Soltech SOLPAD User manual

SPECIFICATIONS
025W / 500LM
3,000mAh / 3.7V
SMD 2835 X 30PCS
2.3 Wp, Mono-crystalline Silicon
135° Adjustable
360° Adjustable
3 Different Modes
120° / 19.7ft
90°
IP65
3 YEARS
35,000 hrs
≤13.1 ft
Solar Light X 1, Screw Bag X 1,
User Manual X 1
POWER / LUMEN
LED
LI-ION BATTERY
SOLAR PANEL
LIGHTING PANEL
BRACKET
WORKING MODE
DETECTION ANGLE / AREA
BEAM ANGLE
IP DEGREE
WARRANTY
LIFESPAN
INSTALLATION HEIGHT
PACKING
Copyright©2021–2022 SOLTECH LLC, All Rights Reserved.
SOLTECH LLC reserves the right to update all product data sheets at any time. Consult
SOLTECH marketing specialists for publication updates at www.soltechlighting.com
SOLTECH offers
advanced LED
technology that
is eco-friendly
and utilizes
clean energy.
SOLPAD
1460 Park Avenue.
Emeryville CA 94608 USA
www.soltechlighting.com
Please read and follow all instructions to operate. Save this
manual for future reference.
SOLAR
LED FLOOD
LIGHT
5W 500LM 4,000K
011
INTRODUCTION
1. This is a solar powered lamp, please install it in a
location where it can get enough sunshine.
2. Please note the duration of the light depends on sun
intake & weather.
3. The lamp will automatically turn on at dusk.
4. Built-in IC with over-charge, over-discharge, and
over-voltage protection.
Warning
1. The lamp is equipped with internal batteries. Non-professionals
please do not disassemble the lamp.
2. Please do not dispose the battery in household garbage to
avoid explosion.
WATERPROOF SUPER
BRIGHT
CORDLESS DUSK TO
DOWN SENSOR
MOTION
SENSOR
LOW
COST

INSTALLATION
03
04
A: Wall Mounted
1. Prepare lamp, accessories, and tools.
2. Use the Allen wrench to loosen the bracket
and adjust to the appropriate angle then
screw tightly.
3. Use the Allen wrench to loosen the
light module then pull it out and adjust to
appropriate lighting angle.
4.Mount the lamp onto any wall surface or
lamp post.
B: Stand On Flat Surface
1. Prepare lamp, accessories, and tools.
2. Use the allen wrench to loosen the bracket
OPERATING
MODES
120°120°120°
When battery capacity is below 30%
Automatically turns on to full brightness (500LM)
when motion is detected in the range <19.7ft, then
turns off after 20 seconds of no motion.
120°120°120°
Press the power button then program the
operating mode. Charge for 6 hours to get 3-4
nights of light.
Power Button
Press the ON/OFF button, the
lamp will automatically turn to
Sensor mode. If you press down
on the button for 3 seconds, the
lamp will flash one time and
change to Constant Lighting mode.
When battery capacity is above 30%
Automatically turns on to full brightness
(500LM) when motion is detected in the range
<19.7ft then dims down in brightness after 20
seconds of no motion.
CONSTANT MODE
Press the On/Off button for 3 seconds to
activate constant lighting mode. The light will
flash one time to indicate the mode has been
switched. Both motion and light sensors are
disabled. The lamp will remain on constant
lighting until the battery capacity reduces
switching back to sensor mode.
