iLive Patio+ User manual

"Patio+" Indoor/Outdoor Water-Resistant
Speakers (Set of 2)
User’s Guide for Model ISBW763BDL-3017
For the most up-to-date version of this User’s Guide, go to: www.iLiveElectronics.com

2
Safety Instructions & Warnings
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. e wide blade or the
third prong are provided for your safety. When the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
• Mains plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect
the apparatus from the mains completely, the mains plug
should be disconnected form the mains socket outlet
completely.
• WARNING: Shock hazard—Do Not Open.
• Caution and marking information is located at the rear or
bottom of the apparatus.
• WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain, moisture, dripping,
or splashing.
• Objects lled with liquids, such as vases, shall not be placed
on the apparatus.
• CAUTION: Use of controls or adjustments or performance
of procedures other than those specied may result in
hazardous radiation exposure.
• WARNING: Changes or modications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment
• WARNING: Do not place this unit directly onto furniture
surfaces with any type of soft, porous, or sensitive nish.
As with any rubber compound made with oils, the feet
could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a
piece of glass between the unit and the surface to reduce the
risk of damage and/or staining.
• WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the unit is
displaying erratic behavior move away from any uorescent
lighting, as it may be the cause.
• CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
• Keep new and used batteries away from children. If the
battery compartment does not close securely, stop using the
product and keep it away from children.
• If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical
attention.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
• Batteries should be recycled or disposed of as per state and
local guidelines.

3
FCC Warnings
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC Radiation Exposure Statement
This equipment complied with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
WARNING: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing
to qualied service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to
persons.
WARNING: DO NOT INGEST BATTERY,
CHEMICAL BURN HAZARD.
WARNING : This product can expose you
to chemicals including lead, which is known
to the State of California to cause cancer and
birth defects or other reproductive harm. For
more information go to www.P65Warnings.
ca.gov. This product meets and complies
with required Federal product guidelines.

4
Table of Contents
Contents
Features & Specications - 5
Includes - 5
Orientation
Left Speaker Rear View - 6
Left Speaker Front View - 6
Right Speaker Rear View - 6
Remote
Functions & Controls - 7
Remote Battery - 7
Connecting Your Speakers
Connect Your Speakers - 8
Connect Your Speaker to Power - 8
Connect with Bluetooth - 8
Mounting Your Speakers
Placing Your Speakers - 9
Attaching the Mounting Hardware -9
Attaching Your Speakers -9
PositioningYour Speakers
Angling Your Speakers (FPO) - 10
Troubleshooting
Problems and Possible Solutions - 11
Company Information
Contact Information - 12
International Support - 12
Warranty - 12

5
Features & Specifications
• Supports Bluetooth v5.0, range 100ft
• IP44 water-resistant
• Protective UV cabinet
• Powder-coated, rustproof aluminum grill
• Built-in 5.25" woofer and 1" tweeter speakers
• Auto pairing
• Mounted vertically or horizontally
• 70° swivel left and right
• Peak audio output: 140W
• Max volume: 97dB
• Frequency response: 80Hz–18kHz
• Speaker weight: 2.42lbs
Includes
• Speakers (Set of 2)
• Remote control with CR2025 battery (included)
• DC adapter with waterproof plug
• 25' connecting wire
• Heavy duty mounting brackets (Set of 2)
• Anchors (4)
• Screws (4)
Contents

6
Left Speaker
Rear View
Orientation
Left Speaker
Front View
Right Speaker
Rear View
Speaker-to-Speaker Positive
Connection Port (Red)
Speaker-to-Speaker Negative
Connection Port (Black)
DC In Port
Power On/Off Switch
Speaker-to-Speaker Negative
Connection Port (Black)
Speaker-to-Speaker Positive
Connection Port (Red)
LED Indicator Light

7
Remote
Functions & Controls
Power
Press to turn
the unit on or off.
Pair
Press to select
Bluetooth Mode. The
indicator light on the
front of the speaker will
turn blue.
Press and hold to
disconnect from a
Bluetooth device and
enter pairing mode. Flat
Press to reset Treble and
Bass default setting
Volume +/-
Press to adjust
the volume.
Bass +/-
Press to adjust the bass
up or down.
Mute
Press to mute the
volume.
Remote Battery
Requires one (1) CR2025 button cell battery (included).
Play/Pause
Skip Forward
Skip Backward
Press the Play/Pause
button to start, stop,
and resume playback.
Press the Skip Backward
button to return to the
previous track.
Press the Skip Forward
button to switch to the
following track.
Treble +/-
Press to adjust the
treble up or down.

8
Connecting Your Speakers
Connect Your Speaker to Power
1. Plug the power adapter into the DC power
input on the speaker and a standard outlet.
2. Press the Power button to turn the speakers on.
Connect Your Speakers
Connect the speakers using the included speaker
cable.
1.Plug the red end of the connection cable into
the red port on the back of the left speaker.
2. Plug the black end of the connection cable
into the black port on the back of the left
speaker.
3. Connect the red plug on the other end of the
cable to the red port on the back of the right
speaker. Then, connect the black plug to the
black port.
Connect with Bluetooth
When the speakers first power ON they default to Bluetooth Mode and are ready to pair automatically. When
pairing, remain within 3 feet of the Bluetooth device.
1. Using the controls on your Bluetooth device, select ISBW763BDL in the Bluetooth settings to pair. If you
have trouble with accessing Bluetooth settings, refer to the user’s manual for your specific device for
more information.
2. When successfully paired, audio from your Bluetooth device will play through the speakers.
3. Use the controls on the connected Bluetooth device to select and play audio.
4. The speaker will remember and try to connect to the last used device. Press and hold the PAIR button on
the remote to disconnect from the last device and connect to a new device.
Note: If you are having trouble with automatic pairing to your device, use the PAIR button on the remote to
enter pairing mode on the speaker. Then, follow the steps listed above.

9
Mounting Your Speakers
Attaching Your Speakers
1. Locate the mounting bracket holes on the top and bottom of the speaker (one on each side)
2. Insert the anchors through the hole in the mounting bracket into the mounting bracket holes on the
speaker.
3. Screw in and tighten the anchors to secure the speaker into place.
Placing Your Speakers
These speakers feature an IP44 water-resistant protection, UV resistant coating, and a powder-coated, rust-
proof grill for outdoor use. If you choose to mount the speakers outside, place them in a covered setting or
somewhere sheltered from rainfall, splashing, or spills.
Note: Remember to keep the distance between the speakers under 25ft. for the connection cables.
Attaching the Mounting Hardware
This speaker set comes with four screws and four external anchors. Make sure the surface you choose is able
to support the weight of the speaker and mounting bracket. Additional tools (such as wood screws or wall
anchors) may be required.
1. Position the mounting bracket vertically or horizontally on your wall.
2. Attach the mounting bracket to the wall with the screws, as seen below.

10
Positioning Your Speakers
To change the angle of your speakers, loosen the anchors and gently turn the speaker to face your desired
direction. Retighten the anchors once the speaker is in place.
Note: Speakers can only swivel when mounted vertically.
The position of your speakers can affect the sound quality of your audio. Here are some points to keep in
mind.
70° swivel
left and right
when mounted
vertically
• If possible, mount your speakers at ear-level in the listening area.
• Point both speakers inward toward the listening area.
• Place each speaker at least two feet away from corners to avoid sound reflection.

11
Troubleshooting
PROBLEM POSSIBLE SOLUTION
Speaker will not power on • Make sure the AC/DC plug is plugged in and
connected to the left speaker
• If using the remote to try powering on the
speaker, check if the remote battery needs to
be changed.
• Check for water damage: this product is water
resistant, but not fully waterproof.
Sound skipping/Audio doesn't play • Turn the speakers off and then on again.
• Check for water damage and dry off speaker.
• Check the volume on the speaker and your
playback device.
Audio Distortion • Check the volume on the speaker and
playback device, the level may be too high.
• Maintain distance from devices or frequencies
that may cause interference.
Bluetooth won't play/fails to connect • Check the volume on the speaker and your
playback device.
• Make sure the Bluetooth setting on your
playback device is on.
• Stay within 3 ft. of the speaker when pairing.
• Remain within xx ft. of the speaker when
paired.
• The speaker will automatically pair to the last
paired device. Disconnect from the previous
device before connecting to another.

12
Contact Information
Website: www.iLiveElectronics.com
Email Support: [email protected]
Email Parts: [email protected]
Phone Support: 1-888-999-4215
Warranty
For Warranty Information and the most up-to-date
version of this User’s Guide, go to:
www.iLiveElectronics.com
Copyright © 2022 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the
property of their respective owners. Specifications are subject to change without notice.
Protect for Today
Sustain for Tomorrow
Made
Green
Company Information
