IMI NORGREN F68G Installation and operating instructions

F68G General purpose filter
Installation & Maintenance Instructions
10/20
I&M/en 8.260.100.01
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8088d) © 2015 IMI International s.r.o.
TECHNICAL DATA
Fluid: Compressed air
Maximum pressure: 17 bar (250 psig)
Operating temperature*:
-20° to +80°C (0° to +175°F)
* Air supply must be dry enough to avoid ice
formation at temperatures below +2°C (+35°F).
Partical removal: 5, 25 or 40 μm
Air quality: Within ISO 8573-1, Class 3 and
Class 5 (particulates)
Typical flow with a 40 μm element at 6,3 bar
(90 psig) inlet pressure and a 0,5 bar (7 psig)
pressure drop: 190 dm3/s (403 scfm)
1/4 turn manual drain connection: 1/8” pipe
thread
Automatic drain connection: 1/8” pipe thread
Automatic drain operating conditions (float
operated): Bowl pressure required to close drain:
Greater than 0,3 bar (5 psig)
Bowl pressure required to open drain:
Less than 0,2 bar (3 psig)
Minimum air flow required to close drain:
1 dm3/s (2 scfm)
Manual operation: Depress pin inside drain
outlet to drain bowl
Nominal bowl size:
0,5 litre (1 pint U.S.)
1 litre (1 quart U.S.)
Materials:
Body: Aluminium
Yoke: Aluminium
Bowl: Aluminium
Liquid level indicator: Pyrex
Element: Sintered bronze or polypropylene
Elastomers: Synthetic rubber
REPLACEMENT ITEMS
Service kit (items circled on exploded view) 4380-300
0.5 litre bowl liquid level lens (19 thru 27) 4380-060
1 litre bowl liquid level lens (30 thru 38) 4380-061
Bronze element KITS:
Filter element, 0,5 litre bowl, 5 µm (54, 55, 56) 5576-197
Filter element, 0,5 litre bowl, 25 µm (54, 55, 56) 5576-198
Filter element, 0,5 litre bowl, 40 µm (54, 55, 56) 5576-199
Plastic element KITS:
Filter element, 0,5 litre bowl, 5 µm (53,55) 5576-97
Filter element, 0,5 litre bowl, 25 µm (53,55) 5576-98
Filter element, 0,5 litre bowl, 40 µm (53,55) 5576-99
Filter element, 1 litre bowl, 5 μm (55) 5311-01
Filter element, 1 litre bowl, 25 μm (55) 5311-02
Filter element, 1 litre bowl, 40 μm (55) 5311-03
Automatic drain, G1/8 outlet (49) 3000-97
Automatic drain, 1/8 PTF outlet (49) 3000-10
Manual drain, spindle type (44) 684-84
Manual drain, 1/4 turn (40) 619-50
Mechanical service life indicator (1) 5797-50
Electrical service life indicator (6) 4020-51R
INSTALLATION
1. Install yoke in air line - with air flow in direction
of arrow on top of yoke, upstream of
regulators, lubricators, and cycling valves, as
close as possible to the air supply when
filter is used as a main line filter, as close as
posible to the device being serviced when
filter is used as a final filter.
2. Connect piping to yoke ports using pipe
thread sealant on male threads only.
3. Lubricate o-rings (15) with a light coat of
o-ring grease, then place o-rings in grooves in
body (14).
4. Place clamp ring under lugs on top of yoke.
5. Make sure arrows on yoke and filter point in
same direction, then plug filter into yoke and
tighten clamp ring hand tight.
6. Turn bowl into body until arrowhead on bowl
is aligned with or to the right of the arrowhead
on the body.
7. Flexible tube with 3mm (0.125”) minimum I.D.
can be connected to the automatic drain.
Avoid restrictions in the
SERVICING
1. Open manual drain to expel accumulated
liquids. Keep liquids below bae (53).
2. Clean or replace filter element when dirty,
when optional mechanical service life
indicator shows approximately all red, or
when optional electrical service life indicator
provides an electrical output.
DIASSEMBLY
1. Shut o inlet pressure. Reduce pressure in
inlet andoutlet lines to zero.
2. Unscrew the clamp ring and remove filter
from yoke.
3. Disassemble in general accordance with the
item numbers on exploded view. Do not
remove the drains or the service indicators
unless replacement is necessary. Remove
and replace only if they malfunction. Do not
attempt to remove rod (59), as it is cemented
to body.
CLEANING
1. Clean lens (3, 24, 35) with warm water only.
Do not submerge electrical service indicator
TECHNICAL FEATURES
Option selector
* See Norgren publication IM-900.920 for specifications and electrical wire connections of the optional electric service indicator.
Port
6 3/4“
8 1“
A 1 1/4“
B 1 1/2“
N No yoke
Options
D With mechanical service life indicator
E With electrical service life indicator*
N No service life indicator
Drain
A Automatic
E Closed bottom
M Manual, spindle type
Q Manual, 1/4 turn
Bowl
C 1 litre (1 quart) no liquid indicator
M 0,5 litre (1 pint) no liquid indicator
R 0,5 litre (1 pint) with liquid indicator
U 1 litre (1 quart) With liquid indicator
Thread
A PTF
B ISO Rc tapered
G ISO G parallel
N No yoke
Element
1 5 µm
2 25 µm
3 40 µm
F68˙– ˙˙˙ – ˙˙˙
Bowl
E Long
G Standard
29
32
32
31
30
36
37
35
31
30
33
39
34
33
38
18
28
19
25
26
24
21
22
19
21
20
20
23
22
27
53
55
56
54
2
5
3
4
7
10
1112 13
15
14
57
1
6
8
9
58
59
41
43
42
40
46
45
47
44
48
51
50
49
52

F68G Filter
Installation & Maintenance Instructions
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8088d) © 2015 IMI International s.r.o.
I&M/en 8.260.100.02
10/20
(6) in water. Clean indicator (6) with dry, clean
cloth. Clean other parts with warm water and
soap.
2. Rinse and dry parts. Blow out internal
passages in body (14) with clean, dry
compressed air. Blow air through filter
element (55) from inside to outside to remove
surface contaminants.
3. Inspect parts. Replace those found to be
damaged.
ASSEMBLY
1. Lubricate o-rings, the portion manual drain
body (43) that contacts the bowl, and the
hole in the manual drain body that accom
modates the stem of drain valve (41) with
o-ring grease.
2. Assemble the unit as shown on the exploded
view.
3. Assemble the liquid indicator parts (19 thru
26, 30 thru 37) to reservoir. Apply a 0.9 to
1.8 kg (2 to 4 pound) clamping force to upper
and lower sight glass brackets (20, 31).
Tighten screws (19, 30).
4. Arrows on indicator (3, 8) and body (14) must
point in same direction.
5. Torque Table
Item Torque in N-m (Inch-Pounds)
2, 7 (Screw) 2,8 to 3,9 (25 to 34)
19, 30 (Screw) 1,8 to 2,3 (16 to 20)
45, 50 (Nut) 0,8 to 1,2 (7 to 10)
53 (Bae) 1,1 to 1,4 (10 to 12)
6. Turn bowl into body until arrowhead on bowl
is aligned with or to the right of the arrowhead
on the body.
WARNING
These products are intended for use in industrial
compressed air systems only. Do not use these
products where pressures and temperatures can
exceed those listed under Technical Data.
Polycarbonate plastic bowls can be damaged
and possibly burst if exposed to such
substances as certain solvents, strong
alkalies, compressor oils containing ester-based
additives or synthetic oils. Fumes of these
substances in contact with the polycarbonate
bowl, externally or internally, can also result in
damage. Clean with warm water only.
Use metal bowl in applications where a plastic
bowl might be exposed to substances that are
incompatible with polycarbonate.
Before using these products with fluids other
than air, for non industrial applications, or for
life-support systems consult Norgren.
Use in potentially explosive atmospheres
Code of device according EC directive
2014/34/EU
II 2G Ex h IIC T6 Gb
II 2D Ex h IIIC T85ºC Db
• Only non-flammable gasese to be used as a
medium.
• Surface temperature dependant on process
fluid temperature and ambient temperature -
must be below the ignition temperature of the
flammable gas or dust.
• Earth unit and/or pipework to avoid
electrostatic discharge.
• Precautions should be taken to prevent hazard
from adiabatic compression.
• Use wet cloth for cleaning.
• Protect the unit from object falling onto it.
• Avoid contact with corrosive environment.
• For servicing the unit it is recommended to
carry out this work outside of the danger
zone.
• For details of ignition hazard assessment
contact Norgren.
