Imada DTX-15 Use and care manual

Making Adjustments
For example on the DTX-40, if the CCW reading is 50.30 and CW
reading is 50.50
Step 1 Determine actual deviation. (50.50 – 50.30) ÷2 = 0.10
(which is smaller than the allowable tolerance of 0.25).
Step 2 Calculate target calibration value, which is capacity less
actual deviation calculated above. 50.00 – 0.10 = 49.90.
Step 3 Determine calibration direction (only one direction calibra-
tion is required). Take the smaller number’s direction,
which in this case is CCW (50.30).
Step 4 Zero the display. Rehang the calibration weight (2.5 kg
only for DTX-40) and calibrate in the CCW direction.
*Note: Removing the warranty seal automatically voids the warranty.
CALIBRATION MANUAL
Models:
DTX and DTX2
Cap Torque Tester
Note: The PC board is mounted on
the front cover and cables are con-
nected to it. Do not force.
3. Using a small flathead screwdriver adjust the VR2 pot adjust-
ment screw to the appropriate setting (screw faces right).
D
DoonnoottaaddjjuussttVVRR11(screw faces top).
4. After adjustment, slide the PC board back and replace the screws.
VR2 POT
VR1 POT
DO NOT ADJUST
1. Remove the 2 screws in the front
cover and the warranty seal.*
2. Gently pull the front cover forward
to expose the PC board.
SCREWS
Specifications subject to change without notice.
Distributed by: ABQ Industrial LP USA
Tel: [phone] eFax: [phone]
Web: https://www.abqindustrial.net E-mail: [email protected]

Calibration Setup
1. Verify the temperature is within
the allowable range (32°-100°F)
and record it.
2. Pull up to remove clamp table
from cap torque tester.
Do Not Twist or Jerk! Permanent
damage may result, whether the
unit is on or off.
3. Place the cap torque tester against
the vertical wall of the test stand
and clamp it to the wall as shown.
4. Place the calibration arm on the cap torque
tester with the 2 wires hanging down,
engage the coupling and press in firmly
(make sure the calibration arm doesn’t
touch the clamp and allow clearance to
hang the calibration weight).
5. Connect AC adapter/charger, plug into
115VAC outlet and turn on the cap torque
tester, select Real Time Mode (not Peak Mode) and change units
to kg-cm (press unit switch and hold for 4 seconds to select units).
6. Press the Zero switch to zero the display.
page 3page 2
6. Hang the correct weight (see Specification
Table above) on the left hook and record the
torque value (make sure the wire stays on
the edge of the calibration arm, use scotch
tape if necessary).
7. Remove the weight and see if the display
returns to zero.
8. If not, repeat from steps 7 - 9 until it does.
Before hanging the calibration weight, refer to the following table to
be sure the correct weight is used to prevent overload. (kgf-cm)
List of Equipment
Calibration arm (20 cm radius)
Small Screwdriver
Clamp
Calibration weight
1
2
3
4
MODEL DTX/DTX2-15 DTX/DTX2-40 DTX/DTX2-85
CAPACITY (kgf-cm) 20.00 50.00 100.0
ALLOWABLE RANGE (kgf-cm) 19.90~20.10 49.75~50.25 99.5~100.5
ALLOWABLE TOLERANCE (kgf-cm) 0.10 0.25 0.5
*WEIGHT (kg) 1 2.5 5
*Weight is appropriate for 20 cm radius calibration arm
9. Zero the display.
10. Hang the weight on the right hook and
record the torque value.
11. Remove the weight and see if the display
returns to zero.
12. If not, repeat from steps 11 - 13 until it does.
Check the table to make sure the CCW & CW
readings are within the allowable range before
making adjustments.
CCW Calibration
CW Calibration
TOP
CLAMP TABLE
Digital Cap Torque Tester
CALIBRATION PROCEDURE
1
2
3
4
Specification Table
Conditions:
Temperature: 72° (±15°F)
Humidity: 10 - 60%
TEST STAND
CLAMP
13. Subtract the smaller from the larger reading, and divide the result
by 2 to determine actual deviation. If actual deviation is larger
than allowable tolerance (see Specification Table), the unit needs
repair before calibration.
If actual deviation is smaller than allowable tolerance, the unit
can be calibrated by the following procedure.
