iLive ISBW240 User manual

Battery Charging
To charge the internal battery, plug the USB charging cable
into the DC Power Input on the speaker and a powered on
computer or USB power adapter (not included) and standard
power outlet. Charging time is approximately 3 hours. Battery
life is approximately 20 hours at 50% volume.
When the battery is low a voice will announce“Low Battery,”
then the unit will automatically power OFF.
While the unit is charging it will display a solid red light. When
the battery is fully charged the light will turn o.
Outdoor Bluetooth Speaker with Removable Stake
User’s Guide for Model ISBW240 v2687-02
CONNECT
SPEAKERS
M
/
/
Controls
Overview
Aux In & Micro SD
Features
• Waterproof
• Bluetooth wireless 5.0: range 33 ft.
• Party Plus Mode
• 360 degree sound
• Built-in microphone
• Solar Panel
• Built-in rechargeable battery: approximately 20 hrs
playtime at 50% volume
• Micro-USB port for battery recharge
Aux In
Requires a 3.5mm audio cable (included).
1. Connect a 3.5mm audio cable to the Aux In on the unit
and the audio output on an audio device. The unit will
automatically change to Aux in mode.
2. Use the controls on the connected device to select and
play audio. Be sure the volume on your connected device
is audible when you begin playing.
1. Mode: Press to change source modes to Bluetooth, Aux
in, FM radio. Press and hold for 5 seconds to enter into
Party Plus mode.
2. Microphone
3. Volume/Skip+/Prev- : Press to adjust volume level. Press
and hold to previous / next track.
4. Charging/Bluetooth Indicator LED: Light will turn solid
red when charging and will turn o when fully charged.
Flashing red when low battery. Flashing blue when in
Bluetooth mode. Solid Blue light when in Aux in mode.
5. : Press and hold to enter into pairing mode manually.
6. Power/Play/Pause: Press and hold to power ON or OFF.
Press to play/pause audio. Press to answer phone calls.
1
2
4
6
5
3
Includes
• 3.5mm audio cable
• Micro-USB to USB charging cable
• Stakes
Using the Stakes
The stakes allow you to stabilize these
speakers on the ground for use outdoors.
1. Remove the stakes from the casing
2. Insert the stake into the bottom of
the casing as shown below.
3. Insert the stake into the bottom of
the speaker and stick the stake into
the ground.
Solar Panel
Note: The solar
panel charges at
a VERY slow rate.
Therefore it is best
as a supplemental
charging method.
Micro SD
1. Load a Micro SD memory card into the Micro SD port.
2. The speaker will automatically switch to SD mode.
3. Use the controls on your device to select and play audio
from the connected drive.
DC IN AUX IN
Micro SDAux In
DCIN AUXIN
CONNECT
SPEAKERS
M
/
DCIN AUXIN

Customer Support
Customer Service: 1-888-999-4215 | Email Support: prodinfo@
dpiinc.com | Email Parts: [email protected]
For Warranty Information and the most up-to-date version of
this User’s Guide, go to www.iLiveElectronics.com
To download this User’s Guide in English, Spanish, or French, or
to get answers to frequently asked questions, visit the support
section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y
francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol
ou français, ou pour obtenir des réponses à des questions
fréquemment posées, consultez la rubrique d’assistance sur:
www.iLiveElectronics.com
Copyright © 2020 Digital Products
International (DPI, Inc.) All other trademarks
appearing herein are the property of their
respective owners. Specications are subject
to change without notice.
FCC Warnings
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings
• WARNING: To prevent re or shock hazards, do not expose this
unit to rain or moisture.
• WARNING : Where the mains plug or appliance coupler is used
as the disconnect device, such disconnect device shall remain
readily operable.
• Lithium batteries, like all rechargeable batteries, are recyclable
and should be recycled or disposed of according to state and local
guidelines. They should never be disposed of in normal household
waste, and they should never be incinerated, as they might
explode. Contact your local government for disposal or recycling
practices in your area.
Party Plus Mode
If you have another ISBW240 speakers, you can pair and play
the two speakers together for a surround sound eect, or have
two speakers playing in dierent rooms.
1. To enter Party Plus Mode, Power ON both speakers and
make sure both units are in Bluetooth mode.
2. Press and hold the Mode button on one of the units (this
is now the primary unit), and the speakers will attempt to
pair to each other.
3. When the two speakers are paired together a voice will
announce the connection.
4. Connect Bluetooth device to speakers using the steps
from the “Pairing and Playing Bluetooth Audio” section
below.
5. Use your device to select and play tracks. The audio will
now be heard through both speakers.
6. The primary unit will control both speakers when
connected. To disconnect the speakers, press the Mode
button on the primary unit.
Note: To use Party Plus Mode, please make sure that you
connect the speakers before pairing to your Bluetooth
device. You will not be able to connect the speakers if you
are already paired to a Bluetooth device.
WARNING: This product can expose you to chemicals
including lead, which is known to the State of California to
cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
This product meets and complies with required Federal
product guidelines.
Made
Green
Pairing & Playing Bluetooth Audio
1. When rst powered on, the speaker defaults to Bluetooth
Mode and is ready to pair automatically. When pairing,
remain within 3 feet of the Bluetooth device.
2. Using the controls on your Bluetooth device, select
ISBW240 in the Bluetooth settings to pair. If need be,
refer to the user’s manual for your specic device for more
information.
3. When successfully paired, a voice prompt will announce
the connection. Your Bluetooth device will now be heard
through the speaker.
4. Use the controls on the connected Bluetooth device to
select and play audio. Use the speaker controls or the
connected Bluetooth device to play, pause, and adjust
the volume level.
5. After initial pairing, the speaker will automatically
connect to the last Bluetooth device used whenever it is
in Bluetooth Mode. Note: If your device should become
unpaired or you nd it is unable to connect, press and
hold the button to enter to Pairing Mode. A voice
will announce,“Bluetooth is connecting,” and you can
connect to the speaker manually.
FM Radio
An FM receiver is built into the speaker but functions best
when the included USB cable is connected to the speaker.
1. Once powered ON, press the Mode button to switch to
FM Radio Mode.
2. Press and hold Power/Play/Pause button for 2 seconds
to scan and save radio stations automatically.
3. Press and hold the +/- buttons to cycle through saved
stations.
If after you have connected the two speakers, you decide
you want to use one of the speakers independently:
1. Press and hold the Mode button on the speaker you
want to use to disconnect the two speakers.
2. Press and hold button on the speaker, the speaker will
then enter into pairing mode. You can now connect to
the speaker manually.
If you want to connect the speakers together again:
1. Access your device’s Bluetooth settings menu and select
all ISBW240s.
2. Select “forget this device” and follow the Party Plus mode
connection procedure listed in the user manual.
