ILP CFS-36W Series User manual

ILP – Industrial Lighting Products, LLC
519 Codisco Way, Sanford, FL 32771
Phone: [phone] Fax: [phone]
www.ilp-inc.com
CONVERTAFLOOD REFLECTOR
INSTALLATION INSTRUCTIONS
MODELS:
CFS-36W-U-XX
CFM-52W-U-XX or CFM-85W-U-XX
CFL-110W-U-XX or CFL-150W-U-XX
(Note: Replace XX with 40 or 50 based on CCT of LED, may be followed by BLK, BRZ, or WHT)
Part Number List:
(Note: The NEMA 7x6 reflector comes Standard on the Convertaflood. Replacements are available.)
1. Introduction
◼ The CF Family LED Floods use easy replaceable snap-in type reflectors to customize
to your lighting needs.
MODEL
REFLECTOR PART NUMBERS
NEMA 3X3
NEMA 4X4
NEMA 5X5
NEMA 7x6
CFS-36W
-
N44/S
N55/S
N76/S
CFM-52W
N33/M52
N44/M52
N55/M
N76/M
CFM-85W
-
N44/M85
N55/M
N76/M
CFL-110W or CFL-150W
N33/L
N44/L
N55/L
N76/L
Warning:
To avoid the risk of fire, explosion, or electric shock, this product shall be installed, inspected,
and maintained by a qualified electrician, in accordance with all applicable electrical codes.
Warning:
To avoid electric shock:
•Allow product to cool before servicing.
•Be certain electrical power is OFF before and during installation or maintenance.
•Luminaire must be connected to a wiring system with equipment-grounding conductor.
Warning:
To avoid LED damage:
•Please do not touch the LED when replacing the reflector. Touching the LED may result in
damage or failure of the LED.

ILP – Industrial Lighting Products, LLC
519 Codisco Way, Sanford, FL 32771
Phone: [phone] Fax: [phone]
www.ilp-inc.com
2. Installation
Step 1
Open the back cover by using the provided tool to loosen the security closure screw, hold and compress
fixture lightly while depressing the cover opening latch. (FIG.1)
Step 2
Remove existing reflector by tilting the reflector forward until the tabs release than slightly pull outward
to remove the reflector. (FIG.2)
Step 3
Replace reflector by tilting the reflector forward and dropping into the bottom tabs. slightly push forward
till the reflector snaps in the remaining tabs. (FIG.3)
Step 4
Close the back cover and tighten the security closure screw using the provided tool to approx. 10 ft lbs.
After installation, please
➢Ensure the lighting fixture is firmly secure to its mount.
➢Ensure wires are connected correctly before applying power.
To complete installation, turn power ON, check for proper operation of luminaire.
FIG.3
FIG.1
FIG.2
