PERSON
USING THESE RESPIRATOR SYSTEMS MUST FIRST READ AND UNDERSTAND THIS
ENTIRE USER INSTRUCTION. FAILURE TO DO SO MAY ADVERSELY AFFECT
RESPIRATOR SYSTEM PERFORMANCE AND RESULT IN INJURY OR DEATH.
IF
THESE RESPIRATOR SYSTEMS FAIL ANY OF THE REQUIREMENTS OF THE USER
INSPECTION AND PERFORMANCE CHECK, DO NOT USE THE RESPIRATOR SYSTEM
UNTIL ALL NECESSARY REPAIRS HAVE BEEN PERFORMED AND THE RESPIRATOR
SYSTEMS PASS THE PERFORMANCE CHECKS. FAILURE TO DO SO MA
Y ADVERSELY
AFFECT RESPIRATOR SYSTEM PERFORMANCE AND RESULT IN INJURY OR DEATH.
3. If you are using the Non-Rechargeable Battery or Alkaline Battery
Adaptor continue onto Step 4. If there is no battery installed into the
blower refer to pages 29 and 30 respectively
for battery installation.
4. Fold the blower compartment’s cover, and
fasten the straps with the buckles.
5. Cartridge installation:
• Remove the Cartridges from the net
receptacles.
• Verify that the Cartridges are the appropriate
type for the application by examining the
label attached to the Cartridge.
• Verify that the foil package maintained vacuum. Remove the Cartridges from their packaging and the
foil bag, inspect for damages; if in doubt do not use. Confirm that the Cartridges do not exceed the “use-
by” date and that the connecting thread is not damaged.
• Confirm that the threads in the blower unit are in good condition and clear of foreign matter.
• Verify that the blower threads have the black rubber gasket seals present.
• Remove all plugs from the Cartridge ends before using the system. Retain the plugs for future use.
• Screw the Cartridges into the threads until they are hand tight.
