IMAQ 810 User manual

GENERAL INTRODUCTION
Thank you for purchasing the IMAQ 810. This S2 Set TopBox will allow you towatch
IPTV/OTT/S2 content in High quality thanks to the H.265 encoder which allows you
to watch high quality streams at a low bit rate.
UNPACKING
Unpack the unit and check to make sure that all of the following items are included
in the packaging.
1 x Remote Control Unit (RCU)
1 x IPTV Set Top Box
1 x User Manual
1 x HDMI Cable
1 x Adapter
GENERAL INTRODUCTION
INTRODUCTION
This manual will help you to learn the basic functions of the STB/IPTV BOX. All
functions can be operated by the remote control.
The remote control is designed for easy access to all the functions at once and for
comfortable grab for your hand.
Itis programmed tocontrol all functions and to allow you to easily watchlivestreams
and movies.
1. WARNING：To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to dripping or
splashing and that objects filled with liquids, such as vases, shall not be placed on
apparatus.
2.WARNING: The battery (battery or batteries or battery pack) shall not be exposed
to excessive heat such as sunshine, fire or the like.
3. WARNING: The mains plug is used as disconnect device, the disconnect device
shall remain readily operable.
SAFETY INSTRUCTIONS
This STB/IPBOX has been manufactured to satisfy the international safety
standards.
Please read the following safety precautions carefully.
MAIN SUPPLY
DC 5V 2A
OVERLOADING
Do not overload a wall outlet, extension cord or adapter as this may result in fire or
electric shock.
Ensure that the power source (socket) is easily accessible.
LIQUIDS
This STB/IPBOX shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the STB/IPBOX.
CLEANING
Disconnect the STB/IPBOX from the main supply before cleaning. Do not use any
kind of solvents to clean the IPBOX, only use a soft-dry cloth.
VENTILATION

The slots on top of the STB/IPBOX must be left uncovered to allow proper airflow to
the unit.
Ensure a minimum distance of 5cm around the apparatus for sufficient ventilation.
Ensure that the ventilation is not impeded by covering the ventilation openings with
items such as newspapers, table-cloths, curtains, etc.
Do not stand the STB/IPBOX on soft furnishings or carpets.
Do not expose the STB/IPBOX to direct sunlight or do not place it near a heater.
Do not stack electronic equipments on top of the STB/IPBOX.
Do not place naked flame sources, such as lighted candles on the apparatus.
ATTACHMENTS
Do not use any unrecommended attachments as these may cause hazard or
damage to the STB/IPBOX.
CONNECTION TO THE TV
Disconnect the STB/IPBOX from the main supply before connecting or
disconnecting the cable from TV.
FAILURE TO DO SO CAN DAMAGE THE TV.
LOCATION
Place the STB/IPBOX indoor in order not to expose to lightening , rain or sunlight.
Use the apparatus only in moderate climates (not in tropical climates).
Battery handling
Batteries may contain toxic agents that are hazardous to the environment.
Therefore, dispose of the batteries immediately according to the prevailing statutory
regulations. Never throw the batteries in normal household waste.
FRONT PANEL/ REAR PANEL AND REMOTE CONTROL UNIT

HOW TO USE
How to connect the STB/IPBOX to a TV set
IPTV
In this menu, IPTV, You can enter your connected server’s IPTV channels.
VOD
In this menu, Video on demand (VOD),You can enter your connected server’s VOD.
SAT TV
In this menu,SAT TV , You can enter your connected satallite’s TV channels.
MUSIC
In this menu, MUSIC, You can listen to music on your connected server.
RADIO
In this menu, RADIO, You can listen to radio on your connected server.
APPS
In this menu, Aplications (APPS), You can use below aplications.
Stalker Portals
In this menu, you can select the portals that you want to connect to
iMedia
In this menu, you will find various Media apps that you can use.
(Youtube, Dailymotion, Google Map, News, Weather)
Media player
In this menu, you will find various Media apps that you can use.
(Video player, Music player, Photo player, e-Book, PVR player)
M3U player
This app allows you to watch m3u files, the links can be uploaded using your
USB or you can enter a .m3u link using the remote control.
SETTINGS
In this menu ,System SETTINGS, You can do all settings for STB.
Menu Settings
Startup Mode; In this menu, you can setup the startup mode of the box.
Parental control; In this menu, you can setup the parent control functions.
(Default pincode is 0000)
Auto Standby; In this menu, you can setup the auto standby functions.
Standby Display; In this menu, you can setup the standby display functions.
AV Settings
In this menu, you can setup the AV settings according to your TV.
IP Settings
In this menu, you can choose the Link Type and you can setup IP settings
according to your connection type.

Account Settings
In this menu, you can setup the account settings of the IPTV server that you
want to connect. (Default pincode is 0000)
Portal Upgrade; You can add your postal’s information with txt file.
SAT Settings
In this menu, you can setup the SAT settings of the satallite dishes that you
want to connect.
Language Settings
In this menu, you can choose languages for all menu. You can choose
languages for subtitle and audio.
Time Settings
In this menu, you can choose to time zone for the date and time.
Software Upgrade Settings
In this menu, You can upgrade software in two ways.
USB Upgrade; You can upgrade software with USB. Put the software on your
USB and insert the USB into the box.
Net Upgrade; You can upgrade software with FTP and HTTP. If automatic
update is on, software upgrade will be done automatically.
Factory Reset Settings
In this menu, You can restore the device to factory settings
System Information
In this menu, You can see decive model number, software version, database
version, build date and MAC address information.
Specifications
Digital Satellite tuner build in supports DVB/S2 UHD decoding
high performance WIFI with inside antenna build in.
Digital Audio S/PDIF
USB 1 * 2.0 Host, media player and PVR ready
Ethernet 1 * RJ45
CPU 667Mhz, LQFP144
Flash 16MByte
SDram DD3 128M x 16 (2G), 1333/1600MHz
Supply Voltage 12V/1.2A Power Adaptor
Power consumption 10W Max
Standby Power Consumption 0.5W Max
Operation Temperature +5 to +40 degree
Storage Temperature -20 to 70 degree
Dimension 132 x 87 x 27 mm
Transport Stream & Profile Level
oMPEG-4 H.264, HEVC H.265
oMPEG-2 MP@HL, MEPG/AVC
Input DataRate 120Mbit/s Max
Video Format 576i, 576P, 720P, 1080i, 1080P
Audio Decoding MPEG1 Layer I & II, MPEG2,
oMPEG4 AAC and MPEG4 AAC-HE(AAC+),
oDolby Digital (AC-3), Dolby Digital Plus
Audio Mode Left, Right , Stereo
Samping Freq 32, 44.1, 48, 96 KHz
HDMI HD Video/Audio Ver 1.4a
CVBS headset Jack output
Bicolor LED light, Red standby, Blue working mode.
