Illumi Led 5M5050RGB User manual

Specication
www.illumiled.co.uk
LED
IP20
Easy ‘plug n play’ RGB colour exi strip has 3M VHB
ultra adhesive backing for easy installation and comes
complete with EN60950 approved UK plugtop driver,
and wireless RGB controller for easy colour control.
Able to select 16 static colours, choose from a range of
dynamic modes to control colour changes and dimming.
Flexi LED Strip & RF Remote Controller
LED STRIP 5M5050RGB
Operating Voltage: 12VDC
Power per meter: 7.2W/m
Number of LEDs: 30LEDs/m
LED Type: 5050 RGB
Beam Angle: 120°
Maximum Power: 36W
Cutting Point: 100mm
Lifetime: 50k hours
Remote Control Parameter:
Working Voltage: 3V (battery CR2025)
Working Temperature: -20°C ~ 60°C
Weight: 16g
Dimensions: 50 x 35 x 22mm
Power Supply
Input: 110~220VAC
Output: 12VDC/3A
5M5050RGB
Cutting
Point
Cutting
Point
5M
100mm
10mm
Designed in
England
2.2mm
RoHS
R
B
G
R
B
G
R
B
G
R
B
G
Mechanical

www.illumiled.co.uk
LED
Flexi LED Strip & RF Remote Controller
Installation instructions
power adaptor
5M5050RGB
Plug in the AC/DC
power cable into the
LED controller unit.
Plug the at 4-pin
connector together
to join the LED
Flexi Strip.
SMOOTH
FLASH
STROBE
FADE
OFF ON
R G B W
PRODUCT FEATURES
This pack contains: a 5metre reel of RGB LED Flexi Strip, Mini RF Remote Controller
and AC/DC plug top driver. Suitable for selecting colours directly using the RF
controller, dimming and selecting light control function using the dynamic mode
buttons on the controller. 16 static colours.
INSTRUCTIONS
■ Connect the cables and connectors together as illustrated above. Plug the AC/
DC plug into a socket and the RGB LED Strip will light up.
Press the‘ON’button on the RF remote controller and press one of the desired
colours. The RF signal will be transmitted to the LED controller unit via the RF aerial.
Ensure the unit isn’t enclosed by any obstructions as this may prevent the RF Remote
FUNCTIONS REMOTE CONTROLER KEYS
LED CONTROLLER
4
2
1
3
4
2
1
3
Power On / O buttons ~ Press the‘ON’ button to turn on the LED remote
controller or press‘OFF’ button to turn o.
Colour direct selection buttons ~ Press these buttons to choose the LED
Strip colour
Dynamic Mode buttons ~ Press these buttons to select one of the 4
Dynamic modes. Choose how the colour changes, fades and ashes using
these buttons.
RF Signal indicator.
Light adjustment buttons ~ Press these buttons to increase and decrease
the brightness of the LED lights.
5
5
Made in China
IP 20
LED CONTROLLER
Input:DC12V/24V
Output:DC12V/24V 3C H
Lo ad IR
Power:72W/144W MAX.
Power Input: DC Connector Infrared Sensor
LED Output
Positive Pole
LED Controller from working properly. The Dimming unit defaults to the previous
setting when switched on.
Press the various coloured buttons to choose a direct colour.
Press the dynamic modes buttons to choose the colour control, such as colour fading
and colour changing.
INSTALLATION
■Power Supply
This unit uses a DC 12V LED driver. Connect all the cables and connectors together as
described in the above instructions. This Dimmer unit supports constant voltage LED
products and has a short circuit, overload and overheating protection function.
Note: Do not short circuit or overload the LED output as this may lead to permanent damage.
SMOOTH
FLASH
STROBE
FADE
OFF ON
RGBW
Brightness/
Speed +
Brightness/
Speed -Power OFF Power ON
WhiteBlueGreenRed
Dark BluePea GreenOrange
BrownCyanDark Yellow
PinkLight BlueYellow
PurpleSky BlueStraw Yellow
3 Colour Change
Fade Colour Change
of 3 Colours
Fade Colour Change
of 7 Colours
Smooth Colour
Change of 7 Colours
